Bristan HY POWSHX W Mounting instructions

eco
Models Covered:
HY POWSHX W
Please keep this booklet for future
reference.
Installer, when you have read these
instructions please ensure you leave
them with the user.
Installation Instructions
and User Guide
Thermostatic Power Shower
1500

2Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Welcome to your new Bristan Power Shower.
It has also been designed and tested in the UK to all of the relevant British
Standards.
These instructions contain all of the necessary installation and operating
information,
so please read them thoroughly and keep for future reference.
These instructions are for your guidance to a safe and successful installation
which we recommend is carried out by a suitably qualified person and
must conform with current I.E.E Wiring Regulations (BS7671) and Building
Regulations (Part P and Part G).
Contents
Contents
• Important Safety Information 3
• Water Requirements 4
• Electrical Requirements 5
• Product Features 6
• Operating the Shower 7
• Dimensions 7
• Specification 8
• Prior to Installation 9
• Installation - Surface Mounted 10
• Installation - Recessed Pipework 11
• Fixing the Riser Rail to the Wall 12
• Commissioning - Testing the System 13
• Maintenance 14
• Troubleshooting 14
• Spare Parts 15

3
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
BEAB
(British Electrotechnical Approvals
Board) Approval of Safety.
• Always switch o the power at
the consumer unit and remove the
correct circuit fuse before making
any electrical connections or if you
have to remove the cover of an
installed unit.
• If the shower unit is fitted in a
hard water area, a scale inhibitor
may have to be fitted and the filter
cleaned regularly. For more advise
on obtaining a scale inhibitor, visit
local merchant or DIY store.
• This appliance must be
permanently connected to the
water mains and not connected by
a hose-set.
• Warning:
This appliance is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision
or instruction concerning use of the
appliance by a person responsible
for their safety.
• Children shall not play with the
appliance.
• Cleaning and maintenance shall
not be made by children without
supervision.
• Important: The shower unit must
be switched o at the isolating
switch (pull cord) when not in use.
• Please read these instructions
thoroughly and retain for future use.
• All products manufactured
and supplied by Bristan are safe
provided they are installed, used
correctly and receive regular
maintenance in accordance with
these instructions.
• If you are in any doubt about
your ability to install this product
safely you must employ the
services of an experienced qualified
plumber/electrically qualified
person.
• Warning:
Do not operate the shower unit if
you suspect it is frozen. Do not site
the shower unit where it might be
subjected to freezing conditions.
• Do not install this shower unit in a
room/environment without adequate
ventilation or an extractor fitted. This
is required to prevent condensation
forming within the unit.
• Do not operate the shower unit if
the showerhead or spray hose has
been damaged or is blocked.
• Do not block the flow of water
from the showerhead, by placing it
(smothering it) on your hand or any
other part of your body or foreign
object.
• Do not operate the shower if the
water stops flowing during use or if
the water is leaking from the shower
unit itself.
If this occurs, turn o at the mains
electrical supply and refer to the
Troubleshooting section or contact
Bristan Customer Services.
Important Safety Information

For correct operation of the Bristan Thermostatic
Power Shower both hot and cold supplies to the unit
must be gravity fed, at nominally equal pressures,
from a cold water storage tank and hot water
storage cylinder.
Please ensure compliance with all Water Regulations.
Please ensure maximum supply head of 10 metres
(1 bar), minimum 1 metre (0.1 bar).
Please note, when using this unit in ‘gravity’ shower
mode, without the boost button depressed, ensure
you have a minimum of 1 metre head from your
shower head to the bottom of your cold water tank.
It is recommended that the hot water supply is at a
temperature of 60°C, in line with British Standard
6700, British Water Regulations, and Plumbing Code
of Practice.
Before proceeding with the installation of this unit,
check that your site requirements allow the shower
unit and handset when positioned on the wall to be
a minimum of 1 metre below the cold water storage
tank.
The unit can be connected to a cylinder system
providing it has cold water storage capacity of 112
litres (25 gallons).
Do not run shower dry as this will damage the
internal seals and invalidate the warranty.
All pipe work into the unit should be 15mm. Non-
restrictive isolating valves must be fitted on hot and
cold supply pipes. When connecting pipe work avoid
using elbows: sweep or formed bends will ensure
optimum performance.
The temperature of your stored water must not
exceed 65°C. A stored water temperature of
60°C is considered sucient to meet all normal
requirements in line with the British Standard 6700.
Water tank detail
Cylinder Flange
Typical Power Shower Installation
60mm
Cold feed
connection
to hot water
cylinder
Cold feed
connection
to the
Power
Shower
51mm
Cold Water
Storage Tank
1m Minimum
Isolating
Valves
1m
Minimum
Hot
Water
Storage
Tank
Mains
Water
Supply
Minimum
25mm
between
Shower head
and spillover
Mains
Electric
Supply
Fused
Spur
2.5m
Manual
Switch
4Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Water Requirements
IMPORTANT
Under no circumstances
must the Power Shower
be connected to the mains
cold water supply, or to
a combination boiler, or
pressurised hot water system.
All plumbing should be
completed before any electrical
connections are undertaken.

