Bosch Conettix D6600 Operating instructions

Conettix Communications Receiver/Gate-
way
D6600/D6100IPv6
en Installation and Operation Guide

Table of contents
1Emergency Procedures 6
2Introduction 7
2.1 About documentation 7
2.2 Bosch Security Systems, Inc. Product Manufacturing Dates 7
3System overview 9
3.1 Parts List 10
4Quick Installation 11
4.1 Setting the Time and Date 13
5Card Functions and Locations 14
5.1 D6600 Front Panel 14
5.2 Line Cards and Modules 15
5.3 D6600 Rear View 16
5.3.1 D6600 Internal View 17
5.4 D6100IPv6 Front Panel 18
5.5 D6100IPv6 Rear View 18
6D6600 Specific Cards 19
6.1 D6640/D6641 Line Cards and D6645 Line Terminator Cards 19
6.1.1 D6640/D6641 LED Descriptions 20
6.2 Card Installation 20
6.3 D6610 CPU Card and D6615 CPU Terminator Card 22
6.4 Card Removal and Replacement 23
7Printer Specifications 24
8Installation 25
8.1 Installation Check List 25
8.2 Rack Mount Instructions 26
8.3 Removing Power to the Receiver 26
9Power 27
9.1 Power Supply Modules 27
9.2 Main Power 27
9.3 Standby Power 27
9.4 Connecting External Batteries 27
9.4.1 Minimum Standby Battery 28
9.4.2 Minimum Standby UPS Power 29
9.4.3 Estimated BTU Load 29
10 Input and Output Ports 30
10.1 Overview of Input and Output Ports 30
10.1.1 UPS Monitoring through CPU Programmable Input Ports 30
10.1.2 Automation Link Monitoring (COM3) through CPU Programmable Output Ports 32
11 D6600/D6100IPv6 Operation 33
11.1 Process Flow 33
11.1.1 Receiver Handshake and Kiss-Off 33
11.1.2 Message Verification 33
11.1.3 Handshake Tone Compatibility 33
11.1.4 Message is Received 33
11.1.5 How Call Groups Work 34
11.1.6 Buzzer Operation 34
11.1.7 Reporting Devices: Primary and Secondary 34
Conettix Communications Receiver/
Gateway Table of Contents | en 3
Bosch Security Systems, Inc. Installation and Operation Guide 2012.11 | 08 | 4998122704

11.2 Normal Operation Mode 35
11.3 Operating in Manual Mode 35
11.4 Keypad Menu Operation 36
11.4.1 Log In 36
11.4.2 Using the Keypad 36
11.4.3 Event Buffer Display 36
11.4.4 Current System Trouble Display 36
11.4.5 Software Version Display 37
11.4.6 Keypad Functions 37
11.5 Busy Seconds (Line Busy) Reports 38
11.6 Two-Way Audio 39
11.6.1 Enhancements and Changes 40
11.6.2 Two-Way Auto Modes of Operation 40
12 Network Communications 42
12.1 Conettix D6600/D6100IPv6 Pre-installation Requirements 46
12.1.1 Setting Up the Conettix D6600/D6100IPv6 over an Ethernet Network 46
12.1.2 Host Computer for Conettix D6600/D6100IPv6 System Setup 46
12.2 Operation 46
12.2.1 Setting Up the Host Computer 46
12.2.2 Network Failover Solution (D6600 Only) 51
12.2.3 Conettix Datagram Type Differences 53
12.2.4 Networking and Encryption 54
12.3 Special Conettix D6600 Applications 56
12.4 D6100IPv6 Configuration Setup Instructions 57
12.4.1 Factory Default IP Address 57
12.4.2 Identifying the MAC Hardware Address 58
12.4.3 Obtaining an IP Address 58
12.4.4 Using the D6200 to configure the D6100IPv6 58
12.4.5 Configuring for Network Communication 63
12.5 D6100i Configuration Setup Instructions 64
12.5.1 Identifying the MAC Hardware Address 64
12.5.2 Obtaining an IP Address 64
12.5.3 Initial IP Address Assignment Using ARP.EXE 65
12.5.4 Using Telnet to Finish the Configuration 66
12.5.5 Configuration Using Telnet 67
12.5.6 Configuring for Network Communication 70
13 No Data Received Reports 72
13.1 No Data Received 72
13.2 Data Error 72
13.3 Wrong Data 72
14 Central Station Automation System 73
15 Central Station Tips 75
15.1 Back-up Receiver 75
15.2 Computer Interface 75
15.3 D6200 Programming Software 75
15.4 Telephone Lines 75
15.5 Proper Ground 75
15.6 Radio Frequency Interference 76
15.7 Test Communicator 76
4en | Table of Contents Conettix Communications Receiver/
Gateway
2012.11 | 08 | 4998122704 Installation and Operation Guide Bosch Security Systems, Inc.

