Bray Flow-Tek 7000 Series User manual

FLOW-TEK SERIES 
 PIECE FULL PORT BALL VALVES
Installation Operation and Maintenance Manual
BRAY.COM THE HIGH PERFORMANCE COMPANY

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
2 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
CONTENTS
DRAFT JULY   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 DEFINITION OF TERMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 PARTS IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 GENERAL INFORMATION FOR ON-SITE INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 SAFETY TIPS AND WARNINGS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 SHORT AND LONG-TERM STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 
 OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 
 STEM SEAL ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 
 INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 DISASSEMBLY AND CLEANING PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 
 VISUAL INSPECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 
 VALVE RE-ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
 RETURN MERCHANDISE AUTHORIZATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
3 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
 DEFINITION OF TERMS
All information within this manual is relevant to the safe operation
and proper care of your Bray valve Please understand the
following examples of information used throughout this manual
DANGER
Indicates a potentially hazardous situation which if not avoided
will result in death or serious injury
WARNING
Indicates a potentially hazardous situation which if not avoided
could result in death or serious injury
CAUTION
Indicates a potentially hazardous situation which if not avoided
could result in minor or moderate injury
NOTICE
Used without the safety alert symbol indicates a potential
situation which if not avoided may result in an undesirable result
or state including property damage
READ AND FOLLOW THESE INSTRUCTIONS CAREFULLY
SAVE THIS MANUAL FOR FUTURE USE

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
4 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
 INTRODUCTION
The design features of this valve include three piece construction
and a “free floating” ball allowing ease of maintenance without
special tools The ball is not fixed but is free to move with the
line pressure As a result of this feature these valves are capable
of tight shut-o with flow in either direction regardless of the
position of the valve in the line
The downstream seat opposite the pressurized side of a closed
valve must carry the load exerted by the line pressure on the
ball while the upstream seat is subject to little load or wear For
this reason it is sometimes possible to increase useful seat life by
turning the valve end-for-end in the pipeline

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
5 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
2
7
8
14
1
11A
12
10
5
11B
15
18
19
20
26
25
28
23
24
29
3
2
9
6
4
4
6
 PARTS IDENTIFICATION
 – - Valves
ITEM NAME QTY
Body 
End Cap 
Ball 
Seat•
Stem 
Body Seal•
Spring Lock Washer *
Body Nut *
Body BoltStud 
 Anti-Static Device 
A Thrust Washer Protector•
B Packing Protector•
 Thrust Washer•
 Stem Packing Set•
 Packing Gland 
 Belleville Washers 
 Tab Lock Washer 
 Stem Gland Nut 
 Travel Stop Set Sleeve 
 Travel Stop Bolt 
 Handle 
 Handle Nut 
 Handle Sleeve 
 Locking Device 
•Recommended spare parts
that are available as a
packaged repair kit
* Quantity of Body Nuts and Spring
Lock Washers per valve size
 to  Valves - 
- Valves - 

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
6 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
 PARTS IDENTIFICATION (Continued)
 –  Valves
ITEM NAME Q T Y
Body 
End Cap 
Ball 
Seat•
Stem 
Body Seal•
Spring Lock Washer 
Body Nut 
Body Stud 
 Anti-Static Device 
A Thrust Washer Protector•
B Packing Protector•
 Thrust Washer•
 Stem Bearing•
 Stem Packing Set•
 Packing Gland 
 Packing Gland Follower 
 Gland Bolt 
 Stop Housing 
 Housing Bolt 
 Travel Stop 
 Handle 
 Handle Set Screw 
 Snap Ring 
•Recommended spare parts
that are available as a
packaged repair kit
0
5
12 A 4
3
B
5
6
7
20
2
22
30
30
27
25
7
8

4
6
8
7
2
2
6
4
3
9
7
8

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
7 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
6
6
2

A
2
13
0
5
27
27
26
25
3
2
9
4A
4
B
5
4B
4A
4B
9
6
7
20
2
22
30
ITEM NAME Q T Y
Body 
End Cap 
Ball 
A Seat•
B Seat Support 
Stem 
Body Seal•
Body Bolts *
 Anti-Static Device 
 -  Valves
 PARTS IDENTIFICATION (Continued)
ITEM NAME Q T Y
A Thrust Washer Protector•
B Packing Protector•
 Thrust Washer•
 Stem Bearing•
 Stem Packing Set•
 Packing Gland 
 Packing Gland Follower 
 Gland Bolts 
 Stop Housing 
•Recommended spare parts
that are available as a
packaged repair kit
* Quantity of Body Bolts per valve
size
 Valves - 
 Valves - 
 Valves - 
 Valves - 
ITEM NAME Q T Y
 Housing Bolts 
 Travel Stop 
 Handle 
 Handle Junction 
 Handle Setscrew 
 Snap Ring 

