1Safety
1.1 About this Manual
This manual has been compiled with great care and the information it contains has been
thoroughly verified. The text was complete and correct at the time of printing. Because of the
ongoing development of products, the content of the manual may change without notice.
Bosch Security Systems accepts no liability for damage resulting directly or indirectly from
faults, incompleteness, or discrepancies between the manual and the product described.
1.2 Conventions in this Manual
In this manual, the following symbols and notations are used to draw attention to special
situations:
1.3 Legal Information
Copyright
This manual is the intellectual property of Bosch Security Systems, Inc. and is protected by
copyright. All rights reserved.
Trademarks
All hardware and software product names used in this document are likely to be registered
trademarks and must be treated accordingly.
1.4 Important Safety Instructions
Read, follow, and retain for future reference all of the following safety instructions. Heed all
warnings on the unit and in the operating instructions before operating the unit.
DANGER!
This symbol indicates an imminently hazardous situation such as “Dangerous Voltage” inside
the product. If not avoided, this will result in an electrical shock, serious bodily injury, or
death.
WARNING!
Indicates a potentially hazardous situation. If not avoided, this could result in serious bodily
injury or death.
CAUTION!
Medium Risk
Indicates a potentially hazardous situation. If not avoided, this may result in minor or
moderate injury. Alerts the user to important instructions accompanying the unit.
CAUTION!
Indicates a potentially hazardous situation. If not avoided, this may result in property damage
or risk of damage to the unit.
NOTICE!
This symbol indicates information or a company policy that relates directly or indirectly to the
safety of personnel or protection of property.

MIC612 Thermal Camera Safety | en 7
Bosch Security Systems, Inc. Installation Manual F.01U.249.416 | 1.1 | 2012.03
1. Install according to the manufacturer’s instructions.
2. Do not install near any heat sources such as furnaces, radiators, heaters, stoves, or other
equipment (including amplifiers) that produce heat.
3. Do not install the camera’s power supply near water (for example, near a bathtub,
washbowl, or swimming pool).
4. Use common sense safety precautions, especially in situations where there could be risk
of injury if any part of the assembly becomes detached and falls. A strong safety chain
between the camera pan shaft and the mounting surface is recommended.
5. Do not open the camera unit. Doing so will void the warranty.
6. Use only the power source indicated in this manual. Ensure that the rating of current of
the supply cable is adequate for the unit.
7. Disconnect the power before moving the unit. Move the unit with care. Excessive force or
shock may damage the unit.
Do not place this camera on an unstable stand, tripod, bracket, or mount. The unit may
fall, causing serious injury and/or serious damage to the unit. When a cart is used, use
caution and care when moving the cart/camera combination to avoid injury from tip-over.
Quick stops, excessive force, or uneven surfaces may cause the cart and/or camera to
overturn. Mount the camera per the manufacturer's instructions, and only with MIC
mounting accessories.
For transportation, rotate the ball so that the window points toward the base. This will
protect the wiper and the windows during transit.
CAUTION!
TO REDUCE THE RISK OF ELECTRIC SHOCK, DISCONNECT THE POWER SUPPLY BEFORE
OPENING THE POWER SUPPLY UNIT.
POWER DISCONNECT: POWER SUPPLY UNITS HAVE POWER SUPPLIED WHENEVER THE
POWER CORD IS INSERTED INTO THE POWER SOURCE.
WARNING!
INSTALLATION SHOULD BE CARRIED OUT BY QUALIFIED PERSONNEL IN ACCORDANCE WITH
THE NATIONAL ELECTRIC CODE, ANSI/NFPA, CANADIAN ELECTRIC CODE, AND ALL LOCAL
COUNTRY CODES.
BOSCH SECURITY SYSTEMS ACCEPTS NO LIABILITY FOR ANY DAMAGES OR LOSSES
CAUSED BY INCORRECT OR IMPROPER INSTALLATION.
WARNING!
