Bosch MAP Control Center IUI-MAP0001-2 User manual

MAPControlCenter
IUI-MAP0001-2
en UserManual

MAPControlCenter TableofContents|en 3
BoschSicherheitssysteme,GmbH UserManual 2014.11|06|F.01U.168.328
TableofContents
1SystemOverview 5
1.1 Certifications 5
1.2 EnvironmentalConditionsforMAPControlCenter 5
1.3 MAPControlCenterDescription 5
1.3.1 LCDScreen 5
1.3.2 MAPControlCenterLEDs 5
1.4 ControlCenterMaintenance 6
1.5 IdleScreen 6
1.6 LoggingIn 6
1.7 LoggingOff 7
1.8 ScreenElements 8
2Operation 10
2.1 AlarmTasks 10
2.1.1 SilenceAlarms 10
2.1.2 ClearAlarms 10
2.1.3 ViewEventMemory 10
2.1.4 ClearingAnAnti-maskingMessage 11
2.2 SearchingandSorting/Filtering 11
2.2.1 Search 12
2.2.2 Sort/Filter 13
2.3 Arm-UsingtheControlCenter 13
2.3.1 ArmAllAreas 15
2.3.2 ArmSelectedAreas 15
2.3.3 ArmControlPanel(Local)Area 15
2.4 Disarm–UsingtheControlCenter 16
2.4.1 DisarmAllAreas 16
2.4.2 DisarmSelectedAreas 16
2.4.3 DisarmControlPanelArea 17
2.5 Users 17
2.5.1 AddUser 18
2.5.2 DeleteUser 28
2.5.3 EditUser 29
2.5.4 ChangePasscode 31
2.6 Schedules 32
2.6.1 ArminganAreaataPre-programmedTime 34
2.7 Status 34
2.7.1 ViewAreaStatus 34
2.7.2 ViewDeviceStatus 37
2.7.3 Bypass/UnbypassDevice 41
2.7.4 UnbypassAllDevices 42
2.8 Service 43
2.8.1 EventHistory 44
2.8.2 ViewVersionInformation 48
2.8.3 Enable/DisableDevice 48
2.8.4 SetTimeandDate 50
2.8.5 WalkTest 50
2.8.6 MotionDetectorTest 55
2.8.7 BellTest 56

4en|TableofContents MAPControlCenter
2014.11|06|F.01U.168.328 UserManual BoschSicherheitssysteme,GmbH
2.8.8 Change/ViewOutputState 57
2.8.9 ManufacturerAuthorization 58
2.8.10 AdjustVolume/Brightness 59
2.8.11 ChimeModeOn/Off 59
2.9 InternalProgram 60
2.10 EventMemory 61
2.10.1 ViewEventMemory 61
2.10.2 ClearEventMemory 62
2.10.3 ViewAlarmCounter 62
2.10.4 Silence 62
2.11 RPS 63

MAPControlCenter SystemOverview|en 5
BoschSicherheitssysteme,GmbH UserManual 2014.11|06|F.01U.168.328
1 SystemOverview
1.1 Certifications
Thecontrolcenterisdesignedtocomplywiththefollowingcertificationsandstandards:
Region Certification
GERMANY VdS ClassC,VdSG111040
Europe CE ConformitéEuropéene
EN50131-1/3grade3 AlarmSystems–IntrusionSystems
1.2 EnvironmentalConditionsforMAPControlCenter
Operatingtemperature: -10ºCto+55ºC
Relativehumidity: 5%to95%
TypeinaccordancewithEN50131: TypeB
EnvironmentalclassII: EN50131,VdS2110
Use: Designedforindooruse
1.3 MAPControlCenterDescription
TheMAPcontrolcenterisaninputdevicefortheModularAlarmPlatform5000system.Each
controlcenterhasavibrant-color14cm(5.7in.)LCDscreen.Thedurabletouchscreen
providesaccesstothevarioussystemfunctionsthroughaninterfacewithintuitivebuttons.
Userstouchtheimagesdirectlyonthescreentoarm,disarm,orselectothermenuoptions.
Thedisplaytextisshowninthelanguagesetbytheuser.
1.3.1 LCDScreen
TooperatetheMAPcontrolcenter,applymoderatepressuretothekeysandbuttonsshown
onthescreen.Toavoiddamagetothetouch-sensitivefoildonotusesharpobjects.
1.3.2 MAPControlCenterLEDs
Threelight-emittingdiodes(LEDs)arelocatedontheleftedgeoftheMAPcontrolcenter(
Figure1.1ControlCenterLEDs,page6):
–GreenLED:Indicatesthatthecontrolcenteriscommunicatingwiththecontrolpanel.
–YellowLED:Indicatesthatthereisatroublecondition,thatsensorsarecovered,orthat
devicesinthesystemareswitchedoffordisabled.
–RedLED:Thedefaultbehaviorindicatesthatanalarmconditionexistsinthesecurity
system

