Bosch VCU User manual

Vehicle Control Unit VCU
Manual
Version 1.3 02/07/2020

Content
ii/136 Vehicle_Control_Unit_VCU_Manual Bosch Motorsport
Content
1 Preparation...................................................................................................................................................................... 4
2 Warnings and safety instructions ................................................................................................................................. 5
3 Onboard Network Concept............................................................................................................................................ 6
4 Technical Data................................................................................................................................................................. 7
5 Pinlayout.......................................................................................................................................................................... 11
6 Communication Channels .............................................................................................................................................. 16
7 Mechanical Drawing ....................................................................................................................................................... 17
8 Starting Up ...................................................................................................................................................................... 18
8.1 Before starting ....................................................................................................................................................................................................... 18
8.2 Feature activation................................................................................................................................................................................................. 23
8.3 First recording (Quick Start) ............................................................................................................................................................................. 25
8.4 Set time and date ................................................................................................................................................................................................. 28
9 Project Configuration..................................................................................................................................................... 30
9.1 Math Channels....................................................................................................................................................................................................... 30
9.2 Conditional Functions......................................................................................................................................................................................... 31
9.3 Conditional Channels.......................................................................................................................................................................................... 33
9.4 Condition Combination...................................................................................................................................................................................... 34
9.5 CPU Load Limits .................................................................................................................................................................................................... 36
10 CAN Configuration ......................................................................................................................................................... 37
10.1 CAN Bus Trivia ....................................................................................................................................................................................................... 37
10.2 CAN input................................................................................................................................................................................................................ 38
10.3 CAN output............................................................................................................................................................................................................. 44
10.4 Multiplexer .............................................................................................................................................................................................................. 46
11 Analog and Frequency Inputs ....................................................................................................................................... 49
11.1 Analog inputs......................................................................................................................................................................................................... 49
11.2 Configuring inputs ............................................................................................................................................................................................... 50
11.3 Configuring computed sources ...................................................................................................................................................................... 64
11.4 Hysteresis................................................................................................................................................................................................................. 65
12 Power Stages ................................................................................................................................................................... 69
13 Online Measurement and Calibration .......................................................................................................................... 70
13.1 Setting up an online measurement............................................................................................................................................................... 70
13.2 Online calibration of measurement channels............................................................................................................................................ 75
13.3 Online calibration of multipoint adjustment channels .......................................................................................................................... 77
14 Recording......................................................................................................................................................................... 79
14.1 Features.................................................................................................................................................................................................................... 79
14.2 Configuration of Recordings............................................................................................................................................................................ 79
14.3 USB recording........................................................................................................................................................................................................ 83
14.4 High speed logging............................................................................................................................................................................................. 88
15 Error Memory .................................................................................................................................................................. 91
15.1 Error memory representation in RaceCon .................................................................................................................................................. 91
15.2 Information on errors available from the error memory ...................................................................................................................... 93

Content
Bosch Motorsport Vehicle_Control_Unit_VCU_Manual iii/136
15.3 Analog Input Diagnosis...................................................................................................................................................................................... 97
16 Lap Trigger ...................................................................................................................................................................... 99
16.1 Lap trigger (timing beacon).............................................................................................................................................................................. 99
16.2 Counting outing/laps/fragments ................................................................................................................................................................... 105
16.3 Lap timing................................................................................................................................................................................................................ 106
16.4 Segment timing..................................................................................................................................................................................................... 108
16.5 Countdown timer ................................................................................................................................................................................................. 110
16.6 Automatic GPS Track Detection...................................................................................................................................................................... 111
17 Firmware .......................................................................................................................................................................... 113
17.1 Firmware and configuration............................................................................................................................................................................. 113
17.2 Firmware update................................................................................................................................................................................................... 113
18 Cloning the Unit.............................................................................................................................................................. 116
19 GPS Sensor....................................................................................................................................................................... 118
19.1 GPS (Global Positioning System).................................................................................................................................................................... 118
19.2 Protocol.................................................................................................................................................................................................................... 118
19.3 Sensor recommendation ................................................................................................................................................................................... 118
19.4 Measurement labels ............................................................................................................................................................................................ 121
19.5 GPS troubleshooting........................................................................................................................................................................................... 122
20 Fuel Consumption Calculation ...................................................................................................................................... 124
20.1 Setting up fuel consumption calculation and tank management..................................................................................................... 124
20.2 Fuel consumption diagnosis/counter reset................................................................................................................................................ 125
20.3 Example .................................................................................................................................................................................................................... 126
21 Predated Laptime............................................................................................................................................................ 127
21.1 Setting up the predated laptime.................................................................................................................................................................... 127
21.2 Functionality and channel outputs ................................................................................................................................................................ 127
22 RaceCon Shortcuts.......................................................................................................................................................... 128
23 Legal ................................................................................................................................................................................. 129
23.1 EC/EU Declaration of Conformity................................................................................................................................................................... 129
23.2 REACH Statement................................................................................................................................................................................................. 131
24 Disposal............................................................................................................................................................................ 132

