BOSS ILLUMINATION SCORPIO User manual

www.bia.lighting | [email protected]page 1 / 3
PRODUCT MANUAL
COPYRIGHT BIA ©2020 V03.20
Disclaimer: Please read these warranty
and installation instructions carefully
before installing the product.
BIA products are manufactured
and certied in accordance with all
mandatory Australian Standards.
All products must be installed by a
licensed electrician, in accordance
with relevant Australian Standards.
Technical data and information subject
to changes, visit our website for the
most updated version.
WARRANTY STATEMENT This product is covered by a 5 year replacement warranty.
BIA guarantees this product to be free of defects from the date of purchase for the stated period above. If product fails within the warranty period, BIA will x
or replace the product. This excludes any costs associated with the removal or installation of product. This warranty is subject to the terms and conditions stated
on www.bia.lighting. Failure to comply with installation guidelines will automatically void the warranty. Please retain purchase receipt. For more information on
warranty please visit www.bia.lighting/warranty
BIA reserves the right to change specications and other information, modify products and discontinue items without prior notication.
PRODUCT VARIANTS
Power : 600W
900W
1200W
1500W
CCT : 3000K
4000K
5000K
Colour : Black
Grey
Beam Angle : 9°
15°
30°
60°
A17
A24
Dimming: No
1-10V
DALI
PRODUCT SPECIFICATIONS
Input Voltage : 90-305VAC
Ambient Temperature : -30 to 45°C
Dimming : No
Weight : 22.2kg to 48.2kg
SCORPIO
FLOOD LIGHT
Must be installed by
a licensed electrician.
Must be installed
in accordance with
relevant Australian
Standards.
ADDITIONAL INFORMATION
1. Luminaire aiming angle is adjustable. Refer instructions overleaf.
2. Installation must be carried out with care to ensure the surface
of the luminaire is not scratched or exposed to harsh weather
conditions. Damaged surfaces will result in material corrosion
when exposed under harsh weather conditions.
3. Please ensure luminaire cover is sealed.
4. If cleaning maintenance is required, use a clean microfibre cloth,
slightly dampened with a mild dilution of detergent that is PH
neutral, alcohol free and non-abrasive.
PARTS INCLUDED
LED
Luminaire
Hexagonal
Socket
Wrench
for Primary
adjustment
Hexagon
Wrench
for Fine
adjustment
M6*12
Allen Screws
Steel Chain Power Supply
Module
IP66
OPTIONAL COMPATIBLE PARTS sold separately
Visor Wireguard Laser Pointer
300m Max
IK10

www.bia.lighting | [email protected]page 2 / 3
PRODUCT MANUAL
COPYRIGHT BIA ©2020 V03.20
INSTALLATION INSTRUCTIONS
A INSTALLING THE VISOR
Secure visor with screws provided.
B INSTALLING THE WIRE GUARD
Secure wire guard with screws provided.
C INSTALLING THE LASER POINTER
1. For precise aiming of the flood light, install the laser pointer
to the back of the luminaire with screws as shown in the
image below.
2. Remove the laser pointer when installation job is done.
D ADJUSTING THE ANGLE
1. Install and switch on laser pointer. (see section C)
2. Remove the black rubber cover.
3. Loosen the hex bolt with the hexagonal wrench provided.
4. Pull out and rotate to desired direction. Push in to hold
the position.
5. Lock the hex bolt to secure the position.
6. Replace rubber cover.
7. Remove laser pointer.
E INSTALLATION OF DRIVER
a. Drivers can be installed directly onto the back of the
luminaire bracket.
or
b. Drivers can also be remotely installed for maintenance
purposes.
F INSTALLATION
1. Before commencing installation, ensure the main power is
switched off.
2. Mount the bracket onto installation surface by securing it
with bolt and screws.
3. Optional: Steel chains can be installed as reinforcement by
wrapping it around the bracket and installation surface.
4. Connect the wires together through the waterproofed cables.
5. The cables go lead to a junction box at the back of the driver.
6. Remove the cover and connect the wires within.
7. Replace cover, adjust angle if necessary (see section D).
Turn on main power.
Note: If necessary, silicon can be applied to wire entry points to
reenforce IP rating.
Ea
Eb
Brown: Dim+
Blue: Dim-
Black: Dim+
White: Dim-
Purple: Dim+
Gray: Dim-
Brown: L
Blue: N
Yellow and green:
C
A B
F2
F3
F5
F6
D2
D3
D5
D4
D6
F6

www.bia.lighting | [email protected]page 3 / 3
PRODUCT MANUAL
COPYRIGHT BIA ©2020 V03.20
DIAMENSION DIAGRAM
636mm
636mm 636mm
636mm448mm
448mm 448mm
448mm
320mm
320mm
320mm
320mm
50mm
50mm
50mm
50mm
80mm
80mm
80mm
80mm
463mm 128mm
422mm
390mm760mm
948mm 575mm
149mm
153mm 138mm
450mm
420mm
25mm
30mm
30mm
600W
22.2kg
900W
29.4kg
1200W
35.5kg
1500W
48.2kg
Visor Wireguard
