Bosch PLR50 C User manual

English | 25
Bosch Power Tools 1 609 92A 1F3 | (20.8.15)
Luxemburg
Tel.: [phone]
Fax: [phone]
E-Mail: outillage.gere[email protected]osch.com
Entsorgung
Messwerkzeuge, Zubehör und Verpackungen sollen einer umweltgerechten Wieder-
verwertung zugeführt werden.
Werfen Sie Messwerkzeuge nicht in den Hausmüll!
Nur für EU-Länder:
Gemäß der europäischen Richtlinie 2012/19/EU müssen nicht
mehr gebrauchsfähige Messwerkzeuge und gemäß der europäi-
schen Richtlinie 2006/66/EG müssen defekte oder verbrauchte Ak-
kus/Batterien getrennt gesammelt und einer umweltgerechten Wie-
derverwendung zugeführt werden.
Nicht mehr gebrauchsfähige Akkus/Batterien können direkt abgegeben werden bei:
Deutschland
Recyclingzentrum Elektrowerkzeuge
Osteroder Landstraße 3
37589 Kalefeld
Schweiz
Batrec AG
3752 Wimmis BE
Änderungen vorbehalten.
English
Safety Notes
Allinstructions mustbereadand observedinorder to work safely
with the measuring tool. The integrated protections in the meas-
uring tool may be compromised if the measuring tool is not used
in accordance with the instructions provided. Never make warn-
ing signs on the measuring tool unrecognisable. STORE THESE IN-
STRUCTIONS IN A SAFE PLACE AND INCLUDE THEM WITH THE MEASURING
TOOL WHEN GIVING IT TO A THIRD PARTY.
OBJ_BUCH-2326-003.book Page 25 Thursday, August 20, 2015 8:43 AM

26 | English
1 609 92A 1F3 | (20.8.15) Bosch Power Tools
Caution – The use of other operating or adjusting equipment or the applica-
tion of other processing methods than those mentioned here can lead to dan-
gerous radiation exposure.
Themeasuringtoolisprovided with a warning label (marked with number 7in
the representation of the measuring tool on the graphics page).
If the text of the warning label is not in your national language, stick the pro-
vided warning label in your national language over it before operating for the
first time.
Do not direct the laser beam at persons or animals and do not
stare into the direct or reflected laser beam yourself, not even
from a distance. You could blind somebody, cause accidents or
damage your eyes.
If laser radiation strikes your eye, you must deliberately close your eyes and
immediately turn your head away from the beam.
Do not make any modifications to the laser equipment.
Do not use the laser viewing glasses as safety goggles. The laser viewing glass-
es are used for improved visualisation of the laser beam, but they do not protect
against laser radiation.
Do not use the laser viewing glasses as sun glasses or in traffic. The laser view-
ing glasses do not afford complete UV protection and reduce colour perception.
Have the measuring tool repaired only through qualified specialists using
original spare parts. This ensures that the safety of the measuring tool is main-
tained.
Do not allow children to use the laser measuring tool without supervision.
They could unintentionally blind other persons or themselves.
Do not operate the measuring tool in explosive environments, such as in the
presence of flammable liquids, gases or dusts. Sparks can be created in the
measuring tool which may ignite the dustor fumes.
Caution! When using the measuring tool with Bluetooth®, interference with
other devicesand systems, airplanes and medical devices(e.g.,cardiac pace-
makers, hearing aids) may occur. Also, the possibility of humans and animals
OBJ_BUCH-2326-003.book Page 26 Thursday, August 20, 2015 8:43 AM

