Bosch Professional GLM 50-27 CG User manual

49.043 m
6.485 m
12.060
0.0° m
m19.020
Robert Bosch Power Tools GmbH
70538 Stuttgart
GERMANY
www.bosch-pt.com
1 609 92A 5YM (2021.01) O / 126
en Original instructions
zh 原始使用說明書
ko 사용 설명서 원본
th หนังสือคู่มือการใช้งานฉบับต้นแบบ
id Petunjuk-Petunjuk untuk Penggunaan
Orisinal
vi Bản gốc hướng dẫn sử dụng
1 609 92A 5YM
GLM 50-27 CG Professional

2 |
English ...................................................Page 13
繁體中文.................................................. 頁31
한국어 ...............................................페이지 48
ไทย...................................................... หน้า 65
Bahasa Indonesia..................................... Halaman 87
Tiếng Việt............................................... Trang 106
1 609 92A 5YM | (19.01.2021) Bosch Power Tools

| 3
49.043 m
6.485 m
12.060
0.0° m
m19.020
GLM 50-27 CG
49.043 m
6.485 m
12.060
0.0° m
m19.020
(1)(2)(3)
(4)
(5)
(6)
(7)
(8)
(a) (c) (d)
(e)
(f)
(g)
(h)
(b)
(9)
Bosch Power Tools 1 609 92A 5YM | (19.01.2021)

4 |
(10)
(11)
(12)
(13)
(14)
(15)
(16)
(10)
1 609 92A 5YM | (19.01.2021) Bosch Power Tools

| 5
B
B
A
(i) (j) (k)
Bosch Power Tools 1 609 92A 5YM | (19.01.2021)

6 |
X
1
1
BD
C
1 609 92A 5YM | (19.01.2021) Bosch Power Tools

| 7
1
2
X
1
2
X
1
1
B
F
GE
Bosch Power Tools 1 609 92A 5YM | (19.01.2021)

8 |
L3
L1
L2
H
0
1
2
0
1
2
1x0,5 m
2x 0,5 m
m
0.500m2x
1.000
0.500 m
set
B
G
G
H
1 609 92A 5YM | (19.01.2021) Bosch Power Tools

| 9
41 cm c m
40 c m 42
8.000
m
8 m
00
B
GJ
K
8.000 m
6.000 m
10.000 m
max
min
0.0°
8 m
I
Bosch Power Tools 1 609 92A 5YM | (19.01.2021)

10 |
49.043 m
6.485 m
12.060
0.0° m
m19.020
49.043 m
6.485 m
12.060
0.0° m
m19.020
49.043 m
6.485 m
12.060
0.0° m
m19.020
180°
90° 180°
180º
90º 180º
B
L
1 609 92A 5YM | (19.01.2021) Bosch Power Tools

| 11
B
M
(17)
(18)
Bosch Power Tools 1 609 92A 5YM | (19.01.2021)

12 |
GLM50 C
Professional
2 607 001 391
1 608 M00 05J (GLM 50-27 CG)
BT 150
0 601 096 B00
B
N
(17)
(18)
(19)
(20)
(21)
(22)
(23)
1 609 92A 5YM | (19.01.2021) Bosch Power Tools

English | 13
English
Safety Instructions
All instructions must be read and observed in order for the meas-
uring tool to function safely. The safeguards integrated into the
measuring tool may be compromised if the measuring tool is not
used in accordance with these instructions. Never make warning
signs on the measuring tool unrecognisable. SAVE THESE IN-
STRUCTIONS FOR FUTURE REFERENCE AND INCLUDE THEM WITH THE MEASUR-
ING TOOL WHEN TRANSFERRING IT TO A THIRD PARTY.
uWarning! If operating or adjustment devices other than those specified here are
used or other procedures are carried out, this can lead to dangerous exposure to
radiation.
uThe measuring tool is delivered with a laser warning sign (marked in the illustra-
tion of the measuring tool on the graphics page).
uIf the text of the laser warning label is not in your national language, stick the
provided warning label in your national language over it before operating for the
first time.
Do not direct the laser beam at persons or animals and do not
stare into the direct or reflected laser beam yourself. You could
blind somebody, cause accidents or damage your eyes.
uIf laser radiation hits your eye, you must close your eyes and immediately turn
your head away from the beam.
uDo not make any modifications to the laser equipment.
uDo not use the laser goggles (accessory) as protective goggles. The laser goggles
make the laser beam easier to see; they do not protect you against laser radiation.
uDo not use the laser goggles (accessory) as sunglasses or while driving. The laser
goggles do not provide full UV protection and impair your ability to see colours.
uHave the measuring tool serviced only by a qualified specialist using only ori-
ginal replacement parts. This will ensure that the safety of the measuring tool is
maintained.
uDo not let children use the laser measuring tool unsupervised. They could unin-
tentionally blind themselves or other persons.
Bosch Power Tools 1 609 92A 5YM | (19.01.2021)

