BriskHeat TOTEW Series User manual

Wet-Area Wrap-Around
IBC / TOTE Tank Heaters
(TOTEW Series)
Instruction Manual
English
You must read and understand this manual before
installing, operating, or servicing this product. Failure to
understand these instructions could result in an
accident causing serious injury or death.
Keep these instructions for future reference.
© BriskHeat® Corporation. All rights reserved.
2
Wet-Area Wrap-Around Tote Tank /IBC Heater
(TOTEW Series)
TABLE OF CONTENTS
Introduction ........................................................................................................................... 2
Important Safety Instructions................................................................................................ 3
Specifications ....................................................................................................................... 4
Installation / Operation Instructions ...................................................................................... 5
Troubleshooting Guide ......................................................................................................... 7
Warranty Information ............................................................................................................ 8
SAVE THESE INSTRUCTIONS!
Additional copies of this manual are available upon request.
INTRODUCTION
BriskHeat® Wet-Area Wrap-Around Tote Tank / IBC Heaters are designed for maintenance
heating of caged, plastic, or metal tote tanks / IBCs. For successful operation of these
heaters, read and understand these instructions prior to use.

© BriskHeat® Corporation. All rights reserved.
3
Wet-Area Wrap-Around Tote Tank /IBC Heater
(TOTEW Series)
IMPORTANT SAFETY INSTRUCTIONS
 Do not immerse or spray any component of the
control system with liquid.
 Keep volatile or combustible material away from
controller when in use.
 Keep enclosure cover tight while circuits are alive.
 Use heater only in approved locations. This heater
is not approved for use in hazardous area
locations.
 Keep sharp metal objects away from heater.
Failure to observe these warnings may result in electric
shock, risk of fire, and personal injury.
A person who has not read and understood all operating
Instructions is not qualified to operate this product.
SAFETY ALERT SYMBOL
The symbol above is used to call your attention to
instructions concerning your personal safety. It points out
important safety precautions. It means “ATTENTION!
Become Alert! Your Personal Safety is involved!” Read
the message that follows and be alert to the possibility of
personal injury or death.
WARNING
CAUTION
Immediate hazards which WILL result in severe personal
injury or death.
Hazards or unsafe practices that COULD result in severe
personal injury or death.
Hazards or unsafe practices that COULD result in minor
personal injury or property damage.
End-User Must Comply to the Following:
 Only qualified personnel are allowed to connect
the electrical wiring.
 Disconnect all supply power at the source before
making any power connections.
 All electrical wiring must follow local electrical
codes.
 The person who performs the final installation /
wiring must be qualified for this work.
 The end-user is responsible for providing a
suitable disconnecting device.
 The end-user is responsible for providing suitable
over-protection device. It is highly recommended
that a ground fault circuit breaker be used.
Failure to observe these warnings may result in personal
injury or damage to the heater.
WARNING
 Never handle the heater while it is in operation;
Always disconnect the heater from the power
source and allow to cool prior to handling.
 Inspect heater before use. Do not use heater with
torn or worn surfaces.
 If spillage of foreign matter onto heater occurs,
disconnect from power source and clean after
heater is allowed to cool.
 Never operate a heater without an appropriate
heat sink (device being heated is considered a
heat sink).
 Fasten heater to device using approved methods
only.
 Do not repair damaged or faulty heater.
 Do not crush or apply severe physical stress on
heater or cord assembly.
 Disconnect heater when not in use.
 Use heater for heating tote tanks / IBCs only. Use
specific sized heater with same sized tote tank /
IBC. Do not use for other applications.
 Do not operate heater above 160°F (71°C).
Failure to observe these warnings may result in personal
injury or damage to the heater.
CAUTION
© BriskHeat® Corporation. All rights reserved.
4
Wet-Area Wrap-Around Tote Tank /IBC Heater
(TOTEW Series)
SPECIFICATIONS
 Full coverage plug and play system
 Moisture resistant PVC coated fabric inner and outer layer
 Adjustable On / Off Digital Controller
 Range of usable temperature values is -40°F to 160°F (-40°C to 71°C) in 1°
increments.
 Patented grounded heating element
 Dielectric strength over 2000 volts
 Power cord 6’ (2m) long
 Available 120 or 240 VAC Models
 Acceptable for use in wet or dry environments
TOTEW Series: Units with Adjustable Straps and Buckles
 Fits any tote tank width from 40” x 40” (1016mm x 1016mm) to 48” x 48”
(1219mm x 1219mm)
 Optional insulated top cover reduces heat loss (PN: TOTEW-TOP)
Top Support straps and Buckles
Adjustable
Straps and
Buckles
“Mouse-hole”
for spigot
Temperature
Controller
6 ft (1.8m)
Power Cord

