Bosch LR 1 Professional User manual

Robert Bosch GmbH
Power Tools Division
70745 Leinfelden-Echterdingen
Germany
www.bosch-pt.com
2 610 A12 917 (2010.01) T / 379 XXX
LR Professional
1 | 1 G
OBJ_BUCH-780-003.book Page 1 Tuesday, January 19, 2010 11:13 AM

2 610 A12 917 | (19.1.10) Bosch Power Tools
4|
45mm
1
3
/
4
inch
45mm
1
3
/
4
inch
45 mm
1
3
/
4
inch
45 mm
1
3
/
4
inch
1
2
3
12
11
10
9
5
6
7
8
LR 1/LR 1 G
Professional
5
7
5
4
e
f
g
b
a
c
d
OBJ_BUCH-780-003.book Page 4 Tuesday, January 19, 2010 10:56 AM

2 610 A12 917 | (19.1.10) Bosch Power Tools
5|
45mm
1
3
/
4
inch
45mm
1
3
/
4
inch
45 mm
1
3
/
4
inch
45 mm
1
3
/
4
inch
13
14 15
12
16
17
B
A
OBJ_BUCH-780-003.book Page 5 Tuesday, January 19, 2010 10:56 AM

English | 19
Bosch Power Tools 2 610 A12 917 | (19.1.10)
en
Safety Notes
Read and observe all instructions. SAVE THESE IN-
STRUCTIONS FOR FUTURE REFERENCE.
Keep the measuring tool away from cardiac pace-
makers. The magnet plate 4generates a field that
can impair the function of cardiac pacemakers.
fKeep the measuring tool away from magnetic data medium
and magnetically-sensitive equipment. The effect of the mag-
net plate 4can lead to irreversible data loss.
fHave the measuring tool repaired only through qualified spe-
cialists using original spare parts. This ensures that the safety
of the measuring tool is maintained.
fDo not operate the measuring tool in explosive environments,
such as in the presence of flammable liquids, gases or dusts.
Sparks can be created in the measuring tool which may ignite
the dust or fumes.
fRead and strictly observe the safety warnings in the operating
instructions of the rotational laser.
OBJ_BUCH-780-003.book Page 19 Tuesday, January 19, 2010 10:56 AM

2 610 A12 917 | (19.1.10) Bosch Power Tools
20 | English
Functional Description
Please unfold the fold-out page with the representation of the
measuring tool and leave it unfolded while reading the operating
instructions.
Intended Use
The measuring tool is intended for swift finding of rotating laser
beams in the wavelength listed in the “Technical Data”.
The measuring tool is suitable for indoor and outdoor use.
OBJ_BUCH-780-003.book Page 20 Tuesday, January 19, 2010 10:56 AM

English | 21
Bosch Power Tools 2 610 A12 917 | (19.1.10)
Product Features
The numbering of the product features shown refers to the illustra-
tion of the measuring tool on the graphic page.
1On/Off button
2Button for adjustment of the measuring accuracy
3Audio signal button
4Magnet plate
5Centre mark
6Reception area for the laser beam
7Display
8Laser receiver spirit level
9Latch of battery lid
10 Serial number
11 Battery lid
12 Retainer openings for holder
13 Locking screw for holder
14 Holder upper edge
15 Construction laser measuring rod*
16 Fastening screw of holder
17 Holder
* The accessories illustrated or described are not included as standard de-
livery.
Display Elements
aDirection indicator, down
b“Medium” adjustment indicator
cBattery indicator
dDirection indicator, up
eAudio signal indicator
fCentre indicator
g“Fine” adjustment indicator
OBJ_BUCH-780-003.book Page 21 Tuesday, January 19, 2010 10:56 AM

2 610 A12 917 | (19.1.10) Bosch Power Tools
22 | English
Technical Data
Laser Receiver LR 1
Professional
Article number 3 601 K15 400
Receivable wavelength 635–650 nm
Suitable for rotational laser level GRL 250 HV,
GRL 300 HV,
GRL 400 H
Please observe the article number on the type plate of your measuring tool.
The trade names of the individual measuring tools may vary.
The measuring tool can be clearly identified with the serial number 10 on the
type plate.
Laser Receiver LR 1 G
Professional
Article number 3 601 K69 700
Receivable wavelength 532–535 nm
Suitable for rotational laser level GRL 300 HVG
Please observe the article number on the type plate of your measuring tool.
The trade names of the individual measuring tools may vary.
The measuring tool can be clearly identified with the serial number 10 on the
type plate.
OBJ_BUCH-780-003.book Page 22 Tuesday, January 19, 2010 10:56 AM

