Bradley MG Series User manual

P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 1.800.BRADLEY Fax: [phone]
bradleycorp.com
215-1586 Rev. D; ECN 13-08-025
© 2014 Bradley
Page 1 of 22 4/9/2014
Installation
MG-3/NDT
Express®Lavatory System
MG-Series
with NDITE® Infrared Control
Table of Contents
Supplies Required by Installer....................2
Dimensions ................................ 3-4
Installation Instructions ...................... 5-13
Cleaning and Maintenance .....................14
Assembly of Components ................... 15-18
Troubleshooting NDITE®Components ......... 19-20
Solenoid Valve Parts ..........................21
Navigator®Valve Maintenance and Parts ..........22
Cleaning the Strainer..........................22
Express®Lavatory Systems
are ADA and TAS compliant.
Patents Pending

MG-3/NDT Installation
24/9/2014 Bradley • 215-1586 Rev. D; ECN 13-08-025
Supplies Required by Installer
• (8)³⁄₈" wall anchors, bolts and 1" min. O.D. washers to mount main frame and bowl to wall
(minimumpull-outratingof1,000lbs.)
• ½"Nominalcoppertubingforhotandcoldsupplies
• 1½"NPTdrainpiping
IMPORTANT!
Read this entire installation manual to ensure proper installation. When finished
with the installation, file this manual with the owner or maintenance department.
Separate parts from packaging and make sure all parts are accounted for
before discarding any packaging material. If any parts are missing, do not begin
installation until you obtain the missing parts.
Make sure that all water supply lines have been flushed and then completely
turned off before beginning installation. Debris in supply lines can cause valves
to malfunction.
Hardware supplied by installer must be appropriate for wall construction. Wall
anchors used must have a minimum pull-out rating of 1,000 lbs.
Product warranties may be found under “Product Information" on our web site at
www.bradleycorp.com.
THIS
SIDE
UP
Packing List
•
•
•
•
Installation

Installation MG-3/NDT
Bradley • 215-1586 Rev. D; ECN 13-08-025 4/9/2014 3
MG-3/NDT Express Lavatory System Dimensions
57"
(1445mm)
77"
(1956mm)
*Subtract 4" from vertical dimensions for compliance with ADA guidelines for children’s use.
22"
(559mm)
*39"
(991mm)
*33½"
(851mm)
*29½"
(749mm)
*17½"
(445mm)
21½"
(546mm)
9½" (241mm)
84"
(2134mm)
72"
(1829mm)
15" (381mm)
30"
(762mm)
30"
(762mm)
15" (381mm)

MG-3/NDT Installation
44/9/2014 Bradley • 215-1586 Rev. D; ECN 13-08-025
MG-3/NDT Express Lavatory System Dimensions continued . . .
TASTAS
TAS Juvenile Height
Grades 6 thru 8 or 9
TAS Juvenile Height
Grades Pre-K thru 5 or 6
37-1/2"
(952mm)
32"
(813mm)
28"
(711mm)
16"
(406mm)
TASTAS
35-1/2"
(902mm)
30"
(762mm)
26"
(660mm)
14"
(356mm)

Installation MG-3/NDT
Bradley • 215-1586 Rev. D; ECN 13-08-025 4/9/2014 5
Installation Instructions
Step 1: Rough in
NOTE: See Figure 1 (below), 1a, 1b (for TAS on page 6) and Figure 2 (on page 7) when roughing in
the MG-3/NDT Express®.
IMPORTANT: Flush the supply lines before making connections. Debris in supply lines will
cause the valves to malfunction.
IMPORTANT: Dimensions shown in Figure 1 are for Standard Height only. Make sure to follow
appropriate dimensions based on configuration and required rim height. Review
appropriate figure before beginning rough-ins.
1. Roughin½"nominalcoppertubingforhotandcoldsupplylinesthroughwallatdimensionsshown.
2. Roughin1½"NPTdrainwasteconnectionthroughwallatdimensionsshown.
2¾"
(70mm)
4" (102mm)
FLOOR
28"
(711mm)
28"
(711mm)
*31½"
(800mm)
*28¼"
(718mm)
*26"
(660mm)
*19½"
(495mm)
³⁄₈" WALL ANCHORS, (8) PLACES
MIN. PULL-OUT STRENGTH 1000 LBS. PER ANCHOR
1½" NPT DRAIN
STUB OUT 2"
*Juvenile Height Mounting:
Subtract 4" (102mm) from vertical dimensions for compliance with ADA guidelines for children’s use.
Figure 1
Standard Height Mounting
CENTERLINE OF FIXTURE
HC
APPROX. DIMENSION
40½" (1029)
AA
B
BB
B
BB
APPROX. DIMENSION
40½" (1029)
4"
(102mm)
½" NOMINAL COPPER TUBING FOR HOT AND COLD SUPPLIES
STUB OUT 2"

