Brickcom MD-100Ae User manual

Megapixel
Mini Dome Network Camera
MD-100A Series
PS-588I
8-port 10/100M PoE Fast
Ethernet Switch
PS-7242IL-AF
24-port 10/100M PoE Web
Smart Ethernet Switch
Dimension Diagram (MD-100A Series)
▪H.264, MPEG-4 and MJPEG Triple Codec Compression with Dual
Simultaneous Streaming
▪Inconspicuous, Sleek Design
▪Built-in Microphone(*)
▪Wide Angle Lens(*)
▪3G USB Dongle Support(*)
▪Built-in Micro SD/SDHC Memory Card Slot for Local Storage(*)
▪Built-in 802.3af Compliant Power over Ethernet (PoE)
▪Anti Vibration and Shock(EN50155)
▪Weather and Vandal-proof Casing (IP67, IK10)
▪EasyConfig for Easy Set Up and GUI Integration
▪Unique Profile Setting for Variable Environment
1. Microphone Hole(*)
2. Security Screws
3. Screw Hole
4. LED Indicators
5. Reset Button
6. Micro SD/SDHC Card Slot(*)
7. Lens Hood
8. Lens
9. USB Port for 3G Dongle(*)
Network Equipment

Model Number
MD-100Ae –IP-67 / Vandal-proof/ PoE/
EN50155
MD-100Ap –IP-67 / Vandal-proof/ PoE/
EN50155/ Local Storage/ Wide Angel Lens/
Built-in Microphone
Hardware System
CPU: 500 MHz
Flash: 16M
RAM: 128M DDR
Image Sensor
Sensor Type : 1/4” CMOS Megapixel Sensor
Sensor Resolution : 1280 x 800 pixel
Minimum Illumination : 5 Lux(F2.0,Color)
3 Lux(F2.0, B/W)
Lens
Lens Type : Board Lens
MD-100Ap/ MD-100Ae
Focal Length: f= 2.86 mm
F-number: F2.0
ViewAngle (Hor): 85°(Ver): 52°(Dia): 104°
Communication
Ethernet : one 10/100Mbps RJ-45
Supported Protocols : TCP/IP, UDP, ICMP,
DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP,
Samba, PPPoE, UPnP, RTP, RTSP,
RTCP
Interface &
Buttons
MD-100Ae
Ethernet Cable Connector(PoE)
Reset Button
MD-100Ap
Ethernet Cable Connector(PoE)
Reset Button
Built-in Microphone
Micro SD/SDHC Card Slot
USB Port for 3G Dongle(Optional)
Power input
802.3af Compliant Power on Ethernet (PoE)
LEDs
Power
Status
Internet
Max. Power
Consumption
MD-100Ae
3.5 watt
MD-100Ap
3.8 watt
Environment
Water Proof: IP67
Operating Temperature :
-20°C ~ 50°C (-4°F ~122°F),
Operating Humidity :
10% ~ 80%
Dimension
Ø 110 mm x 45 mm
Weight
335g
Certification
FCC, CE, EN50155, IK10
Warranty
Limited 2-year warranty
Video Image
Compression
H.264 / MPEG4 / MJPEG
Video Setting
Auto Exposure Control:
Sport/ Normal/ Night Vision/ User Defined
Auto Gain Control: 1X~5X
Shutter Speed: 1/5~1/20000 sec
S/N Ratio
39dB
Image Resolution
16:10
- 1280 x 800 / 640 x 400 / 320 x 192
16:9
- 1280 x 720 / 640 x 352 / 320 x 176
4:3
- 640 x 480 / 320 x 240
Frame Rate at
Max. Resolution
MD-100Ae
H.264: 15 fps
MPEG4: 15 fps
MJPEG: 30 fps
MD-100Ap
H.264: 30 fps
MPEG4: 15 fps
MJPEG: 30 fps
Audio Streaming
MD-100Ap
One-way audio support
Audio
Compression
G.711, AMR (8 kHz, Mono, PCM)
Audio Input
MD-100Ap
Built-in Microphone
Camera
Video
Network
General
Brickcom Corporation Headquarters
Address: No.1 Jen Ai Rd, Hsinchu Industrial Park, Hukou, Hsinchu, Taiwan,
R.O.C. 303 Tel: + 886-3-5982022 Fax: + 886-3-5982023
Mail: [e-mail] http://www.brickcom.com
(*) These are optional features. Please refer to the Buying Guide for the full
list of optional features available for this product.