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
8 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
 GENERAL INFORMATION FOR ON-SITE INSTALLATION
The valve may be installed in any orientation on the pipeline and
should be installed in the full open position Ensure the adjoining
pipe on each end of the valve is aligned to prevent external
piping loads Piping misalignment may cause excessive external
loads on the valve resulting in body joint leaks
Before installing the valves the pipes must be flushed clean of
dirt burrs and welding residues or the seats and ball surface
will be damaged If for any reason the valve is installed prior to
flushing of the piping system the valve must remain in the full
open position until the piping system has been fully flushed clean
of debris
For hydrostatic testing of the piping system the valves must be
placed in the full or half open position prior to pressurizing the
system
NOTICE
Hydrostatic system testing with the valve in the closed position
may result in damage to the valve seats aecting their ability
to create a proper seal Failure to implement the installation and
testing instructions as outlined resulting in a valve failure will
void the warranty coverage of the product
As shipped from the factory valves may contain silicone
based lubricant This is for break-in and may be removed by
disassembly and solvent washing if it is objectionable for a
particular application
 Use
The valve should be maintained as part of a preventative
maintenance program and in accordance with manufacturer’s
recommended pressure temperature and corrosion limits to
ensure a long service life During shipment storage and in
operation the valve should be fully open or fully closed (“open”
is preferred for shipping and storage) Do not use in throttling
service without investigating flow and pressure conditions
WARNING
Before installing this equipment confirm that it is suitable for the
intended service
The identification tags describe the maximum allowable service
conditions for this product
Be sure that the installation is protected by appropriate pressure
control and safety devices to ensure that acceptable limits are
not exceeded

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
9 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
 SAFETY TIPS AND WARNINGS
 Read completely and understand all instructions provided
prior to beginning installation or maintenance
 Follow all instructions as described using the correct tools for
the job
 Before installing this equipment confirm that it is suitable for
the intended service
 The identifications tags describe the maximum allowable
service conditions for this product
 Be sure that the installation is protected by appropriate
pressure control and safety devices to ensure that acceptable
limits are not exceeded
 Remove actuation air and power connections and confirm
that there is no stored energy in the actuation such as
compressed springs or trapped air before beginning Stored
energy devices can cause serious injury if the energy is
released without warning
 Confirm that line pressure has been removed and that there
is no pressure trapped within the valve prior to beginning
service Do not attempt to remove any packing components
or other fittings before confirming that pressure has been
completely removed!
 Do not begin service work without proper tools and
protective safety measures
 The work area should be clear of obstructions and other
safety hazards

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
10 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
 SHORT AND LONG-TERM STORAGE
 Short-Term Storage
Short-term storage is defined as storage of products and
equipment to be used in the construction of a project for periods
of one to three months Short-term storage must be carried out
in a controlled manner as follows
 Valves must be stored in a closed clean and dry
environment
 Ball valves should be stored in the fully open position to
protect the ball and seats
 Ball valves should remain in the original shipping container
and be placed on pallets of wood or other suitable materials
End protectors should remain on the valve ends to prevent
the entrance of dirt and removed only at time of installation
 Long-Term Storage
Long-term storage is defined as storage of products andor
equipment for periods longer than three months Long-term
storage must be carried out in a controlled manner as follows
 Valves must be stored in a closed clean and dry
environment
 Ball valves should be stored in the fully open position to
protect the ball and seats
 Ball valves should remain in the original shipping container
and be placed on pallets of wood or other suitable materials
End protectors should remain on the valve ends to prevent
the entrance of dirt and removed only at time of installation
 Periodically the valves should be checked to ensure the
above conditions are maintained
These are general guidelines for valve storage Please consult the
factory for information regarding specific requirements

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
11 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
 OPERATION
Operation of the valve is done by turning the handle a  turn
( degree turn) Clockwise to close counter clockwise to open
 Valve Open Position
The handle is parallel with the pipeline
 Valve in Closed Position
The handle is perpendicular to the pipeline
Valves with actuators should be checked for actuator-valve
alignment Misalignment will result in high operational torque and
damage to valve stem and seals