The shower must only be connected to a
230/240V AC electrical supply, from a 13-amp
ring main; via a fused double pole switch with
at least 3mm contact separation.
A manual switch is to be clearly identifiable,
with a minimum distance of 2.5m from a fixed
tap or shower, i.e. mounted in an adjacent
room or via a ceiling-type pull cord.
It should be fused at no more than 3 amps.
This appliance must be earthed, and all
associated metal pipe work earth crossbonded
in line with current I.E.E. regulations.
Please use the cable entry point provided.
Failure to comply will eliminate any BEAB
approval.
As the colours of the wires in the cable (not
supplied) used to connect to this appliance
may not correspond with the coloured
markings identifying the terminals in your
switch, please follow the procedure below:
• The wire, which is coloured Blue or
Black, must be connected to the terminal
that is marked with the letter N.
• The wire, which is coloured Brown or
Red, must be connected to the terminal that
is marked with the letter L.
• The wire, which is coloured Green or
Yellow, must be connected to the terminal
that is marked with the earth symbol .
• The installation and wiring must comply
with I.E.E regulations.
Typical Power Shower Installation
Cold Water
Storage Tank
1m Minimum
Isolating
Valves
1m
Minimum
Hot
Water
Storage
Tank
Mains
Water
Supply
Minimum
25mm
between
Shower head
and spillover
Mains
Electric
Supply
Fused
Spur
2.5m
Manual
Switch
5
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Electrical Requirements
IMPORTANT
This appliance MUST be
earthed!
All electrical wiring for the
shower must comply with the
current I.E.E. Regulations which
includes earth-cross bonding
to all metal pipe work.

eco
1. Push Button STOP/START
Switch
Electronic switch
2. Temperature Control
Adjustable Temperature Control
3. Eco Button
Non-powered shower
4. Hose outlet
Shower hose outlet
Handset
The Handset has three spray
modes:
1. Spray
2. Jet spray
3. Combination spray
To select the desired showering
mode, simply rotate the spray
head one way or the other to the
desired spray pattern.
Rub-Clean Handset
To remove any build up of
limescale from your handset,
remove it from its holder and
rub your fingers over the rubber
spray jets. Turn the shower on
and any build up of limescale will
be flushed out of the handset.
1 2
3
2
1
3
4
6Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Product Features

To operate the shower ensure the
temperature control knob (1) is set
approximately to the 12 o’clock position
and press the Stop /Start button (2).
Adjust the shower temperature by
turning the knob anti-clockwise -
towards red, for warmer temperature,
and clockwise - blue, for cooler.
Setting the knob in the same position
in future will give the same showering
temperature.
If a less powerful shower is required,
press the Shower Eco
button (3).
The handset holder has a friction grip
on the rail and simply slides up and
down to adjust the height. The angle of
the handset in the holder has 5, spring
loaded positions. To adjust, grip the
handset handle next to the hose nut,
and move it to it’s required position.
eco
eco
Dimensions
660
74117
250
260
Reduce Elbow to 63mm
1
2
3
7
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Operating the Shower

Top Fed
Rear Access
Bottom Fed
eco
Cross Head Screwdriver
Adjustable Spanner Cordless Drill Detector
Safety Glasses Flat-head Screwdriver
Pipe Cutter Masking Tape Spirit Level
Cold Water
Storage Tank
1m Minimum
Isolating
Valves
1m
Minimum
Hot
Water
Storage
Tank
Mains
Water
Supply
Minimum
25mm
between
Shower head
and spillover
Mains
Electric
Supply
Fuse
Spur
5°C
20°C
Light
Commercial
Maximum Static Pressure: 10.0 Bar
Inlet Water Temperature
15mm
Push-Fit
Outlet Connection
Min: 0.1 Bar Max: 1.0 Bar
Working Pressures
Suitable for low pressure, gravity fed
water systems only
Multi-Function
Handset
Inlet Connection
Cold Water Supply
Min: 5°C Max: 20°C 1/2” BSP
Male
Threaded
Recommended Usage
Healthcare
Heavy
Commercial
Domestic
IMPORTANT
Specifications
Hot Water Supply
60°C
65°C
Recommended: 60°C
Max: 65°C
Pack Contents
Water Inlet Entry Points
x2
x2
x2
x1
x1
x1
x1
x1
2.5m
Manual
Switch
8
1.0
5.0
4.0
3.02.0
Pressure
BAR
0
1.0
5.0
4.0
3.02.0
Pressure
BAR
0
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Specification
Tools You’ll Need