INSTALL EXTERNAL INTERCONNECTING CABLES IN ACCORDANCE WITH NEC, ANSI/NFPA70
(FOR US APPLICATION) AND CANADIAN ELECTRICAL CODE, PART I, CSA C22.1 (FOR CAN
APPLICATION), AND IN ACCORDANCE WITH LOCAL COUNTRY CODES FOR ALL OTHER
COUNTRIES. BRANCH CIRCUIT PROTECTION INCORPORATING A 20 A, 2-POLE LISTED
CIRCUIT BREAKER OR BRANCH RATED FUSES ARE REQUIRED AS PART OF THE BUILDING
INSTALLATION. A READILY ACCESSIBLE 2-POLE DISCONNECT DEVICE WITH A CONTACT
SEPARATION OF AT LEAST 3 mm MUST BE INCORPORATED.ROUTING OF EXTERNAL WIRING
MUST BE DONE THROUGH A PERMANENTLY-EARTHED METAL CONDUIT.
WARNING!
THE CAMERA MUST BE MOUNTED DIRECTLY AND PERMANENTLY TO A NON-COMBUSTIBLE
SURFACE.

8en | Safety MIC612 Thermal Camera
F.01U.249.416 | 1.1 | 2012.03 Installation Manual Bosch Security Systems, Inc.
8. Do not point the camera at the sun. Bosch Security Systems will not be liable for any
damage to cameras that have been pointed directly at the sun.
9. Do not back drive the pan or tilt axis of the camera. Doing so will damage the motor drive
gear chain and will invalidate the warranty.
1.5 EC Directives
The MIC612 complies with the following EC directives:
– EMC Direct (89/336/EC as amended)
– Machinery Directive (98/37/EC)
– LV Directive (73/23/EC)
– RoHS (Restriction of Hazardous Substances) 2002/95/EC
– WEEE (Waste Electrical and Electronic Equipment) 200/96/EC
Environmental statement - This symbol means that electronic and electrical appliances
which have reached the end of their working life must be collected and disposed of separately
from household waste material. Separate collecting systems are usually in place for electronic
and electrical products. Please dispose of these units at an environmentally compatible
recycling facility, per European Directive 2002/96/EC.
Bosch has a strong commitment towards the environment. The camera was designed and
manufactured with high-quality material and components that can be recycled and reused.
1.6 Important Notices
Cold Start-ups - If camera is powered up in extremely cold temperature (for example, -
40°C),please allow 30 minutes warm-up after powering camera prior to operation. In some
cases,camera may require soft reset (Aux ON 911) or a power cycle before usable video is
available.
Ventilation - The camera is a completely sealed unit and requires no special consideration as
regards to ventilation.
Object and liquid entry - With the exception of the base connector, the camera can be
exposed to non corrosive liquids without damage. Never push objects into the base connector
as this may damage the connection pins and prevent the camera operating correctly.
Lightning - For added protection during a lightning storm, or when leaving this unit
unattended and unused for long periods, unplug the unit from the wall outlet and disconnect
the cable system. This will prevent damage to the unit from lightning and power line surges.
Power sources - Operate the unit only from the type of power source indicated on the label.
Before proceeding, disconnect the power from the cable to be installed into the camera.
– For external power supplied units, use only the recommended or approved power
supplies.
– For limited power source units, this power source must comply with EN60950.
Substitutions may damage the unit or cause fire or shock.
NOTICE!
This device is intended for use in public areas only.
U.S. federal law strictly prohibits surreptitious recording of oral communications.
NOTICE!
This equipment contains electrical or electronic components that must be recycled properly in
order to comply with Directive 2002/96/EC of the European Union regarding the disposal of
waste electrical and electronic equipment (WEEE). Contact your local supplier for procedures
for recycling this equipment.

MIC612 Thermal Camera Safety | en 9
Bosch Security Systems, Inc. Installation Manual F.01U.249.416 | 1.1 | 2012.03
– For 18 VAC units, voltage applied to the unit's power input should not exceed ±10%.
User-supplied wiring must comply with local electrical codes (Class 2 power levels). Do
not ground the supply at the terminals or at the unit's power supply terminals.
– If unsure of the type of power supply to use, contact your dealer or local power company.
Video loss - Video loss is inherent to digital video recording; therefore, Bosch Security
Systems cannot be held liable for any damage that results from missing video information. To
minimize the risk of lost digital information, Bosch Security Systems recommends multiple,
redundant recording systems, and a procedure to back up all analog and digital information.