16 Troubleshooting Guide 77
17 Specifications 80
18 Service Information 84
Conettix Communications Receiver/
Gateway Table of Contents | en 5
Bosch Security Systems, Inc. Installation and Operation Guide 2012.11 | 08 | 4998122704

Emergency Procedures
i
Notice!
Throughout this document references to D6100IPv6 also apply to the D6100IPv6 unless other-
wise noted.
The Service Information, page 84 section of this guide contains a Service Information form.
Keep this form current and accessible to central station personnel at all times in case of
emergency.
If your D6600/D6100IPv6 becomes inoperable or experiences trouble receiving signals:
1. Notify your supervisor.
2. Refer to Troubleshooting Guide, page 77.
3. Contact Bosch Security Systems, Inc. at [phone] for assistance if you have a
receiver spares package and need to replace a circuit card or module.
i
Notice!
The AC/DC Power Supply Module and DC/DC Power Supply Module for the D6600 are not
field serviceable. Contact Bosch Security Systems, Inc. for service.
Caution!
Disconnect power to the receiver before removing the CPU or CPU terminator card.
Before Calling
1. Have this guide nearby and opened to Troubleshooting Guide, page 77.
2. Have your spares package, the D6200 Programming Software, and the D6600/D6100IPv6
Program Entry Guide (P/N: 4998122702) nearby.
3. Know the location of the telephone line jacks for the receiver.
4. Know the telephone numbers to the receiver’s telephone line cards.
5. Know the exact nature of the problem you are experiencing such as reports received,
LEDs lit, or Operator Alert Buzzer sounded.
6. Have the service information form nearby (refer to Service Information, page 84).
1
6en | Emergency Procedures Conettix Communications Receiver/
Gateway
2012.11 | 08 | 4998122704 Installation and Operation Guide Bosch Security Systems, Inc.

Introduction
About documentation
Document Terminology
Action buttons for the D6600/D6100IPv6 are described using the following terminology:
D6600 D6100IPv6 Terminology
[M/E] [ENTER] Enter
[∆] [∆] Up (a level)
[∇] [∇] Down (a level)
[CAN] [CANCEL] Cancel
[] [ACKNOWLEDGE] Acknowledge
[F] [FUNCTION] Function
Copyright
This document is the intellectual property of Bosch Security Systems, Inc. and is protected by
copyright. All rights reserved.
Trademarks
All hardware and software product names used in this document are likely to be registered
trademarks and must be treated accordingly.
Conettix Documentation
Conettix DX4020 Installation Guide – F01U045288
Conettix D6600/D6100IPv6 Quick Start (this document) – 4998122701
Conettix D6600/D6100IPv6 Program Entry Guide – 4998122702
Conettix D6600/D6100IPv6 Computer Interface Manual – 4998122703
Conettix D6600/D6100IPv6 Release Notes – 4998122709
D6202 Operation and Installation Guide – 4998122713
Conettix D6201 Installation Instructions – 4998122717
C900TTL-E Installation Guide – 4998122718
DeviceInstaller Operation and Installation Guide – 4998138688
Conettix D6680 Installation Guide – 4998138732
Conettix ITS-D6686 Installation Guide – F01U078049
Conettix D6600 Card Insertion Installation Guide – 4998141059
Conettix D6200 Operation and Installation Guide – 4998154991
Conettix C900V2 Installation Guide – F01U003472
Ethernet Communication Module B420 Operation and Installation Guide – F01U215236
Ethernet Communication Module B426 Operation and Installation Guide – F01U266226
Bosch Security Systems, Inc. Product Manufacturing Dates
Use the serial number located on the product label and refer to the Bosch Security Systems,
Inc. web site at http://www.boschsecurity.com/datecodes.
The following image shows an example of a product label and highlights where to find the
manufacturing date within the serial number.
2
2.1
2.2
Conettix Communications Receiver/
Gateway Introduction | en 7
Bosch Security Systems, Inc. Installation and Operation Guide 2012.11 | 08 | 4998122704

8en | Introduction Conettix Communications Receiver/
Gateway
2012.11 | 08 | 4998122704 Installation and Operation Guide Bosch Security Systems, Inc.

