Bowflex SelectTect BDS1642 User manual

2-In-1 Stand
Assembly Instructions
Model: BDS1642

2


























  

Complete Stand Component Diagram

3
Tools Required
7/32" Allen Wrench (included)
You will also need:
9/16" Socket
9/16" Wrench or Adjustable Wrench
Utility knife or scissors to cut nylon ties
Parts
# Qty. Description
1 1 TUBE, BOTTOM CROSS BRACE
2 1 ASSEMBLY, REAR LEFT STABILIZER
3 1 ASSEMBLY, REAR RIGHT STABILIZER
4 2 ASSY, STAND LEG
5 1 WELDMENT, LEFT DUMBBELL PLATFORM
6 1 WELDMENT, RIGHT DUMBBELL PLATFORM
7 1 WELDMENT, TOWEL BAR
8 1 FOOT PEGS, SET OF FOUR
9 1 HOLD DOWN STRAPS, 2F 2M
10 20 NUT-NL 0.375-16 G2-BlkZ
11 36 WASHER-FLAT 0.375 REGULAR BLKZ
12 8 SCREW-BHCS 0.375-16x3.0 G2-BlkO
13 4 SCREW-BHCS 0.375-16x2.75 G2-BlkO
14 4 SCREW-BHCS 0.375-16x2.5 G2-BlkO
15 4 SCREW-FHCS 0.375-16x1.0 G2-BlkO
16 1 WHEELS, CASTER SET OF FOUR
17 1 PLATE, CENTER W/ LOGO
2.5"
2.75"
3.0"
Flat Head
Button Head
Lock Nut Flat Washer
Button Head
Button Head
Hardware
Qty
Hardware Card A:
2.75" Screw, Button Head 4
2.5" Screw, Button Head 4
1.0" Screw, Flat Head 4
Nut, Lock 12
Washer, Flat 20
Hardware Card B:
3.0" Screw, Button Head 8
Nut, Lock 8
Washer, Flat 16
7/32" Allen Wrench

4
step
1
Parts:
• Stand Leg (#4)
• Rear Left Stabilizer (#2)
Hardware Qty
• 3" Screws (#12) 2
• Washers (#11) 4
• Nuts (#10) 2
Tools:
• Hex Key (7/32”)
1-1 Attach the Rear Left Stabilizer (#2) to the Stand Leg (#4) using the hardware shown in Figure 1.
Note: Do not tighten hardware.
Figure 1







5
step
2
Figure 2
Parts:
• Stand Leg (#4)
• Rear Right Stabilizer (#3)
Hardware Qty
• 3" Screws (#12) 2
• Washers (#11) 4
• Nuts (#10) 2
Tools:
• Hex Key (7/32”)
2-1 Attach the Rear Right Stabilizer (#3) to the Stand Leg (#4) using the hardware shown in Figure 2.
Note: Do not tighten hardware.







Parts:
• Cross Brace (#1)
• Left Stand Leg assembly from Step 1
• Right Stand Leg assembly from Step 2
Hardware Qty
• 3" Screws (#12) 4
• Washers (#11) 8
• Nuts (#10) 4
Tools:
• Hex Key (7/32”)
3-1 Attach the Bottom Cross Brace (#1) to the Rear Left Stabilizer (#2) and Rear Right Stabilizer (#3)
using the hardware shown in Figure 3. Make sure that the narrower edge of the Cross Brace
(#1) is closer to the Stand Leg (#4) uprights.
Note: Do not tighten hardware.
step
3
6








Figure 3

7
step
4
Parts:
• Stand Leg and Cross Brace assembly from Step 3
• Center Plate (#17)
Hardware Qty
• 2.5" Screws (#14) 4
• Washers (#11) 8
• Nuts (#10) 4
Tools:
• Hex Key (7/32”)
• Wrench/Socket (9/16”) or Adjustable Wrench
4-1 Install the Center Plate (#17) to both Stand Legs (#4) using the hardware shown in Figure 4.
Note: Make sure that the Center Plate edges are on the outer sides of the legs, and that the logo
on the Plate is right side up.
4-2 Tighten all hardware from Steps 1, 2 and 3 securely.









Figure 4

step
5
8
Parts:
• Stand base assembly from Step 4
• Left Dumbbell Platform (#5)
Hardware Qty
• 2.75" Screws (#13) 2
• Washers (#11) 4
• Nuts (#10) 2
Tools:
• Hex Key (7/32”)
• Wrench/Socket (9/16”) or Adjustable Wrench
5-1 Secure the Left Dumbbell Platform (#5) to left Stand Leg (#4) using the hardware shown in
Figure 5.
Note: Make sure the screw holes in the Platform are toward the center of the stand.





Figure 5

9
step
6
Parts:
• Stand base assembly from Step 5
• Right Dumbbell Platform (#6)
Hardware Qty
• 2.75" Screws (#13) 2
• Washers (#11) 4
• Nuts (#10) 2
Tools:
• Hex Key (7/32”)
• Wrench/Socket (9/16”) or Adjustable Wrench
6-1 Secure the Right Dumbbell Platform (#6) to right Stand Leg (#4) using the hardware shown in
Figure 6.
Note: Make sure the screw holes in the Platform are toward the center of the stand.





Figure 6

step
7
10
Parts:
• Stand assembly from Step 6
• Towel Bar (#7)
Hardware Qty
• 1" Screws (#15) 4
• Washers (#11) 4
• Nuts (#10) 4
Tools:
• Hex Key (7/32”)
• Wrench/Socket (9/16”) or Adjustable Wrench
7-1 Attach the Towel Bar (#7) to the Left Dumbbell Platform (#5) and the Right Dumbbell Platform
(#6) using hardware shown in Figure 7. Hand tighten screws in a cross pattern, to ensure
even fit.
7-2 Tighten all screws securely.

 

 

Figure 7