Camera signal - Protect the cable with a primary protector if the camera signal is beyond 140
feet, in accordance with NEC800 (CEC Section 60).
Camera grounding - For mounting the camera in potentially damp environments, ensure to
ground the system using the ground connection of the power supply connector (see section:
Connecting external power supply).
Coax grounding:
– Ground the cable system if connecting an outside cable system to the unit.
– Connect outdoor equipment to the unit's inputs only after this unit has had its grounding
plug connected to a grounded outlet or its ground terminal is properly connected to a
ground source.
– Disconnect the unit's input connectors from outdoor equipment before disconnecting
the grounding plug or grounding terminal.
– Follow proper safety precautions such as grounding for any outdoor device connected to
this unit.
Grounding and polarization - This unit may be equipped with a polarized alternating current
line plug (a plug with one blade wider than the other blade). This safety feature allows the
plug to fit into the power outlet in only one way. If unable to insert the plug fully into the
outlet, contact a locally certified electrician to replace the obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
U.S.A. models only - Section 810 of the National Electrical Code, ANSI/NFPA No.70, provides
information regarding proper grounding of the mount and supporting structure, grounding of
the coax to a discharge unit, size of grounding conductors, location of discharge unit,
connection to grounding electrodes, and requirements for the grounding electrode.
Fuse rating - For security protection of the device, the branch circuit protection must be
secured with a maximum fuse rating of 16A. This must be in accordance with NEC800 (CEC
Section 60).
Alternately, this unit may be equipped with a 3-pole grounding plug (a plug with a third pin for
earth grounding). This safety feature allows the plug to fit into a grounded power outlet only.
If unable to insert the plug into the outlet, contact a locally certified electrician to replace the
obsolete outlet. Do not defeat the safety purpose of the grounding plug.
Permanently connected equipment - Incorporate a readily accessible disconnect device in
the building installation wiring.
Pluggable equipment - Install the socket outlet near the equipment so it is easily accessible.
Overloading - Do not overload outlets and extension cords. This can cause fire or electrical
shock.
Controls adjustment - Adjust only those controls specified in the operating instructions.
Improper adjustment of other controls may cause damage to the unit.
Attachments, changes or modifications - Only use attachments/accessories specified by
Bosch. Any change or modification of the equipment, not expressly approved by Bosch, could
void the warranty or, in the case of an authorization agreement, authority to operate the
equipment.

10 en | Safety MIC612 Thermal Camera
F.01U.249.416 | 1.1 | 2012.03 Installation Manual Bosch Security Systems, Inc.
1.7 FCC and ICES Compliance
FCC & ICES Information
(U.S.A. and Canadian Models Only)
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
– reorient or relocate the receiving antenna;
– increase the separation between the equipment and receiver;
– connect the equipment into an outlet on a circuit different from that to which the
receiver is connected;
– consult the dealer or an experienced radio/TV technician for help.
Intentional or unintentional modifications, not expressly approved by the party responsible
for compliance, shall not be made. Any such modifications could void the user's authority to
operate the equipment. If necessary, the user should consult the dealer or an experienced
radio/television technician for corrective action.
The user may find the following booklet, prepared by the Federal Communications
Commission, helpful: How to Identify and Resolve Radio-TV Interference Problems. This booklet
is available from the U.S. Government Printing Office, Washington, DC 20402, Stock No. 004-
000-00345-4.
INFORMATIONS FCC ET ICES
(modèles utilisés aux États-Unis et au Canada uniquement)
Suite à différents tests, cet appareil s'est révélé conforme aux exigences imposées aux
appareils numériques de classe B, en vertu de la section 15 du règlement de la Commission
fédérale des communications des États-Unis (FCC), et en vertu de la norme ICES-003 d'Industrie
Canada. Ces exigences visent à fournir une protection raisonnable contre les interférences
nuisibles lorsque l'appareil est utilisé dans le cadre d'une installation résidentielle. Cet
appareil génère, utilise et émet de l'énergie de radiofréquences et peut, en cas d'installation
ou d'utilisation non conforme aux instructions, engendrer des interférences nuisibles au
niveau des radiocommunications. Toutefois, rien ne garantit l'absence d'interférences dans
une installation particulière. Il est possible de déterminer la production d'interférences en
mettant l'appareil successivement hors et sous tension, tout en contrôlant la réception radio
ou télévision. L'utilisateur peut parvenir à éliminer les interférences éventuelles en prenant
une ou plusieurs des mesures suivantes:
– Modifier l'orientation ou l'emplacement de l'antenne réceptrice;
– Éloigner l'appareil du récepteur;
– Brancher l'appareil sur une prise située sur un circuit différent de celui du récepteur;
– Consulter le revendeur ou un technicien qualifié en radio/télévision pour obtenir de
l'aide.