Please note that this product comes packaged
with the front cover and control knobs already
in place. These have to be removed to install
the shower. Please follow the procedure below.
Removing Cover
1. Temperature Control handle
2. Graphic Ring
3. Logo
4. Screws (x3)
Pull o control knob (1).
To remove the graphic ring (2) which
surrounds the main control knob, insert a thin
bladed screwdriver into the recess (arrowed)
gently prise o the ring, revealing two fixing
screws.
Remove lower logo (3) by inserting a thin
bladed screwdriver in the slot, to reveal the
lower fixing screw.
Remove all three fixing screws (4). The cover
can now be slowly removed - care should be
taken not to strain wiring which is attached to
the front cover.
This procedure can be reversed to replace the
front cover and control knob after installation
to the wall.
We recommend that the shower unit is fitted
at chest height, and set to one side of the
intended riser rail position, ensuring that the
top of the shower unit is at least 1 metre below
the base of the cold water storage tank.
The outlet connection for the hose should be
sited at the bottom of the unit.
The integral fittings on the valve are of the
self-seal push-fit type. Ensure that all burrs are
removed from the ends of the supply pipes.
Where chromium plated pipe is used then the
first 25mm of chrome must be roughened or
removed to ensure that the push fit fittings in
the supply retain the pipe in position.
The inlet elbows supplied are of a standard
length, in some cases these will need to be
shortened for correct installation.
1
2
3
4
9
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Prior to Installation
IMPORTANT
The unit must be fitted on the
finished tiled surface.
Do not seal the edge of the
shower unit to the tiled surface
with any form of sealant.
The gap between the back of
the shower unit and the tiles
is needed for ventilation.
REMEMBER
Isolate mains water
and electrical
supplies before
starting installation

Side Feed
Connecting pipework can feed from above or
below the unit, or straight through the wall at
nominal centres of 40mm.
If exposed pipe work is the chosen
option, the pipes enter the unit on the
right hand side with the cold on the
top. The pipe centres are 40mm
apart, and need to penetrate the
mixer connections to a depth of 25mm.
Position the unit on the wall and mark
the fixing hole positions. Drill and secure
to wall using appropriate fixings (not supplied).
Make the necessary measurements, remove the
unit from the wall, and bring the
pipe work and wiring to finished
positions.
Make the hot water
connection into the hot
water supply pipe from
the cylinder, ensuring
that it is the first draw
o (below the
expansion tee),
to minimise the eects
of water drawn o
elsewhere in the house,
and a minimum of 1 metre
below the base of the cold
water storage tank. This should not be directly
beneath the ball valve as aeration of the water
going to the shower could cause pump damage.
If connection to the hot water storage pipe is
not possible, a cylinder flange type connection
may be used.
Make the cold water connection into the base of
the cold water storage tank, 60mm below the
level of the cold water take o to the hot water
cylinder.
Flush out the pipe work to ensure that no debris
enters the unit.
Detach the pipe entry grommet and, using a
sharp knife or similar, remove the centre (15mm
dia.) portions, and refit the grommet.
Fit the shower unit over the pipe work, and
insert the mains wiring through the aperture at
the top of the base moulding. Ensure that the
supply pipes are fully inserted into the mixer
valve ‘push fit’ connections, and fix to the wall.
Connect the wiring in line with the polarity
indications moulded into the base unit.
COLD
LN
E
HOT COLD
HOT COLD
Hole Fixing Positions
Wiring Connections
Collett
For chrome
plated pipes
remove the
first 25mm
of plating
Remove
center
portion
(15mm)
Pipe entry grommet
Slide out Backing Plate
10 Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Installation - Surface Mounted
REMEMBER
Hot on the
bottom, cold
on the top
IMPORTANT
Do not fit a fuse or switch
on mains electrical supply
until all plumbing work is
completed
Do not use jointing
compounds, or solder
within 300mm of the unit.

