Bradley Equa-Flo HD Operation manual

1 of 2 Bradley Corporation • 215-1369-29 Rev. E: EN 10-03-007
Operation and Service Guide: Showers
P.O. Box 309 •Menomonee Falls, WI 53052-0309
1.800.BRADLEY •Fax: [phone] •bradleycorp.com
Equa-Flo HD Pressure Balancing Valve
For Individual, Econo-Walls, Wall Savers and Panelons Showers (2003 to Present)
20
11
14
15
17
24
16
10
8
7
5
6
4
3
2
1
8
9
12
13
Escutcheon Screws (2)
160-142
Escutcheon:
300-1140 (Individual & Econowall)
300-1141 (Panelon)
300-1147 (Wall Saver) August 2004 to Present
Set Screw
UP
Align Item 5, Valve Cap
to Item 18, Valve Body
as shown
(Introduced February
2007)
22
23
19
18
19
Valves are equipped with a temperature limit stop which can be used to limit the temperature of tempered water discharged. To adjust
the temperature, remove the handle and adjust the set screw on the valve cap. Turn the set screw clockwise for COLDER setting and
counterclockwise for WARMER setting.
NOTE: When replacing the double face seals, lubricate the top face with a small amount of lubricant when reassembling.
When assembling the valve cap into valve body, use lubricant on 125-154 O-ring to prevent twisting of O-ring.
If lubricant is not available, a slight film of soap may be used.
*
*
*
* Used on Anti-Ligature HSR20 Only
(Introduced June, 2010)

2 of 2 Bradley Corporation • 215-1369-29 Rev. E: EN 10-03-007
Operation and Service Guide: Showers
P.O. Box 309 •Menomonee Falls, WI 53052-0309
1.800.BRADLEY •Fax: [phone] •bradleycorp.com
Equa-Flo HD Pressure Balancing Valve Parts List
Individual, Econo-Walls, Wall Savers and Panelons (2003 to Present)
Item Part No. Description
Assembly
Cartridge
Assembly
S67-602S
Stem Assembly
S21-076
Gasket Repair
Kit S65-248
Qty
1 128-163 Handle 1 — — —
2 160-226 Screw 1 — — —
3 160-225 Screw 2 — — —
4 160-441 Set Screw 1 — — —
5 107-521 Valve Cap 1 — — —
6 125-154 O-Ring 1 — — 1
7 125-001AY O-Ring — — 1 1
8 142-131 Washer — — 2 —
9 135-089 Spring — — 1 —
10 120-150 Stem — — 1 —
11 120-155A Rotor 1 — — —
12 125-081 Double-Face Seal — 2 — 2
13 118-311 Cartridge Housing — 1 — —
14 153-428 Retainer — 2 — —
15 125-001BQ O-Ring — 2 — 2
16 119-242 Piston — 1 — —
17 125-155 O-Ring — 2 — 2
18 118-144 Valve Body 1 — — —
19 S27-102 Stops (Optional) 2 — — —
20 142-130 Washer — 2 — 2
21 300-0402 Foam Rim Seal (not shown) 1 — — —
22 142-002BT Lock Washer 4 — — —
23 153-463 Anti-Ligature Spacer 4 — — —
24 128-179 Anti-Ligature Handle 1 — — —
Complete Valve Replacement/Retrofit Kit:
S65-249 Individual and Econowall Showers
S65-249A Panelon
S65-249B Wall Saver
Note: Above part numbers contain all parts necessary to replace/retrofit
one station only. Customer must order proper amount of kits; example:
Three S65-249 kits required for a 3W Econo-Wall Shower.