1 | Preparation
4/136 Vehicle_Control_Unit_VCU_Manual Bosch Motorsport
1 Preparation
Use the Vehicle Control Unit VCU only as intended in this manual. Any maintenance or re-
pair must be performed by authorized and qualified personnel approved by Bosch
Motorsport.
Operation of the Vehicle Control Unit VCU is only certified with the combinations and ac-
cessories that are specified in this manual. The use of variant combinations, accessories,
and other devices outside the scope of this manual are only permitted when they have
been determined to be compliant from a performance and safety standpoint by a repres-
entative from Bosch Motorsport.
Read the manual carefully and follow the application hints step by step. Do not hesitate to
contact us, contact data can be found on the last page of this document.
Important information on Electromagnetic Conformity
To avoid unwanted interference with the environment (people, animals, electronic devices)
or unwanted harm to the environment, it is mandatory that the user of the Vehicle Control
Unit VCU carries out an appropriate analysis to determine the electromagnetic interaction
the Vehicle Control Unit VCU may have with its individual installation environment.
Disclaimer
Due to continuous enhancements, we reserve the rights to change any illustrations, pho-
tos and technical data within this manual.
Please retain this manual for your records.
NOTICE
In this document, many screenshots are created by way of example
for a display. Please consider this and replace the product names
with the name of your device.

Warnings and safety instructions | 2
Bosch Motorsport Vehicle_Control_Unit_VCU_Manual 5/136
2 Warnings and safety instructions
The classification of the warnings and safety instructions is carried out by the respective
signal word (Danger, Warning, Caution) next to the warning symbol.
Danger
DANGER
Nature and source of danger
Consequences
Warning of death or serious physical injury, which are sure to occur if ignored.
Warning
WARNING
Nature and source of danger
Consequences
Warning of death or serious injury, which can occur if this is not observed.
Caution
CAUTION
Nature and source of danger
Consequences
Warning of slight bodily injury in case of Disregard.
Notice
NOTICE
Nature and source of danger
Consequences
Warning of damage to equipment in case of ignoring.

3 | Onboard Network Concept
6/136 Vehicle_Control_Unit_VCU_Manual Bosch Motorsport
3 Onboard Network Concept
Please ensure that you have a good ground installation. That means:
– A ground that has a solid, low resistance connection to the negative battery terminal
– Connection should be free from dirt, grease, paint, anodizing, etc.
– Use large diameter wire
– More metal-to-metal contact is better!
The following notations for power signals are used:
– KL 15 is a switched battery rail controlled by the IGN-switch
– KL 30 is an unswitched battery positive rail (same as battery positive terminal)
– KL 31 is an unswitched ground rail (same as battery negative terminal)
Be careful to observe current limits of wires and connector pins!
G
Engine_GND
GND_Starpoint
Chassis
KL31
LS_GND_1
LS_GND_2
Main
Switch
UBAT
Star connection
(term30) positive terminal
Electric Loads
IGN-
Switch
KL15
SENSPWR5
SENSGND
active
Sensor
ANA_IN(xx) NTC
Sensor
ANA_IN(xy)
switched pos. terminal
Star connection
dig. sensors
(e.g. wheelspeed)
µC
As short as
possible
SENSPWR10
UBATT_FUSE
KL30
LS_SWITCH1…4
Bosch Motorsport
diagnosis connector
PC
Device
NOTICE
This schematic is not device specific. Please see the section Technical
Data [}7] for the specifications of your device.