MG-3/NDT Installation
64/9/2014 Bradley • 215-1586 Rev. D; ECN 13-08-025
TAS — Texas Accessibility Standards:
Juvenile Height (grades Pre-K thru 5 or 6)
2¾" (70mm)
4" (102mm)FLOOR
28"
(711mm)
28"
(711mm)
28"
(711mm)
24¾"
(629mm)
22½"
(572mm)
16"
(406mm)
³⁄₈" WALL ANCHORS, (8) PLACES MIN. PULL-OUT
STRENGTH 1000 LBS. PER ANCHOR
1½" NPT
DRAIN
STUB OUT 2"
Figure 1a
HC
APPROX. DIMENSION
40½" (1029mm)
AA
B
BB
B
B
B
APPROX. DIMENSION
40½" (1029mm)
4"
(102mm)
½" NOMINAL COPPER TUBING FOR HOT AND COLD SUPPLIES
STUB OUT 2"
2¾" (70mm)
4" (102mm)FLOOR
28"
(711mm)
28"
(711mm)
30"
(762mm)
26¾"
(679mm)
24½"
(622mm)
18"
(457mm)
³⁄₈" WALL ANCHORS, (8) PLACES MIN. PULL-OUT
STRENGTH 1000 LBS. PER ANCHOR
1½" NPT
DRAIN
STUB OUT 2"
Figure 1b
CENTERLINE
OF FIXTURE
HC
APPROX. DIMENSION
40½" (1029mm)
AA
B
BB
B
B
B
APPROX. DIMENSION
40½" (1029mm)
4"
(102mm)
½" NOMINAL COPPER TUBING FOR HOT AND COLD SUPPLIES
STUB OUT 2"
TAS — Texas Accessibility Standards:
Juvenile Height (grades 6 thru 8 or 9)
CENTERLINE
OF FIXTURE

Installation MG-3/NDT
Bradley • 215-1586 Rev. D; ECN 13-08-025 4/9/2014 7
Installation Instructions continued . . .
Step 2: Rough in wall anchors
1. Install six ³⁄₈"wallanchorswithaminimumpull-outratingof1,000lbs.(suppliedbyinstaller)atthe
locationsmarked(ref.location“B"showninFigure1,1aor1bonpages5-6).
NOTE: The dimensions for the wall anchors at location “A" are for reference only.
2. On the back of the bowl, measure the distance between the ¾" bowl mounting holes. Divide this
measurement in half. Measure and mark this dimension on the wall to the left of the centerline and to the
right of the centerline. Install two ³⁄₈"wallanchorswithaminimumpull-outratingof1,000lbs.(suppliedby
installer)atthelocationsmarked(ref.location“A"showninFigure1,1aor1bonpages5-6).
NOTE: The anchors will be used to mount the Express bowl and frame to the wall.
Figure 2
1-1/2" NPT DRAIN
STUB OUT 2"
1/2" NOMINAL COPPER
TUBING FOR HOT AND
COLD SUPPLIES OR
TEMPERED SUPPLY.
STUB OUT 2"

MG-3/NDT Installation
84/9/2014 Bradley • 215-1586 Rev. D; ECN 13-08-025
Installation Instructions continued . . .
Step 3: Mount frame to wall
1. Loosen, but do not remove the bottom three access panel screws.
2. Remove the top three access panel screws and washers securing the access panel to the frame and
removetheaccesspanel(seeFigure3).
3. Position the frame with Terreon®End Caps attached, against the wall, ensuring that it is level.
IMPORTANT: Anchoring the frame to a wall that is not flat may cause the frame to bend. If
necessary, install shims to compensate for wall distortion.
4. Ensure that the back of the frame is flat against the wall. If wall is not flat, insert shims behind the frame to
ensure that it will not bend when anchored.
5. Once you have positioned the frame such that it is level and flat against the wall or shimmed, use the ³⁄₈"
bolts and washers to mount the frame to the wall.
Figure 3
³⁄₈" BOLTS AND WASHERS
(6) PLACES
TERREON
END CAP
LEFT
STAINLESS STEEL
ACCESS PANEL
TERREON
END CAP
RIGHT
FRAME
¼" - 20 SCREWS
AND FINISHING WASHERS
(6) PLACES
FRONT VIEW