English | 27
Bosch Power Tools 1 609 92A 1F3 | (20.8.15)
in direct vicinity being harmed cannot be completely exempt. Do not use the
measuring tool with Bluetooth®in the vicinity of medical devices, petrol sta-
tions, chemical plants, areas where there is danger of explosion, and areas
subject to blasting. Do not use the measuring tool with Bluetooth®in air-
planes. Avoid operation in direct vicinity of the body over longer periods.
Do not use the measuring tool if the touchscreen is visibly damaged (e.g.
cracks in the surface etc.).
The Bluetooth®word mark and logos are registered trademarks owned by Blue-
tooth SIG, Inc. and any use of such marks by Robert Bosch GmbH is under li-
cense.
Product Description and Specifications
Intended Use
The measuring tool is intended for measuring distances, lengths, heights, clearances
and inclines, and for calculating areas and volumes.
The measuring results can be transferred to other devices via Bluetooth®.
The help function integrated into the measuring tool provides detailed animations
about individual measuring functions/procedures.
Technical Data
Digital Laser Measure PLR 50 C
Article number 3 603 F72 2..
Distance measurement
Measuring range 0.05–50 mA)
Measuring accuracy (typical) ±2.0mmB)
Lowest indication unit 0.1 mm
Inclination measurement
Measuring range 0°–360°(4x90°)
Measuring accuracy (typical) ±0.2°C)/E)
Lowest indication unit 0.1°
General
Operating temperature –10 °C...+50 °CD)
Storage temperature –20 °C...+70 °C
Relative air humidity, max. 90 %
OBJ_BUCH-2326-003.book Page 27 Thursday, August 20, 2015 8:43 AM

28 | English
1 609 92A 1F3 | (20.8.15) Bosch Power Tools
Laser class 2
Laser type 635 nm, <1 mW
Laser beam diameter (at 25 °C)
approx.
–at10mdistance
–at50mdistance
9mm
45 mm
Automatic switch-off after approx.
–Laser
–Measuringtool
(without measurement)
–Bluetooth® (if inactive)
20 s
5min
3min
Weight according to EPTA-Procedure
01:2014 0.16 kg
Dimensions (length x width x height) 115x50x23mm
Batteries 3x1.5VLR03(AAA)
Battery life, approximately
– Individual measurements
– Continuous measurement
10000E) G)
2.5 hE) G)
Data transmission
Bluetooth®Bluetooth® 4.0 (Classic and Low Energy)F)
A) For measurements from the rear measuring-tool edge.Theworking range increases depending
on how well the laser light is reflected from the surface of the target (scattered, not reflective) and
the brighter the laser point is to the ambient light intensity (interior spaces, twilight). For distances
of less than 20 m a retro-reflective target plate should not be used, as it can lead to measurement
errors.
B) For measurements from the rear measuring-tool edge, 100 % reflectance of the target (e.g., a
white-painted wall), weak backlight and 25 °C operating temperature. Additionally, a deviation in-
fluence of ±0.05 mm/m must be taken into account.
C) After calibration at 0 ° and 90 ° with an additional grade error of ±0.01 °/degree to 45 ° (max.).
D) In the continuous measurement function, the maximum operating temperature is +40 °C.
E) At 25 °C operating temperature
F) For Bluetooth® low energy devices, establishing a connection may not be possible, depending on
model and operating system. Bluetooth® devices must support the SPP profile.
G) Bluetooth® deactivated
The measuring tool can be clearly identified with the serial number 6on the type plate.
Digital Laser Measure PLR 50 C
OBJ_BUCH-2326-003.book Page 28 Thursday, August 20, 2015 8:43 AM