6en|SystemOverview MAPControlCenter
2014.11|06|F.01U.168.328 UserManual BoschSicherheitssysteme,GmbH
Figure1.1ControlCenterLEDs
1–GreenLED
2–YellowLED
3–RedLED
1.4 ControlCenterMaintenance
Ifthecontrolcenterhousingisdirty,cleanitwithasoftdampenedcloth.Donotusecorrosive
orabrasivecleaners.Makesurethatnofluidgetsinsideofthehousing.Toremovefingerprints
ordustfromtheLCDscreen,useasoftcloththatyouhavedampenedslightlywithwater.
1.5 IdleScreen
ThecontrolcentershowstheIdlescreen(Figure1.2Idlescreen,page6)whenitisnotin
use.Tousethesystem,touchthecontrolcenterdisplay.
Figure1.2Idlescreen
1.6 LoggingIn
UsetheLoginscreen(Figure1.3Loginscreen,page7)toenteryourpasscode.Theuser
passcodeismadeupofathree-digituserID(004–999)andasix-digitusercode,whichis
enteredimmediatelyaftertheuserID.

MAPControlCenter SystemOverview|en 7
BoschSicherheitssysteme,GmbH UserManual 2014.11|06|F.01U.168.328
Figure1.3Loginscreen
Ifthesystemdoesnotrecognizethepasscode,thecontrolcentershowstheInvalidLogin
screen(Figure1.4InvalidLoginscreen,page7).Toemptythepasscodefield,pressClear
(thepencileraserbutton).Ifaninvalidpasscodeisenteredten1timesinsuccession,the
controlcenterislockedfortwominutes1.
Figure1.4InvalidLoginscreen
Aftertheuserentersavalidpasscode,thetouchscreenshowstheMainMenu(Figure1.5Main
Menu–screen1,page8).
Seealso
– ,page9
1.7 LoggingOff
Auserisloggedoff
– Bypressingtheexitbutton(Table1.1NavigationBardescription,page9)
– Iftherehasbeennouseractivityonthecontrolcenterfortwominutes1
1Programmablevalue

8en|SystemOverview MAPControlCenter
2014.11|06|F.01U.168.328 UserManual BoschSicherheitssysteme,GmbH
1.8 ScreenElements
Figure1.5MainMenu–screen1
1. Screenname:identifiestheactivescreen.
2. Menubuttons:Pressamenubuttontoperformatask.
3. InstallerModeIcon:Indicatesthatthecontrolpanelisininstallermode.
4. RPSConnectedIcon:IndicatesthatRPSisconnectedtothecontrolpanel.
5. Informationbutton:Ifitisflashing,pressthisbuttontoviewadditionalsystem
informationandtocleartheevents,alarmsortroubles.FormoreEventMemory
information,refertoSectionViewEventMemory,page10.
– IftheInformationbuttonisflashingred,therearesystemeventsandalarmsthatthe
userhasnotcleared.
– IftheInformationbuttonisflashingyellow,therearesystemtroubleswhichtheuser
hasnotcleared.
– IftheInformationbuttonisgreen,noadditionalsysteminformationisavailable.
6. Navigationbar:Pressthebuttonsinthenavigationbartofindtasksortoviewsystem
information.RefertoTable1.1NavigationBardescription,page9.Buttonsinthe
navigationbarthatappearwithouttheirnormalcolorsarenotactivated.