Installation MG-3/NDT
Bradley • 215-1586 Rev. D; ECN 13-08-025 4/9/2014 9
Installation Instructions continued . . .
Step 4: Install bowl assembly
IMPORTANT: See Figure 4 below when installing the bowl assembly. If the fixture has soap option,
refer to the soap system installation manual 215-1585 before installing the bowl
assembly.
1. With someone to assist you, place the bowl assembly squarely onto the frame being careful not to pinch
tubing between bowl and frame.
2. Attachthefrontofthebowlassemblytotheframeusingthefour¼-20x½"pan-headscrewsandwashers
provided. Do not tighten screws at this time.
IMPORTANT: When bolting the bowl assembly to the wall, do not overtighten the bolts.
Overtightening bolts can damage the Terreon material.
3. After the bowl assembly is attached to the frame, install the two 3/8" bolts and washers
(suppliedbytheinstaller)toboltthebowltothewallanchors.Do not overtighten bolts.
4. Tighten the screws installed in procedure #2 above to secure the bowl assembly to the frame.
Do not overtighten.
5. If necessary, adjust sprayhead body to fit closely to wall by adjusting sprayhead mounting bolts. See
Figure 7 on page 14 for sprayhead mounting bolt locations.
Figure 4
³⁄₈" BOLT
AND WASHER
TERREON
END CAP (R)
TERREON
END CAP (L)
FRAME SPRAYHEAD
³⁄₈" BOLT
AND WASHER
BOWL
¼"-20 x ½"
PAN HEAD
SCREWS AND
WASHERS
(4) PLACES
BACK VIEW

MG-3/NDT Installation
10 4/9/2014 Bradley • 215-1586 Rev. D; ECN 13-08-025
Installation Instructions continued . . .
Step 5: Connecting supply
1. Loosen but do not remove the two mounting screws holding the valve bracket to the frame. Slide the
valvebracketupuntilthelargercutoutintheframe’sslotalignswiththescrewhead(seeFigure5b).
Then lift up to remove the valve bracket from the frame.
2. FOR HOT AND COLD SUPPLY: Attach the stops to the hot and cold water supply piping from the wall.
ConnecttheflexiblehosestotheNavigatorMixingValveandtothestops(seeFigure5a).
NOTE: The “H" on Navigator Mixing Valve indicates hot water supply inlet.
 FORSINGLETEMPEREDSUPPLY:Attachthestoptothe½"temperedsupplyline.Connectthestopto
thetemperedlineadapterwiththeflexiblesupplyhose(Figure5c).
3. AssembletheP-trapbyconnectingthe1½"tubularpipetothetailpieceandtothe1½"drainpipe
stubbed out of the wall.
4. Install the strainer on the drain plug opening inside the bowl, and push the strainer firmly into place.
Secure the strainer with the screw provided.
Figure 5c
FLEXIBLE
SUPPLY HOSE
(TO SOLENOID
BRACKET)
TO SUPPLY
LINE
TEMPERED
LINE ADAPTER
(S39-804)
Figure 5a
NAVIGATOR
THERMOSTATIC
MIXING VALVE
FLEXIBLE
SUPPLY
HOSE
CONNECT TO
HOT WATER
SUPPLY
CONNECT TO
COLD WATER
SUPPLY
FLEXIBLE
SUPPLY
HOSE
Hot and Cold Supplies
Single Tempered
Supply
Figure 5b
SLOT IN
FRAME
VALVE BRACKET
MOUNTING SCREW