14 | English
uDo not use the measuring tool in explosive atmospheres which contain flam-
mable liquids, gases or dust. Sparks may be produced inside the measuring tool,
which can ignite dust or fumes.
uCaution! Using the measuring tool with Bluetooth® can cause faults to occur in
other devices and systems, aeroplanes and medical devices (e.g. pacemakers,
hearing aids). Also, damage to people and animals in the immediate vicinity can-
not be completely excluded. Do not use the measuring tool with Bluetooth® in the
vicinity of medical devices, petrol stations, chemical plants, areas with a poten-
tially explosive atmosphere and in blasting areas. Do not use the measuring tool
with Bluetooth® on aeroplanes. Avoid using the product near your body for exten-
ded periods.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Robert Bosch Power Tools GmbH is under li-
cense.
Product Description and Specifications
Intended Use
The measuring tool is intended for measuring distances, lengths, heights, clearances and
inclines, and for calculating areas and volumes.
The measuring tool is suitable for indoor use.
The measuring results can be transferred to other devices via Bluetooth®.
Product features
The numbering of the product features shown refers to the illustration of the measuring
tool on the graphic page.
(1) Bluetooth® button
(2) Function button [Func]
(3) Minus/left [−] button
(4) Display
(5) Measuring button [ ]
(6) Plus/right [+] button
(7) Basic settings [ ] button
(8) On/off/back button [ ]
(9) Eyelet for carrying strapa)
1 609 92A 5YM | (19.01.2021) Bosch Power Tools

English | 15
(10) Laser warning label
(11) Serial number
(12) Battery compartment cover locking mechanism
(13) Battery compartment cover
(14) 1/4" tripod thread
(15) Reception lens
(16) Laser beam output
(17) Belt clipa)
(18) Screwa) for belt clipa)
(19) Laser target platea)
(20) Laser viewing glassesa)
(21) Tripoda)
(22) Carrying strapa)
(23) Protective bag
a) Accessories shown or described are not included with the product as standard. You can
find the complete selection of accessories in our accessories range.
Display elements (selection)
(a) Reference level of measurement
(b) Connection status
Bluetooth® activated, connection not established
Bluetooth® activated, connection established
(c) Battery indicator
(d) Measured value lines
(e) Result line
(f) Measuring function
(g) Slope angle display
(h) Status bar
(i) Measuring function display indicator
(j) Basic settings display indicator
(k) More settings display indicator
Bosch Power Tools 1 609 92A 5YM | (19.01.2021)

16 | English
Technical data
Digital laser measure GLM 50-27 CG
Article number 3 601 K72 U..
Distance measurement
Measuring range 0.05–50mA)
Measuring range (unfavourable conditions) 0.05–20mB)
Measuring accuracy ±1.5mmA)
Measuring accuracy (unfavourable conditions) ±3.0mmB)
Smallest display unit 0.5mm
Indirect distance measurement and level
Measuring range 0°–360° (4x90°)
Grade measurement
Measuring range 0°–360° (4x90°)
Measuring accuracy (typical) ±0.2°C)D)
Smallest display unit 0.1°
General
Operating temperature –10°Cto+45°CE)
Storage temperature –20°Cto+70°C
Relative air humidity max. 90%
Max. altitude 2000m
Pollution degree according to IEC61010-1 2F)
Laser class 2
Laser type 515nm, <1mW
Divergence of the laser beam <1.5mrad (full angle)
Automatic switch-off after approx.
– Laser 20s
– Measuring tool (without measurement) 5minsG)
Weight according to EPTA-Procedure01:2014 0.17kg
Dimensions 119x53x29 mm
1 609 92A 5YM | (19.01.2021) Bosch Power Tools

