Bosch Professional Series User manual

Professional Series TriTech AM Motion
Detectors with Anti‑mask, LSN
en Reference Manual

Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN Table of contents | en 3
Bosch Building Technologies Reference Manual 2018.10 | 01 | F.01U.352.414
Table of contents
1Safety 4
2Introduction 5
2.1 About documentation 5
2.2 Bosch Security Systems, Inc. product manufacturing dates 5
3Detector overview 6
4Installation considerations 7
5Installation 9
5.1 Self-locking cam 9
5.2 Install options 10
5.3 Wire knockouts 13
5.4 Bubble level 14
6Wiring 16
7Look-down and walk test 17
7.1 Look-down zone 17
7.2 Walk test LED 17
8Configuration 19
8.1 Classic/LSNi mode 19
8.1.1 Classic mode 19
8.1.2 LSNi mode 20
8.2 Detection range 20
8.3 Anti-mask 21
8.4 Walk test 23
8.4.1 Establish the PIR and microwave doppler radar coverage 23
8.4.2 Establish the coverage pattern 24
8.4.3 Adjustable microwave doppler radar sensitivity 24
8.5 Self test 25
9Troubleshooting 26
9.1 Detector does not appear to respond to motion 26
9.2 Detector is in continuous alarm 26
9.3 Detector appears normal but does not send alarms to the control panel 26
9.4 Detector does not appear to detect motion in the space directly under it 26
9.5 Detector does not appear to detect motion in farthest coverage area 26
9.6 Detector LED flashes continuously 26
9.7 Detector LED flashes three times in a row repeatedly 27
9.8 Detector LED flashes four times in a row repeatedly 27
9.9 Detector LED flashes five times in a row repeatedly 27
9.10 Detector does not detect motion near the edge of the coverage area 27
10 Appendix 28

4en | Safety Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN
2018.10 | 01 | F.01U.352.414 Reference Manual Bosch Building Technologies
1 Safety
Changes or modifications not expressly approved by Bosch Security Systems, Inc. can void the
user’s authority to operate the equipment.
At least once per year, vary the range and coverage. To ensure continual daily operation,
instruct the end user to walk through the far end of the coverage pattern. This ensures an
alarm output prior to arming the system.
Old electrical and electronic appliances
Electrical or electronic devices that are no longer serviceable must be collected separately and
sent for environmentally compatible recycling (in accordance with the European Waste
Electrical and Electronic Equipment Directive).
To dispose of old electrical or electronic devices, you should use the return and collection
systems put in place in the country concerned.
ROHS
For use in China: CHINA ROHS DISCLOSURE TABLE
Sensors
Hazardous substance table according to SJ/T 11364-2014
Pb
(Pb)
Hg
(Hg)
Cd
(Cd)
Cr 6+
(Cr 6+)
PBB
(PBB)
PBDE
(PBDE)
PCB X O O O O O
Electronic components X O X X O O
PCBA X O X O X X
Cables X O X O X X
Plastic materials O O O O X X
Metal materials X O X X O O
Glass material (lenses) X O O O O O
Terminal block X O X X O O
This table was created according to the provisions of SJ/T 11364
O: The content of such hazardous substance in all homogeneous materials of such
component is below the limit defined in GB/T 26572
X: The content of such hazardous substance in a certain homogeneous material is above the
limit defined in GB/T 26572
The manufacturing datecodes of the products are explained in:
http://www.boschsecurity.com/datecodes/

Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN Introduction | en 5
Bosch Building Technologies Reference Manual 2018.10 | 01 | F.01U.352.414
2 Introduction
This document provides install-related information for Professional Series LSN detectors.
2.1 About documentation
Copyright
This document is the intellectual property of Bosch Security Systems, Inc. and is protected by
copyright. All rights reserved.
Trademarks
All hardware and software product names used in this document are likely to be registered
trademarks and must be treated accordingly.
Notifications
This document uses Notices, Cautions, and Warnings to draw your attention to important
information.
Notice!
These include important notes for successful operation and programming of equipment, or
indicate a risk of damage to the equipment or environment.
!
Caution!
These indicate a hazardous situation which, if not avoided, could result in minor or moderate
injury.
!
Warning!
These indicate a hazardous situation which, if not avoided, could result in death or serious
injury.
2.2 Bosch Security Systems, Inc. product manufacturing dates
Use the serial number located on the product label and refer to the Bosch Security Systems,
Inc. website at http://www.boschsecurity.com/datecodes/.
The following image shows an example of a product label and highlights where to find the
manufacturing date within the serial number.