English | 23
Bosch Power Tools 2 610 A12 917 | (19.1.10)
LR 1/LR 1 G
Working range1) with rotational
laser level:
–GRL250HV
– GRL 300 HV/HVG
–GRL400H
125 m
150 m
200 m
Receiving angle 120°
Receivable rotation speed >200 min-1
Measuring accuracy2)
– “Fine” adjustment
– “Medium” adjustment
±1mm
±3mm
Operating temperature – 10 °C ... +50 °C
Storage temperature – 20 °C ... +70 °C
Battery 1x9V6LR61
Operating life time, approx. 50 h
Weight according to
EPTA-Procedure 01/2003 0.36 kg
Dimensions 148 x 73 x 30 mm
Degree of protection IP 65 (dust-proof and
protected against powerful
water jets)
1) The working range (radius) can be reduced due to unfavourable ambient
conditions (e.g. direct sunlight).
2) depends on clearance between laser receiver and rotational laser level
OBJ_BUCH-780-003.book Page 23 Tuesday, January 19, 2010 10:56 AM

2 610 A12 917 | (19.1.10) Bosch Power Tools
24 | English
Assembly
Inserting/Replacing the Battery
Alkali-manganese batteries are recommended for the measuring tool.
Press the latch 9of the battery lid outward and open the battery
lid 11.
When inserting the battery, pay attention to the correct polarity ac-
cording to the representation on the inside of the battery compart-
ment.
When the battery indication cappears for the first time on the dis-
play 7, the measuring tool can still be operated for approx. 3 h.
fIf the measuring tool is not used for a long period of time, the
battery must be removed. The battery can corrode or discharge
itself over long periods.
Operation
Initial Operation
fProtect the measuring tool against moisture and direct sun
light.
fDo not subject the measuring tool to extreme temperatures or
variations in temperature. As an example, do not leave it in ve-
hicles for longer periods. In case of large variations in tempera-
ture, allow the measuring tool to adjust to the ambient temper-
ature before putting it into operation. In case of extreme
temperatures or variations in temperature, the accuracy of the
measuring tool can be impaired.
Position the measuring tool at least 50 cm away from the rotational
laser level. Position the measuring tool in such a manner that the
laser beam can reach the reception area 6. Set the highest rotation-
al speed on the rotational laser level.
OBJ_BUCH-780-003.book Page 24 Tuesday, January 19, 2010 10:56 AM

English | 25
Bosch Power Tools 2 610 A12 917 | (19.1.10)
Switching On and Off
fA loud audio signal sounds when switching on the measuring
tool. “The A-weighted sound pressure level of the audio signal
at a distance of one meter is 95 dB(A).”
fDo not hold the measuring tool close to your ear! The loud au-
dio signal can cause hearing defects.
To switch on the measuring tool, press the On/Off button 1. Two
audio signals sound and all display indicators light up briefly.
To switch off the measuring tool, press the On/Off button 1again.
When no button is pressed on the measuring tool for approx.
10 minutes and when no laser beam reaches the reception area 6
for 10 minutes, the measuring tool automatically switches off in or-
der to save the battery. The switching off is indicated by an audio
signal.
Selecting the Setting of the Centre Indicator
With button 2, you can specify with which accuracy the position of
the laser beam is indicated as central on the reception area:
– “Fine” adjustment, (indication gon the display),
– “Medium” adjustment, (indication bon the display).
An audio signal sounds when the accuracy setting is changed.
Whenever switching on the measuring tool, the accuracy level “me-
dium” is set.
OBJ_BUCH-780-003.book Page 25 Tuesday, January 19, 2010 10:56 AM

2 610 A12 917 | (19.1.10) Bosch Power Tools
26 | English
Direction Indicators
The bottom a, centre fand top dindicators (both on the front and
rear side of the measuring tool) indicate the position of the rotat-
ing laser beam in the reception area 6. Additionally, the position
can be indicated with an audio signal (see “Audio Signal for Indica-
tion of the Laser Beam”, page 27).
Measuring tool too low: When the laser beam runs through the top
half of the reception area 6, the bottom direction indicator aap-
pears on the display.
When the audio signal is switched on, a slow-beat signal sounds.
Move the measuring tool upward in the direction of the arrow.
When approaching the centre mark 5, only the tip of the direction
indicator ais indicated.
Measuring tool too high: When the laser beam runs through the
bottom half of the reception area 6, the top direction indicator d
appears on the display.
When the audio signal is switched on, a fast-beat signal sounds.
Move the measuring tool downward in the direction of the arrow.
When approaching the centre mark 5, only the tip of the direction
indicator dis indicated.
Measuring tool in centre position: When the laser beam runs
through the reception area 6at the centre mark 5, the centre indi-
cator flights up. When the audio signal is switched on, a continu-
ous signal sounds.
OBJ_BUCH-780-003.book Page 26 Tuesday, January 19, 2010 10:56 AM