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
12 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
 STEM SEAL ADJUSTMENT
For  -  if slight leakage is noticed at the stem straighten
lock washer tab tighten stem gland nut in  turn increments
to compress the Belleville washers If Belleville washers are
compressed flat back stem gland nut o  turn Once
tightening is complete secure the lock washer tabs against the
stem gland nut
For sizes larger than  simply tighten gland bolts evenly
in  turn increments until the leak stops Be careful to not
over tighten the packing as this can result in excess operating
torque and accelerated wear of the packing See Table  for
recommended stem gland nut and gland bolt torque for a new
valve assembly When making packing adjustments while the
valve is in service torque values may vary due to cycle frequency
temperature and other operating conditions
WARNING
DO NOT remove stem gland nut gland bolts or any other
pressure containing parts while line is under pressure!
Stem seal leakage may be corrected without disassembly of the
valve by tightening the stem gland nut or gland bolts (dependent
on valve size) until such leakage stops If the leakage continues
or valve operating torque becomes excessive the seals are worn
and replacement will be necessary
Table  - Recommended Stem Gland NutGland Bolt Torque
Valve Size
NPS Recommended Torque lb-in Valve Size DN Recommended Torque N m
  
   
   
  
-   
-   
  
-   
  
  
  
  
   
   

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
13 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
 INSTALLATION
 Installation of Threaded End Valves
The use of a thread sealant is recommended use conventional
sealant such as hemp core Teflon etc
Apply wrench only on the hexoctagon nearest the valve end
being tightened Do not tighten by applying torque to the
opposite end cap or other valve component Tightening by using
the valve body handle or the opposite end cap can seriously
damage the valve use a wrench on both the near end cap and
pipe to avoid applying torque to the body through the bolting
In some applications threaded end valves may be back-welded
on site Confirm that the end cap bolt holes are aligned with the
body bolt holes on both ends and that the end caps are parallel
and correctly spaced to fit the valve body before re-assembly
or back welding Make up both of the threaded connections
normally and then remove the body assembly as described in
Section  for weld-end connections before back welding the
threaded connection
Do not use the body boltsstuds to pull the pipe ends together or
into alignment
 INSTALLATION OF WELD-END VALVES
(   &  Series)
Ensure that weld procedures are implemented that are
compatible with the materials used
Tack weld the valve to the pipe at four points on both end caps
With the valve in open position (the valve is in the open position
when the handle is parallel to the axis of the valve and pipe)
loosen all body bolts and remove the body from between the end
caps
Turn the handle to the half open position Remove the seats and
body gaskets
Turn handle to the closed position and remove ball
Place all removed parts in a clean and secure place
Replace the body and all body bolts between the end caps and
tighten them slightly This operation is very important so that the
body and end caps remain perfectly parallel thus preventing any
leakage at the body joint after welding
Finish welding both end caps onto the pipe
When cool remove the body clean end caps and reassemble per
instructions in Section 
NOTICE
Use a spare body gasket for reassembly as the original body
gasket will have been compressed during the original assembly
and tightening of the body bolts

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
14 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
Place body between the two end connections then replace all
body bolts and cross tighten per the torque values in Table 
 Installation of Extended Weld End Valve
Ensure that weld procedures are implemented that are
compatible with the materials used
Weld end valves with  inch or longer extended weld ends do not
require disassembly for installation welding
Ensure that ball is in the full open position and perform normal
welding procedures using care that the valve body does not
reach a temperature above F Use a temperature indicator
stick to monitor the body temperature especially near the body
to end cap joint
Table  - Recommended Torque for Body BoltsBody Nuts
Valve Size
NPS Recommended Torque lb-in Valve Size DN Recommended Torque N m
  
   
   
  
-   
-   
  
-   
  
  
  
  
   
   
NOTICE
Body boltsbody nuts must be tightened in a cross or star
pattern depending on the quantity of bolts to prevent uneven
loading of the body seal

