Brighter PRO BAR 18IP User manual

PRO BAR 18IP
18IP
18x18W RGBWAUV Waterproof Pixelbar
This product manual contains important information about the
safe installation and use of this projector. Please read and follow
these instructions carefully and keep this manual in a safe place
for future reference.
User manual
Please read the instructions carefully before use

1.The introduction of led display panel：
A．Menu
B．UP
C．Down
D．Enter
E．Led display Window
A B C D
Operating introduction：Press A button, there will be 8 different functions.
The first two letters stands for functions (Refer to Diagram 2).
The last two letters stands for DMX Address or speed.
You can modify it with B or C button. And press D button for confirmation.
2. Functions from led display window(Press D to confirm all
the functions).
No.
Display
Functions
1
A001
CH code，add code by changing B.C button（001—
512）
2
29ch/11ch/119ch/108ch
Choosing CH （options: 29CH,11CH,119CH,108CH
by changing C.B Button)
3
CC00
Color jump to change,by changing B.C button to
modify the speed. (01—99）
4
Ed00
Color pulse，by changing B.C button to changed the
speed.（01—99）
5
Er00
Color running 1，by changing B.C button to changed
the speed.（01—99）(Setting ID to have water
running
effects by a group light work.)
6
Po00
Color running 2，by changing B.C button to changed
the speed.（01—99）(Setting ID to have water
running
effects by a group light work.)
7
tr00
ways of running effect，（00—8）by
changing B.C button to changed the ways.
8
tU00
Speed of running effect，（00—99）by
changing B.C button to changed the speed.
9
BE50
Sound control running change. by changing B.C button
to change the sensitivity.
10
R200
R color，（000—255）.
11
G200
B color，（000—255）
12
B200
G color，（000—255）
13
W200
W color，（000—255）

14
Y200
A color，（000—255）
15
P200
UV color，（000—255）
16
ID00
DMX 512 ID ，（ 01 — 14 ） change B.C to modify ID. (a
group of lights working, can have a group pixel
running effects).
3.DMX512
11 CH Explanation
Channels
Functions
Explanation
CH1
General
R.G. B.W.A.UV linear 0%~100% dimmer. from dark to bright.
Dimmer
CH2
General strobe
R.G.B. W.A.UV Strobe, from slow to fast
CH3
Control Mode
0--25：Null
Selection 1
26--35：Null
36--45：Color running（jump）；(with different Id ,can do
color water running effect with a group of lights, CH1,CH6~
~CH9 available)
46--55 ： Color running (fade) ；（ with different Id ,can do color
water running effect with a group of lights, CH1,CH6~
~CH9 available）
56--65 ： color choosing ；（ CH1,CH2 available ）
66--75：color jump；（CH1,CH2 available）
76--85：color fade ,color pulse；（CH1,CH2 available）
86--95：fade running water effect 1；（CH1
available）
96--105：fade running water effect 2；（CH1
available）
......
146--155：fade running water effect 7；（CH1 available）
156--165 ：running water effect
8 ；（ CH1,CH6~ ~CH9
available）
......
236--245 ：running water effect 15 ；（ CH1,CH6~ ~CH9
available）
246--255：Sound control；（CH1,CH6~ ~CH9 available）
CH4
Control Mode
0--30：Null
Selection 2
31--45：running water effect
1；（CH1,CH6~
~CH11
available）
46--60：running water effect
2；（CH1,CH6~
~CH11
available）
......
240--255 ：running water effect 2 ；（ CH1,CH6~ ~CH11
available）

Control mode 3
Direction of water-running effect；（0--127：left；128--
255：right；）
CH5
Control mode
From slow to fast
speed
CH6
R dimmer
R linear 0%~100% dimmer, dark to bright.
CH7
G dimmer
G linear 0%100% dimmer,dark to bright.
CH8
B dimmer
B linear 0%~100% dimmer, dark to bright.
CH9
W dimmer
W linear 0%~100% dimmer, dark to bright.
CH10
Y dimmer
A linear 0%~100% dimmer, dark to bright.
CH11
P dimmer
UV linear 0%~100% dimmer, dark to bright.
4.DMX512
29CH Explanation
Channels
Functions
Explanation
CH1
General
R.G. B.W.A.UV
A linear 0%~100% dimmer. from dark to
Dimmer
bright.
CH2
General strobe
R.G.B. W.A.UV. Strobe, from slow to fast
CH3
Control Mode
0--25：Null
Selection 1
26--35：Null
36--45：Color running（jump）；(with different Id ,can do
color water running effect with a group of lights, CH1,CH6~
~CH6 available)
46--55 ： Color running (fade) ；（ with different Id ,can do color
water running effect with a group of lights, CH1,CH6~
~CH6 available）
56--65：color choosing；（CH1 available）
66--75：color jump；（CH1 available）
76--85：color fade ,color pulse；（CH1 available）
86--95：fade running water effect 1；（CH1
available）
96--105：fade running water effect 2；（CH1
available）
......
147--155：fade running water effect 7；（CH1 available）
157--165 ：running water effect 8 ；（ CH1,CH6~ ~CH11
available）
......
236--245 ：running water effect 15 ；（ CH1,CH6~ ~CH11
available）
246--255：Sound control；（CH1,CH6~ ~CH11 available）
CH4
Control Mode
1--30：Null
Selection 2
32--45：running
water effect 1；（CH1,CH6~ ~CH11
available）
47--60 ： running water effect 2 ；（ CH1,CH6~
~CH11 available）
......