6en | Detector overview Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN
2018.10 | 01 | F.01U.352.414 Reference Manual Bosch Building Technologies
3 Detector overview
6
1
2
3
4
5
7
LSNi
CL
XX X
2
1
0
9
3
4
5
6
7
8
2
1
0
9
3
4
5
6
7
88
9
Callout — Description Callout — Description
1 — Terminal block 6 — LSN address switches
2 — Wall Tamper 7 — LSN address 1 switch (not used)*
3 — Removable bubble level 8 — LSN address 2 switch (not used)*
4 — Self-locking cam lock 9 — Look-down zone On/Off switch*
5 — Microwave Doppler radar range
adjustment
*T-tapping is not supported by the bus.
Notice!
Location and number of features and configuration switches varies by model.

Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN Installation considerations | en 7
Bosch Building Technologies Reference Manual 2018.10 | 01 | F.01U.352.414
4 Installation considerations
When installing the detector, observe the following installation considerations.
Notice!
Bracket use
Using a mounting bracket might reduce catch performance, range, as well as increase false
alarms. Reduced catch performance might invalidate regulatory certification on the
installation. The use of mounting brackets has not been evaluated by regulatory agencies.
Microwave Doppler radar energy passes through glass and most common non-metallic walls.
The PIR detector reacts to objects rapidly changing temperature within its field-of-view.
Detectors using passive infrared (PIR) technology recognize that all objects give off (emit)
infrared energy. The warmer an object is, the greater the amount of infrared energy is emitted.
The PIR receiver technology is designed to detect the change in infrared energy caused when
a target of a different temperature from a stable background passes through its field of view
(coverage pattern).
Point the detector away from:
Glass exposed to the outdoors.
Objects that might change temperature rapidly such as heat sources, air
conditioning outlets, or surfaces heated by sunlight.
Objects that small animals such as birds and mice might climb on (stairs,
shelves, ledges, furniture) and appear in the upper zones of the PIR which
are more sensitive. Small animals in close proximity to the detector,
within the field of view might, also cause false alarms.
Do not install:
In a location where direct sunlight shines onto the detector.
Outdoors.
Near rotating machines or other moving objects within the field of view.

8en | Installation considerations Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN
2018.10 | 01 | F.01U.352.414 Reference Manual Bosch Building Technologies
Do not install:
Near objects that can block the field of view.
Where an intruder would walk only directly toward or away from the
detector.
In a location where the detector’s field of view is blocked by movable
objects such as boxes, furniture, doors or windows, window coverings,
hanging signs, etc. The PIR detector does not detect through glass.
Near doors and windows or other openings where cold or warm air can
flow onto the detector.

Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN Installation | en 9
Bosch Building Technologies Reference Manual 2018.10 | 01 | F.01U.352.414
5 Installation
This section includes hardware details and the instructions you need to install the motion
detector base.
5.1 Self-locking cam
The detector includes a self-locking cam for easy installation. Refer to the following
information to open and close the detector.
Open the detector and remove the base
1. Insert a flathead screwdriver into the self-locking cam hole.
2. Turn to the unlock position.
3. Slide, then lift the detector from the base.
1 2 3
Attach the detector back onto the base
Notice!
When you remove the detector from the base, the cam automatically returns to the locked
position. When you place the detector onto the base, the cam must remain in locked position.
Do not manually change the cam once you remove the detector from the base; doing so
unlocks the detector and prevents you from putting the detector correctly onto to base.
1. Put detector onto the base.
2. Slide the detector up until you hear it "click."