COLD
LN
E
HOT COLD
HOT COLD
Hole Fixing Positions
Wiring Connections
Back Feed
Collett
For chrome
plated pipes
remove the
first 25mm
of plating
40mm
40mm
Reduce Elbows to 40mm
Connecting pipework can feed from
above or below the unit, or straight
through the wall at nominal centres
of 40mm.
If the pipe work is to be recessed,
it should be let into the wall with
the ends of the hot and cold pipes
standing 40mm o the finished
surface of the wall, and centres 40mm
apart, with the cold above the hot. Knock out
the inlet holes in the rear of the unit.
Make the hot water connection into the hot
water supply pipe from the cylinder, ensuring
that it is the first draw o (below the expansion
tee), to minimise the eects of water drawn
o elsewhere in the house, and a minimum of 1
metre below the base of the cold water storage
tank.
This should not be directly beneath the ball
valve as aeration of
the water going to the
shower could cause pump
damage. If connection
to the hot water
storage pipe is not
possible, a cylinder
flange type
connection may be
used.
Make the cold water
connection into the base of
the cold water storage tank,
60mm below the level of the cold water take
o to the hot water cylinder
Flush out the pipe work to ensure that no debris
enters the unit.
Position the unit on the wall with the inlet pipes
centred in the holes in the rear of the base
moulding, mark the fixing screw positions on the
wall and remove the unit. Drill the fixing screw
holes and secure with appropriate fixings (not
supplied).
Cut the plastic inlet elbows supplied to 40mm
long from the centre of the elbow, and remove
any burrs from the cut end. Fit the cut inlet
elbows into the push-fit connectors on the
shower mixer valve.
Connect the wiring in line with the polarity
indications moulded into the base unit.
IMPORTANT
Do not fit a fuse or switch
on mains electrical supply
until all plumbing work is
completed
Do not use jointing
compounds, or solder
within 300mm of the unit
11
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Installation - Recessed Pipework
REMEMBER
Hot on the
bottom, cold
on the top

Position the wall
bracket fixings in the
marked positions
against the wall, ensuring
they are vertically in line
with each other and mark
the centres of the fixing
holes onto the wall.
Drill suitable holes and
insert the wall plugs.
Securely attach the wall
bracket fixings to the
wall using the screws.
Slider
Wall bracket
Wall bracket
Wall bracket
fixing
1
3
5
6
78
4
Position the assembled riser rail
on the wall, bearing in mind the
dierent heights of people likely
to use the shower and the length
of the hose when connected to
the shower.
With the riser rail vertical, mark
the wall bracket positions onto the
wall.
Release the slider handle and
remove the slider and wall
brackets from the rail.
2
Rail clamp
Insert the rail
clamps into both
wall brackets,
ensuring the screw
is accessible .
Bottom wall
Bracket
Top Wall
Bracket
Slider Bracket
Push the riser
rail up through
the bottom wall
bracket.
Push the slider
down onto the
riser, ensuring it is
correct way up.
Then push the top
wall bracket down
onto the riser rail.
Centre the riser rail within the wall
brackets and tighten both clamps onto
the rail.
Slide the wall brackets over
the wall bracket fixings.
Tighten the grub screw
on the under side of each
wall bracket using a 2.5mm
hexagonal key.
Screw the shower hose (ribbed nut
end) onto the shower ensuring that
the rubber washer is fitted and feed
the hose through the hose retainer.
Your shower is now ready to
be commissioned for first use.
When working near a basin, bath or shower insert plug or cover waste to prevent losing small parts.
Take care not to drop tools/equipment into basin, bath or shower during shower installation.
Note: If replacing an existing riser rail, check to see if the existing holes can be reused or covered by
the new wall brackets. Try to avoid drilling close to the edge of tiles, drill in the middle of the tiles or
in the tile joints.
12 Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Fixing the Riser Rail to the Wall
REMEMBER
Check for any
hidden pipes and
cables before
drilling!