English | 29
Bosch Power Tools 1 609 92A 1F3 | (20.8.15)
Declaration of Conformity
We declare under our sole responsibility that the product described under “Technical
Data” complies with all applicable provisions of the directives 1999/5/EC and
2011/65/EU including their amendments and is in conformity with the following
standards: EN 61010-1: 2010-10, EN 60825-1: 2014-08,
EN 300 328 V1.8.1: 2012-06, EN 301 489-1 V1.8.1: 2008-04,
EN 301 489-1 V1.9.2: 2011-09, EN 301 489-17 V2.2.1: 2012-09,
EN 62479: 2010-09.
Technical documents at:
Robert Bosch GmbH, PT/ETM9,
70764 Leinfelden-Echterdingen, GERMANY
Robert Bosch GmbH, Power Tools Division
70764 Leinfelden-Echterdingen, GERMANY
Leinfelden, 20.08.2015
Product Features
The numbering of the product features shown refers to the illustration of the measur-
ing tool on the graphic page.
1Measuring button/On/Off button
2Touchscreen
3Positioning plate
4Battery lid
5Latch of battery lid
6Serial number
7Laser warning label
8Laser beam outlet
9Reception lens
10 Laser viewing glasses*
11 Laser target plate*
12 Protective pouch
Henk Becker
Executive Vice President
Engineering
Helmut Heinzelmann
Head of Product Certification
PT/ETM9
OBJ_BUCH-2326-003.book Page 29 Thursday, August 20, 2015 8:43 AM

30 | English
1 609 92A 1F3 | (20.8.15) Bosch Power Tools
Display elements (selection)
aStatus Bluetooth®
bTemperature warning
cBattery indicator
dLaser switched on
eButton for reference level of measurement
fPrevious measured values
gReading
hDelete button
iMenu button
jBluetooth® button
kMeasuring functions button
lHelp function button
mScroll up/down button
nBack button
Bluetooth® activated, no connection established
Bluetooth® activated, connection established
Length measurement
Area/surface measurement
Volume measurement
Addition/subtraction of lengths
Addition/subtraction of areas
Addition/subtraction of volumes
Indirect height measurement
Indirect length measurement
Double indirect height measurement
Inclination Measurement
Digital Spirit Level
Continuous measurement
OBJ_BUCH-2326-003.book Page 30 Thursday, August 20, 2015 8:43 AM

English | 31
Bosch Power Tools 1 609 92A 1F3 | (20.8.15)
oSettings button
pMeasured-value list button
* The accessories illustrated or described are not included as standard delivery.
Assembly
Inserting/Replacing the Batteries
Using alkali-manganese or rechargeable batteries is recommended for operation of
the measuring tool.
Less measurements are possible when using 1.2 V rechargeable batteries than with
1.5 V batteries.
To open the battery lid 4, fold out the positioning plate 3, press the latch 5in the di-
rection of the arrow and remove the battery lid. Insert the batteries/rechargeable bat-
teries. When inserting,payattentiontothecorrectpolarityaccordingtotherepresen-
tation on the inside of the battery compartment.
If the battery symbol first appears in the display, then at least 100measurements
are still possible. When the battery symbol is empty, you have to replace the batter-
ies/rechargeable batteries because measurements are no longer possible.
Always replace all batteries/rechargeable batteries at the same time. Do not use dif-
ferent brands or types of batteries/rechargeable batteries together.
Remove the batteries/rechargeable batteries from the measuring tool when
not using it for longer periods. When storing for longer periods, the batteries/re-
chargeable batteries can corrode and self-discharge.
Operation
Using the Touchscreen
Do not use the measuring tool if the touchscreen is visibly damaged (e.g.
cracks in the surface etc.).
The display is divided into the Status bar (A), Touchscreen
(B) and Menu bar (C) sections.
The status bar shows the Bluetooth® connection status, the
temperature warning and the charging state of the batteries/
rechargeable batteries.
The measuring tool can be controlled by touching the buttons
on the touchscreen.
A
C
B
OBJ_BUCH-2326-003.book Page 31 Thursday, August 20, 2015 8:43 AM