English | 17
Digital laser measure GLM 50-27 CG
Protection rating IP65 (protection against
dust ingress and water jets)
Batteries 2 x 1.5 V LR6 (AA)
Unit of measurement setting m, ft, in
Data transfer
Bluetooth® Bluetooth®
(4.2 low-energy)H)
Operating frequency band 2402–2480MHz
Max. transmission power 8mW
A) For measurements from the front edge of the measuring tool, this applies for high reflectivity of
the target (e.g. a white-painted wall), weak backlighting and 25°C operating temperature. In ad-
dition, a deviation of ±0.05mm/m must be taken into account, depending on the distance.
B) For measurements from the front edge of the measuring tool, this applies for high reflectivity of
the target (e.g. a white-painted wall), strong backlighting and 25°C operating temperature. In
addition, a deviation of ±0.15mm/m must be taken into account, depending on the distance.
C) After user calibration at 0 ° and 90 °; An additional grade error of ±0.01 °/degree to 45 ° (max.)
has to be taken into account. The left-hand side of the measuring tool serves as the reference
level for grade measurement.
D) At an operating temperature of 25 °C
E) In continuous measurement mode, the max. operating temperature is +40 °C.
F) Only non-conductive deposits occur, whereby occasional temporary conductivity caused by
condensation is expected.
G) Bluetooth® deactivated
H) When using Bluetooth® Low Energy devices, it may not be possible to establish a connection de-
pending on the model and operating system. Bluetooth® tools must support the GATT profile.
The serial number (11) on the type plate is used to clearly identify your measuring tool.
Bluetooth® interface
Transmitting data to other devices
The measuring tool is fitted with a Bluetooth® module which enables wireless data trans-
fer to certain mobile devices with a Bluetooth® interface (e.g. smartphone, tablet).
Information about the system requirements for a Bluetooth® connection can be found on
the Bosch website at www.bosch‑pt.com
uFurther information can be found on the Bosch product page.
Bosch Power Tools 1 609 92A 5YM | (19.01.2021)

18 | English
When transmitting data by means of Bluetooth®, time lags may occur between the mobile
device and the measuring tool. This can be due to the distance between the two devices
or the measurement object itself.
Activating the Bluetooth® interface for transmitting data to a mobile device
Ensure that the Bluetooth® interface is activated on your mobile device.
Press the(1) button to bring up the Bluetooth® menu and press the(1) button again (or
the (6) [+] button), to activate the Bluetooth® interface. If multiple active measuring
tools are found, select the appropriate measuring tool using the serial number. You can
find the serial number(11) on your measuring tool's type plate. The connection status
and the active connection(b) are displayed in the status bar(h) of the measuring tool.
Bosch applications are available to expand the range of functions. Depending on the
device, you can download these applications from the corresponding app stores.
Deactivating the Bluetooth® interface
Press the(1) button to bring up the Bluetooth® menu and press the(1) button again (or
the (3) [–] button), to deactivate the Bluetooth® interface.
Assembly
Inserting/changing the batteries
Using alkali-manganese or nickel metal hydride rechargeable batteries (especially at low
operating temperatures) is recommended for operation of the measuring tool.
With 1.2 V batteries, more measurements may be possible than with 1.5 V batteries, de-
pending on the capacity.
Press the locking mechanism (12) to open the battery compartment cover (13) and re-
move the battery compartment cover. Insert the batteries. When inserting, pay attention
to the correct polarity according to the representation on the inside of the battery com-
partment.
When the state of charge of the batteries or reusable batteries is low, a request to activ-
ate the battery saver mode will appear on the display. When the battery saver mode is
activated, the battery runtime will be extended and the battery symbol on the display will
have a yellow outline(see "“Settings” menu (see figure B)", page20).
When the empty battery symbol first appears on the display, only a limited number of
measurements is still possible. When the battery symbol is empty and flashes red, no fur-
ther measurements are possible. Replace the batteries or reusable batteries.
Always replace all the batteries at the same time. Only use batteries from the same man-
ufacturer and which have the same capacity.
1 609 92A 5YM | (19.01.2021) Bosch Power Tools