10 en | Installation Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN
2018.10 | 01 | F.01U.352.414 Reference Manual Bosch Building Technologies
5.2 Install options
Install the detector using the detector base.
Install the detector on a flat wall or in a corner. Refer to Mount directly –
for linking.
Install the detector using a bracket. Refer to Install on a bracket, page 11.
Detector coverage patterns are designed for optimal performance when
installed vertically and horizontally level. The detector base includes a
removable bubble level which helps you align the unit. Before drilling the
installation holes, use the bubble level to align the detector. Refer to
Bubble level, page 14.
Install directly to the surface
When installing onto a flat surface, select the installation holes shown in the figure. Drill or tap
out holes with a screwdriver.
To use the wall tamper feature, use one of the installation holes shown in red in the following
figure.

Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN Installation | en 11
Bosch Building Technologies Reference Manual 2018.10 | 01 | F.01U.352.414
Install on a bracket
Mounting brackets help align the detector to a vertical angle and to correct imperfections
(non-perpendicular angles) of installation surfaces.
Choosing a mounting bracket:
– The B335 bracket allows a vertical pivot range of +10º to -20º and a horizontal pivot
range of ±25º.
– The B328 bracket installs on a single-gang box and allows rotation of the detector. The
bracket allows you to insert the wiring through the black tube section in the center of the
bracket mounting plate and through the back of the detector base.
– The B338 bracket designed for ceiling mounting allows a vertical pivot range of +7º to
-16º and a horizontal pivot of ±45º. The bracket allows you to insert the wiring through
the ceiling cavity and into the detector base.
When using a mounting bracket, pre-drill or tap out all of the mounting holes shown for that
bracket in the following figure.

12 en | Installation Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN
2018.10 | 01 | F.01U.352.414 Reference Manual Bosch Building Technologies
=
B328 B338
B335
Notice!
Using a mounting bracket might reduce catch performance and range, as well as increase
false alarms.
Always install the detector within the recommended installation height, with or without a
mounting bracket.
The use of mounting brackets has not been evaluated by regulatory agencies.

Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN Installation | en 13
Bosch Building Technologies Reference Manual 2018.10 | 01 | F.01U.352.414
Notice!
Do not use the bracket to tip the detector vertically unless you intend to compensate for a
non-vertical surface. It might cause false alarms or reduced catch performance.
5.3 Wire knockouts
Use the figure to determine the knockouts to use for installation locations.
1
2
3
4
Callout ᅳ Description
1 ᅳ Surface wiring knockout, detector’s left side
2 ᅳ Through-the-wall wiring knockout
3 ᅳ Surface wiring knockout, detector’s right side
4 ᅳ Through-B328-bracket wiring knockout*
* If you use the bracket mount knockout for wires, run the wires between the walls marked
in red in the figure. With the wiring between the walls and behind the terminal block, other
features, such as EOL resistor jumper pins, cannot interfere with or puncture the wires.

14 en | Installation Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN
2018.10 | 01 | F.01U.352.414 Reference Manual Bosch Building Technologies
5.4 Bubble level
The detector’s coverage pattern performs best when the detector is installed vertically and is
level both vertically and horizontally. The detector base includes a removable bubble level
which helps you align the unit. Use the bubble level to align the detector before drilling holes.
4Put the detector base on the surface and install it in place using one screw only. Do not
over-tighten the screw.
4Make sure the base is level from side to side.
4Remove the bubble level and place it into the round cavity on the right side of the base.
Make sure the base is level and not tipped forwards or back.
4Make adjustments until the base is level, and mark the remaining surface hole locations.
4Remove the bubble level and place it back to its original position.

Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN Installation | en 15
Bosch Building Technologies Reference Manual 2018.10 | 01 | F.01U.352.414
Notice!
Do not leave the bubble level in the circular holder. You cannot properly place the detector
body onto the mounting base with the bubble level in the circular holder.
Do not use a bracket to tip the detector in any direction as it might cause false alarms or
reduced catch performance.
4Install the remaining screws.

