Breville Slice'n'Carve Cordless User manual

the Slice ‘n’ Carve™ Cordless
Instruction Book - LEK200

2
BREVILLE
RECOMMENDS SAFETY
FIRST
At Breville we are very safety conscious.
We design and manufacture consumer
products with the safety of you, our valued
customer, foremost in mind. In addition,
we ask that you exercise a degree of care
when using any electrical appliance and
adhere to the following precautions.
2Breville Recommends Safety First
7Components
8Functions
12 Slicing Hints
13 Care & Cleaning
14 Troubleshooting
15 Battery Disposal
Contents

3
IMPORTANT
SAFEGUARDS
READ ALL INSTRUCTIONS BEFORE
USE AND SAVE FOR FUTURE
REFERENCE
• Do not immerse the knife body or USB
cord in water or any other liquid.
• Do not remove knife blades from the knife
body whilst blades are in operation.
• Do not place your hands near the blades
when the knife is in operation.
• Switch o the power outlet and remove the
USB plug before removing the blades and/
or cleaning.
• Press the LOCK button after use to ensure
no unintentional operation.
• Make sure the motor and blades have
completely stopped before disassembling.
• The appliance is not intended for use by
young children or infirm persons without
supervision.
• Do not leave the appliance unattended
when in use. Young children should be
supervised to ensure that they do not play
with the appliance. Keep out of reach of
children.
• Do not let the USB cord hang over the
edge of a table or counter, touch hot
surfaces or become knotted.
• Do not place this appliance on or near a
hot gas or electric burner, or where it could
touch a heated oven.
• This appliance is for household use only.

4
• Do not use this appliance for anything
other than its intended use. Do not use
outdoors.
• Regularly inspect the USB cord, plug
and actual appliance for any damage. If
found damaged in any way, immediately
cease use of the appliance and return the
entire appliance to the nearest authorised
Breville service centre for examination,
replacement and repair.
• Disconnect the USB cord before
assembling or before cleaning and when
the knife is not in use.
• Never carry the knife by the USB cord.
• Never yank the USB connector to
disconnect the USB cord from the USB
port; instead, grasp the USB connector as
close to the connection as possible and
pull to disconnect.
• Do not twist or pull the USB cord around
sharp edges or corners.
• Ensure that the USB port is free of any
debris before inserting USB cord.
• The battery is non-replaceable. Please refer
to the battery disposal instructions on
page 15.
IMPORTANT SAFEGUARDS
FOR ALL ELECTRICAL
APPLIANCES
• Fully unwind the power cord before use.
• Do not let the power cord hang over
the edge of a bench or table, touch hot
surfaces or become knotted.

5
• To protect against electric shock do not
immerse the power cord, power plug or
appliance in water or any other liquid.
• The appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for their
safety.
• Children should be supervised to ensure
that they do not play with the appliance.
• It is recommended to regularly inspect the
appliance. To avoid a hazard do not use
the appliance if power cord, power plug or
appliance becomes damaged in any way.
Return the entire appliance to the nearest
authorised Breville Service Centre for
examination and/or repair.
• Any maintenance other than cleaning
should be performed at an authorised
Breville Service Centre.
• This appliance is for household use only.
Do not use this appliance for anything
other than its intended use. Do not use
in moving vehicles or boats. Do not use
outdoors. Misuse may cause injury.
• The installation of a residual current
device (safety switch) is recommended to
provide additional safety protection when
using electrical appliances. It is advisable
that a safety switch with a rated residual
operating current not exceeding 30mA be
installed in the electrical circuit supplying
the appliance. See your electrician for
professional advice.

6
PLEASE READ THE FOLLOWING WHEN
CHARGING THE KNIFE WITH USB
POWER ADAPTOR
• Use only an electrical safety compliant, DC
5V 1A (or a minimum of 5W) or 9V 2A
(Fast Charging), USB power adaptor (not
included).
• It must only be supplied at safety extra low
voltage corresponding to the marking on
the appliance.
• Fully unwind the USB cord before
attaching to the knife for charging.
• Connect the knife only with the USB cord
provided.
• To protect against electric shock, do not
immerse the USB cord or knife in water
or any other liquid or allow moisture to
come in contact with the part, unless it is
recommended in the cleaning instructions.
• It is recommended to regularly inspect
the knife and USB cord. To avoid a hazard,
do not use the knife or USB cord if they
become damaged in any way. If the knife
is faulty, return the knife and the USB cord
provided to the nearest authorized Breville
service centre for examination and or
repair.
• During electrical storms, while charging,
the knife should be disconnected from the
power source at the wall socket to prevent
any electrical surges that may arise during
the storm and which may inadvertently
cause damage to the knife and its
electronic components.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS

7
Components
A. Motor body/handle with
11.1V 1500mAh battery
B. ON/OFF Trigger
C. Battery life indicator light
D. Blades release button
(from motor body)
E. Safety lock button
F. Stainless steel serrated
short blade set
G. Stainless steel serrated
long blade set
H. Blades safety handling
guards
I. Blades throngs for
attaching to motor body
J. Blades storage case
K. Blades release button
(from storage case)
L. USB cord for charging
A
H
I
B
C
K
F G
D
JE
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
L

8
Functions
The Breville Slice ‘n’ Carve™
cordless electric knife
comes with an inbuilt 11.1V
1500mAh battery and is
designed for convenient,
cordless usage. Once fully
charged, the electric knife
can operate for up to 25
minutes before charging is
required, making it ideal for
camping, picnics or carving
at the table.
NOTE
For safety, the electric knife
can operate continuously
for up to 1 minute, then will
stop automatically. Press the
trigger again to continue
operation.
BEFORE FIRST USE
1. Before using your electric
knife for the first time,
remove all packaging
material and promotional
labels.
2. Check for any missing or
damaged parts as per the
components list.
3. Clean all parts according
to the Care, Cleaning &
Storage section of this
book.
4. To check the current
battery life, use the
provided USB cord to
connect to a power source.
The trigger will illuminate
a colour that indicates the
current % of battery life.
Refer to the table titled
Charging Colour Table
found in this booklet for
more details.
NOTE
This electric knife comes
with a charging cable only.
A power adaptor is not
included.
NOTE
It is recommended to fully
charge the battery before
first use. To maximise battery
longevity, avoid completely
discharging the battery.
CHARGING THE
BATTERY
The electric knife is fully
portable once charged, and
may take up to 2 hours to
recharge once the battery is
fully drained if connected to
an optimal charging source.
The electric knife can be
charged using the USB cord
provided and a compatible
electronic device or DC 5V
1A (or a minimum of 5W)
USB power adaptor (not
included).
In order to minimise charge
time, a DC9V 2A charger
can be used to recharge in
approximately 2 hours.
1. Ensuring that no blade
set is attached, connect
the provided USB cord
to the unit with a power
adaptor and plug into a
220-240V power outlet.
Alternatively, if equipped,
plug the charging cord
into a USB charging outlet
directly. The indicator

9
light on the trigger will
light up based on the
current battery life. Refer
to the Charging Colour
Table for more details.
The electric knife is now
being charged.
• From fully charged to
discharged, the knife
operating time is 25
minutes, depending
on the load. The
charge time will be
approximately 2
hours with a DC9V
2A charger.
• The indicator light on
the trigger will change
colours to indicate the
% of battery charge.
• Once the indicator
light illuminates
white, the electric
knife is fully charged
and ready to use.
• If operating the electric
knife while connected
to the charger, the unit
will continue to charge,
and the indicator light
will change colour
according to the % of
charge. Refer to the In
Operation Colour Table
found in this book.
Charging Colour Table
Colour % Battery
charged
Red (slow flashing) < 30%
White (slow flashing) > 30%
White 100%
In operation Colour Table
Colour % left on
battery
White > 30%
Red < 30%
Red (flashing) < 5%
BLADES ASSEMBLY
The Breville Slice ‘n’ Carve™
Cordless electric knife comes
with 2 stainless steel blade
set options. Each set is made
up of two interlocked blades
to create a cutting action. The
smaller serrated blade set is
perfect for smaller food tasks
such as tomatoes and sushi,
while the larger blade set suits
larger tasks such as bread
loaves and roasts.
CAUTION
The blades of your
rechargeable electric knife are
sharp! Handle with extreme
care. We recommend holding
the blade set by the safety
guards at all times when
handling the blades. Never
attempt to fit or remove the
blades whilst the knife is in
operation Ensure the knife is
switched o before removing
and changing the blades.
1. To insert, select the
matching size of blade set
appropriate to the task.
The two blades for that set
must be interlocked before
inserting into the electric
knife body. To interlock the
blades, hold the shaft ends
below the safety guards and
slip the rivet found on one
blade onto the tip of the
other blade.
NOTE
Always use both blades in the
blade set when operating the
electric knife.

10
2. Hold the assembled
blades by the safety
guards and insert blades
into the individual blade
slots (See Fig. 1). A click
will sound when locked
into position.
Fig. 1
NOTE
Ensure both blades in the
blade set click into position
before use.
NOTE
This knife was tested by
slicing through the length of
a hard sausage. The sausage
is approximately 55 mm in
diameter and cut into slices
approximately 5 mm thick.
The sausage is stored for at
least 4 hours at a temperature
of 23°C ± 2°C before slicing.
BLADES DISASSEMBLY
Ensure the electric knife
is not turned on before
disassembling the blade set
from the unit. The light ring
should not illuminate.
1. Hold the blades by the
safety guard, aimed away
from the body and press
the BLADE RELEASE
button on the body to
eject and lift the blade set
out.
2. To return the blade set
to the blades storage
case, press and hold the
RELEASE button on the
storage case and holding
the knife set by the safety
guard, place the blade into
the slots and push in (See
Fig. 2).
Fig. 2