English | 19
uTake the batteries out of the measuring tool when you are not using it for a pro-
longed period of time. The batteries can corrode and self-discharge during pro-
longed storage.
Operation
Start-Up
uNever leave the measuring tool unattended when switched on, and ensure the
measuring tool is switched off after use. Others may be dazzled by the laser beam.
uProtect the measuring tool from moisture and direct sunlight.
uDo not expose the measuring tool to any extreme temperatures or variations in
temperature. For example, do not leave it in a car for extended periods of time. In
case of large variations in temperature, allow the measuring tool to adjust to the ambi-
ent temperature before putting it into operation. The precision of the measuring tool
may be compromised if exposed to extreme temperatures or variations in temperat-
ure.
uAvoid substantial knocks to the measuring tool and avoid dropping it. Always
carry out an accuracy check before continuing work if the measuring tool has been
subjected to severe external influences (see "Checking accuracy and calibrating the
grade measurement (see figureL)", page28) and (see "checking accuracy of the
distance measurement", page29).
uThe measuring tool is equipped with a wireless interface. Local operating restric-
tions, e.g. in aeroplanes or hospitals, must be observed.
Switching on/off
– To switch on the measuring tool and the laser, briefly press the measuring button(5)
[ ].
– To switch on the measuring tool without the laser, briefly press the on/off/back
button(8) [ ].
uDo not direct the laser beam at persons or animals and do not stare into the laser
beam yourself (even from a distance).
When switching on the measuring tool for the first time, you will be prompted to set your
preferred language for the display text.
To switch off the measuring tool, press and hold the on/off/back button(8) [ ].
The measured values and device settings in the memory are retained when you switch off
the measuring tool.
Bosch Power Tools 1 609 92A 5YM | (19.01.2021)

20 | English
Measuring process
When switching on for the first time, the measuring tool will be in the length measure-
ment function. When switching on every subsequent time, the measuring tool will be in
the measuring function that was last used. For a different measuring function, press the
(2) [Func] button. Use the (6) [+] button or the (3) [–] button to select the required
measuring function Measuring Functions. Activate the measuring function with the (2)
[Func] button or with the measuring button(5) [ ].
There are three settings available for the reference level for measurement (see "Selecting
the reference level (see figureA)", page20).
Apply the measuring tool to the point at which you want to start the measurement (e.g.
wall).
Note: If the measuring tool has been switched on using the on/off/back button(8) [ ],
briefly press the measuring button(5) [ ] to switch the laser on.
To initiate the measurement, briefly press the measuring button(5) [ ]. The laser beam
will then switch off. For a further measurement, repeat this process.
uDo not direct the laser beam at persons or animals and do not stare into the laser
beam yourself (even from a distance).
Note: The measured value typically appears within half a second, and no later than ap-
proximately four seconds. The duration of the measurement depends on the distance,
the lighting conditions and the reflective properties of the target surface. Upon comple-
tion of the measurement, the laser beam will automatically switch off.
Selecting the reference level (see figureA)
You can choose between three different reference levels for the measurement:
– The rear edge of the measuring tool (e.g. when placing against walls)
– The front edge of the measuring tool (e.g. when measuring from a table edge)
– The centre of the thread(14) (e.g. for tripod measurements)
To select the reference level, press the (7) [ ] button. Then select the “Reference level”
setting with the measuring button(5) [ ] or the (2) [Func] button. Then use the (6) [+]
button or the (3) [–] button to select the required reference level. Every time the meas-
uring tool is switched on, the last selected reference level is preset.
“Settings” menu (see figure B)
Press the(7) [ ] button to access the “Settings” menu(j).
Use the (6) [+] button or the (3) [–] button to select the required setting and confirm
this by pressing the measuring button (5) [ ] or the (2) [Func] button.
1 609 92A 5YM | (19.01.2021) Bosch Power Tools