Installation MG-3/NDT
Bradley • 215-1586 Rev. D; ECN 13-08-025 4/9/2014 11
3. Insert the three sprayhead supply tubes into the three solenoid tube connectors by loosening the
compressionnutandfirmlypushingthetubeintotheconnectoruntiltheyarefullyseated(blacktube
forleft-handstation,greentubeforcenterstationandredtubeforright-handstation).Retightenthe
compression nut by hand.
4. Align the valve bracket mounting screws with slots on the frame. Let the valve bracket slide down to lock
into place.
NOTE: Optional Battery Power Pack (p/n S65-284) for quickstart power-up is available from Bradley.
Installation Instructions continued . . .
Step 6: Connecting electrical and supply tubing
WARNING: The MG-3/NDT must be connected to the NDITE
power management module. Connection to 110
VAC can result in personal injury and damage
to electronics .
CAUTION: Connection of leads other than shown may
cause permanent damage to the sensor.
CAUTION: To avoid activating the sprayhead valve, make
sure to connect sensor cable plugs to the circuit
board before connecting the power supply. If the
cable is connected or disconnected while the
batteries are installed, the station will activate
and continue running for 75 seconds.
IMPORTANT: It will take approximately 60 minutes @ 700 lux
for the system to charge.
NOTE: Refer to Figure 6a (right) and 6b (on page 12).
1. Snap the sensor plugs from the sprayhead into the proper valve’s
circuit board.
2. Connect the photovoltaic cell plug from the photovoltaic cover to
thepower-incableonthepowermanagementmodule(Figure6a).
POWER MANAGEMENT MODULE
(LOCATED ON FRAME)
POWER SUPPLY
CABLES
PHOTOVOLTAIC
CELL PLUG (FROM
PHOTOVOLTAIC
COVER)
POWER
MANAGEMENT
MODULE
Figure 6a
POWER-IN
CABLE

MG-3/NDT Installation
12 4/9/2014 Bradley • 215-1586 Rev. D; ECN 13-08-025
Figure 6b
Installation Instructions continued . . .
POWER
MANAGEMENT
MODULE
POWER-IN
CABLE
GANG VALVE
ASSEMBLY
GANG VALVE
CIRCUIT BOARD
SENSOR CABLE (FROM
SPRAYHEAD LH STATION)
POWER SUPPLY
CABLE
SENSOR
CABLE (FROM
SPRAYHEAD
CENTER STATION)
SENSOR
CABLE (FROM
SPRAYHEAD RH
STATION)
COMPRESSION NUT
(RED SUPPLY, RH
STATION)
COMPRESSION NUT (GREEN
SUPPLY, CENTER STATION)
COMPRESSION NUT (BLACK
SUPPLY, LH STATION)

Installation MG-3/NDT
Bradley • 215-1586 Rev. D; ECN 13-08-025 4/9/2014 13
Installation Instructions continued . . .
Step 7: Adjust the temperature
1. Checkthetemperaturewhenapproximately1.0GPMwaterflowisreachedandadjustifnecessary(the
rangeofthevalveis95°F–125°F(35°C–52°C).
2. LoosenCapScrewabout¼"(4-6turns)andliftupcover(donotremove).
3. Using cover, turn cartridge gently until desired water temperature is reached. Do not turn past stops as
this may damage unit. Push cover down and tighten screw.
4. After testing is complete, reinstall access panel to frame. Fasten access panel with the six panel screws
andwashersprovided(Figure3,page8).
Figure 7
H
C
This valve is NOT factory preset. Upon installation, the temperature of this valve must be checked and
adjusted to ensure delivery of a safe water temperature. Water in excess of 110°F (43°C) may cause scalding.