32 | English
1 609 92A 1F3 | (20.8.15) Bosch Power Tools
The menu bar provides additional functions (e.g. Bluetooth® on/off, menu, delete).
Use only your fingers to operate the touchscreen.
Lightly tap the corresponding button. Do not apply high pressure or use sharp ob-
jects to tap the touchscreen.
Do not bring the touchscreen into contact with other electrical devices or water.
To clean the touchscreen, switch the measuring tool off and wipe off dirt using, for
example, a microfibre cloth.
Initial Operation
Do not leave the switched-on measuring tool unattended and switch the mea-
suring tool off after use. Other persons could be blinded by the laserbeam.
Protect the measuring tool against moisture and direct sun light.
Do not subject the measuring tool to extreme temperatures or variations in
temperature. As an example, do not leave it in vehicles for a long time. In case of
large variations in temperature, allow the measuring tool to adjust to the ambient
temperature before putting it into operation. In case ofextreme temperatures or
variations in temperature, the accuracy of the measuring tool can be impaired.
Avoid heavy impact to or falling down of the measuring tool. After severe exte-
rior effects to the measuring tool, it is recommended to carry out an accuracy
check (see “Accuracy Check and Calibration of the Grade Measurement” and “Ac-
curacy Check of the Distance Measurement” on page 40) each time before contin-
uing to work).
Switching On and Off
To switch on the measuring tool, briefly press the measuring button 1. When the
measuring tool is switched on, the laser beam is not yet switched on.
To switch off the measuring tool, press the measuring button 1and hold it down.
If no physical or graphical button is pressed on the measuring tool for approx. 5 min-
utes, the measuring tool will switch off automatically to save the batteries/rechargea-
ble batteries.
All stored valuesare retained when the tool is switched off.
OBJ_BUCH-2326-003.book Page 32 Thursday, August 20, 2015 8:43 AM

English | 33
Bosch Power Tools 1 609 92A 1F3 | (20.8.15)
Measuring Procedure
Once switched on, the measuring tool is in the length measure-
ment function. Other measuring functions can be set by pressing
the kbutton (see “Measuring Functions”, page 34).
Once the measuring tool has been switched on, the rear edge of
the measuring tool is selected as the reference level for measure-
ment. Press the ebutton to change the reference level (see “Se-
lecting the Reference Level”, page 34).
Place the measuring tool with the selected reference plane against the desired start-
ing point of the measurement (e.g. a wall).
To switch on the laser beam, briefly press the measuring button 1.
Do not point the laser beam at persons or animals and do not look into the la-
ser beam yourself, not even from a large distance.
Aim the laser beam at the target surface. To initiate the measurement, briefly press
the measuring button 1again.
In the function continuous measurement, the measurement begins the first time you
press the measuring button 1.
The measured value typically appears within 0.5 seconds and no later than 4 sec-
onds. The duration of the measurement depends on the distance, the lighting condi-
tions and the reflective properties of the target surface.
If no measurement has taken place approx. 20 seconds after sighting, the laser beam
is switched off automatically to save the batteries and the display is dimmed.
Integrated Help Function
Help in the form of an animation is stored in the measuring tool for
each measuringfunction. Firstselect the kbutton andthenthere-
quired measuringfunction.Theanimationshowsyouthedetailed
procedure for the selected measuring function.
The animation can be stopped and started again at any time. You
can scroll forward and back.
OBJ_BUCH-2326-003.book Page 33 Thursday, August 20, 2015 8:43 AM

34 | English
1 609 92A 1F3 | (20.8.15) Bosch Power Tools
Selecting the Reference Level (see figures A – C)
For the measurement, you can select between three different reference planes:
– the rear measuring-tool edge (e.g. when measuring onward from a wall),
–Thepositioningplate3folded out by 180° (e.g. when measuring from a corner),
– The front edge of the measuring tool (e.g. when measuring from a table edge).
To select the reference level, press theebutton and select the required reference lev-
el on the touchscreen. The rear edge of the measuring tool is preset as the reference
level every time the measuring tool is switched on.
Subsequentchangingofthe referencelevel formeasurementsthathavealreadybeen
carried out (e.g. when indicating measuring values in the measured-value list) is not
possible.
“Basic Settings”
To go to the “Basic Settings” menu, press the ibutton and then
the obutton.
Now select the required button to deactivate or to activate the
function. A deactivated setting is shown as a grey symbol, while
an activated setting is shown as a white symbol.
To exit the “Basic Settings” menu, press the nbutton.
Measuring Functions
Simple Length Measurement
Use simple length measurement to measure distances, lengths, heights and clearanc-
es, etc.
Press the kbutton and then select the button for length measurement .
Briefly press the measuring button 1once to switch on the laser and once to measure.
Basic Settings
Inclination Calibration Start
Tone Signals On Off
Bluetooth®OnOff
OBJ_BUCH-2326-003.book Page 34 Thursday, August 20, 2015 8:43 AM

