Bradley Equa-Flo Pressure Balancing Valve Operation manual

1 of 2 Bradley Corporation • 215-1369-32A : EN 04-318
Operation and Service Guide: Showers
P.O. Box 309 •Menomonee Falls, WI 53052-0309
1.800.BRADLEY •Fax: [phone] •bradleycorp.com
Equa-Flo valves are equipped with a temperature limit stop which can be used to limit the temperature of tempered water discharged.
IMPORTANT: The hot limit stop as shown above has been set for maximum temperature operation. For temperatures
other than the maximum, the stop may be repositioned as described below. Failure to adjust the hot limit
stop to a safe shower temperature could result in the user being scalded.
To adjust the temperature, remove the handle and loosen the set screw. Remove the HOT limit stop and reposition to desired setting.
Turn the limit stop clockwise for a HOTTER setting and counterclockwise for a COOLER setting.
When assembling the cartridge assembly into the valve body and cap, lubricate the stem and O-rings with S45-125 grease.
If the desired position falls between adjacent positions on the spline, flip the HOT limit stop over so the other face shows. This shifts the
stop position by 1/2 spline.
Equa-Flo Pressure Balancing Valve (August, 2004 to Present)
For Column Showers
9
4
11
12 13
10
8
57
3
2
16
Escutcheon Screws (2)
160-278
Escutcheon:
150-206 (6 Person)
150-205 (2-5 Person)
(Note: These parts have
a chrome finish with
cast-in recessed lettering)
Valve shown in "OFF" position
with HOT limit stop shown set
for maximum temperature operation.
Shower
Manifold
Notch in Stem
UP
Position of Arrow on Cap

2 of 2 Bradley Corporation • 215-1369-32A : EN 04-318
Operation and Service Guide: Showers
P.O. Box 309 •Menomonee Falls, WI 53052-0309
1.800.BRADLEY •Fax: [phone] •bradleycorp.com
Equa-Flo Pressure Balancing Valve Parts List (August, 2004 to Present)
For Column Showers
Item Part No. Description
Assembly
Gasket Repair Kit
S65-278
Cartridge Assembly
Repair Kit S65-
277
Qty
1 128-161 Handle 1 — —
2 160-214 Screw #10-24 x 1 Flat Head 1 — —
3 144-033 Limit Stop, HOT 1 — —
4 160-252 Set Screw #8-32 x 1/4 1 — —
5 144-041 OFF Stop 1 — —
6 160-454 Screw #10-24 x 3/8 Flat Head 2 — —
7 107-551 Cap 1 — —
8 125-161 O-Ring 1 1 (See Note 2) 1 (See Note 3)
9 269-1785 Cartridge Assembly 1 — 1 (See Note 3)
10 169-256 Screw #10-24 x 5/8 4 — —
11 118-143 Valve Body 1 — —
12 169-269 Gasket 1 1 (See Note 2) —
13 125-001BS Washer 1 1 (See Note 2) —
Notes:
1. Complete Column Valve Replacement/Retrofit Kit:
S65-266 for 2-5 Person
S65-267 For 6 Person
Kit part numbers contain all parts necessary to replace/retrofit one station only.
Customer must order proper amount of kits; example" Five S65-266 kits required
for a 5 Person Column Shower.
2. Gasket Repair kit also contains the three external O-rings (not shown
on exploded diagram) supplied with the 269-1785 cartridge assembly.
3. 269-1785 Cartridge assembly cannot be ordered separately; cartridge
assembly must be ordered as part of the Repair Kit that includes the O-ring.