MG-3/NDT Installation
14 4/9/2014 Bradley • 215-1586 Rev. D; ECN 13-08-025
Cleaning and Maintenance Instructions
IMPORTANT: Strong alkaline or acid-based chemicals and cleansers should not be used to clean
the Express. If these chemicals come in contact with the Terreon surface, wipe
off the surface immediately and flush with soapy water. Avoid unnecessary or
prolonged contact with hot pans and objects.
Terreon®and panel maintenance
The bowl, sprayhead and pedestal end caps are made of Terreon, a solid cast polyester resin material.
Terreon resists chemicals, stains, burns and impact, and is repairable with everyday cleaners or fine-grit
abrasives. The panel is made of stainless steel. With regular cleaning, your Terreon fixture will provide
years of dependable service.
Terreon Bowl, Sprayhead and Pedestal End Cap cleaning
• DailyCleaning: Wipe the surface with a damp cloth and wipe dry.
• WeeklyCleaning: Wipe the surface with a damp cloth and a household liquid detergent. Stubborn
stains can be removed as follows:
1. Using a #7448 Scotch-Brite®pad, scrub with an abrasive cleanser such as Ajax®, Comet®or
Soft Scrub®and water.
2. Clean thoroughly with soapy water and allow to dry.
• ScorchMarks: Although Terreon will not burn, a lit cigarette in contact with Terreon could leave
a scorch mark. Scorch marks can be removed by buffing with a #7448 Scotch-Brite pad or with an
abrasive cleaner.
• Repair kit: In the unlikely event your Terreon surface becomes damaged, it can easily be repaired.
Contact your Bradley representative to order a repair kit and be sure to specify color when ordering.
Stainless Steel Access Panel cleaning
Stainless steel is extremely durable, and maintenance is simple and inexpensive. Proper care, particularly
under corrosive conditions, is essential. Ordinary deposits of dirt and grease are quickly removed with soap
and water. Whenever possible, the metal should be thoroughly rinsed and dried after washing. To remove
tightly adhering deposits, use stainless steel polishing powder. In all cases, rub in the direction of the
stainless steel grain.
IMPORTANT: Never use ordinary steel wool or steel brushes on stainless steel. Always use
stainless steel wool or stainless steel brushes.
Avoid prolonged contact with chlorides, bromides, thiocyanates, and iodides on stainless steel equipment,
especially if acid conditions exist. Do not permit salty solutions to evaporate and dry on stainless steel. The
appearance of rust streaks on stainless steel leads to the belief that the stainless steel is rusting. Look for
the source of the rust in some iron or steel particles which may be touching, but not actually a part of the
stainless steel structure.
NOTE: Strongly acidic or caustic cleaners may attack the steel causing a reddish film to appear. The use
of these cleaners should be avoided.
NOTE: Use of brand names is intended only to indicate a type of cleaner. This does not constitute an
endorsement, nor does the omission of any brand name cleaner imply its inadequacy. Many
products named are regional in distribution and can be found in local supermarkets, department
and hardware stores or through your cleaning service. It is emphasized that all products should
be used in strict accordance with package instructions.

Installation MG-3/NDT
Bradley • 215-1586 Rev. D; ECN 13-08-025 4/9/2014 15
Assembly of Components
SPRAYHEAD BODY
(PART NUMBER VARIES WITH
COLOR OF UNIT. CONTACT
YOUR LOCAL BRADLEY REP.
FOR ASSISTANCE).
BOWL
(PART NUMBER VARIES WITH
COLOR OF UNIT. CONTACT
YOUR LOCAL BRADLEY REP.
FOR ASSISTANCE).
END CAP (RIGHT)
(PART NUMBER VARIES WITH
COLOR OF UNIT. CONTACT
YOUR LOCAL BRADLEY REP.
FOR ASSISTANCE).
END CAP (LEFT)
(PART NUMBER
VARIES WITH
COLOR OF UNIT.
CONTACT YOUR
LOCAL BRADLEY
REP FOR
ASSISTANCE).
SPRAYHEAD
MOUNTING BOLTS (5)
STAINLESS STEEL
ACCESS PANEL
186-1262.
#8-32 SCREW
(160-319)
STRAINER
(P16-075)
DRAIN PLUG
(P16-072)
1/8" RUBBER WASHER
(125-001DP)
WASTE SHOE
(111-062)
P-TRAP (POLYPROPYLENE)
(269-1697)
OPTIONAL P-TRAP
(CHROME-PLATED BRASS)
(S29-094)
DRAIN
ASSEMBLY
WASTE TEE
(111-063)
1/4"-20 x 1/2"
PAN HEAD
SCREW (qty. 4)
(160-389)
1/4"-20
WASHER
(qty. 4)
(142-002DB)
BOWL MOUNTING
HARDWARE
Figure 8