English | 35
Bosch Power Tools 1 609 92A 1F3 | (20.8.15)
Area Measurement
Use area measurement to measure the length and width one after the other as with a
length measurement. Thelaser beam remains switched on between the two measure-
ments. After the second measurement has been completed, the area will be automat-
ically calculated and displayed.
Press the kbutton and then select the button for area measurement .
Volume Measurement
Use volume measurement to measure the length, width and height one after the other
as with a length measurement. The laser beam remains switched on between the
three measurements. After the third measurement has been completed, the volume
will be automatically calculated and displayed.
Press the kbutton and then select the button for volume measurement .
Addition/Subtraction of Lengths, Areas, Volumes
Use addition/subtraction of lengths, areas or volumes to measure lengths, areas or
volumes and to automatically add or subtract them (e.g. helpful when calculating ma-
terials).
Press the kbutton and then select the button for length calculation or area
calculation or volume calculation .
Use the button to switch between “+” and “–” or to start a new calculation. To
complete the addition/subtraction, press the measuring button 1.
Values above 9999999 m3or below –999999 m3cannot be shown; “ERROR” ap-
pears on the display.
Indirect Distance Measurement
Note: Indirect distance measurement is always less accurate than direct distance
measurement. For application-relatedreasons, measuring errors can be greater than
with direct distance measurement. To improve measuring accuracy, we recommend
placing themeasuring tool againstor on a firm surface.
The indirect distance measurement is used to measure distances that cannot be
measured directly because an obstacle would obstruct the laser beam or no target
surface is available as a reflector. This measuring procedure can only be used in ver-
tical direction. Any deviation in horizontal direction leads to measuring errors.
For indirect length measurements, three measuring modes are available. Each meas-
uring mode can be used for determining different distances.
OBJ_BUCH-2326-003.book Page 35 Thursday, August 20, 2015 8:43 AM

36 | English
1 609 92A 1F3 | (20.8.15) Bosch Power Tools
a) Indirect height measurement
Press the kbutton and select the button for indirect height measurement .
Pay attention that the measuring tool is positioned at the same height as the bottom
measuring point.
b) Double indirect height measurement
Press thekbutton and select the button for double indirect height measurement .
Pay attention that the reference plane of the measurement (e.g. the rear edge of the
measuring tool) remains exactly at the samelocation for all individual measurements
within a measuring sequence.
c) Indirect length measurement
Press the kbutton and select the button for indirect length measurement .
Pay attention that the measuring tool is positioned at the same height as the sought
measuring point.
Inclination Measurement
Press the kbutton and select the button for grade measurement .
Inclination measurement is used to measure a slope or incline
(e.g. of stairs, railings, when fitting furniture, laying pipes, etc.).
The left-hand side of the measuring tool serves as the reference
level for grade measurement. If no incline angle is shown on the
display, the measuring tool was tipped sideways too severely dur-
ing measurement.
You can hold the current measured value by pressing the measur-
ing button 1or the button on the display.
Digital Spirit Level
Press the kbutton and select the button for the digital spirit level .
The digital spirit level is used to check the horizontal alignment of
an object simultaneously on two axes (e.g. washing machine, re-
frigerator, etc.).
Therearofthemeasuringtoolservesasthe reference level for the
digital spirit level.
You can hold the current measured value by pressing the measur-
ing button 1or the button on the display.
OBJ_BUCH-2326-003.book Page 36 Thursday, August 20, 2015 8:43 AM