System overview
i
Notice!
The D6600/D6100IPv6 Installation and Operation Guide covers the general installation and op-
eration of the products.
Refer to the appropriate Installation Supplement included with your product for the specifics
of your particular installation.
Customers ordering a D6100IPv6-01 receive a Model D6100IPv6 Communications Receiver/
Gateway, and should refer to the UL864 & UL1610 Installation Supplement (P/N: F01U134241)
included with the product.
The Conettix D6600/D6100IPv6 Communications Receiver/Gateway offers several unique
features:
– Modular construction with plug-in circuit boards for quick, easy service
– Open-structure PC platform for future development
– Programmable formatting for receiving data from most major brands of digital
communicators
– Easy and inexpensive updating using modular cards (D6600 only)
– Convenient software downloads
– Superior digital signal processing to reduce noise and signal loss
– User interface module with LED indicators
– Front panel keypad
– Alphanumeric liquid crystal display (LCD The D6600 metal enclosure contains several
modular cards:
– Conettix D6610 Central Processing Unit (CPU) Card
– Conettix D6615 CPU Terminator Card
– Conettix D6640 or D6641 Telephone Line Card that supports four telephone line
interfaces
– Conettix D6645 Telephone Line Terminator Card
Up to seven additional telephone line cards along with seven additional line terminator cards
can be installed in the D6600 to expand the receiver’s capacity to 32 receiving lines.
D6600/D6100IPv6 Supported Communication Formats
Acron Super Fast ROBOFON*
Ademco Slow Scantronics Scancom*
Ademco Express Seriee FSK/DTMF*
Ademco High Speed Sescoa Super Speed
Ademco Contact ID SIA 8/20/300
CFSK Bell/V.21* SIA ADT*
FBI Superfast SIA V.21*
Franklin/Sescoa Silent Knight Fast
ITI* Silent Knight FSK
Radionics BFSK Standard Pulse Formats
Radionics Hex Sur-Gard DTMF
3
Conettix Communications Receiver/
Gateway System overview | en 9
Bosch Security Systems, Inc. Installation and Operation Guide 2012.11 | 08 | 4998122704

Radionics Modem II Telim*
Bosch Modem4/ModemIIIa²/ModemIIe Veritech FSK
RB2000 (D6641 only)* VONK (D6641 only)*
* Not investigated by UL.
– Use a printer to permanently record date, time, group number or transmission format and
line number, account number, receiver number, and event by area, zone, and point. The
printer tape and the D6600/D6100IPv6 LCD display show other receiver status messages
such as software revision levels of the CPU Card.
– Program the D6600/D6100IPv6 using the front panel keypad or through the COM4 port
with the D6200 Programming Software package.
– The Conettix D6600/D6100IPv6 support data network communications including an
account database capacity of up to 3200 accounts with the optional Conettix D6201 IP
Security Key.
– The D6600/D6100IPv6 works with the following Bosch Security Systems, Inc. control
panels (referred to throughout this manual as “Bosch control panels”): D9412GV3/
D7412GV3/D7212GV3, D9412GV2/D7412GV2/D7212GV2, D9412G/D7412G/D7212G/
D9412/D7412/D7212, and D911.
Parts List
Conettix D6600 System Components
– One Conettix D6600 Communications Receiver/Gateway
– One AC power cord
– One Battery cable P6601
– I/O cable P6602
– Two rack mount brackets
– Four 8/32 phillips-head screws
– One CD-ROM D6200CD
The D6X00 README.TXT file on the CD lists the installation files contained on the CD.
Conettix D6100IPv6 System Components
– Conettix D6100IPv6 Communications Receiver/Gateway
– 18 VAC transformer
– Battery cable P6601
– I/O cable P6602
– CD-ROM D6200CD
The D6X00 README.TXT file on the CD lists the installation files contained on the CD.
3.1
10 en | System overview Conettix Communications Receiver/
Gateway
2012.11 | 08 | 4998122704 Installation and Operation Guide Bosch Security Systems, Inc.