MG-3/NDT Installation
16 4/9/2014 Bradley • 215-1586 Rev. D; ECN 13-08-025
Assembly of Components continued . . .
Sensor assembly and solenoid valve access
• Toaccesssolenoids:
Using a ⁵⁄₃₂" Allen socket wrench, loosen, but do not remove the bottom three access panel screws. Remove
the top three access panel screws and washers securing the panel to the frame and remove the access panel
(seeFigure3onpage8).Solenoidsarelocatedonleftsideofframe(seeFigure9).
• Toremovesprayhead:
Remove(5)boltslocatedundersideofbowlneck(seeFigures8and10).Carefullyremovesprayheadfrombowl.
•To access sprayhead/aerator/lens and sensor assembly:
Remove(2)screwsandwashersfromtheaccessplateassemblyusinga¹⁄₈" Allen socket wrench. The access
plateassemblyislocatedunderneaththesprayhead(3)places(seeFigure11aonpage17),theassemblywill
drop down to access the lens, sensor, and sensor eyes, housing flow control and tube connector.
Figure 9
FRAME
SOLENOIDS
⁵⁄₁₆" I.D. BRAIDED HOSE
NAVIGATOR
MIXING VALVE
Figure 10
SPRAYHEAD BODY
MOUNTING LOCATION
TO BOWL (5) PLACES
SPRAYHEAD ASSEMBLY
S05-166

Installation MG-3/NDT
Bradley • 215-1586 Rev. D; ECN 13-08-025 4/9/2014 17
Assembly of Components continued . . .
Figure 11b
WINDOW
PURPLE EYE
Figure 11a
INFRARED
WINDOW
269-1241
SENSOR EYES
30" (251-019A)
60" (251-019B)
SPRAYHEAD
CONNECTOR ¼" TUBE
145-089
ACCESS PLATE
150-201
SCREW BUTTON HD SOCKET
#10-24 160-138
HOUSING,
FLOW CONTROL
S05-142A
NUT
110-115

MG-3/NDT Installation
18 4/9/2014 Bradley • 215-1586 Rev. D; ECN 13-08-025
Assembly of Components continued . . .
SCREW
(160-120)
SCREW
(160-289)
DIFFUSER
(269-508)
AERATOR HOUSING
(115-133)
¼" ELBOW
(145-090)
SENSOR ASSY. COMPONENTS
"A"
SENSOR EYES
LENGTH OF “A" = 36" (251-019A)
LENGTH OF “A" = 60" (251-019B)
O-RING
(125-001CK)
NUT
(110-115)
STREAMFORMER
(115-125)
INFRARED
WINDOW
(269-1241)
POWER
SUPPLY
CABLES
PHOTOVOLTAIC
CELL PLUG
(S83-183)
(FROM
PHOTOVOLTAIC
COVER)
POWER
MANAGEMENT
MODULE
(S83-182)
POWER-IN
CABLE
OPTIONAL BATTERY
START-UP PACK
(S65-284)

Installation MG-3/NDT
Bradley • 215-1586 Rev. D; ECN 13-08-025 4/9/2014 19
Troubleshooting NDT Components
IMPORTANT: NDITE technology requires a minimum of 400 LUX to operate. Before proceeding make
sure all of the lights in the room are operating and that there are no obstructions
blocking the light hitting the surface of the sprayhead. If available, use a light meter to
measure the amount of light on the surface of the Lavatory System sprayhead. Also
check for severe vandalism or other physical damage to the sprayhead.
Leave the lights in the room on for aproximately four hours to fully charge the system
before operating.
NOTE: If there is inadequate lighting in the location where the unit is installed, add additional lighting or convert
the system to battery power. Contact Bradley and order Battery Pack Kit S45-2083 (one per station).
NOTE: Refer to Figure 11 (solenoid valve) on page 20 when necessary.
Problem: Water will not shut off.
Cause: Water pressure is too low.
Solution: Test for proper water pressure.
The Express Lavatory System operating specifications require a water pressure of between 20- 80 PSI at the
connection to the fixture. If the pressure is above 80 PSI the valve may not operate. When verifying water
pressure always use a reliable pressure gauge at the connection to the fixture.
Cause: Faulty solenoid valve.
Solution: Test station; replace solenoid valve if required.
Disconnect the plug from the power management module to the circuit board of the problem valve. Remove
the three #8 Phillips-head screws that hold the solenoid valve assembly together. Be careful not to lose the
armature or spring. Remove the diaphragm. Remove any particles that are trapped between the diaphragm and
the valve seat. Rinse off the diaphragm and inspect for damage. Make sure the center orifice and both small
side orifices are open. Reassemble in reverse order, being careful not to over tighten the Phillips-head screws
or the plastic valve body may crack. Tighten until the armature plate makes contact with the plastic body.
Reconnect the power plug. Turn on water supply to the unit.
Problem: Water in multiple stations will not activate.
Cause: Inadequate lighting.
Solution: Test for adequate lighting.
NDITE technology requires a minimum of 400 LUX to operate. Before proceeding make sure all of the lights in
the room are operating and that there are no obstructions blocking the light hitting the surface of the sprayhead.
If available, use a light meter to measure the amount of light on the surface of the lavatory system sprayhead.
Also check for severe vandalism or other physical damage to the sprayhead. If there is inadequate lighting
available in the location where the unit is installed, add additional lighting. If additional lighting is unavailable,
thesystemmaybeconvertedtobatterypower.ContactBradleyandorderBatteryPackKitS45-2083(oneper
station)
Cause: Improper water pressure.
Solution: Test for proper water pressure.
The Express Lavatory System operating specifications require a water pressure of between 20- 80 PSI at the
connection to the fixture. If the pressure is above 80 PSI the valve may not operate. When verifying water
pressure always use a reliable pressure gauge at the connection to the fixture. If water pressure is high but not
above 80 PSI the following may be raising the pressure: circulation system , booster pumps, or undersized or
no expansion tank. If any of this equipment is raising the pressure above the specified pressure levels it will be
characterized by the system working for a short time after the supply connections are made and then stopping.