English | 37
Bosch Power Tools 1 609 92A 1F3 | (20.8.15)
Continuous Measurement (Tracking) / Minimum/Maximum Measurement
(see figure D)
For continuous measurements, the measuring tool can be moved relative to the tar-
get, whereby the measuring value is updated approx. every 0.5 seconds. In this man-
ner, as an example, you can move a certain distance away from a wall, while the actual
distance can always be read.
Press thekbutton and select the button for continuous measurement .Pressthe
measuring button 1to start the continuous measurement.
The minimum measurement is used to determine the shortest distance from a fixed
reference point. It is used, as an example, for determining plumb lines or horizontal
partitions.
The maximum measurement is used to determine the greatest distance from a fixed
reference point. It is used, as an example, for determining diagonals.
Continuous measurement automatically switches off after 4 mins. The last measured
value remains on the display.
List of the Last Measured Values/Calculations
The measuring tool stores the last 10 measured values and their calculations and dis-
plays them in reverse order (most recent measured value/most recent calculation
first).
Press the ibutton and select the pbutton.
Deleting Measured Values in the Measured-Value List
Press the ibutton and select the pbutton.
After selecting the hbutton, you can delete either the entire
measured-value list or individual measured values. Press the but-
ton hto delete the selected individual measured value.
Data Transmission to other Devices
The measuring tool is equipped with a Bluetooth® module, which enables data trans-
mission via radio technology to certain mobile terminals/devices with a Bluetooth® in-
terface (e.g., smartphones, tablets).
OBJ_BUCH-2326-003.book Page 37 Thursday, August 20, 2015 8:43 AM

38 | English
1 609 92A 1F3 | (20.8.15) Bosch Power Tools
For information on the necessary system requirements for a Bluetooth® connection,
please refer to the Bosch website at
www.bosch-pt.de.
For data transmission via Bluetooth®, time delays between mobile terminal/device
andmeasuringtoolmayoccur.Thiscanbepossibleduetothe distancebetweenboth
devices or the object being measured.
Activating the Bluetooth®Interface for Data Transmission to a Mobile Terminal/
Device
To activate the Bluetooth® interface, press the Bluetooth® jbutton on the measuring
tool. Alternatively, the Bluetooth® interface can be activated via the “Basic Settings”
menu (see page 34).
Ensure that the Bluetooth® interface is activated on your mobile terminal/device.
ThespecialBoschapp“PLRmeasure&go”isavailabletoextendtherangeoffunctions
of the mobile terminal/device and to make data easier to process. It can be download-
ed in the respective stores, depending on the device:
The connection between mobile terminal/device and measuring tool is established af-
ter the Bosch application has started. If multiple active measuring tools are found, se-
lect the appropriate measuring tool.
The connection status and the active connection are displayed in the status bar of the
measuring tool (a).
If no connection can be established within 3 minutes of pressing the Bluetooth® jbut-
ton, Bluetooth® will automatically switch off to save the batteries/rechargeable bat-
teries.
OBJ_BUCH-2326-003.book Page 38 Thursday, August 20, 2015 8:43 AM

English | 39
Bosch Power Tools 1 609 92A 1F3 | (20.8.15)
Deactivating the Bluetooth®Interface
To deactivate the Bluetooth® interface, press the Bluetooth® jbutton or switch the
measuring tool off. Alternatively, the Bluetooth® interface can be deactivated via the
“Basic Settings” menu (see page 34).
Working Advice
Themeasuringtoolisequippedwitharadiointerface. Local operating restric-
tions, e.g. in airplanes or hospitals, are to be observed.
General Information
The reception lens 9and the laser beam outlet 8must not be covered when taking a
measurement.
The measuring tool must not be moved while taking a measurement (with the excep-
tion of the continuous measurement and grade measurement functions). Therefore,
place the measuring tool, as far as this is possible,againstoronafirmstoporsupport-
ing surface.
Influence Effects on the Measuring Range
The measuring range depends upon the light conditions and the reflection properties
ofthetarget surface. For improved visibilityofthelaserbeam when workingoutdoors
and whenthesunlightisintense,usethelaserviewingglasses10(accessory) and the
laser target plate 11 (accessory), or shade off the target surface.
Influence Effects on the Measuring Result
Due to physical effects, faulty measurements cannot be excluded when measuring on
different surfaces. Included here are:
– Transparent surfaces (e.g., glass, water),
– Reflecting surfaces (e.g., polished metal, glass),
– Porous surfaces (e.g. insulation materials),
– Structured surfaces (e.g., roughcast, natural stone).
If required, use the laser target plate 11 (accessory) on these surfaces.
Furthermore,faulty measurements are also possible when sighting inclined target
surfaces.
Also, air layers with varying temperatures or indirectly received reflections can affect
the measured value.
OBJ_BUCH-2326-003.book Page 39 Thursday, August 20, 2015 8:43 AM