Connect the shower hose to the unit but do not
fit the handset. Fit the front cover as shown in
‘Prior to Installation’.
Turn on the hot and cold isolating valves, and the
electricity-isolating switch. Place the open end of
the hose in the bath or shower tray.
Set the temperature control knob to cold, fully
clockwise, and press the ‘stop/start’ button.
Cold water will run from the hose, and you should
allow this to continue for two minutes after which
the control knob should be returned to the ‘12
o’clock’ position. Allow the water to run for a
few minutes to stabilise the hot water flow, and
then check that the water is at a comfortable
showering temperature.
If it is too hot or cold, turn o the electricity-
isolating switch, pull o the control knob, and
adjust the brass spindle anti-clockwise to increase
the temperature, clockwise to decrease. Replace
the knob in the ‘12 o’clock’ position, switch the
electricity on, and check the water temperature.
Readjust as necessary until a satisfactory
temperature is achieved.
Pass the shower hose through the hole in the
soap dish and, using the rubber sealing washer
supplied, fit the handset to the hose and place
the handset in the handset holder.
Press the Stop/Start button. Water flows from
the shower head under the gravity pressure from
the storage tank. The ‘Eco’ button allows you to
switch from a power shower to a gravity (non-
powered) shower.
Temperature Adjustment
Temperature Adjustment
The valve allows the maximum showering
temperature to be set at a safe level,
preventing accidental scalding. This setting
should be made during commissioning and
will require that the hot water cylinder is at its
normal operating temperature.
IMPORTANT:
The handset must be in the spray mode.
We recommend the reading of User
Instructions before proceeding further. This
will familiarise you with the operation of the
shower.
Turn the brass mixer valve spindle fully
clockwise, and then anti-clockwise until the
black line on the spindle is aligned with the
groove on the mixer body, and fit the control
knob in the fully cold position. Check that it is
correctly fitted by turning fully clockwise to
the stop, pull the knob o and check that the
black line and groove are aligned. Adjust if
necessary. This sets the shower temperature
to 38-40°C, with the control knob pointing
to ‘12 o’clock’, if the stored hot water is at the
recommended 60°C.
Mixer Valve
Spindle
13
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Commissioning - Testing the System

Symptom Likely Cause Action/Remedy
Shower not operating Electric is not switched
on Check all fuses and electrical supply.
No water flow (Hot or
Cold)
Isolating valves turned
o
Check isolating valves are turned on
Check cold-water storage tank has not run dry
Poor performance
Restrictions in water
supply Check both hot and cold isolating valves are fully open
Pump may have
overheated
Allow unit to cool and it will automatically re-set
Check for adequate ventilation
Unit may be incorrectly
installed
Check that the top of the shower unit is at least 1 metre
below the base of the cold water tank
Blockage in handset or
shower hose Check and clean as necessary
Cleaning
Do not at anytime use bath cleaning liquids, powders or
specified scratch cleaners on any surface finishes. In order to
avoid surface wear or chemical attack on any of your shower
fittings when cleaning, always use a damp cloth. For persistent
stains or marks, you may use domestic liquid or soap.
The hardness of the water in your area will determine how
often you should clean your showerhead. Build up of scale
in particularly hard water areas combined with constant use
means you may need to clean your showerhead once a week.
To ensure continued performance of your electric shower
the showerhead needs to be regularly descaled.
Why not Visit our Youtube Channel?
To see our latest how-to videos, simply
scan the QR code with your smart
phone or tablet.
Alternatively visit www.youtube.com/bristantv
Spare Parts
To replace any spare parts
for your shower why not
scan the below QR Code
and search for your product.
Alternatively visit www.bristan.com/search
14 Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Maintenance
Troubleshooting
IMPORTANT
Before carrying out
general repairs or testing
the shower, ensure that
the electricity supply is
turned o at the mains
and the correct circuit
fuse is removed.

No. Part No. Description Qty
01 COVER-1500XY-HY-WT Front Cover Assembly incl. Wiring 1
02 SP-087-0505-WT Control Knob 1
03 SP-087-0230 Solenoid Valve 1
04 SP-087-0110 Pump Unit 1
05 SP-087-0154 Mixer Valve Assembly 1
06 490-0141 Non-Return Valve 1
07 086-0060 Long Inlet Elbow 1
08 SP-087-0231 Wiring Loom 1
09 HAND125 WC Multi-Function Handset 1
10 100048 Riser Rail Bracket 1
11 100050 Riser Rail 1
12 100049 Slider 1
13 SK100052 Hose Retainer 1
14 100051 Fixing Kit 1
15 HOS 150CN01 C 1.5m Hose 1
eco
1
3
4
5
6
7
2
8
910
11
13
12
14
15
15
Need help? Give us a call on 0330 026 6273 and speak to one of our trained advisors.
Spare Parts

Bristan Group Ltd.
Birch Coppice Business Park
Dordon
Tamworth
Staordshire
B78 1SG
Web: www.bristan.com
Email: [e-mail]
A Masco Company
At Bristan, we want to make things as easy as possible for our customers. That’s why we oer solid guarantees on
all our products, eective from the date of purchase, to give you peace of mind.
To start your free guarantee simply scan the QR code and register your product.
Alternatively visit www.bristan.com/register.
For any other queries, please call our Customer Service on 0330 026 6273 where our expert team of advisors
will beable to oer you any help and advice
For full guarantee terms and conditions visit www.bristan.com/guarantees.
Part Number: POW SHX 1500
Issue: D4