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
15 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
 DISASSEMBLY PROCEDURE
CAUTION
Line must be depressurized before disassembly Valve should be
cycled after draining the system to relieve any pressure trapped
in valve cavity Ball valves can trap pressurized media when
closed Flush line with valve  open to remove hazardous
media If the valve has been used to control hazardous media it
must be decontaminated before disassembly
WARNING
DO NOT attempt to remove packing components or any other
valve parts while line is under pressure!
CAUTION
Properly support the valve before removing or loosening any
body bolts The larger sizes are heavy and may cause injury if
allowed to swing or fall freely
Remove actuation air and power connections and confirm that
there is no stored energy in the actuation such as compressed
springs or trapped air before beginning Stored energy devices
can cause serious injury if the energy is released without warning
 Disassembly for Stem and Seal Service
It is not necessary to remove the flanges from the pipeline
Removing any actuation and controls may make service easier
For valves sizes up to and including  you may remove one of
the upper body bolts and loosen the remaining bolts The center
body will swing out for service leaving the end caps in place on
the pipe ends It is not recommended to perform in-line service
for valves ” and larger by swinging the center section out due to
the size and weight of the body center section
To completely remove the valve from the pipeline remove the
remaining upper body bolt and the body will lift free Gently
support the body in a vise to complete the remainder of the
disassembly To avoid damage to the seal surfaces hold the body
horizontally across its diameter not across the end faces
Remove the seats body seals and seat supports (if applicable)
 thru - sizes Remove the handle nut and handle
Straighten the tab on the tab lock washer and remove the stem
gland nut Remove the tab lock washer Belleville washers and
packing gland
 and  sizes Loosen the handle set screw and remove the
handle Remove the snap ring travel stop housing bolts and stop
housing Remove the gland bolts packing gland follower and
packing gland

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
16 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
 thru  sizes Loosen the handle junction set screw and
remove the handle assembly Remove the snap ring travel stop
housing bolts and stop housing Remove the gland bolts packing
gland follower and packing gland
To remove the ball rotate the stem so the ball is fully closed
Lift the ball from body using a strap and lift device if necessary
NOTE Extreme caution should be taken to avoid damage to the
ball
The stem must be removed from inside the body - a tap on the
top of the stem should loosen it The thrust washer thrust washer
protector and stem bearing (if applicable) should come out with
removal of the stem Then remove the stem packing set and
packing protector from the packing box A screw driver or pick
may be required to remove the packing rings Use caution not to
scratch the inner diameter of the packing box as this may aect
the ability to properly seal
NOTE Disassembly for servicing seats and stem seals may be
performed without removing the end flanges from the pipeline
This feature allows the removal of the valve from service without
disturbing piping connections

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
17 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
 VISUAL INSPECTION
Clean and inspect metal parts It is not necessary to replace the
ball and stem unless the sealing surfaces have been damaged
by abrasion or corrosion Replacement of all soft parts is
strongly recommended whenever the valve is disassembled for
reconditioning to protect against subsequent leakage after valve
reassembly The soft good replacement parts can be ordered in
kit form
NOTE The valve may be assembled and operated dry where no
lubricants are allowed in the system however a light lubrication
of mating parts will aid in assembly and reduce initial operating
torque Lubricant used must be compatible with the intended line
fluid

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
18 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
 VALVE RE-ASSEMBLY
  -  Valve Re-Assembly Procedures - Refer to page 
Hold the body horizontally in a vise firmly enough that it will not
move but do not crush it
Put thrust washer protector and thrust washer on valve stem and
insert the stem into the stem bore from inside valve body
Slide the stem packing set onto the stem until they are fully
inserted into the packing box
Put packing protector and packing gland onto the stem on top of
the packing set
Install the Belleville washers tab lock washer and stem gland nut
onto the stem Tighten hand tight
Note The Belleville washers are to be installed in an alternating
orientation with the concave side of the washers facing each
other
Turn the stem until the upper stem flat is perpendicular to the
valve centerline (closed so that the ball can fit onto the stem)
Install the ball inside the valve body The lower stem flats will fit
into the slot on top of the ball
Turn the stem so that the ball is in the open position (the ball will
not fall out of the valve)
Install the seats and body seals into the body ends Make sure the
spherical curvature side of the seat will face the ball
Lift the valve into position between the flanges in the pipeline
Install the body bolts spring lock washers and body nuts Cross
tighten all nuts to the values indicated in Table 
Note The use of a bore alignment tool about  mm ( inch)
less than the internal diameter of the end cap and ball inserted
through the end cap and ball will prevent the ball from turning as
the stem gland nut is lightened on the stem
The bore alignment tool should be made from a material softer
than  Series SS so that it will not inadvertently scratch the
valve end cap or ball Suggested materials aluminum T
Acetal or other suitable hard polymerplastic material
Tighten the stem gland nut to the recommended torque values in
Table  If a slight leak is noticed at the stem once back in service
continue tightening the stem gland nut in  turn increments to
compress the Belleville washers until a seal is achieved Secure
the tab lock washer by bending tabs up to contact the side of
the stem gland nut Place the handle onto the stem on top of the
stem gland nut
Secure the handle with the handle nut
Cycle the valve slowly several times By cycling slowly the seats
will align with and conform to the ball A fast turning motion
initially may damage the seats before they have a chance to form
the proper seal