MAPControlCenter SystemOverview|en 9
BoschSicherheitssysteme,GmbH UserManual 2014.11|06|F.01U.168.328
Figure1.6MainMenu–screen2
Notice!
ThebuttonsonyourtouchscreenmightbedifferentfromthebuttonsshowninFigure1.5
MainMenu–screen1,page8andFigure1.6MainMenu–screen2,page9.Thebuttonson
yourtouchscreenaredeterminedbyyouruserauthoritylevel.
Aftertheuserpressesabutton,thetouchscreenshowsthetaskbuttonscontainedwithin
thatfolder.Forexample,Figure2.45Statusmenu,page34showstheStatustasks.
Table1.1NavigationBardescription
Button Description
Back:Showsthepreviousscreen.
Home:ShowstheMainMenu.
Pageup:Showsthepreviouspageonscreenswithmorethanonepage.
Pagedown:Showsthenextpageonscreenswithmorethanonepage.
Help:Showshelpfulinformationabouttheactivescreen.
Exit:Logstheuseroffandswitchesthedisplaytotheidlescreen(Figure1.2
Idlescreen,page6).

10 en|Operation MAPControlCenter
2014.11|06|F.01U.168.328 UserManual BoschSicherheitssysteme,GmbH
2 Operation
2.1 AlarmTasks
2.1.1 SilenceAlarms
Ifthesystemgeneratesanalarm,pressthetouchscreenandenteryourpasscode(Figure1.3
Loginscreen,page7).Ifthesystemacceptsyouruserpasscode,thetouchscreenshowsthe
firstalarm,e.g.anexternalintrusionalarm(Figure2.1ExternalIntrusionAlarmscreen,page
10)andthelatestalarm.Anytroubleeventsinthesystemarenotshownonthisdisplay.
Figure2.1ExternalIntrusionAlarmscreen
Tosilencethealarm,pressSilence.Ifthesystemrecordedmorethanonealarm,thescreen
showsthefirstandlastalarms.PressViewMoretoseeallcurrenteventsintheevent
memory.Formoreinformationabouteventmemory,refertoSectionViewEventMemory,page
10.
2.1.2 ClearAlarms
Aftersilencinganalarm,theusermustclearthealarm.Fromthealarmscreen(Figure2.1
ExternalIntrusionAlarmscreen,page10),pressViewMoretoopentheViewEventMemory
screen(Figure2.2ViewEventMemoryscreen,page11).Toclearthealarm,pressClearEvents
.
2.1.3 ViewEventMemory
IftheInformationbuttonontheMainMenu(Figure1.5MainMenu–screen1,page8)flashes
redoryellow,presstheInformationbuttontoviewtheViewEventMemoryscreen(Figure
2.2ViewEventMemoryscreen,page11).Foradditionaleventmemoryoptions,referto
SectionEventMemory,page61.

MAPControlCenter Operation|en 11
BoschSicherheitssysteme,GmbH UserManual 2014.11|06|F.01U.168.328
Figure2.2ViewEventMemoryscreen
Notice!
Thesystemdisplayseventswiththenewesteventbeingdisplayedfirst.
Ifyourpasscodeauthorizestheclearingofalarmsandotherevents,pressClearEvents.Ifyou
cannotclearcertaineventsbecauseyoudonothavethenecessaryaccessrights,thentheNot
Authorizedscreenappearsonthecontrolcenter.Inthiscase,pleasenotifyyourinstalleror
maintenanceengineer.Formoreinformationaboutviewingeventmemory,refertoSection
ViewEventMemory,page10.
2.1.4 ClearingAnAnti-maskingMessage
1. Turnonthewalktestfortheareainwhichthepointislocated(refertoSectionMotion
DetectorTest,page55).
2. Removetheobjectmaskingthepointandthentriggerthepointusingmotion.
3. Turnoffthewalktestagain.Theanti-maskingmessageisnowcleared.
2.2 SearchingandSorting/Filtering
SomefunctionsintheMAPsystemuserinterfacecallfororrequiresearching,sorting,or
filtering.Wherethesefunctionsarepossible,theSearchandSort/Filter(Table2.1Search
andSort/Filterbuttondescriptions,page11)buttonsappearonthescreen.
Table2.1SearchandSort/Filterbuttondescriptions
Button Description
Search:ShowstheAlphanumericKeypadscreen(Figure2.31.Alphanumeric
Keypadscreen1,page12).
Sort/Filter:Showsalistofsortcategoriesappropriatetothefunction,and
theA-ZandZ-Abuttons.
A-Z:Sortsinalphabeticalorder.