English | 27
Bosch Power Tools 2 610 A12 917 | (19.1.10)
Audio Signal for Indication of the Laser Beam
The position of the laser beam on the reception area 6can be indi-
cated via an audio signal.
After the measuring tool has been switched on, the audio signal is
always switched off.
When switching on the audio signal, you can choose between two
volume levels.
To switch on the audio signal or change the volume level, push the
acoustic signal button 3until the requested volume level is indicat-
ed. At medium volume level, the audio signal indicator ein the dis-
play flashes; at high volume level, the indicator is continuously lit.
When the audio signal is set to off, the indicator goes out.
Working Advice
Marking
When the laser beam runs through the center of the reception area
6, its height can be marked at the centre mark 5right and left on
the measuring tool. The centre mark is located 45 mm away from
the top edge of the measuring tool.
Aligning with the Spirit Level
The measuring tool can be aligned vertically (plumb line) with the
spirit level 8. A measuring tool applied out-of-level leads to faulty
measurements.
OBJ_BUCH-780-003.book Page 27 Tuesday, January 19, 2010 10:56 AM

2 610 A12 917 | (19.1.10) Bosch Power Tools
28 | English
Attaching with the Holder (see figure A)
With the holder 17, the measuring tool can be fastened to a con-
struction laser measuring rod 15 (accessory) as well as to other
auxiliary tools with a width of up to 65 mm.
Screw the holder 17 to the retainer opening 12 on the rear side of
the measuring tool with fastening screw 16.
Loosen the locking screw 13, slide the holder onto the construc-
tion laser measuring rod 15, for example, and retighten the locking
screw 13.
The upper edge 14 of the holder is located at the same height as
the centre mark 5and can be used for marking of the laser beam.
Attaching with the Magnet (see figure B)
When a positive-lock attachment is not absolutely required, the
measuring tool can be attached to steel parts via the face side us-
ing the magnet plate 4.
Maintenance and Service
Maintenance and Cleaning
Keep the measuring tool clean at all times.
Do not immerse the measuring tool in water or other fluids.
Wipe off debris using a moist and soft cloth. Do not use any clean-
ing agents or solvents.
If the measuring tool should fail despite the care taken in manufac-
turing and testing procedures, repair should be carried out by an
authorised after-sales service centre for Bosch power tools. Do not
open the measuring tool yourself.
In all correspondence and spare parts orders, please always in-
clude the 10-digit article number given on the type plate of the
measuring tool.
OBJ_BUCH-780-003.book Page 28 Tuesday, January 19, 2010 10:56 AM

English | 29
Bosch Power Tools 2 610 A12 917 | (19.1.10)
After-sales Service and Customer Assistance
Our after-sales service responds to your questions concerning main-
tenance and repair of your product as well as spare parts. Exploded
views and information on spare parts can also be found under:
www.bosch-pt.com
Our customer service representatives can answer your questions
concerning possible applications and adjustment of products and
accessories.
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: [phone]
Fax: [phone]
E-Mail: [email protected]
Ireland
Origo Ltd.
Unit 23 Magna Drive
Magna Business Park
City West
Dublin 24
Tel. Service: [phone]
Fax: [phone]
OBJ_BUCH-780-003.book Page 29 Tuesday, January 19, 2010 10:56 AM

2 610 A12 917 | (19.1.10) Bosch Power Tools
30 | English
Australia, New Zealand and Pacific Islands
Robert Bosch Australia Pty. Ltd.
Power Tools
Locked Bag 66
Clayton South VIC 3169
Customer Contact Center
Inside Australia:
Phone: [phone]
Fax: [phone]
Inside New Zealand:
Phone: [phone]
Fax: [phone]
Outside AU and NZ:
Phone: [phone]
www.bosch.com.au
Republic of South Africa
Customer service
Hotline: [phone]
Gauteng – BSC Service Centre
35 Roper Street, New Centre
Johannesburg
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
KZN – BSC Service Centre
Unit E, Almar Centre
143 Crompton Street
Pinetown
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
OBJ_BUCH-780-003.book Page 30 Tuesday, January 19, 2010 10:56 AM