Technical Data | 4
Bosch Motorsport Vehicle_Control_Unit_VCU_Manual 7/136
4 Technical Data
– 667 MHz Dual Core Processor exclusively for customer code execution (MATLAB
based)
– Identical, dedicated 667 MHz Dual Core Processor exclusively for logging purposes
– High Speed Logging 200 kHz of 6 analogue inputs (optional)
– Real time Ethernet SERCOS 3
– Event logging, Configurable pre-event logging
The Vehicle Control Unit VCU is a highly powerful processing unit for customer-developed
functions integrating a flexible logging device with high speed logging capability of up to
200kHz.
The processing cores feature floating-point arithmetic and a high-end FPGA for ultimate
performance and flexibility. The customer software development process is based on
MATLAB/Simulink to significantly speed up algorithm development (automatic code and
documentation generation).
It offers real time Ethernet functionality to exchange e.g. data used in control algorithms
between devices (guaranteed latency time 1 ms).
This device comes with a basic software consisting of operating system, H/W-drivers and
low-level functions like pin setup, diagnostics, etc. The customer can freely develop his
own application software using the MATLAB/Simulink environment.
Mechanical Data
Size 166 x 121 x 41 mm
Weight ≤ 660 g
Protection classification IP67
Operating temperature internal -20 to 80°C
3 motorsport connectors, 198 pins in total
Max. vibration Vibration profile 1 (see www.bosch-
motorsport.com)
Electrical Data
Supply voltage 5 to 18 V
Inputs
Analog channels
0 to 5 V, 0.5 % precision between 0.2 and
4.8 V, switchable pull-up
20
Digital PWM inputs
f_max=30 kHz
Hall-type speed measurement possible,
Switchable pullup 2.15 kOhm, (required for
Hall),
Tooth count differential*
8
Digital PWM inputs
f_max=30 kHz
Hall- and DF11 type speed measurement
4

4 | Technical Data
8/136 Vehicle_Control_Unit_VCU_Manual Bosch Motorsport
possible,
Fixed pullup 2.15 kOhm (required for Hall),
Tooth count differential*
Thermocouple 4 universal
Bosch Laptrigger 1
TimeSync master and slave (specific to
Bosch measurement system)
1
Internal measurement 1 ambient pressure
1 ECU temperature
20 supply voltage
20 supply current
1 battery voltage (external VCU supply)
1 external VCU supply current
4 HS output current
Outputs
PWM High side 2*; 7.5 A each, PWM, 50 Hz
PWM Low side 4*; 2.2 A each, PWM, 10 kHz
*can be enhanced by Upgrade I/O Package, see below
Power Supplies
12 V, 400 mA each 5*
Switchable 5 V/12 V, 400 mA each 5*
Max overall current 4 A on all 12 V
2 A on all 5 V
Precision 12 V ± 1 % on the pin
Precision 5 V ± 0.1 % on the pin
Sensor ground 20
*can be enhanced by Upgrade I/O Package, see below
Adaptation and Documentation
Function documentation Automatically created during code genera-
tion
MatLab code generation Support for customer own MatLab function
development
Software Tools (free download)
Data Analysis tool WinDarab 7 Free
System Configuration tool RaceCon Logger configuration, calibration and on-
line measurement
USB Kit
Software license for USB-port unlocked
Rugged USB flash drive
Adapter cable to USB-port