Quick Installation
D6600
1. Place the D6600 in a secure location.
2. Remove the tie wrap from the receiver door handle. Open the door and remove the
packaging foam from the front of the CPU Card.
3. Gently push the CPU and line cards into their slots until they connect securely.
4. Ensure that the D6600 power switch is in the OFF position.
5. Plug the AC power cord into the rear of the D6600.
6. Plug the other end into an unswitched 100 to 120 VAC (or 220 to 230 VAC), 50 to 60 Hz
line.
7. Refer to the figure AC Power and Telephone Connections, page 12. Plug the telephone
lines into the connectors on the first line terminator card.
8. If you need a network automation connection, skip this step and continue with the
remainder of the installation. For additional instructions on connecting automation
software to the network, refer to Network Communications, page 42. Refer to the figure
Automation PC and External Parallel Printer Connections, page 12. Connect the
automation computer (callout 1) to COM3 the center DB-9 connector on the CPU
terminator card, using a null-modem cable (callout 2).
9. Refer to the figure Automation PC and External Parallel Printer Connections, page 12.
Connect an external parallel printer, with the power off (callout 4), to the lower 25-pin
connector on the CPU terminator card (callout 5).
10. Turn the power switch on the D6600 to the ON position.
11. Press the UP button to increase display contract. Press the Down button to decrease
display contrast.
12. Press the Menu button to enter the menu.
13. On the Enter Password screen, type 6600 (default password).
14. Press the Enter button to enter the menu.
Use these keys to operate the D6600 menus:
Enter – Enter a menu level
Cancel– Return to the previous menu level
UP/Down arrow – Scroll through the menus
15. Set the Time and Date on the D6600 (refer to Setting the Time and Date, page 13).
16. The D6600 is ready to accept calls.
D6100IPv6
1. Place the D6100IPv6 in a secure location (such as a rack mount or desktop).
2. Refer to the figure AC Power and Telephone Connections, page 12. Plug telephone lines
into the connectors on the back of the D6100IPv6.
3. If you need a network automation connection, skip this step and continue with the
remainder of the installation. For additional instructions on connecting automation
software to the network, refer to Network Communications, page 42. Refer to the figure
Automation PC and External Parallel Printer Connections, page 12. Connect the
automation computer (callout 1) to COM3, the DB-9 connector using a null-modem cable
(callout 2).
4. Refer to the figure Automation PC and External Parallel Printer Connections, page 12.
Connect an external parallel printer (callout 4), with the power off, to the 25-pin
connector (callout 6).
5. Connect the transformer leads to the 18 VAC terminals and plug the other end into the
power source.
4
Conettix Communications Receiver/
Gateway Quick Installation | en 11
Bosch Security Systems, Inc. Installation and Operation Guide 2012.11 | 08 | 4998122704

6. Press the Up to increase the display contrast. Press the Down arrow to decrease the
display contrast.
7. Press the Menu button to enter the menu.
8. On the Enter Password screen, type 6100 (default password).
9. Press the Menu button to enter the menu.
Use these keys to operate the D6100IPv6 menus:
Menu – Enter a menu level
Cancel – Return to the previous menu level
Up/Down arrow – Scroll through the menus
10. Set the Time and Date on the D6100IPv6 (refer to Setting the Time and Date, page 13).
11. The D6100IPv6 is ready to accept calls.
AC Power and Telephone Connections
D6100IPv6D6600
Figure 4.1: AC Power and Telephone Connections
Callout ᅳ Description
1 ᅳ Telephone connection
2 ᅳ AC power terminals
3 ᅳ AC power connector
Automation PC and External Parallel Printer Connections
D6100IPv6
D6600
Figure 4.2: Automation PC and External Parallel Printer Connections
12 en | Quick Installation Conettix Communications Receiver/
Gateway
2012.11 | 08 | 4998122704 Installation and Operation Guide Bosch Security Systems, Inc.

Callout ᅳ Description
1 ᅳ Automation PC
2 ᅳ COM3 9-pin port (D6600)
3 ᅳ COM3 9-pin port (D6100IPv6)
4 ᅳ Parallel printer
5 ᅳ 25-pin parallel port (D6600)
6 ᅳ 25-pin parallel port (D6100IPv6)
Setting the Time and Date
i
Notice!
The Time and Date display format is determined by the programming for Menu Item 2.2.3 Set
Country.
Time Setup D6600/D6100IPv6
1. Press the Enter button to go to the log in screen.
2. Enter the password (6600 – default password).
3. Press the Enter button to go to the 1 Event Database
4. Press the Down button to go to 2 CPU Configuration.
5. Press the Enter button to go to 2.2 Global.
6. Press the Enter button to go to 2.2.1 Time Setup.
7. Press the Enter button to go to Set Time.
8. Enter the current time.
9. Press the Enter button to go to 2.2.1 Time Setup/New Time Set…
10. Press the Cancel button to return to the previous level.
Date Setup D6600/D6100IPv6
1. Press the Enter button to go to the log in screen.
2. Enter the password (6600 – default password).
3. Press the Enter button to go to the 1 Event Database.
4. Press the Down button to go to 2 CPU Configuration.
5. Press the Enter button to go to 2.2 Global.
6. Press the Enter button to go to 2.2.2 Date Setup.
7. Press the Enter button to go to Set Date.
8. Enter the current time.
9. Press the Enter button to go to 2.2.2 Date Setup/Current Setting…
10. Press the Cancel button to return to the previous level.
4.1
Conettix Communications Receiver/
Gateway Quick Installation | en 13
Bosch Security Systems, Inc. Installation and Operation Guide 2012.11 | 08 | 4998122704