NOTICE!
This is a class B product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.

MIC612 Thermal Camera Safety | en 11
Bosch Security Systems, Inc. Installation Manual F.01U.249.416 | 1.1 | 2012.03
Toute modification apportée au produit, non expressément approuvée par la partie
responsable de l'appareil, est strictement interdite. Une telle modification est susceptible
d'entraîner la révocation du droit d'utilisation de l'appareil.
La brochure suivante, publiée par la Commission fédérale des communications (FCC), peut
s'avérer utile : How to Identify and Resolve Radio-TV Interference Problems (Comment identifier
et résoudre les problèmes d’interférences de radio et de télévision). Cette brochure est
disponible auprès du U.S. Government Printing Office, Washington, DC 20402, États-Unis,
sous la référence n° 004-000-00345-4.
1.8 Bosch Notices
Disclaimer
Underwriter Laboratories Inc. (“UL”) has not tested the performance or reliability of the
security or signaling aspects of this product. UL has only tested fire, shock and/or casualty
hazards as outlined in UL's Standard(s) for Safety for Closed Circuit Television Equipment, UL
2044 and in Standard(s) for Safety for Information Technology Equipment, UL 60950-1. UL
Certification does not cover the performance or reliability of the security or signaling aspects
of this product.
UL MAKES NO REPRESENTATIONS, WARRANTIES, OR CERTIFICATIONS WHATSOEVER
REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING-
RELATED FUNCTIONS OF THIS PRODUCT.
1.9 Customer Support and Service
If this unit needs service, contact the nearest Bosch Security Systems Service Center for
authorization to return and shipping instructions.
USA
Repair Center
Telephone: [phone] / Fax: [phone]
E-mail: [email protected]
Customer Service
Telephone: [phone] / Fax: [phone]
E-mail: [email protected]
Technical Support
Telephone: [phone] / Fax: [phone] or 717-735-6560
E-mail: [email protected]
Canada
Telephone: [phone] / Fax: [phone]
Europe, Middle East, Africa Region
Repair Center
Telephone: [phone] / Fax: [phone]
E-mail: [email protected]
Asia Region
Repair Center
Telephone: [phone] / Fax: [phone]
E-mail: [email protected]
Customer Service
Telephone: [phone] or 86 (0) 756 7633121 / Fax: [phone]
E-mail: [email protected]
For additional information and warranty queries, please contact your Bosch Security Systems
representative or visit our website at www.boschsecurity.com.

12 en | Unpacking MIC612 Thermal Camera
F.01U.249.416 | 1.1 | 2012.03 Installation Manual Bosch Security Systems, Inc.
2 Unpacking
– This equipment, although ruggedized, should be unpacked and handled with care. Check
the exterior of the packaging for visible damage. If an item appears to have been
damaged in shipment, notify the shipper immediately.
– Verify that all the parts listed in the Parts List below are included. If any items are
missing, notify your Bosch Security Systems Sales or Customer Service Representative.
– Do not use this product if any component appears to be damaged. Please contact Bosch
Security Systems in the event of damaged goods.
– The original packing carton is the safest container in which to transport the unit and must
be used if returning the unit for service. Save it for possible future use.
2.1 Parts List
The package containing the MIC Series 612 camera should include the following items:
2.2 Additional Products Required
The following table lists additional products, sold separately by Bosch or other
manufacturers, required to operate MIC Series 612 cameras:
2.3 Additional Tools Required
The following table lists additional tools required (not supplied by Bosch):
CAUTION!
Take extra care lifting or moving MIC612 cameras because of their weight.