Technical Data | 4
Bosch Motorsport Vehicle_Control_Unit_VCU_Manual 9/136
Adapter for wiring harness
Upgrade High Speed Logging Package
6 ANA 0 to 5 V, 200 kHz logging rate
Upgrade I/O Package
Communication
4 CAN
Inputs
4 Analog channels
0 to 20 V,
0.5 % precision between 0.8 and 19.2 V, switchable pull-up
4 Digital PWM inputs
f_max=30 kHz
Hall-type speed measurement possible,
Fixed pullup 2.15 kOhm (required for Hall),
Tooth count differential*
4 LVDT, 5 pin configuration,
excitation frequency 1 to 20kHz,
excitation voltage 0 to 5 V (rms)
Outputs
4 “TTL” Digital output, 10 kHz, PWM, 250 mA each
2 PWM High side; 7.5 A each, PWM, 50 Hz
4 PWM Low side; 2.2 A each, PWM, 10 kHz
Power Supplies
5 x12 V, 400 mA each
5 switchable 5 V/12 V, 400 mA each
* The tooth count differential between any two of the PWM inputs is available two meas-
ure e.g. shaft torsion.
Upgrade Real Time Ethernet
Enables the VCU to operate as a real time Ethernet master or slave. Guaranteed latency
time of 1ms. Ideal for time critical data transfer as needed in online control algorithms
involving data from different devices.
Two interfaces allow for a ring topology (redundancy in case the RTE line experiences
damage).
The VCU features a reasonable set of SERCOS3 instructions although not the full SER-
COS3 standard is implemented. The ECU side can act as a SERCOS3 master; the logger
side can act as a SERCOS3 slave.
Upgrade CCP Master
Enables CCP master functionality to request data from foreign devices via CAN/CCP pro-
tocol.

4 | Technical Data
10/136 Vehicle_Control_Unit_VCU_Manual Bosch Motorsport
Connectors
Connector LIFE (red) AS018-35PN Mating connector AS618-35SN (not in-
cluded)
Connector SENS-A (yellow) AS018-35PA Mating connector AS618-35SA (not in-
cluded)
Connector SENS-B (blue) AS018-35PB Mating connector AS618-35SB (not in-
cluded)

Pinlayout | 5
Bosch Motorsport Vehicle_Control_Unit_VCU_Manual 11/136
5 Pinlayout
Connector LIFE (red), Mating connector AS618-35SN
Pin I/O Signal Level, Power
LIFE 01 I/O BI_CAN7_H 0 to 5 V
LIFE 02 I/O BI_CAN7_L 0 to 5 V
LIFE 03 I I_DIGIN04_HALL_DF11 0 to 5 V
LIFE 04 I I_DIGIN09 0 to 5 V
LIFE 05 I/O BI_CAN8_H 0 to 5 V
LIFE 06 I I_DIGIN10 0 to 5 V
LIFE 07 I/O BI_CAN4_H 0 to 5 V
LIFE 08 I/O BI_CAN4_L 0 to 5 V
LIFE 09 I/O BI_LIN 0 to 12 V
LIFE 10 I I_DIGIN02_HALL_DF11 0 to 5 V
LIFE 11 I/O BI_CAN8_L 0 to 5 V
LIFE 12 I/O BI_CAN3_H 0 to 5 V
LIFE 13 I/O BI_CAN3_L 0 to 5 V
LIFE 14 I I_DIGIN13 0 to 5 V
LIFE 15 I/O B_D_RS232_RX 12 V
LIFE 16 I/O B_D_RS232_TX 12 V
LIFE 17 I/O B_D_ETH2TXN ETH
LIFE 18 I/O B_D_ETH2TXP ETH
LIFE 19 I I_DIGIN14 0 to 5 V
LIFE 20 G GND GND
LIFE 21 I I_S_LAPTRIG 0 to 5 V
LIFE 22 I/O BI_TIMESYNC 0 to 5 V
LIFE 23 I/O B_D_SERCOS2RXN ETH
LIFE 24 I/O B_D_SERCOS2RXP ETH
LIFE 25 I/O B_D_ETH2RXN ETH
LIFE 26 I/O B_D_ETH2RXP ETH
LIFE 27 I/O B_D_ETH3TXN ETH
LIFE 28 G G_USB_SCR GND, 2 A fused
LIFE 29 I I_DIGIN15 0 to 5 V
LIFE 30 I/O BI_CAN5_H 0 to 5 V
LIFE 31 I/O BI_CAN5_L 0 to 5 V
LIFE 32 I/O B_D_SERCOS2TXN ETH
LIFE 33 I/O B_D_SERCOS2TXP ETH
LIFE 34 I/O B_D_ETH3RXN ETH
LIFE 35 I/O B_D_ETH3RXP ETH
LIFE 36 I/O B_D_ETH3TXP ETH
LIFE 37 I I_DIGIN03_HALL_DF11 0 to 5 V
LIFE 38 I/O BI_CAN6_H 0 to 5 V
LIFE 39 I/O BI_CAN6_L 0 to 5 V

