Brighter 6X40W User manual

6X40W Led Moving Beam Bar with Zoom
Panel Zoom RGBW
reference.
future
for
place
safe
a
in
manual
this
keep
and
carefully
instructions
these
follow
and
read
Please
projector.
this
of
use
and
installation
safe
the
about
information
important
contains
manual
product
This
Please read the instructions carefully before use
User manual

1. Checking before using
No.
Item
Quan
tity
Unit
1
Color Pixel Strobe-RGBW Light
1
piece
2
Power cable with blue head
1
piece
3
User manual
1
piece
★For security reasons and in accordance with the terms, reassemble or modify the product is not allowed without
permission. Please note that due to human damage caused by improper use of the product, it will break the
warranty qualification. Moreover, the unprofessional operation may lead to short circuits, burns or electric shock,
and so on.
★This device has been full inspection before shipping. For your safety, please operate it according the User
Manual.
★If any damage caused by improper operation will result in the termination of the warranty claims. The
manufacturer does not accept any responsibility of property damage due to improper operation or personal injury
due to non-compliance with the operating instructions.
★Keep the manual in a safe place for future reference as well as after the product sale, lease, etc.
★Note: Based on product improvements, specification may change without notice. Changes in product
specifications related rights will be reserved.
2. Safety Instruction

1. When opening the packing, take all accessories out, and remove the light to a horizontal table for good
operation. First check whether the accessories are complete, then check carefully whether the whole light has no
damage. If there is any damage, please contact us as soon as possible.
2. AC Power: Check whether the local power supply is accordance with the
requirements of the product rated voltage.
3. The product is only suitable for indoor working environment. The light should
keep dry, keep away from wet, overheat or dusty environment. Don't come into contact with water and other
liquids to prevent or reduce the risk of electric shock or fire.
4. Please do not install the light directly on the surface of the combustible substance.
5. The people who install, operate and maintain of light professional certificate required.
6. When there are faults of the light, please stop using the light immediately. Don't try to repair, please contact the
nearest authorized technical assistance center, if the parts damage, always use the same type of parts replaced.
7. Don't touch any electrical wiring in the process of operation to prevent the risk of electric shock.
8. To make sure the light working environment temperature, the highest do not exceed 40℃, the lowest do not
exceed - 20 ℃.
9. Under the stable cooling working situation, the highest temperature of the housing of the light can reach 80 ℃,
please do not touch.
10. The light is design according to the type of electric shock protection. The light should be use in good
connection grounding power system and the earth sign port of the light should be connected to the installing
fixtures.
11. Do not use the damage of the insulating layer wire and also do not use the power cord overlap on the other
wire. When not in use or clean the light, please disconnect the power, don't pull the plug in hard or just drag the
wires.
12. There are no components inside for maintenance. Before start operation the light, please check whether all of
the shell is installed. In the case of the shell open used the light is prohibited.
Note: Before performing any installation, repair and cleaning of the lamp, please confirm that the
power cable has been cut off.

3. Product specification
1. Voltage: AC100-240V 50-60Hz
2. Power Consumption:260W
3. Light Source: 6×40w RGBW
4. Beam Angle: 5-45°
5. Source life: 100,000 hours
6. Color: 1670 million kinds of colors
7. Working modes: Sound (Audio) Active, Show Mode, DMX, Master/ Slave.
8. Powercon: Input / Output
9. DMX Channel: 14CH/15CH/27CH/39CH
10. W:8.5KG
11.Size: 670*180*350mm
4. LCD Display Function Instruction

5. DMX 512 Channel-27CH
27CH
Function
DMX Value
Description
1
Tilt
0-255
0-100%
2
Tilt Fine
0-255
0-100%
3
Zoom
0-255
0-100%
4
Red1
0-255
0-100%
5
Green1
0-255
0-100%
6
Blue1
0-255
0-100%
7
White1
0-255
0-100%
8
Red2
0-255
0-100%
9
Green2
0-255
0-100%
10
Blue2
0-255
0-100%
11
White2
0-255
0-100%
…
……
…
…

6. DMX 512 Channel-15CH
15CH
Function
DMX Value
Description
1
Tilt
0-255
0-100%
2
Tilt Fine
0-255
0-100%
3
Zoom
0-255
0-100%
4
Dimmer
0-255
0-100%
5
Strobe
0-19
No Effect
20-255
Strobe slow to fast
6
Red
0-255
0-100%
7
Green
0-255
0-100%
8
Blue
0-255
0-100%
9
White
0-255
0-100%
10
Color Macro
0-10
No Function
11-30
R 100%,G 50-100-50%,B 0
31-50
R 100%-0,G 100%, B,0
51-70
R 0,G 100%,B 0-100%
71-90
R 0,G 100%-0,B 100%

91-110
R 0-100%, G 0, B 100%
111-130
R 100%,G 0, B 100%-0
131-150
R 100% ,G 0-100% ,B 0-100%
151-170
R 100%-0 , G 100%-0 , B 100%
171-200
R 100%,G 100%, B 100%
201-205
Color 1
206-210
Color 2
211-215
Color 3
216-220
Color 4
221-225
Color 5
226-230
Color 6
231-235
Color 7
236-240
Color 8
241-245
Color 9
246-250
Color 10
251-255
Color 11
11
Foreground Dimmer
0-255
0-100%