Quantity Part
1 MIC Series 612 Thermal Camera
1 MIC Series 612 Installation Manual (this booklet)
4 M8 stainless screws and washers
1 Nebar gasket
Quantity Product Part Number Size
1 per MIC612 Shielded Composite Cable for MIC thermal cameras
(See the model numbers and lengths at right.)
MIC-THERCBL-2M 2 m
MIC-THERCBL-10M 10 m
MIC-THERCBL-20M 20 m
MIC-THERCBL-20M 25 m
1 per MIC612 Power Supply Unit (PSU) for thermal cameras MIC-240PSU-2 or
MIC-115PSU-2
-- Mounting accessories
1 BNC terminal connector --
Quantity Part
1 13 mm wrench for the PCD foot, fixing bolts
1 3 mm screwdriver for the terminal blocks in the MIC PSU
1 8 mm screwdriver for captive screws for MIC PSU enclosure
1 safety chain
1 Silicone sealant for ensuring a water tight seal [if not using the Nebar gasket]

MIC612 Thermal Camera Installation Overview | en 13
Bosch Security Systems, Inc. Installation Manual F.01U.249.416 | 1.1 | 2012.03
3 Installation Overview
The MIC Series cameras are designed for easy installation on a variety of common fittings. The
most common type of mount used is a dedicated CCTV camera pole where the camera is
bolted directly to the top using industry-standard 4 in. (101.6 mm) fitting. This type of camera
pole provides a robust mounting platform that minimizes camera motion and typically has a
large base cabinet for mounting ancillary equipment such as power supplies.
The camera can also be mounted on lamp post columns using the Pole Mount Bracket (MIC-
PMB); however, users should be aware that lamp posts can often be subject to movement and
are not suitable platforms in all conditions or for all applications.
For mounting directly onto buildings, Bosch Security Systems manufactures a range of
brackets suitable for all typical building installations for upright (90°) or Inverted positions.
Figure 3.1 MIC camera mounting positions: Inverted, and Upright (Graphic is not of MIC612)
The camera’s adaptability enables easy integration in a wide variety of mobile and re-
deployable installations. These have included lifeboats and other surface/subsurface vessels,
emergency service vehicles, highway agency vehicles, council/contractor parking enforcement
vehicles, and crowd-control vehicles.
CAUTION!
Installation should be made by qualified service personnel and conform to the National
Electrical Code and applicable local codes.

14 en | Installation Overview MIC612 Thermal Camera
F.01U.249.416 | 1.1 | 2012.03 Installation Manual Bosch Security Systems, Inc.
3.1 Typical Mounting Arrangements
Below are examples of typical mounting arrangements for MIC Series cameras.
Figure 3.2 Typical pole mount (showing Pole Mount Bracket (MIC-PMB) with Shallow Conduit Adapter (MIC-
SCA) and Wall Mount Bracket (MIC-WMB))
Figure 3.3 Wall Mount Bracket (MIC-WMB) with Shallow Conduit Adapter (MIC-SCA) and Spreader Plate
(MIC-SPR)
Number Description
1 Securing bolts for Shallow Conduit Adapter
2 90 mm stainless steel pole banding
3 Blocks for Pole Mount Bracket
4 Plate for Pole Mount Bracket
5 Securing bolts for plate for Pole Mount Bracket
6 Shallow Conduit Adapter
7“O”ring
8 Wall Mount Bracket
9 Securing bolts for Wall Mount Bracket

MIC612 Thermal Camera Installation Overview | en 15
Bosch Security Systems, Inc. Installation Manual F.01U.249.416 | 1.1 | 2012.03
Figure 3.4 Typical corner mount (from left to right: Wall Mount Bracket (MIC-WMB), Shallow Conduit
Adapter (MIC-SCA), and Corner Mount Bracket (MIC-CMB))
3.2 Mounting Positions
MIC Series 612 cameras are designed to be mounted upright (straight up, 90°) or inverted
(straight down, 90°). See the figure below for the correct ways to mount the camera.
Figure 3.5 Mounting diagram: Correct ways (left) and Incorrect ways (right)
CAUTION!
The upright unit can be mounted either with the camera ball up or down. To get the picture
the correct way for installation with the camera ball down, rotate the camera tilt axis 180°.