40 | English
1 609 92A 1F3 | (20.8.15) Bosch Power Tools
Accuracy Check and Calibration of the Grade Measurement
The tilt sensor is used in the “Inclination Measurement”, “Digital Spirit Level” and “In-
direct Distance Measurement” modes. When you are using these modes, we recom-
mend regular calibration (see “Basic Settings”, page 34). Follow the instructions on
the touchscreen.
We recommend that you perform an accuracy check and if necessary a calibration of
the measuring tool after extreme temperature variations and after impact to the tool.
After a temperature variation, the measuring tool must acclimatise for a while before
grade calibration is performed.
The measuring tool will automatically suggest a calibration after severe variations in
temperature.
Accuracy Check of the Distance Measurement
The accuracy of the distance measurement can be checked as follows:
– Select a permanently unchangeable measuring section which is approx. 3 to 10 m
long and which you know the exact length of (e.g. room width, door opening). The
measuring section must be indoors, and the target surface of the measurement
must be smooth and reflect well.
–Measurethedistance10 times after another.
The deviation of the individual measurements from the mean value must not exceed
±2 mm (max.). Log the measurements, so that you can compare their accuracy at a
later point of time.
Measuring with Positioning Plate (see figure B)
Using the positioning plate 3is suitable for applications such as measuring from a cor-
ner (room diagonal) or from hard-to-reach areas.
Fold out the positioning plate 3.
Set the reference level to measurement with positioning plate in the measuring tool.
When the measurement has been completed, fold the positioning plate 3back in.
Troubleshooting – Causes and Corrective Measures
Cause Corrective Measure
Temperature warning indicator (b) flashing; measurement not possible
The measuring tool is outside the operating tem-
perature range from – 10 °C to + 50 °C (in the
continuous measurement function up to
+40 °C).
Wait until the measuring tool has
reached the operating tempera-
ture
OBJ_BUCH-2326-003.book Page 40 Thursday, August 20, 2015 8:43 AM

English | 41
Bosch Power Tools 1 609 92A 1F3 | (20.8.15)
Battery indicator decreasing
Battery voltage decreasing (measurement still
possible).
Replace batteries/rechargeable
batteries
Battery indicator empty, measurement not possible
Battery voltage too low Replace batteries/rechargeable
batteries
“ERROR” indication in the display
The angle between the laser beam and the target
is too acute.
Enlarge the angle between the la-
ser beam and the target
The target surface reflects too intensely (e.g. a
mirror) or insufficiently (e.g. black fabric), or
the ambient light is too bright.
Workwiththelasertargetplate11
(accessory)
The laser beam outlet 8or the reception lens 9
are misted up (e.g. due to a rapid temperature
change).
Wipe the laser beam outlet 8
and/or the reception lens 9dry us-
ing a soft cloth
Calculated value is larger than 9 999 999 or
smaller than – 999 999 m/m2/m3.
Divide calculation into intermedi-
ate steps
The calibration of the grade measurement was
not carried out in the correct sequence or in the
correct positions.
Repeat the calibration according
to the instructions on the display
and in the operating instructions.
The surfaces used for calibration werenot pre-
cisely horizontal.
Repeat the calibration on a hori-
zontal surface and check the sur-
face beforehand if necessary us-
ing a spirit level.
The measuring tool was moved or tilted while
pressing the button.
Repeat the calibration and hold
the measuring tool in place while
pressing the button.
Cause Corrective Measure
OBJ_BUCH-2326-003.book Page 41 Thursday, August 20, 2015 8:43 AM