Card Functions and Locations
D6600 Front Panel
1 2
Figure 5.1: D6600 Communications Receiver/Gateway (Front View)
Callout ᅳ Description
1 ᅳ LCD – shows up to 80 characters of information (two lines of up to 40 characters each).
2 ᅳ Keypad – the D6600 has a 20-button keypad.
The table below shows and defines the D6600/D6100IPv6 Power LEDs.
2.234
Battery
Supervision
Present Power LED Status
A
C
Battery Green Clear
Solid Blinking
On X X
X
X
Off X X
X
5
5.1
14 en | Card Functions and Locations Conettix Communications Receiver/
Gateway
2012.11 | 08 | 4998122704 Installation and Operation Guide Bosch Security Systems, Inc.

X
Table 5.1: Power LED Indications
The figure below shows and defines the D6600/D6100IPv6 System Trouble LEDs.
System Trouble LED Status
Solid Red or Yellow Clear
No System Trouble
Any System Trouble*
* Refer to Appendix B: D6600/D6100IPv6 Internal Messages in the D6600/D6100IPv6 Computer
Interface Manual (P/N: 4998122703). The following items cause system trouble. The items
indicated by ** can be enabled or disabled. If they are disabled, they will not cause a system
trouble condition.
Battery Missing**
UPS AC Fail**
Battery Bad**
UPS Battery Low**
AC Fail
System Temperature High
External Printing Error**
Line Fault**
COM# Error**
Line Card Trouble**
COM3 Trouble**
Table 5.2: System Trouble LED
Line Cards and Modules
Name Model Description
Telephone line card D6640 Legacy Card:
Up to eight line cards can be installed in
one D6600 Receiver, for up to 32
telephone line connections.
Telephone line card D6641 Functions like the D6640. Includes
improved Public Switched Telephone
Network (PSTN) processing, additional
memory for future enhancements such as
VoIP Compensation, and single firmware
upgrade package.
CPU card D6610 The D6600 uses one CPU card. The CPU
card takes the incoming information from
the line card and routes the information
to an automation port, the LCD on the
front of the receiver, and an external
printer.
5.2
Conettix Communications Receiver/
Gateway Card Functions and Locations | en 15
Bosch Security Systems, Inc. Installation and Operation Guide 2012.11 | 08 | 4998122704

Power supply modules D6630 and
D6631
The power supply modules regulate the
power used by the D6600. These are not
field serviceable.
Telephone line terminator
card
D6645 Located behind the line card, the
telephone line terminator card isolates
and protects the line card against outside
voltage surges that might come over the
telephone line. Each line card must have a
line terminator card.
CPU terminator card D6615 Located behind the CPU card, the CPU
terminator card provides the D6600 with
two serial ports (COM3 and COM4), a
parallel port (parallel printer), and a
general I/O port (I/O). The serial ports
can be used for computer automation, PC
connection for programming, or a network
connection with a Network Ethernet
Module (see specific installation guide
supplied with your product).
Table 5.3: D6600 Line Cards and Modules
D6600 Rear View
The D6600 has input and output pin connector sockets for up to eight line cards, network
option (if installed), and one CPU card. It also has slots for connecting these cards to their
corresponding terminator cards.
1
2
3
4
Bosch Security Systems
Fairport, NY USA
Input:
100 - 120/
220 - 240V~
50 - 60 Hz
2.5 Amps
B
A
T
T
E
R
Y
1 2 3
Figure 5.2: D6600 Communications Receiver/Gateway (Rear View)
Callout ᅳ Description
1 ᅳ Blank plate and location of optional Conettix D6672 COM1 Expansion Kit
2 ᅳ Conettix D6615 CPU Terminator Card
3 ᅳ Card slot covers
4 ᅳ Conettix D6645 Line Terminator Card
5.3
16 en | Card Functions and Locations Conettix Communications Receiver/
Gateway
2012.11 | 08 | 4998122704 Installation and Operation Guide Bosch Security Systems, Inc.