If the camera is mounted ball down, it is essential that the connector and base area of the
camera are completely sealed from water ingress. Any water getting into the connector is
liable to cause corrosion to the connector pins, leading to unreliable operation of the camera
unit. To prevent water penetrating the composite cable connector threads, seal the 25 mm
thread at final installation using PTFE tape. Alternately, a suitable sealant may be liberally
applied to the thread prior to final tightening.
Number Description
1 Correct way, Upright
2 Correct way, Inverted
3 Incorrect way, Inverted and canted
4 Incorrect way, inverted on top of pole

16 en | Installation Overview MIC612 Thermal Camera
F.01U.249.416 | 1.1 | 2012.03 Installation Manual Bosch Security Systems, Inc.
3.3 About the MIC Shielded Composite Cable
MIC shielded composite cables are 2-conductor cables of various lengths (and gauges ranging
from 14 - 18) that provide all power, video, and telemetry connections between the MIC PSU
and the MIC camera. The cables are pre-made with a female-terminated 14-pin connector at
one end for attachment to the male connector installed into the base of the camera. The other
end of the cables has free (non-terminated) wires for wiring into terminals in the MIC PSU.
Figure 3.6 Composite cable before connection to a MIC camera
Figure 3.7 Composite cable connected to a MIC camera
3.4 About the Video Connection
The table below identifies the recommended cable types, maximum distance, and other
specifications for the coax video connection between the MIC camera and the power supply.
3.5 About Alarm Inputs and Outputs
The table below identifies the number of alarm inputs and outputs available with and without
an 8-input alarm card installed in the MIC PSU.
NOTICE!
Bosch does not recommend using the composite cable for distances greater than 25 m
between the MIC camera and the power supply.
Cable Type Maximum Distance
RG-59/U 300 m (1000 ft)
RG-6/U 450 m (1500 ft)
RG-11/U 600 m (2000 ft)
Size O.D. between 4.6 mm (0.181 in.) and 7.9 mm (0.312 in.)
Shield Copper braid: 95%
Central Conductor Standard copper center
Alarm Card
Installed?
Number of
Alarm Inputs
Number of
Alarm Outputs
Yes 8 2
No 1 0

MIC612 Thermal Camera Installation | en 17
Bosch Security Systems, Inc. Installation Manual F.01U.249.416 | 1.1 | 2012.03
4 Installation
4.1 Overview of Installation Steps
Follow these steps in sequence to install the MIC612 camera.
Note: Depending on your desired mounting position and location, as well as your chosen
accessories, you may not need to complete every step.
1. Mount the camera. See Section 4.2 Mounting the Camera, page 17.
2. Install the power supply unit (PSU). See Section 4.3.4 Installation Instructions, page 21.
3. Make the necessary connections for power, telemetry, and video. See
Section 4.3.4 Installation Instructions, page 21.
4. Connect the camera to the computer. See Section 5 Getting Started.
5. Configure the camera for inverted operation (for cameras mounted in inverted
position). See Section 5.6 Configuring the Camera for Inverted Operation, page 34.
6. Fit the optional sunshield. See Section 4.4 Fitting the Optional Sunshield (MIC612),
page 27.
4.2 Mounting the Camera
To mount a MIC Series camera, follow these steps:
1. Identify a secure location for the mount and for the camera. Locate the mounting position
so that the camera cannot be interfered with intentionally or accidentally. Ensure that the
installation location has the appropriate clearance from power and lightning conductors,
in accordance with NEC725 and NEC800 (CEC Rule 16-224 and CEC Section 60). Do not
install the camera near:
– Any heat sources
– Any overhead power lines, power circuits, or electrical lights, or where it may
contact power lines, circuits, or lights
CAUTION!
Installation must be made by qualified personnel and conform to ANSI/NFPA 70 (the National
Electrical Code®(NEC)), Canadian Electrical Code, Part I (also called CE Code or CSA C22.1),
and all applicable local codes. Bosch Security Systems, Inc. accepts no liability for any
damages or losses caused by incorrect or improper installation.
CAUTION!
Ensure that a strong safety chain is used to secure the MIC camera to prevent any danger of
dropping the product during installation. Particular care should be taken with MIC612 models
because of the additional weight.
CAUTION!