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
19 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
Refer to the operation and stem seal adjustment instructions
provided to commission the valve after re-installation if
necessary
For automated installations follow the instructions provided with
actuation instrumentation to correctly set up and recalibrate the
installation
  &  Valve Re-Assembly Procedures - Refer to page 
Hold the body horizontally in a vise firmly enough so it will not
move but do not crush it
Install the stem bearing thrust washer protector and thrust
washer onto the valve stem and insert the stem into the stem
bore in the valve body
Slide the stem packing set onto the stem until it is fully inserted
into the packing box
Place packing protector then packing gland on top of the stem
packing
Install packing gland follower and gland bolts Lightly tighten the
gland bolts to secure the packing gland follower
Install stop housing and housing bolts hand tight Install travel
stop and snap ring
Rotate the stem to the closed position (the upper stem flat is
perpendicular to the port centerline) and install the ball inside the
valve body The lower stem flats will fit into the slot on top of the
ball
Turn the stem so that the ball is in the open position and the
upper stem flat is parallel to the bore centerline The ball will not
fall out of the valve
Install the seats and body seals into the body ends Make sure the
spherical curvature side of the seat will face the ball
Lift the valve into position between the flanges in the pipeline
Install the body studs tab lock washers and body nuts Cross
tighten all body nuts to the values indicated in Table 
Finish tightening the gland bolts to the recommended gland bolt
torques shown in Table  Over tightening can result in excess
torque and accelerated wear of the packing
Secure the handle with the handle set screw
Cycle the valve slowly several times By cycling slowly the seats
will align with and conform to the ball A fast turning motion
initially may damage the seats before they have a chance to form
the proper seal
Refer to the operation and stem seal adjustment instructions
provided to commission the valve after re-installation if
necessary
For automated installations follow the instructions provided with
actuation instrumentation to correctly set up and recalibrate the
installation

FLOW-TEK SERIES 7000/8000
3-PIECE FULL PORT BALL VALVES
Installation, Operation, and Maintenance Manual
20 of 22©  BRAY INTERNATIONAL INC ALL RIGHTS RESERVED BRAYCOM The Information
contained herein shall not be copied transferred conveyed or displayed in any manner that would
violate its proprietary nature without the express written permission of Bray International Inc
  -  Valve Re-Assembly - Refer to page 
Hold the body horizontally in a vise firmly enough so it will not
move but do not crush it
Install the stem bearing thrust washer protector and thrust
washer onto the valve stem and insert the stem into the stem
bore on the valve body
Slide the stem packing set onto the stem until it is fully inserted
into the packing box
Place packing protector then packing gland onto the stem on
top of the stem packing
Install packing gland follower and the gland bolts Lightly tighten
the gland bolts to secure the packing gland follower
Install stop housing and housing bolts hand tight Install travel
stop and snap ring
Rotate the stem to the closed position (the upper stem flat is
perpendicular to the port centerline) and install the ball inside the
valve body The lower stem flats will fit into the slot on top of the
ball
Turn the stem so that the ball is in the open position and the
upper stem flat is parallel to the bore centerline The ball will not
fall out of the valve
Install the seats seat supports and body seals into the body
ends Make sure the spherical curvature side of the seat faces the
ball
Lift the valve into position between the flanges in the pipeline
Install the body bolts Tighten the body bolts in a star pattern to
the values indicated in Table 
Finish tightening the gland bolts to the recommended gland bolt
torques shown in Table  Over tightening can result in excess
torque and accelerated wear of the packing
Install the handle junction onto the valve stem Secure in place
with one of the handle setscrews provided
Secure the handle with the remaining handle setscrew
Cycle the valve slowly several times The seats will align with and
conform to the ball A fast turning motion initially may damage
the seats before they have a chance to form the proper seal
Refer to the operation and stem seal adjustment instructions
provided to commission the valve after re-installation if
necessary
For automated installations follow the instructions provided with
actuation instrumentation to correctly set up and recalibrate the
installation