5 | Pinlayout
12/136 Vehicle_Control_Unit_VCU_Manual Bosch Motorsport
Pin I/O Signal Level, Power
LIFE 40 G G_COMSCR GND, 2 A fused
LIFE 41 I/O B_D_SERCOS1RXN ETH
LIFE 42 I/O B_D_SERCOS1RXP ETH
LIFE 43 I I_DIGIN01_HALL_DF11 0 to 5 V
LIFE 44 G G_DIGIN GND, 2 A fused
LIFE 45 I/O BI_USB_DN USB
LIFE 46 I I_DIGIN11 0 to 5 V
LIFE 47 I I_DIGIN12 0 to 5 V
LIFE 48 I/O BI_CAN1_H 0 to 5 V
LIFE 49 I/O B_D_SERCOS1TXN ETH
LIFE 50 I/O B_D_SERCOS1TXP ETH
LIFE 51 I/O BI_USB_DP USB
LIFE 52 O O_V_USB_VDD float
LIFE 53 I I_DIGIN08_HALL 0 to 5 V
LIFE 54 I/O B_D_ETH1RXN ETH
LIFE 55 I/O BI_CAN2_L 0 to 5 V
LIFE 56 I/O BI_CAN1_L 0 to 5 V
LIFE 57 I I_DIGIN16 0 to 5 V
LIFE 58 O G_USB_GND float
LIFE 59 I I_DIGIN07_HALL 0 to 5 V
LIFE 60 I I_DIGIN06_HALL 0 to 5 V
LIFE 61 I/O B_D_ETH1TXN ETH
LIFE 62 I/O BI_CAN2_H 0 to 5 V
LIFE 63 V V_UBAT VBAT
LIFE 64 I I_DIGIN05_HALL 0 to 5 V
LIFE 65 I/O B_D_ETH1RXP ETH
LIFE 66 I/O B_D_ETH1TXP ETH
Connector SENS-A (yellow), Mating connector AS618-35SA
Pin I/O Signal Level, Power
SENS-A 01 O O_LSOUT6 VBAT / 2 A
SENS-A 02 O G_SENSGND10 GND, 2 A fused
SENS-A 03 O O_LSOUT7 VBAT / 2 A
SENS-A 04 O O_HSOUT4 VBAT / 8 A
SENS-A 05 O O_HSOUT4 VBAT / 8 A
SENS-A 06 O G_SENSGND09 GND, 2 A fused
SENS-A 07 O G_SENSGND17 GND, 2 A fused
SENS-A 08 O O_HSOUT3 VBAT / 8 A
SENS-A 09 O O_HSOUT3 VBAT / 8 A
SENS-A 10 O O_LSOUT5 VBAT / 2 A
SENS-A 11 O G_SENSGND08 GND, 2 A fused
SENS-A 12 O G_SENSGND07 GND, 2 A fused