12
Background
0-10
No Function
11-255
Background Color
13
Background Dimmer
0-255
0-100%
14
Show
0-10
No Function
11-15
Show1
16-20
Show2
21-25
Show3
26-30
Show4
31-35
Show5
36-40
Show6
41-45
Show7
46-50
Show8
51-55
Show9
56-60
Show10
61-65
Show11
66-70
Show12
71-75
Show13

76-80
Show14
81-85
Show15
86-90
Show16
91-95
Show17
96-100
Show18
101-105
Show19
106-110
Show20
111-115
Show21
116-120
Show22
121-125
Show23
126-130
Show24
131-135
Show25
136-140
Show26
141-145
Show27
146-150
Show28
151-155
Show29
156-160
Show30

161-165
Show31
166-170
Show32
171-175
Show33
176-180
Show34
181-185
Show35
186-190
Show36
191-195
Show37
196-200
Show38
201-205
Show39
206-210
Show40
211-215
Show41
216-220
Show42
221-235
Show43
236-245
Sound1
246-255
Sound2
15
Show Speed
0-127
Show Speed Slow to Fast &XY
128-254
Show Speed Slow to Fast

255
reset
7. DMX 512 Channel-39CH
39CH
Function
DMX Value
Description
1
Tilt
0-255
0-100%
2
Tilt Fine
0-255
0-100%
3
Zoom
0-255
0-100%
4
Dimmer
0-255
0-100%
5
Strobe
0-19
No Effect
20-255
Strobe slow to fast
6
Red
0-255
0-100%
7
Green
0-255
0-100%
8
Blue
0-255
0-100%
9
White
0-255
0-100%
10
Color Macro
0-10
No Function
11-30
R 100%,G 50-100-50%,B 0

31-50
R 100%-0,G 100%, B,0
51-70
R 0,G 100%,B 0-100%
71-90
R 0,G 100%-0,B 100%
91-110
R 0-100%, G 0, B 100%
111-130
R 100%,G 0, B 100%-0
131-150
R 100% ,G 0-100% ,B 0-100%
151-170
R 100%-0 , G 100%-0 , B 100%
171-200
R 100%,G 100%, B 100%
201-205
Color 1
206-210
Color 2
211-215
Color 3
216-220
Color 4
221-225
Color 5
226-230
Color 6
231-235
Color 7
236-240
Color 8
241-245
Color 9

246-250
Color 10
251-255
Color 11
11
Foreground Dimmer
0-255
0-100%
12
Background
0-10
No Function
11-255
Background Color
13
Background Dimmer
0-255
0-100%
14
Show
0-10
No Function
11-15
Show1
16-20
Show2
21-25
Show3
26-30
Show4
31-35
Show5
36-40
Show6
41-45
Show7
46-50
Show8
51-55
Show9
56-60
Show10

61-65
Show11
66-70
Show12
71-75
Show13
76-80
Show14
81-85
Show15
86-90
Show16
91-95
Show17
96-100
Show18
101-105
Show19
106-110
Show20
111-115
Show21
116-120
Show22
121-125
Show23
126-130
Show24
131-135
Show25
136-140
Show26
141-145
Show27

146-150
Show28
151-155
Show29
156-160
Show30
161-165
Show31
166-170
Show32
171-175
Show33
176-180
Show34
181-185
Show35
186-190
Show36
191-195
Show37
196-200
Show38
201-205
Show39
206-210
Show40
211-215
Show41
216-220
Show42
221-235
Show43
236-245
Sound1

246-255
Sound2
15
Show Speed
0-127
Show Speed Slow to Fast &XY
128-254
Show Speed Slow to Fast
255
reset
16
White1
0-255
0-100%
:
8. DMX 512 Channel-14CH
14CH
Function
DMX Value
Description
1
Tilt
0-255
0-100%
2
Tilt Fine
0-255
0-100%
3
Zoom
0-255
0-100%
4
Dimmer
0-255
0-100%
5
Strobe
0-19
No Effect
20-255
Strobe slow to fast
6
1 Color Select
0-10
No Function

11-25
Red
24-40
Green
41-55
Blue
56-70
White
71-85
R +G
86-100
R+B
101-115
G+B
116-130
R+W
131-145
G+W
146-160
B+W
161-175
R+G+W
176-190
R+B+W
191-205
G+B+W
206-255
R+G+B+W
：
11
12 Color Select
0-10
No Function
11-25
Red

24-40
Green
41-55
Blue
56-70
White
71-85
R +G
86-100
R+B
101-115
G+B
116-130
R+W
131-145
G+W
146-160
B+W
161-175
R+G+W
176-190
R+B+W
191-205
G+B+W
206-255
R+G+B+W
12
Background Dimmer
0-255
0-100%
13
Show
0-10
No Function
11-15
Show1
16-20
Show2

21-25
Show3
26-30
Show4
31-35
Show5
36-40
Show6
41-45
Show7
46-50
Show8
51-55
Show9
56-60
Show10
61-65
Show11
66-70
Show12
71-75
Show13
76-80
Show14
81-85
Show15
86-90
Show16
91-95
Show17
96-100
Show18
101-105
Show19

106-110
Show20
111-115
Show21
116-120
Show22
121-125
Show23
126-130
Show24
131-135
Show25
136-140
Show26
141-145
Show27
146-150
Show28
151-155
Show29
156-160
Show30
161-165
Show31
166-170
Show32
171-175
Show33
176-180
Show34
181-185
Show35
186-190
Show36