42 | English
1 609 92A 1F3 | (20.8.15) Bosch Power Tools
No Bluetooth®connection
“ERROR” indication in the display
Failure of the Bluetooth® connection Switch Bluetooth® off and back on
again.
Check the application on your mo-
bile terminal/device.
CheckifBluetooth®isactivated on
your measuring tool and mobile
terminal/device.
Check your mobile terminal/de-
vice for overload.
Reduce the distance between
measuring tool and your mobile
terminal/device.
Avoid obstructions (e.g., rein-
forced concrete, metal doors) be-
tween measuring tool and your
mobile terminal/device. Observe
clearance to electromagnetic dis-
turbances (e.g., WLAN transmit-
ters).
Bluetooth®cannot be activated
Battery voltage too low Replace batteries/rechargeable
batteries
Measuring result not plausible
The target surface does not reflect correctly
(e.g. water, glass).
Cover off the target surface
The laser beam outlet 8or the reception lens 9
are covered.
Make sure that the laser beam out-
let8or the reception lens 9are un-
obstructed
Wrong reference level set Select reference level that corre-
sponds to measurement
Obstruction in path of laser beam Laserpointmustbecompletelyon
target surface.
Cause Corrective Measure
OBJ_BUCH-2326-003.book Page 42 Thursday, August 20, 2015 8:43 AM

English | 43
Bosch Power Tools 1 609 92A 1F3 | (20.8.15)
The measuring tool monitors the correct operation in each measure-
ment. If a defect is detected, the display will show only the adjacent
symbol. In this case, or when the above mentioned corrective meas-
ures cannot correct an error, have the measuring tool checked by an
after-sales service agent for Bosch power tools.
Maintenance and Service
Maintenance and Cleaning
Store and transport the measuring toolonly in the supplied protective pouch.
Keep the measuring tool clean at all times.
Do not immerse the measuring tool in water or other fluids.
Wipe off debris using a moist and soft cloth. Do not use any cleaning agents or sol-
vents.
Maintain the reception lens 9in particular, with the same care as required for eye
glasses or the lens of a camera.
In case of repairs, send in the measuring tool packed in its protective pouch 12.
After-sales Service and Application Service
Our after-sales service responds to your questions concerning maintenance and re-
pair of your product as well as spare parts. Exploded views and information on spare
parts can also be found under:
www.bosch-pt.com
Bosch’s application service team willgladly answerquestions concerning our prod-
ucts and their accessories.
In all correspondence and spare parts orders, please always include the 10-digit arti-
cle number given on the nameplate of the product.
The display remains unchanged or the measuring tool reacts unexpectedly
when the measuring button or the buttons are pressed
Software error Remove the batteries/rechargea-
ble batteries, reinsert them and
restart the measuring tool.
Cause Corrective Measure
OBJ_BUCH-2326-003.book Page 43 Thursday, August 20, 2015 8:43 AM

44 | English
1 609 92A 1F3 | (20.8.15) Bosch Power Tools
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
At www.bosch-pt.co.uk you can order spare parts or arrange the collection of a prod-
uct in need of servicing or repair.
Tel. Service: [phone]
E-Mail: [email protected]
Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: [phone]
Fax: [phone]
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: [phone]
Fax: [phone]
Inside New Zealand:
Phone: [phone]
Fax: [phone]
Outside AU and NZ:
Phone: [phone]
www.bosch.com.au
Supplier code ERAC000385
OBJ_BUCH-2326-003.book Page 44 Thursday, August 20, 2015 8:43 AM