Pinlayout | 5
Bosch Motorsport Vehicle_Control_Unit_VCU_Manual 13/136
Pin I/O Signal Level, Power
SENS-A 13 O G_SENSGND16 GND, 2 A fused
SENS-A 14 O G_SENSGND18 GND, 2 A fused
SENS-A 15 O G_SENSGND19 GND, 2 A fused
SENS-A 16 O O_LSOUT8 VBAT / 2 A
SENS-A 17 O O_VSENS19_12V 12 V, 250 mA
SENS-A 18 O O_VSENS20_12V 12 V, 250 mA
SENS-A 19 O O_VSENS10_12/5V 5 V / 12 V, 250 mA
SENS-A 20 G GND GND
SENS-A 21 O G_SENSGND20 GND, 2 A fused
SENS-A 22 G G_ANASCR GND, 2 A fused
SENS-A 23 I I_THERM1_N 0 to 5 V
SENS-A 24 I I_THERM1_P 0 to 5 V
SENS-A 25 O O_VSENS08_12/5V 5 V / 12 V, 250 mA
SENS-A 26 O O_VSENS16_12V 12 V, 250 mA
SENS-A 27 O O_VSENS09_12/5V 5 V / 12 V, 250 mA
SENS-A 28 O G_SENSGND06 GND, 2 A fused
SENS-A 29 I I_THERM2_P 0 to 5 V
SENS-A 30 O O_DIGOUT4 5 V / 50 mA
SENS-A 31 O O_DIGOUT3 5 V / 50 mA
SENS-A 32 O O_DIGOUT2 5 V / 50 mA
SENS-A 33 O O_DIGOUT1 5 V / 50 mA
SENS-A 34 O O_VSENS18_12V 12 V, 250 mA
SENS-A 35 O O_VSENS07_12/5V 5 V / 12 V, 250 mA
SENS-A 36 O O_VSENS06_12/5V 5 V / 12 V, 250 mA
SENS-A 37 O O_VSENS17_12V 12 V, 250 mA
SENS-A 38 I I_THERM2_N 0 to 5 V
SENS-A 39 I I_ANA08_5V 0 to 5 V
SENS-A 40 I I_ANA09_5V 0 to 5 V
SENS-A 41 I I_ANA10_5V 0 to 5 V
SENS-A 42 I I_ANA07_5V 0 to 5 V
SENS-A 43 I I_LVDT4_SEC2N -5 to 5 V
SENS-A 44 I I_LVDT4_SEC_M -5 to 5 V
SENS-A 45 O O_LVDT4_PRI2 -5 to 5 V
SENS-A 46 G G_SCR_LVDT4 GND, 2 A fused
SENS-A 47 I I_ANA16_5V 0 to 5 V
SENS-A 48 I I_ANA20_5V 0 to 5 V
SENS-A 49 I I_ANA17_5V 0 to 5 V
SENS-A 50 I I_ANA24_20V 0 to 20 V
SENS-A 51 I I_LVDT4_SEC1P -5 to 5 V
SENS-A 52 O O_LVDT4_PRI1 -5 to 5 V
SENS-A 53 I I_LVDT3_SEC_M -5 to 5 V
SENS-A 54 G G_SCR_LVDT3 GND, 2 A fused