16 en | Wiring Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN
2018.10 | 01 | F.01U.352.414 Reference Manual Bosch Building Technologies
6 Wiring
!
Caution!
Apply power only after you have made and inspected all connections. Do not coil excess
wiring inside the motion detector.
Refer to the wiring illustration for LSN wiring.
A1 B1 A2 B2 SP SP SH
LSN
LSN
A1 = aLSN1
B1 = bLSN1
A2 = aLSN2
B2 = bLSN2
SH =
Specification recommendations
– LSN Bus operating voltage limits are 9-29 V.
– Use no smaller than 0.4 mm (26 AWG) wire.
– Shielded cable is recommended.
Notice!
For all components and connections, only shielded cables are permitted.

Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN Look-down and walk test | en 17
Bosch Building Technologies Reference Manual 2018.10 | 01 | F.01U.352.414
7 Look-down and walk test
7.1 Look-down zone
The detector has a manual cam to enable or disable the look-down zone. Enable the look-
down zone to detect motion under the detector area.
To reduce false alarms, disable the look-down lens for locations where small animals are likely
to cross the look-down zone.
Turn left to disable the look-down zone. Turn right to enable the look-down zone.
7.2 Walk test LED
The walk test LED indicates the detector's operational status.
2 min
During the warm-up period (after providing power to the
device), the LED flashes continuously until the device is
ready for use.
During walk test, the LED indicates PIR and microwave
activity activity and also a motion alarm condition (dual
alarm).
If the detector is in a self test fault condition, the LED
flashes 4 times repeatedly.

18 en | Look-down and walk test Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN
2018.10 | 01 | F.01U.352.414 Reference Manual Bosch Building Technologies
If the detector is in a low power supply fault condition, the
LED flashes 5 times repeatedly.
Notice!
Some regulations require that you disable the LED after the walk test.

Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN Configuration | en 19
Bosch Building Technologies Reference Manual 2018.10 | 01 | F.01U.352.414
8 Configuration
Selecting the detector configuration setups are done using the control panel's supported
remote programming software. The remote programming software allows you to enable or
disable the configuration setups by selecting the appropriate menu options within the
software.
Accessing through MAP RPS
1. Launch MAP 5000 RPS program.
2. Open Hardware Manager.
3. Expand Internal BDB menu tree.
4. Expand [LSN GW 1] menu tree.
5. Find Dual PIR option under Toolbox.
6. Click and drag [LSNPro/PDL1-WA18x/WAC25x LSN from Toolbox to the LSN loop box.
7. Right-click, and select Properties.
8. Scroll down and find Misc to find the configuration setups. (for example, Anti-mask
Detection, Anti-mask Latched, Detection Range).
Notice!
A description of the configuration setup appears when you select it in the field below the
configuration setup selection.
8.1 Classic/LSNi mode
8.1.1 Classic mode
Classic Mode was first introduced with traditional LSN configuration setups. The address for
the detector is not set by selecting the LSN address switch, but is automatically assigned an
address on the bus by the supporting control panel. The address range is restricted up to a
range of 127.

20 en | Configuration Professional Series TriTech AM Motion Detectors
with Anti-mask, LSN
2018.10 | 01 | F.01U.352.414 Reference Manual Bosch Building Technologies
8.1.2 LSNi mode
Most of the classic features like topology characteristics and initialization order are
transferable to the Neo-Classic (or LSNi) mode. The address assignment command, the
address range and the cable range are different.
The address for the detector is not set by selecting the LSN address switch, but is
automatically assigned an address on the bus by the supporting control panel. The address
range is extended up to 254. Additionally the cable length can be increased up to 3000 m
(9842 ft). Numerous range tests confirm the law of Ohm as main restriction of the bus range.
Therefore, the cable length is dependent on the bus current and the number of installed
network elements.
8.2 Detection range
8 M 25 FT
The detector is designed to work in two different range modes. With the full range (or long
range) mode, both the upper and lower PIR elements operate to provide the rated coverage.
When the detector is set to short-range mode, the upper PIR element is disabled and the
device ignores the microwave Doppler radar signal changes caused by movement in the area
not covered by the PIR.
Both long range and short range modes are configured using remote programming software.
Refer to your remote programming software for detection range information.
Configuration
RPS
Detection range is configured using remote programming software (RPS). The detection range
options show Level 1 through Level 8:
– Level 1-4 stand for short range (0-8 m)
– Level 5-8 for long range