English | 31
Bosch Power Tools 2 610 A12 917 | (19.1.10)
Western Cape – BSC Service Centre
Democracy Way, Prosperity Park
Milnerton
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Bosch Headquarters
Midrand, Gauteng
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
People’s Republic of China
Website: www.bosch-pt.com.cn
China Mainland
Bosch Power Tools (China) Co., Ltd.
567, Bin Kang Road
Bin Jiang District 310052
Hangzhou, P.R.China
Service Hotline: [phone]
Tel.: [phone]
Fax: [phone]
HK and Macau Special Administrative Regions
Robert Bosch Hong Kong Co. Ltd.
21st Floor, 625 King’s Road
North Point, Hong Kong
Customer Service Hotline: [phone]
Fax: [phone]
E-Mail: [email protected]
www.bosch-pt.com.cn
OBJ_BUCH-780-003.book Page 31 Tuesday, January 19, 2010 10:56 AM

2 610 A12 917 | (19.1.10) Bosch Power Tools
32 | English
Indonesia
PT. Multi Tehaka
Kawasan Industri Pulogadung
Jalan Rawa Gelam III No. 2
Jakarta 13930
Indonesia
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
www.multitehaka.co.id
Philippines
Robert Bosch, Inc.
Zuellig Building
Sen. Gil Puyat Avenue
Makati City 1200, Metro Manila
Philippines
Tel.: [phone]
www.bosch.com.ph
Malaysia
Robert Bosch (SEA.) Pte. Ltd.
No. 8a, Jalan 13/6
46200 Petaling Jaya,
Selangor,
Malaysia
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Toll Free Tel.: [phone]
Fax: [phone]
www.bosch.com.sg
OBJ_BUCH-780-003.book Page 32 Tuesday, January 19, 2010 10:56 AM

English | 33
Bosch Power Tools 2 610 A12 917 | (19.1.10)
Thailand
Robert Bosch Ltd.
Liberty Square Building
No. 287, 11 Floor
Silom Road, Bangrak
Bangkok 10500
Tel.: [phone] – 18 88 (10 lines)
Fax: [phone]
Robert Bosch Ltd., P. O. Box 2054
Bangkok 10501, Thailand
Bosch Service – Training Centre
2869-2869/1 Soi Ban Kluay
Rama IV Road (near old Paknam Railway)
Prakanong District
10110 Bangkok
Thailand
Tel.: [phone] – 4
Fax: [phone]
Fax: [phone]
Singapore
Robert Bosch (SEA.) Pte. Ltd.
38 C Jalan Pemimpin
Singapore 915701
Republic of Singapore
Tel.: [phone]
Fax: [phone]
www.bosch.com.sg
OBJ_BUCH-780-003.book Page 33 Tuesday, January 19, 2010 10:56 AM

2 610 A12 917 | (19.1.10) Bosch Power Tools
34 | English
Vietnam
Robert Bosch (SEA) Pte. Ltd – Vietnam
Representative Office
Saigon Trade Center, Suite 1206
37 Ton Duc Thang Street,
Ben Nghe Ward, District 1
HCMC
Vietnam
Tel.: [phone]
Fax: [phone]
Disposal
Measuring tools, accessories and packaging should be sorted for
environmental-friendly recycling.
Only for EC countries:
Do not dispose of measuring tools into household
waste!
According the European Guideline 2002/96/EC for
Waste Electrical and Electronic Equipment and its
implementation into national right, measuring tools
that are no longer usable must be collected separate-
ly and disposed of in an environmentally correct
manner.
OBJ_BUCH-780-003.book Page 34 Tuesday, January 19, 2010 10:56 AM

English | 35
Bosch Power Tools 2 610 A12 917 | (19.1.10)
Battery packs/batteries:
Do not dispose of battery packs/batteries into household waste,
fire or water. Battery packs/batteries should, if possible, be dis-
charged, collected, recycled or disposed of in an environmental-
friendly manner.
Only for EC countries:
Defective or dead out battery packs/batteries must be recycled ac-
cording the guideline 2006/66/EC.
Batteries no longer suitable for use can be directly returned at:
Great Britain
Robert Bosch Ltd. (B.S.C.)
P.O. Box 98
Broadwater Park
North Orbital Road
Denham
Uxbridge
UB 9 5HJ
Tel. Service: [phone]
Fax: [phone]
E-Mail: [email protected]
Subject to change without notice.
OBJ_BUCH-780-003.book Page 35 Tuesday, January 19, 2010 10:56 AM