5 | Pinlayout
14/136 Vehicle_Control_Unit_VCU_Manual Bosch Motorsport
Pin I/O Signal Level, Power
SENS-A 55 I I_ANA18_5V 0 to 5 V
SENS-A 56 I I_ANA19_5V 0 to 5 V
SENS-A 57 I I_ANA23_20V 0 to 20 V
SENS-A 58 I I_LVDT3_SEC1P -5 to 5 V
SENS-A 59 I I_LVDT3_SEC2N -5 to 5 V
SENS-A 60 O O_LVDT3_PRI2 -5 to 5 V
SENS-A 61 I I_ANA06_5V 0 to 5 V
SENS-A 62 I I_THERM3_N 0 to 5 V
SENS-A 63 I I_THERM3_P 0 to 5 V
SENS-A 64 O O_LVDT3_PRI1 -5 to 5 V
SENS-A 65 I I_THERM4_N 0 to 5 V
SENS-A 66 I I_THERM4_P 0 to 5 V
Connector SENS-B (blue), Mating connector AS618-35SB
Pin I/O Signal Level, Power
SENS-B 01 O O_VSENS04_12/5V 5 V / 12 V, 250 mA
SENS-B 02 O O_VSENS05_12/5V 5 V / 12 V, 250 mA
SENS-B 03 I I_LVDT2_SEC1P -5 to 5 V
SENS-B 04 O O_VSENS02_12/5V 5 V / 12 V, 250 mA
SENS-B 05 O O_VSENS03_12/5V 5 V / 12 V, 250 mA
SENS-B 06 O O_VSENS15_12V 12 V, 250 mA
SENS-B 07 O O_VSENS14_12V 12 V, 250 mA
SENS-B 08 I I_LVDT2_SEC_M -5 to 5 V
SENS-B 09 O O_LVDT2_PRI1 -5 to 5 V
SENS-B 10 O O_VSENS01_12/5V 5 V / 12 V, 250 mA
SENS-B 11 O O_VSENS12_12V 12 V, 250 mA
SENS-B 12 O O_VSENS13_12V 12 V, 250 mA
SENS-B 13 O G_SENSGND02 GND, 2 A fused
SENS-B 14 I I_LVDT2_SEC2N -5 to 5 V
SENS-B 15 O O_LVDT2_PRI2 -5 to 5 V
SENS-B 16 G G_SCR_LVDT1 GND, 2 A fused
SENS-B 17 O O_LSOUT2 VBAT / 2 A
SENS-B 18 O O_VSENS11_12V 12 V, 250 mA
SENS-B 19 O G_SENSGND04 GND, 2 A fused
SENS-B 20 O G_SENSGND03 GND, 2 A fused
SENS-B 21 O G_SENSGND01 GND, 2 A fused
SENS-B 22 O O_LVDT1_PRI1 -5 to 5 V
SENS-B 23 O O_LVDT1_PRI2 -5 to 5 V
SENS-B 24 I I_LVDT1_SEC2N -5 to 5 V
SENS-B 25 O O_HSOUT1 VBAT / 8 A
SENS-B 26 O O_HSOUT1 VBAT / 8 A
SENS-B 27 O G_SENSGND11 GND, 2 A fused

Pinlayout | 5
Bosch Motorsport Vehicle_Control_Unit_VCU_Manual 15/136
Pin I/O Signal Level, Power
SENS-B 28 O G_SENSGND05 GND, 2 A fused
SENS-B 29 V V_UBAT VBAT
SENS-B 30 G GND GND
SENS-B 31 G G_SCR_LVDT2 GND, 2 A fused
SENS-B 32 I I_LVDT1_SEC_M -5 to 5 V
SENS-B 33 I I_LVDT1_SEC1P -5 to 5 V
SENS-B 34 O O_LSOUT1 VBAT / 2 A
SENS-B 35 O G_SENSGND12 GND, 2 A fused
SENS-B 36 V V_UBAT VBAT
SENS-B 37 V V_UBAT VBAT
SENS-B 38 G GND GND
SENS-B 39 G GND GND
SENS-B 40 I I_ANA13_5V 0 to 5 V
SENS-B 41 I I_ANA21_20V 0 to 20 V
SENS-B 42 I I_ANA22_20V 0 to 20 V
SENS-B 43 O O_LSOUT3 VBAT / 2 A
SENS-B 44 O G_SENSGND13 GND, 2 A fused
SENS-B 45 V V_UBAT VBAT
SENS-B 46 G GND GND
SENS-B 47 I I_ANA05_5V 0 to 5 V
SENS-B 48 I I_ANA11_5V 0 to 5 V
SENS-B 49 I I_ANA14_5V 0 to 5 V
SENS-B 50 I I_ANA15_5V 0 to 5 V
SENS-B 51 O O_HSOUT2 VBAT / 8 A
SENS-B 52 O G_SENSGND14 GND, 2 A fused
SENS-B 53 O G_SENSGND15 GND, 2 A fused
SENS-B 54 I I_ANA01_5V 0 to 5 V
SENS-B 55 I I_ANA02_5V 0 to 5 V
SENS-B 56 I I_ANA_HSL2 0 to 5 V
SENS-B 57 I I_ANA12_5V 0 to 5 V
SENS-B 58 O O_HSOUT2 VBAT / 8 A
SENS-B 59 O O_LSOUT4 VBAT / 2 A
SENS-B 60 I I_ANA_HSL5 0 to 5 V
SENS-B 61 I I_ANA_HSL4 0 to 5 V
SENS-B 62 I I_ANA04_5V 0 to 5 V
SENS-B 63 I I_ANA_HSL1 0 to 5 V
SENS-B 64 I I_ANA_HSL6 0 to 5 V
SENS-B 65 I I_ANA03_5V 0 to 5 V
SENS-B 66 I I_ANA_HSL3 0 to 5 V