© BriskHeat® Corporation. All rights reserved.
5
Wet-Area Wrap-Around Tote Tank /IBC Heater
(TOTEW Series)
INSTALLATION / OPERATION INSTRUCTIONS
STEP 1
Remove heater from box. Visually inspect the heater and all components for rips, tears,
punctures, and/or any visual damage. Do not use if damaged.
STEP 2
Heater should be placed on a clean, IBC/Tote, free of oil, chemical, debris, etc. Locate
“mouse-hole” on heater. Loosely wrap heater around IBC / tote tank with the mouse-hole
positioned to accommodate the exit spigot. The temperature controller must be facing
outward and positioned on the upper portion of the heater. Secure the two top straps by
fastening the quick-release plastic buckles. Overlap the side of the heater with the nylon
straps secured closest to the edge on the outside, over the other side of the heater.
Secure and tighten the bottom, middle and top straps. All five straps should now be firmly
tightened so the heater is tight against the tote tank / IBC with no sagging or bunching.
Cover the top of the tote tank / IBC with optional insulation cover (TOTEW-TOP).
STEP 3
Connect standard 3-prong plug (if applicable) to appropriate electrical power supply. The
power connection must be adequately rated to electrically support the voltage and
amperage of the heater. The identification label located on the power cord displays voltage
and amperage requirements. Follow all local electrical codes for proper electrical
connections.
STEP 4 Program Controller
The control panel display features a backlit LCD display and three buttons for set-up and
adjustment of the controller’s settings.
The use of two individuals is
highly recommended for this
installation.
Binary
Input Indicator
Menu
Button
Down
Button
Up
Button
Relay
Status
LED
Temperature
Units Indicator
Operating Modes
(Heat/Cool)
Indicator
Liquid Crystal
Display
Figure 1: Control Front Panel with LCD and Three-Button User Interface
Read and understand this entire manual
before operating this heater.
WARNING
© BriskHeat® Corporation. All rights reserved.
6
Wet-Area Wrap-Around Tote Tank /IBC Heater
(TOTEW Series)
Note: The default setting for your temperature controller displays basic menu options only.
The Basic menu allows you to quickly edit the On and OFF temperature values, as
well as the Sensor Failure Mode (SF) and Anti-Short Cycle Delay (ASd) value.
Parameter Code Definitions:
On: Lower limit parameter, temperature at which the heater turns on.
OFF: Upper limit parameter, temperature at which the heater turns off.
Note: During normal operation your heater will cycle between the On and OFF parameter
values. For a tighter temperature tolerance, program the On and OFF parameter
values closer together.
For basic programming and temperature setting instructions, follow these steps:
1. Press MENU to display the basic menu.
2. Press ▲or ▼ to scroll through basic parameter options.
3. With OFF parameter displayed, press MENU.
4. Press ▲or ▼ to select the upper limit temperature value desired.
5. Press MENU to save OFF value setting.
6. With On parameter displayed, press MENU.
7. Press ▲or ▼ to select the lower limit temperature value desired.
8. Press MENU to save On value setting.
Note: If you do not press MENU to save a displayed value, the control reverts to the last
saved value. After 30 seconds of inactivity, while in any screen, the control reverts
to the Main screen.
For additional explanation of basic menu options and for programming instructions for
advanced menu options, please review instruction manual for the A421 Series Standard
Electronic Temperature Control or contact BriskHeat factory at 1-800-848-7673 (toll free in
US/Canada) or 1-614-294-3376 (worldwide) for assistance.
STEP 5 (Optional IBC/Tote Tank Insulator)
PN: TOTEW-TOP
Universal Size: 48”x48” (1219mm x 1219mm)
Install optional IBC/Tote Tank Insulator by disconnecting the buckle of one of the two top
straps and sliding the insulator underneath the remaining top strap. Reconnect the top
strap buckle and tighten both straps if necessary. Depending on the size of your IBC/Tote
Tank, tuck excess insulator between the IBC/Tote Tank and the heater.

© BriskHeat® Corporation. All rights reserved.
7
Wet-Area Wrap-Around Tote Tank /IBC Heater
(TOTEW Series)
PROBLEM SOLUTION(S)
Does not heat Verify heater is connected to proper voltage. The identification
label located on the power cord displays the heater’s voltage
requirement.
Verify temperature controller is properly programmed for
heating operating mode by visually checking “Operating Mode
Indicator” on LCD display (see figure 1).
Flame Icon = Heating Mode
Snowflake Icon = Cooling Mode
For heating mode of operation, OFF parameter must be
programmed greater than On parameter.
Check to see if there is a resistance reading (not an open
circuit) in heater using an ohm meter.
Circuit breaker is tripping Validate that the circuit breaker is capable of handling the
amp requirement of the heater. The identification label located
on the power cord displays the heater’s amperage
requirement.
Examine heater and cord for any damage.
Does not fit Confirm that the heater provided was designed to fit around
your specified tote tank / IBC.
If the heater was designed for the specified tote tank / IBC,
please call 1-800-848-7673 or 614-294-3376 for further
assistance.
Something has lightly
spilled on exterior or
interior
Apply any general household cleaner, that does not contain
any silicone rubber dissolving type ingredients, with a clean
cloth fabric.
TROUBLESHOOTING GUIDE
Please read this guide prior to contacting BriskHeat®. This guide is designed to answer the
most commonly asked questions. If you are unable to identify the problem or need
additional assistance, please contact your local distributor/ representative or us at
1-800-848-7673, 614-294-3376, or [email protected]m.
© BriskHeat® Corporation. All rights reserved.
8
Wet-Area Wrap-Around Tote Tank /IBC Heater
(TOTEW Series)
WARRANTY INFORMATION
BriskHeat warrants to the original purchaser of this product for the period of eighteen (18)
months from date of shipment or twelve (12) months from date of installation, whichever
comes first. BriskHeat’s obligation and the exclusive remedy under this warranty shall be
limited to the repair or replacement, at BriskHeat’s option, of any parts of the product which
may prove defective under prescribed use and service following BriskHeat’s examination, is
determined by BriskHeat to be defective. The complete details of the warranty can be
found online at www.briskheat.com or by contacting us at 1-800-848-7673 (toll free, U.S. /
Canada) or 1-614-294-3376 (Worldwide).
PN:11630-06 Rev B NOV 2017
Toll Free: 800-848-7673
Phone: [phone]
Fax: [phone]
Email: bhtsal[email protected]
Corporate Headquarters:
4800 Hilton Corporate Dr.
Columbus, OH 43232, U.S.A.
Europe:
P.O. Box 420124
44275 Dortmund, Germany