MG-3/NDT Installation
20 4/9/2014 Bradley • 215-1586 Rev. D; ECN 13-08-025
Troubleshooting NDT Components continued . . .
Problem: Water in multiple stations will not activate.
Cause: No power to the sensor board.
Solution: Check for power to the sensor board.
Remove the front cover from the fixture. Wave your hand in front of the sensor window, one station at a time,
while looking at the sensor boards below the fixture. A light should flash on the sensor board when each station
isactivated.Ifnolightflashes,testtheoutputfromthephotovoltaiccellswithamultimeter(availablefrommost
homeimprovementstoresandprofessionalsupplydistributors).
Cause: Improper output from voltaic cells.
Solution: Test output from photovoltaic cells.
Testtheoutputfromthephotovoltaiccellswithamultimeter(availablefrommosthomeimprovementstoresand
professionalsupplydistributors).
NOTE: The electrical system on NDITE powered Express Lavatory Systems is low voltage and low
amperage.
With the room lighting on, unplug the cord running from the photovoltaic cells to the power management
module. Touch the red multimeter probe to the inside of the plug and the black multimeter probe to the outside
of the plug. With the Multimeter in the DC Volts setting, it should have a reading of 6 volts or more. If the
reading is under 6 volts, doublecheck the room lighting levels. If the reading is over 6 volts and the system will
not operate, replace the NDITE power management module.
Problem: Water in one station will not activate
Cause: Faulty sensor eyes.
Solution: Test sensor eyes and replace, if necessary.
Disconnect the sensor cable from the circuit board of the problem valve. Disconnect the sensor cable from
the circuit board of an adjacent working valve. Connect the sensor cable from the adjacent working valve to
the problem valve. Activate the problem station’s sensor. The station should turn on. If it turns on and cycles
normally, replace the eyes in the problem station.
Cause: Problem with control boards.
Solution: Test the control boards and replace the battery, if necessary.
Disconnect the plug from the power supply to the circuit board of the problem valve. Disconnect the plug from
the power supply to the circuit board of a working adjacent valve. Connect the power plug from the adjacent
working valve to the problem valve. Wait for ten seconds. Activate the problem station’s sensor ten times. The
station should turn on. If it turns on, and cycles normally, replace the batteries in the problem station.
Troubleshooting – Stop Valve
Problem Cause Solution
Water just
dribbles or does
not flow from
sprayhead
Water supply malfunctioning 1. Close the stops and check the valves that supply water to
the lavatory system.
2. Inspect the stop valves for proper installation.
Water sprayhead
delivers all hot or
cold water
Water supply or mixing valve
malfunctioning
1. Close the stops and check the valves that supply water to
the lavatory system.
2. Inspect the stop valves for proper installation.
3. Inspect mixing valve for proper hot and cold installation. A
red marking indicates the hot inlet.