6 | Communication Channels
16/136 Vehicle_Control_Unit_VCU_Manual Bosch Motorsport
6 Communication Channels
CAN bus
The Vehicle Control Unit VCU has two CAN buses configurable as input and output. Dif-
ferent baud rates are selectable. Please note that the Vehicle Control Unit VCU does not
contain any CAN termination resistors. Thus, the CAN termination resistors need to be in-
tegrated into the wiring loom.
Ethernet channels
The Vehicle Control Unit VCU has three 100 MBit full duplex Ethernet communication
ports. The ports are internally connected with an Ethernet switch. The Ethernet ports have
'cable auto crossover' functionality.
RS232 port
The Vehicle Control Unit VCU has one RS232 serial port dedicated to inbound GPS data.
Vehicle diagnosis connector
The Bosch Motorsport vehicle diagnosis connector is used as a standard interface to con-
nect the vehicle to a PC e.g. via a MSA-Box II. Loom connector: AS012-35SN
Pin Name Description Used for Vehicle Control Unit
VCU
Pin 1 Terminal 30 Permanent positive +
Pin 2 Terminal 15 Switched positive +
Pin 3 Terminal 31 GND +
Pin 4 CAN High Diagnostic CAN bus
Pin 16 CAN Low Diagnostic CAN bus
Pin 10 K-Line ECU diagnosis
Pin 8 Ethernet RxD + Ethernet interface +
Pin 9 Ethernet RxD - Ethernet interface +
Pin 11 Ethernet TxD + Ethernet interface +
Pin 12 Ethernet TxD - Ethernet interface +
Pin 22 Screen Cable screen +

Mechanical Drawing | 7
Bosch Motorsport Vehicle_Control_Unit_VCU_Manual 17/136
7 Mechanical Drawing
86.6
20
86.6
16
YAW RATE SENSOR
Drehratensensor

8 | Starting Up
18/136 Vehicle_Control_Unit_VCU_Manual Bosch Motorsport
8 Starting Up
8.1 Before starting
Install the software required Vehicle Control Unit VCU operation. It is developed for Win-
dows system software. Following software versions are used in this manual:
– Vehicle Control Unit VCU setup, configuration and calibration: RaceCon
– Measurement data analysis: WinDarab
Set up the 100 Mbit Ethernet connection to the Vehicle Control Unit VCU.
– The Ethernet port has ‘cable auto crossover’ functionality
8.1.1 Setting up a new RaceCon Project
The following screenshot shows an overview of the RaceCon Main Screen with its areas.
All (sub-) windows are resizable and dockable. You can find them under the ‘Windows’
tab.
Project
Tree
Data Area Message Area
Main Area
Toolbox
1. Start the RaceCon software.

Starting Up | 8
Bosch Motorsport Vehicle_Control_Unit_VCU_Manual 19/136
2. In the ‘File’ menu select ‘New project’ to create a new project.
Note: The Vehicle Control Unit VCU is represented in RaceCon by two symbols: VCU-
Logger and VCU-ECU.
3. Unlike other Bosch Motorsport devices, the Vehicle Control Unit VCU needs two dif-
ferent program archives – the Logger program archive and the ECU program archive.
For the Logger program archive, go to the Toolbox and select the Vehicle Control
Unit VCU. Drag it into the Main Area. A pop up window appears, to specify the
Vehicle Control Unit VCU Logger program archive.

8 | Starting Up
20/136 Vehicle_Control_Unit_VCU_Manual Bosch Motorsport
4. In the next step, the ECU needs to be specified.
A pop up window appears, to specify the ECU program archive.
5. Download the firmware for the Vehicle Control Unit VCU from www.bosch-
motorsport.com.
An information shows if the archive is valid or not.
6. Click ‘Next’.
