Bowflex 220 DUMBBELLS User manual

220 • 552 • 1090 DUMBBELLS
and BDS1642 • BDS552 STAND
Service Manual
Patent #6,422,979 other USA and Foreign Patents Pending
PN 001-6872 Rev B (03/2007)

This manual is intended for authorized Bowex®or Nautilus® certied service personnel and not for the
consumer. There are no user-serviceable parts. Servicing of the Bowex® SelectTech™ equipment by other
than authorized Bowex®or Nautilus® certied service personnel will result in voiding of the warranty.
If you are a consumer and require technical support to resolve a problem with your Bowex® SelectTech™
Dumbbell Set, please call Nautilus® Customer Service at 800-864-1270 (North America) or [phone]
(outside North America).
Important—Please Read
ATTENTION!
FOR DETAILED INSTRUCTIONS AND INFORMATION ON USE FOR YOUR BOWFLEX®
SELECTECH™ DUMBELL SET, MODELS BD 220, 552, 1090, AND BDS552 STAND,
BDS1642 STAND, REFER TO THE OWNER’S MANUAL.

Table of conTenTs
Important Safety Information ......................................................................................................... 1
Product Specifications ......................................................................................................................... 2
Troubleshooting - BD220, 552, AND1090 Dumbbell
Troubleshooting Guide: BD220, 520 and 1090 Dumbbell...................................................................................4
Troubleshooting Guide: BDS552, and BDS1642 2-1 stand.................................................................................5
Troubleshooting Flowcharts ................................................................................................................................7
Reference Images - Damage ............................................................................................................................13
Reference Images - Cover Screw on Handle ...................................................................................................14
Warranty Information........................................................................................................................................ 15
Contact Information ...........................................................................................................................................16

1
Important symbols
This symbol appearing throughout this manual means:
PAY ATTENTION! BE ALERT! YOUR
SAFETY IS INVOLVED!
The following definitions apply to the words “Danger” and
“Warning” found throughout this manual.
Danger - Used to call attention to IMMEDIATE hazards that,
if not avoided, will result in immediate, serious
personal injury or loss of life.
Warning - Used to call attention to POTENTIAL hazards that
could result in personal injury or loss of life.
Before beginning any exercise program, consult your
physician or health care professional. Only he or she
can determine the exercise program that is appropriate
for your particular age and condition. If you experience
any lightheadedness, dizziness or shortness of breath
while exercising, stop the exercise and consult your
physician immediately.
IMPORTANT SAFETY INSTRUCTIONS
1. Read and fully understand all instructions contained in this
manual prior to using the product.
2. This product is intended for home use only and is not suit-
able for commercial application.
3. Never allow children to use or play near this equipment.
Teenagers under the age of 18 must always have parental
supervision and instruction on the use of this product.
4. Inspect the dumbbells prior to each use. Do not use a
dumbbell with worn or damaged parts.
5. Periodically inspect and test the locking mechanism for
proper function. Follow the test procedures included in this
manual.
6. Never attempt to force the adjustment knob to rotate when
the dumbbell has been removed from the dumbbell base.
7. Never allow the dumbbells to drop freely to the ground.
Damage to the product and potential personal injury may
occur. Please see the warranty section for specific war-
ranty limitations related to dropped dumbbells.
8. Never allow dumbbells to forcefully bump together during
use. Damage to the product and potential personal injury
may occur.
9. Never attempt to disassemble your SelectTech™ Dumbbell
handle, or base assembly–the product is not designed to
be user serviced. Contact your Bowflex retailer or Bowflex
directly for service.
10. Before beginning your workout, make certain that your sur-
roundings are free from potential interference.
11. The SelectTech™ dumbbells are very heavy; if you are not
using the optional SelectTech™ Dumbbell Stand we sug-
gest you place the dumbbell assembly directly on the floor
for best support.
ATTENTION
WARNING

2
ProducT sPecificaTions
BD552 Dumbbell Assembly Footprint
WEIGHT: 58 LBS. (26.4 KG)
153/4”
9”
8”
BD1090 Dumbbell Assembly Footprint
WEIGHT: 98 lbs (44.5 kg)
17.5”
10
9.5”
“
BD220 Dumbbell Assembly Footprint
WEIGHT: 55.12 LBS. (25.05 KG)
12”
8
7”
“