12 en|Operation MAPControlCenter
2014.11|06|F.01U.168.328 UserManual BoschSicherheitssysteme,GmbH
Button Description
Z-A:Sortsinreversealphabeticalorder.
Figure2.31.AlphanumericKeypadscreen1
Figure2.42.AlphanumericKeypadscreen2
2.2.1 Search
Searchusesanalphanumerickeypaddisplayforinput.Thealphanumerickeypaddisplayhas
thenumerals0-9,aQWERTYarrangementofletterswithadditionalspecialcharacters,and
fivecommands(refertoTable2.2AlphanumericKeypadCommanddescriptions,page12).
Table2.2AlphanumericKeypadCommanddescriptions
Command Description
Shift Createscapitalletters.Pressonce.Thenextletterpressediscapitalized.
Clear ClearsallinputintheSearchfield.
Space Insertsaspace(samefunctionasthespacebaronamanualkeyboard).
Backspace Clearsthepreviouscharacter.

MAPControlCenter Operation|en 13
BoschSicherheitssysteme,GmbH UserManual 2014.11|06|F.01U.168.328
Command Description
Enter Startsthesearchprocess.
2.2.2 Sort/Filter
WhenyouusetheSort/Filterfunction,thesortingcanbealphabetical(fromA-ZorfromZ
toA)foralldevicesorallareas,forexample,orthefunctioncanbenarrowedbyselecting
faulted,bypassed,unbypassed,enabled,ordisableddevices.
Allareascanbesorted,orthesortingfunctioncanbenarrowedbyselectingarmed,disarmed,
readytoarm,notreadytoarm,readytodisarm,ornotreadytodisarmareas.More
informationisprovidedinthesectionsthatcoverthecommandsthatallowsortingand
filtering.
2.3 Arm-UsingtheControlCenter
Notice!
AsysteminstalledwithSmartkeyorBlocklockcontrolscanonlybearmedordisarmedby
thosecontrols.Itcannotbearmedordisarmedusingacontrolcenter.
TheArmmenuallowstheusertoarmallareas,armselectedareas,orarmthecontrolpanel
area.
Notice!
Forthesystemdefault,theareacontainingthecontrolcenteristhelocalarea.During
installation,eachcontrolcentercanbeassignedtoaspecificareamakingthatareathelocal
areaforthatcontrolcenter.Therefore,thedisplayedbuttonnameoneachcontrolcenteris
uniqueforeachinstallation.Dependingonhowyoursystemisconfigured,youmightneedto
armthecontrolpanelareafirst.
OntheMainMenu(Figure1.5MainMenu–screen1,page8),pressArm,thenselectan
armingoptionfromtheon-screenbuttons(ArmAllAreas,ArmSelectedAreas,orArmControl
PanelArea)ontheArmMenu(Figure2.5Armmenu,page14).SelectinganareathatisReady
toArminitiatesthearmingsequenceanddisplaystheExitDelayscreen(Figure2.6ExitDelay
screen,page14)whichindicateshowmuchtimeyouhavetoevacuatethearmingarea(s)
beforeyourpresencesetsoffanalarm.SelectinganareathatisNotReadytoArmdisplaysan
ArmingFailurescreen(Figure2.7ArmingFailurescreen,page14)whichindicateswhich
area(s)canbeforcearmed[armedbyforcingbypass(refertoSectionBypass/Unbypass
Device,page41)ofallpointsthatarenotreadytobearmed]andwhichareascannotbe
forcearmed.
Notice!
Forcearmingisnotavailablewhenarelatedareamustbearmedfirst,whentoomanypoints
arealreadybypassed,orwhenanareacontainsspecificunbypassablepoints.