Fasteners are not supplied with MIC612 cameras because the type of fastener used depends
on the material to which the fastener is attached. The material must accommodate a minimum
pull-out strength of 275 kg (600 lbs.) Fasteners can include wedge anchors, sleeve anchors,
single expansion anchors, double expansion anchors, machine screw anchors, or "Thru-
Bolting" with a nut. All fasteners must be made of 303(A2) stainless steel, at a minimum, with
a diameter of 8 mm (5/16-in).All bolts must fully extend through the mounting surface and be
secured with a flat washer, lock washer, and a nut. All studs must be anchored to concrete or
welded to a steel backing plate. Anchor bolts can be used for blind structures where there is
no access to the rear.

18 en | Installation MIC612 Thermal Camera
F.01U.249.416 | 1.1 | 2012.03 Installation Manual Bosch Security Systems, Inc.
2. Ensure that the mounting surface is capable of supporting the combined weight of the
camera and mounting hardware under all expected conditions of load, vibration, and
temperature. MIC612 cameras must be secured to one of the following surfaces:
– Concrete Solid/Cast
– Concrete Masonry Unit (Concrete Block)
– Brick (all types)
– Metal (Steel/Aluminum, minimum 1/8-in. thick)
Note: If the camera is positioned in a highly exposed area where lightning strikes may
occur, it is recommended to install a lightning conductor within 0.5 m of the camera and
at least 1.5 m higher than the camera. The construction of the housing itself is capable of
coping with secondary strikes. If the correct lightning protection is applied, no damage to
the internal electronics or camera should result. An earth bonding connection to the case
also provides protection against damage from secondary strikes. (See step 8.)
3. Fit the mounting brackets securely, observing all appropriate safety precautions and local
building regulations.
4. Carefully lift the camera to the mounting point.
5. Attach the security attachment point to a safety chain (not supplied).
6. Attach the safety chain to a secure part of your mounting structure.
7. Connect the female 14-pin connector end of the shielded composite cable to the male
plug in the base of the camera. Screw the cable connector sleeve onto the plug until it is
firmly secured (approximately four (4) turns from the start of thread engagement).
8. Earth the camera using one of the securing supplied bolts. Only earth the camera at a
single point to prevent earth loops and video distortion (hum bars), caused by electrical
interference, from appearing on the camera picture in the control room. Please note the
following:
– The camera module and housing are electrically isolated, so the housing should be
safety earthed regardless. The safety earth should be a bonding connection (for
example, one of the securing bolts) to the camera’s outside case, and should be
attached to the Earth terminal post on the PCD base of the camera.
– If the system is copper throughout and the camera pictures are fed back to the
control room via coaxial copper cable, then the camera should be earthed only at the
video termination point in the control room. In this case, the "Earth Link" on the PCB
should be broken. Refer to
– If the video is transmitted back to the control room via some non-electrical
connecting medium (for example, fiber optic, radio, or microwave link), then the
camera should be earthed at the transmitter point in the power supply unit. The PSU
"Earth Link" may be used for this purpose.
– If dual earthing is unavoidable, then a video isolation transformer should be fitted
between the two earths.
9. Use M8 x 20 mm stainless steel nuts, bolts, and washers to secure the PCD base of the
camera to the mounting bracket. An additional Nebar gasket or suitable silicone sealant
can be used to ensure a water tight seal between the base and mounting surface. Tighten
all bolts securely.
10. Secure all cabling and conduit.
WARNING!
If the camera is mounted ball down, it is essential that the connector and base area of the
camera are completely sealed from water ingress. Any water getting into the connector is
liable to cause corrosion to the connector pins, leading to unreliable operation of the camera
unit.