3
ProducT sPecificaTions
7EIGHT0LATE
3ELECTION4ONGUE

4
Troubleshooting guide
Problem Solution
Dumbbell handle does not fully insert into
base when no plates are selected (handle
has no plates attached).
1. Make certain that both adjustment knobs are set directly to
the number 5.
2. Make certain that all of the weight plates have the “selection
tongue” facing away from the dumbbell grip. If one or more of
these are backwards (selection tongue facing inward toward
grip), the handle can get blocked, and the plates may wedge
into the handle.
Dumbbell handle does not fully insert into
base when plates are selected (handle has
plates attached).
1. Check to see if you have selected different weights on each side
of the dumbbell (for example one adjustment knob is set to 5
and the other is set to 7.5). If this is the case, you must replace
the dumbbell in the base with the same orientation in which
was withdrawn. This is to allow the plates to settle back into
the correct and vacant openings in the base.
2. Verify that the plates not selected (those plates remaining in
the dumbbell base) are in their correct spots and have not
been moved to a different support slot. This may be blocking
the dumbbell from fitting back into the base.
3. See solution #2 from problem above.
Adjustment knob will not turn while handle
is in base.
1. Check to assure that the dumbbell handle is fully depressed
into the dumbbell base. If not fully depressed, the locking
mechanism will not be released and may be keeping the
adjustment knobs from rotating.
2. Check to see if any weight plates have been put into the base
assembly backwards with the “support tongue” facing the
grip of the dumbbell handle. All weight plates must have the
selection tongue facing away from the grip of the dumbbell
handle.
3. Check to see if there is any dirt, debris or other obstruction
in the dumbbell base. You may need to remove the weight
plates from the base to accomplish this check. Remember to
put each weight plate back in its appropriate location with the
selection tongue facing away from the dumbbell grip.
4. Depress the locking tab in the handle and test rotation. If the
silver locking tab in the base is loose, replace the base.
TroubleshooTing guide

5
BDS552 Chrome Stand and BDS1642 2-in-1
STAND- Assembly Troubleshooting
Problem:
The Towel Bar cannot be attached to both Dumbell Platforms.
See Figures 1A and 1B.
Solution:
The Left and Right Dumbbell Platforms are installed on the
wrong Legs, and need to be switched. Please refer to the Parts
List item numbers and Exploded View in this service manual.
Detailed assembly instructions are provided in the Assembly
Manual.
Tools:
• 7/32” Hex Key
• 9/16” Socket
• 9/16” Wrench or Adjustable Wrench
Steps:
1-1 Unscrew the Towel Bar (#9) from the Dumbbell Platform
(#7 / #8). Set the hardware safely aside.
1-2 Unscrew the Dumbbell Platforms (#7 and #8) from the
stand Legs (#1). Set the hardware for each Platform
safely aside.
1-3 Attach the Right Platform (#7) to the right Leg (#1) and the
Left Platform (#8) to the left Leg (#1) using the hardware
from Step 1-2.
Note: When you reinstall the Dumbbell Platforms on the stand,
check the following:
• The Dumbell Platforms should be installed so that the
screw holes for attaching the Towel Bar are closer to
the upper end of each platform. See Figure 2.
Figure 1B – Close-up
Figure 1A – Incorrect Assembly
TROUBLESHOOTING GUIDE

6
TROUBLESHOOTING GUIDE
• The Hold Down Straps should be next to
the lower screw holes. See Figure 2.
• The “L” or “R” sticker should be at the
lower edge of the platform. See Figure 2.
The“L” sticker should be on the left-hand
side and the “R” sticker should be on the
right-hand side. (However, the platforms
may be mislabeled or the stickers may be
missing.)
1-4 Attach the Towel Bar (#9) to the Dumbbell
Platforms (#7 and #8) using the hardware
from Step 1-1. See Figure 3.
1-5 Tighten all hardware completely.
Figure 2 – Correct Assembly
Stickers
Screw
holes
Hold Down
Strap
Figure 3 – Installed Towel Bar (bottom view)