14 en|Operation MAPControlCenter
2014.11|06|F.01U.168.328 UserManual BoschSicherheitssysteme,GmbH
Figure2.5Armmenu
Notice!
ClickingontheNotReadytoArmicon( )providesinformationonwhytheareaisnot
readytoarm.
Figure2.6ExitDelayscreen
Figure2.7ArmingFailurescreen

MAPControlCenter Operation|en 15
BoschSicherheitssysteme,GmbH UserManual 2014.11|06|F.01U.168.328
2.3.1 ArmAllAreas
FromtheArmmenu,presstheArmAllAreasbutton.Asabove,ifallareasareReadytoArm,
theExitDelayscreenisdisplayed;ifnot,theArmingFailurescreenopenswiththelockbutton
inthelockedpositionandthearmedstatusshowingontheArmAllAreasbutton.
2.3.2 ArmSelectedAreas
FromtheArmmenu(Figure2.5Armmenu,page14),presstheArmAllAreasbutton.TheArm
SelectedAreasscreen(Figure2.8ArmSelectedAreasscreen,page15)opens.Thetextand
thelockbuttonshowstatusinformationonthebuttonforeacharea.Toarmanarea,press
thebuttonforanareathatisnotalreadyarmed;thenpresstheArmbutton.
Figure2.8ArmSelectedAreasscreen
Tosortthelistofareasbeforeselectingsometoarm,presstheSort/Filterbutton.Referto
Table2.3Armingindicators,page15forthepossiblearmingindicators.
Table2.3Armingindicators
Indicator Description
Disarmed Areacurrentlydisarmed
ReadytoArm Allpointsintheareaarereadytoarm
NotReadytoArm Somepointsintheareaarefaultedandnot
readytoarm;allpointsmusteitherbe
returnedtonormalorbypassed.
Armed Areacurrentlyarmed
2.3.3 ArmControlPanel(Local)Area
FromtheArmmenu(Figure2.5Armmenu,page14),presstheArmControlPanelArea
button.
Notice!
Dependingonhowyoursystemisconfigured,thedisplayedbuttonnameoneachcontrol
centerisuniqueforeachinstallation.
TheArmmenuopenswiththelockbuttoninthelockedpositionandthearea’sarmedstatus
showingontheArmControlPanelAreabutton.

16 en|Operation MAPControlCenter
2014.11|06|F.01U.168.328 UserManual BoschSicherheitssysteme,GmbH
2.4 Disarm–UsingtheControlCenter
TheDisarmmenuallowstheusertodisarmallareas,disarmselectedareas,ordisarmthe
entirecontrolpanel(orinstallation-specificlocal)area.OntheMainMenu(Figure1.5Main
Menu–screen1,page8),pressDisarm,thenselectadisarmingoptionfromtheon-screen
buttonsontheDisarmmenu(Figure2.9Disarmmenu,page16).
Figure2.9Disarmmenu
2.4.1 DisarmAllAreas
FromtheDisarmmenu(Figure2.9Disarmmenu,page16),presstheDisarmAllAreas
button.Thecontrolcenterdisplayshowsthemessage:Attention-Allauthorizedareasare
disarmed(Figure2.10Attentionmessage:Allauthorizedareasaredisarmed,page16).Thenthe
Disarmmenuopenswiththelockbuttonintheunlockedpositionandthedisarmedstatus
showingontheDisarmAllAreasbutton.
Figure2.10Attentionmessage:Allauthorizedareasaredisarmed
2.4.2 DisarmSelectedAreas
FromtheDisarmmenu,presstheDisarmSelectedAreasbutton.TheDisarmSelectedAreas
screen(Figure2.11DisarmSelectedAreasscreen,page17)opens.Thetextandthelock
buttonshowstatusinformationonthebuttonforeacharea.Todisarmanarea,pressthe
buttonforanareathatisnotalreadydisarmed;thenpresstheDisarmbutton.Tosortthelist
ofareasbeforeselectingsometodisarm,presstheSort/Filterbutton.