240--255 ：running water effect 15 ；（
CH1,CH6~ ~CH11available）
Control mode 3
Direction of water-running effect；（0--127：left；128--
255：right；）
CH5
Control mode
From slow to fast
speed
CH6
R dimmer
R linear 0%~100% dimmer, dark to bright.
CH7
G dimmer
G linear 0%100% dimmer,dark to bright.
CH8
B dimmer
B linear 0%~100% dimmer, dark to bright.
CH9
W dimmer
W linear 0%~100% dimmer, dark to bright.
CH10
Y dimmer
A linear 0%~100% dimmer, dark to bright.
CH11
P dimmer
UV linear 0%~100% dimmer, dark to bright.
CH12
Dimmer 1
R、G、B ,W.A.UV dimmer
CH13
Dimmer 2
R、G、B ,W. A.UV dimmer
CH14
Dimmer 3
R、G、B ,W. A.UV dimmer
CH15
Dimmer 4
R、G、B ,W. A.UV dimmer
......
.......
..........
CH29
Dimmer 14
R、G、B, W. A.UV dimmer
5.DMX512
119 CH
Explanation
Channels
Functions
Explanation
CH1
General
R.G. B.W. A.UV. A linear 0%~100% dimmer. from dark to
Dimmer
bright.
CH2
General strobe
R.G.B.W. A.UV Strobe, from slow to fast

CH3
Control Mode
0--25：Null
Selection 1
26--35：choose color running. (CH1~CH20)
36--45：Color running（jump）；(with different Id ,can do
color water running effect with a group of lights, CH1~CH6
available)
46--55 ： Color running (fade) ；（ with different Id ,can do color
water running effect with a group of lights, CH1~CH6
available）
56--65：color choosing；（CH1 available）
66--75：color jump；（CH1 available）
76--85：color fade ,color pulse；（CH1 available）
86--95：fade running water effect 1；（CH1 available）
96--105：fade running water effect 2；（CH1 available）
......
148--155：fade running water effect 7；（CH1 available）
158--165 ：running water effect 8 ；（ CH1,CH6~ ~CH11
available）
......
236--245 ：running water effect 15 ；（ CH1,CH6~ ~CH11
available）
246--255：Sound control；（CH1,CH6~ ~CH11 available）
CH4
Control Mode
2--30：Null
Selection 2
33--45：running water
effect 1；（CH1,CH6~ ~CH11
available）
48--60 ： running water effect 2 ；（ CH1,CH6~
~CH11 available）
......
240--255 ： running water effect 15 ；（ CH1,CH6~ ~CH922
available）
Control mode 3
Direction of water-running effect；（0--127：left；128--
255：right；）
CH5
Control mode
From slow to fast
speed
CH6
R dimmer
R linear 0%~100% dimmer, dark to bright.
CH7
G dimmer
G linear 0%100% dimmer,dark to bright.
CH8
B dimmer
B linear 0%~100% dimmer, dark to bright.
CH9
W dimmer
W linear 0%~100% dimmer, dark to bright.
CH10
Y dimmer
A linear 0%~100% dimmer, dark to bright.
CH11
P dimmer
UV linear 0%~100% dimmer, dark to bright.
CH12
R1
R1 linear 0%~100% dimmer, dark to bright.
CH13
G1
G1 linear 0%100% dimmer,dark to bright.
CH14
B1
B1 linear 0%~100% dimmer, dark to bright.
CH15
W1
W1 linear 0%~100% dimmer, dark to bright.
CH16
R2
A1 linear 0%~100% dimmer, dark to bright.
CH17
G2
UV1 linear 0%100% dimmer,dark to bright.

CH18
B2
R2 linear 0%~100% dimmer, dark to bright.
CH19
W2
G2 linear 0%~100% dimmer, dark to bright.
......
.......
..........
CH119
P 18
P18 linear 0%~100% dimmer, dark to bright.
6.DMX512
108 CH Explanation
Channels
Functions
Explanation
CH1
R1 dimmer
R1 linear 0%~100% dimmer, dark to bright.
CH2
G1 dimmer
G1 linear 0%~100% dimmer, dark to bright.
CH3
B1 dimmer
B1 linear 0%~100% dimmer, dark to bright.
CH4
W1 dimmer
W1 linear 0%~100% dimmer, dark to bright.
CH5
Y1 dimmer
A1 linear 0%~100% dimmer, dark to bright.
CH6
P1 dimmer
UV1 linear 0%~100% dimmer, dark to bright.
CH7
R2 dimmer
R2 linear 0%~100% dimmer, dark to bright.
CH8
G2 dimmer
G2 linear 0%~100% dimmer, dark to bright.
......
......
......
CH108
P18 dimmer
UV18 linear 0%~100% dimmer, dark to bright.
7.Fixture features：
Easy to operate, humanization designed, flicker free. Stable. Applicable to photograph,
camera.
8. Parameter:
Voltage: AC100~240V,50-60HZ
LED source: 18pcs 18w 6in1 LED
Control model: DMX512, Auto, M/S,Sound
Channels: 11/29/8119ch/108CH
Effects: dimmer,color jump, color fade, flash, color choose, color pulse,water running
Dimmer: 0~100% linear dimming
Flash:1~20HZ
Lens: chrysanthemum type high transparent PMMA second optical lens
Beam angle: 25 degree
Dimensions: 1050*110*170mm
Weight: 7.2kg
Housing color: Black/Silver
IP grade: IP65
Working temperature: -30℃~-