MIC612 Thermal Camera Installation | en 19
Bosch Security Systems, Inc. Installation Manual F.01U.249.416 | 1.1 | 2012.03
4.3 Installing the MIC Power Supply Unit (PSU)
Each MIC power supply unit (PSU) provides all of the connections needed for power, video,
and telemetry for a single MIC camera. Each MIC PSU has CE and FCC approval and has a
cast-aluminum enclosure that is weather-resistant (rated IP65). Features include:
– A provision for driving various optional interface cards mounted internally to the MIC
power supply enclosure (for example, an 8-input alarm card (MIC-ALM))
– A provision for a signal interface card (MIC-BP4) to connect telemetry to Bosch Biphase
equipment
– Screw termination of all cables (composite, telemetry, and ancillary) into and out of the
enclosure
– Earth isolation and termination within the unit to control video earthing correctly and
thus prevent earth loops
Each MIC PSU ships with the following parts:
– Three (3) M12 cable glands for telemetry, video and ancillary equipment
– One (1) M16 gland for connection of the shielded composite cable to the MIC camera
– One (1) 1/2 in. NPT cable gland for the power cable connection
– One (1) 1/2 in. NPT and one (1) M12 blanking plug
MIC612 cameras can use the MIC-240PSU-2 power supply (a 230 VAC source) or the MIC-
115PSU-2 power supply (a 115 VAC source). The dimensions (H x W x D) of the enclosures
are: 90 x 260 x 160 mm (3.54 x 10.24 x 6.3 in.). The weight is 3.2 kg (7.1 lb).
4.3.1 Earth Link on PCB
The printed circuit board (PCB) has one Earth Link option, near terminal block HD1, to allow
the PSU to be set up for different earthing schemes:
– If there is a separate connection between video screen and earth, the Earth Link should
be broken. This usually occurs on copper-connected systems where all of the copper
video coaxes are taken back to the control room to be connected to a central earth point.
– If fiber optics or other indirect connections are used to get data and video to and from
the control room, then the Earth Link should be left intact, as long as it is the only
camera-end earth reference point.
4.3.2 Fuse Ratings
The MIC PSUs for MIC612 cameras have four (4) off 20 mm fuses (numbers 13 - 16 in
Figure 4.1) in fuse holders. The ratings for these fuses are fixed on the low voltage secondary
side but change with input voltage on the high voltage primary side. The following table shows
the fuse values that should be fitted to provide proper protection for the MIC-240PSU-2 and
MIC-115PSU-2 power supplies. Note: FS 4 does not exist.
WARNING!
To prevent water from penetrating the composite cable connector threads, the 25 mm thread
should be sealed at final installation using PTFE tape (not supplied). Alternatively, a suitable
sealant may be liberally applied to the thread prior to final tightening.
Fuse ID Fuse Function Type Rating for 240 V Primary Rating for 115 V Primary
FS 1 MIC camera protection Glass 1.6 A Anti surge (T) 1.6 A Anti surge (T)
FS 2 Primary protection Glass 200 mA quick blow 500 mA quick blow
FS 3 Heater protection 1 Glass 1.6 A Anti surge (T) 1.6 A Anti surge (T)
FS 5 Heater protection 2 Glass 1.6 A Anti surge (T) 1.6 A Anti surge (T)

20 en | Installation MIC612 Thermal Camera
F.01U.249.416 | 1.1 | 2012.03 Installation Manual Bosch Security Systems, Inc.
4.3.3 Layout of MIC Power Supply Units (PSUs) for MIC612
The figure below displays the layout of the PCB in the MIC PSUs for non-IR cameras, with call-
out numbers to the side of or below the connection/terminal ID or the terminal, and ’on’ the
fuses. The table below the figure identifies the connections.
Figure 4.1 Layout of MIC-240PSU-2 and MIC-115PSU-2
Number Connection /
Terminal ID on PCB
Description/Function ofConnection
/ Terminal
Type of Connection /
Terminal
1 HD1 AC Power input Screw terminal
2 HD3 Shielded composite cable
(connections to camera )
Screw terminal
3 HD5 RS-485 control Screw terminal
4 HD4 Telemetry header Molex connector
5 HD8 USB to RS-485 converter Molex connector
6 HD6 [Optional] Auxiliary, heater Screw terminal
7 HD7 Video (composite cable) Screw terminal
8 HD2 Tamper switch Screw terminal
9CN3
(Video Switched)
Coax connection BNC socket
10 CN1
(Video Out)
Coax connection BNC socket
11 CN2 Auxiliary card terminal Plug in
12 Earth Link Earth Link --
13 FS2 Fuse 2 - Primary protection --
14 FS1 Fuse 1 - MIC camera protection --
15 FS3 Fuse 3 - Heater protection 1 --
16 FS5 Fuse 5 - Heater protection 2 --