MAPControlCenter Operation|en 17
BoschSicherheitssysteme,GmbH UserManual 2014.11|06|F.01U.168.328
Figure2.11DisarmSelectedAreasscreen
2.4.3 DisarmControlPanelArea
FromtheDisarmmenu(Figure2.9Disarmmenu,page16),presstheDisarmControlPanel
Areabutton.Usually,thisbuttonistheareawherethecontrolcenterislocated,butitcould
beanyareadesignatedasthelocalarea.Thebuttonnameisuniqueateachinstallation.
Todisarmthecontrolpanelarea,presstheControlPanelAreabuttonthenpresstheDisarm
button.ThelockiconontheControlPanelAreabuttonchangestotheunlockedpositionand
thearea'sdisarmedstatusshowsonthebutton.
2.5 Users
Notice!
Theoptionstoperformuser-relatedoperationsarerestrictedbypermissionset/access
profile.
TheUsersmenuallowstheusertoadd(uptothemaximumnumberofusersallowed),delete
oreditauser’sprofileortochangeauser’spasscode.OntheMainMenu(Figure1.5Main
Menu–screen1,page8)pressUsers,thenselecttheusercategoryfromtheon-screen
buttons(Figure2.12Usersmenu,page17).
Figure2.12Usersmenu

18 en|Operation MAPControlCenter
2014.11|06|F.01U.168.328 UserManual BoschSicherheitssysteme,GmbH
Seealso
– Users,page17
2.5.1 AddUser
Notice!
ASmartkeyusermustalsobeenteredasacontrolcenteruser.RefertoSectionAddSmartkey
User,page21.
AcontrolcenteruserisnotrequiredtobeaSmartkeyuser.RefertoSectionAddControl
CenterUser,page23.
– FromtheUsersmenu(Figure2.12Usersmenu,page17),pressAddUser.TheAddUser
screen(Figure2.13AddUserscreen,page18)opens
Figure2.13AddUserscreen
EnterUserID
– FromtheAddUserscreen(Figure2.13AddUserscreen,page18),pressEnterUserID.
TheEnterUserIDscreen(Figure2.14EnterUserIDscreen,page18)opens.
Figure2.14EnterUserIDscreen
– PressEnterUserIDtoenteraspecificthree-digituserID,orpressRequestNext
AvailableUserIDtohavethesystemassignauserID.WhenyouselectEnterUserID,
theEnterUserIDtelephonekeypaddisplayscreen(Figure2.15EnterUserIDKeypad
screen,page19)opens.

MAPControlCenter Operation|en 19
BoschSicherheitssysteme,GmbH UserManual 2014.11|06|F.01U.168.328
– Pressthenumberedbuttonsonthekeypadscreen.Eachnumberappearsinthe
EnternewuserIDfield.PressCleartomakecorrections.
– PressOKtoenterthespecificuserID.
Figure2.15EnterUserIDKeypadscreen
– TheassigneduserIDappearsinlightertextunderthebuttonnameonaconfirmation
screen(Figure2.16UserIDControlCenterConfirmationscreen,page19).PressOKto
completetheentry.
Figure2.16UserIDControlCenterConfirmationscreen
EnterUserName
– FromtheAddUserscreen(Figure2.13AddUserscreen,page18),pressEnterUserName
.TheEnterUserNamescreen(Figure2.17EnterUserNamescreen,page20)opens.

20 en|Operation MAPControlCenter
2014.11|06|F.01U.168.328 UserManual BoschSicherheitssysteme,GmbH
Figure2.17EnterUserNamescreen
– OntheEnterUserNamescreen,pressEnterUserFirstName.Thealphanumerickeypad
screen(Figure2.181.EnterUserName-Alphanumerickeypadscreen1,page20)opens.
AlsorefertoFigure2.192.EnterUserName-Alphanumerickeypadscreen2,page21
– Usethealphanumericbuttonstoentertheuser’sfirstname.RefertoTable2.3Arming
indicators,page15forinformationaboutusingthecommandsatthebottomofthe
screen.
– PressEntertocompletetheentry.Theuser’sfirstnameappearsinlightertextunderthe
EnterUserFirstNamebuttonname.
Figure2.181.EnterUserName-Alphanumerickeypadscreen1