D6600 Internal View
Figure 5.3: Receiver Card Placement
Callout ᅳ Description
1 ᅳ Conettix D6645 Telephone Line Terminator Card
2 ᅳ Backplane
3 ᅳ Conettix D6615 CPU Terminator Card
4 ᅳ D6630 AC/DC Power Supply (not serviceable)
5 ᅳ Conettix D6610 CPU Card
6 ᅳ D6631 AC/DC Power Supply (not serviceable)
7 ᅳ Card guides
8 ᅳ Conettix D6640/D6641 Telephone Line Card
9 ᅳ Direction of receiver front
5.3.1
Conettix Communications Receiver/
Gateway Card Functions and Locations | en 17
Bosch Security Systems, Inc. Installation and Operation Guide 2012.11 | 08 | 4998122704

D6100IPv6 Front Panel
COMMUNICATIONS RECEIVER/GATEWAY
POWER
SYSTEM
TROUBLE
12
Figure 5.4: D6100IPv6 Communications Receiver/Gateway (Front View)
Callout ᅳ Description
1 ᅳ Liquid crystal display (LCD) - Displays up to 80 characters of information (two lines of
up to 40 characters each).
2 ᅳ 23-button keypad.
D6100IPv6 Rear View
Line Cards and Modules
The D6100IPv6 does not use the same line cards and modules as the D6600. These functions
are built in.
1 2
1
765 4 32
Figure 5.5: D6100IPv6 Communications Receiver/Gateway (Rear View)
Callout ᅳ Description
1 ᅳ Telephone line connections
2 ᅳ Input/output ports
3 ᅳ COM RS-232 port
4 ᅳ COM3 auxiliary RS-232 port
5 ᅳ Parallel port connection
6 ᅳ Ethernet port (D6100IPv6 only)
7 ᅳ USB port
8 ᅳ Power connection terminal block
5.4
5.5
18 en | Card Functions and Locations Conettix Communications Receiver/
Gateway
2012.11 | 08 | 4998122704 Installation and Operation Guide Bosch Security Systems, Inc.

D6600 Specific Cards
D6640/D6641 Line Cards and D6645 Line Terminator Cards
i
Notice!
Starting with D6200 v2.0 the D6640 Line Card is no longer be supported. Information about
the D6640 is provided in this section for legacy support only.
Figure 6.1: D6640/D6641 Line Card
Callout ᅳ Description
1 ᅳ 48-pin connection to D6645 Line Termination Card
2 ᅳ 40-pin connection to D6600 Back Plate
3 ᅳ LEDs (Refer to D6640/D6641 LED Descriptions, page 20)
6
6.1
Conettix Communications Receiver/
Gateway D6600 Specific Cards | en 19
Bosch Security Systems, Inc. Installation and Operation Guide 2012.11 | 08 | 4998122704

Figure 6.2: D6645 Line Terminator Card
Callout ᅳ Description
1 ᅳ 48-pin connection to D6640/D6641 Line Card.
2 ᅳ Alignment Guide - Stabilizes the connection and acts as a guide for connecting the
terminator card to the line card.
3 ᅳ Telco Line Jacks - Standard telephone lines connect to the RJ11C jacks.
D6640/D6641 LED Descriptions
Each LED represents a line. For example, LED 1 is for line 1. The LED is active until the system
acknowledges the entire transmission and the telephone line is ready to receive signals. The
following table describes LED patterns and colors, and their indications.
Flash Pattern (Color) Function
Flashes (green) An incoming call is ringing.
ON Steady (green)
The receiver is online.
ON Steady (red or yellow)
The line card detects a line fault condition.
OFF
The line card is ready to receive signals, or is
disabled.
Table 6.1: LED Descriptions
Card Installation
!
Warning!
Discharge static electricity from your body by touching the receiver’s internal frame (unpain-
ted section) before handling any circuit card.
6.1.1
6.2
20 en | D6600 Specific Cards Conettix Communications Receiver/
Gateway
2012.11 | 08 | 4998122704 Installation and Operation Guide Bosch Security Systems, Inc.
