Bristan PRISM PM SNK C User manual

Bristan, Birch Coppice Business Park, Dordon, Tamworth, B78 1SG
Telephone: [phone] Facsimile: 08 701 6275
Web Site: www.bristan.com Email: [email protected] D2
ProductSpecification
Product Code: PM SNK C
Finish: Chrome plated
Product Type: Contemporary
Construction: Body is of brass construction
and is designed to conform to BS EN 817
Cartridge Type: 5 ceramic disc cartridge
Supply: Suitable for all plumbing systems
Inlet Connections: M10 x 15mm screw-in flexi connection tail pipes
Water Pressure: Min 0.2 bar, Max 8.0 bar
AdditionalInformation
•Supplied with two non-return valves.
•Supplied with metal handle.
•Chrome plated to BS EN 248.
Technical Advice: For further information please call 0844 7016273 or email [e-mail]
Guarantee: 5 years covering manufacturing faults
Compliance/Approvals
WRAS: Pending
System
Pressure
0.
2
bar
0.5
bar
1
bar
2
bar
3
bar
5
bar
PM SNK C (mixed) 3.3 6.6 9.9 14.5 18.0 23.4
TECHNICA DATASHEET
PRISM
PRISM MONOBLOC SINK MIXER
FlowRates (litres per minute)

AFTERCARE INSTRUCTIONS
Your fitting has a high quality finish and should be treated with care to
preserve the visible surfaces. All surface finishes will wear if not
cleaned correctly, the only safe way to clean your mixer is to wipe
with a soft damp cloth. Stains can be removed using washing up
liquid. All bath cleaning powders and liquids will damage the surface
of your fitting even the non-scratch cleaners.
GUARANTEE
All products are manufactured to the highest standards and a 5 year
guarantee covers any defect in manufacture. As gold and special
effect finishes are softer than chromium plate, special care must be
taken when cleaning; a 3 year guarantee covers these finishes.
NOTE: The 5 year guarantee on the valves is invalidated if damaged
by any waterborne debris.
In the interests of continuous product development we reserve the
right to alter specification as necessary.
PRODUCT CODE: PM SNK C
TELEPHONE HELP LINE: 0844 701 6273
Bristan Group Ltd
Birch Coppice Business Park
Dordon
Tamworth
Staffordshire
B78 1SG
UK
A Masco Company
Web Site: www.bristan.com
Telephone: [phone]
Facsimile: 0844 701 6275
Email: [email protected]
(FI PM SNK) (Rev. D2) (H)
Prism
Kitchen Mixer
Fitting
Instructions
Please keep these instructions for future reference and for the
ordering of spare parts.

6
2
4
3
5
1
'C' PLATE
FIXING KIT
7
8
9
WATER PRESSURE
This mixer is suitable for use at all supply pressures. If the fitting is
installed at low pressure (tank fed), then the minimum height from the
outlet of the nozzle to the underside of the cold tank should be
approximately 2 metres to ensure adequate performance. This mixer
should be installed in compliance with Water Regulations.
Where the supplies are unbalanced, i.e. hot water from the cylinder
tank/cold from the mains, approved check valves must be fitted in the
supply pipes. For further details contact your Local Water Authority.
CONTENTS
1. Mixer (x1)
2. Plinth (x1)
3. O-ring (x1)
4. C-shaped rubber washer (x1)
5. C-shaped metal washer (x1)
6. Threaded rod (x2)
7. Retainer (x2)
8. Tail pipes (x2)
9. Check valve (x1)
INSTALLATION
1. Identify all components and check for completeness, particularly
before arranging installation.
2. Fit the mixer body (1) to the sink using the 'C' plate fixing kit. The
metal plinth (2) and o-ring (3) go between the fitting and the sink,
and the 'C' shaped rubber (4) and metal (5) washers on the
underside of the sink to be secured by the threaded rod (6) and
retainer (7)
3. Screw the tail pipes (8) into to the fitting, fit the check valve (9)
to the hot side and connect the hot and cold supplies. Note:
with the handle on the right, the hot supply should be
connected on the left.
4. Fully open the mixer in the mid position and check all joints and
connections for leaks.
5. See over the page for aftercare instructions.
MAINTENANCE AND/OR CARTRIDGE REPLACEMENT
1. Isolate water supplies.
2. Lever out the small indice plug in the front of the handle.
Unscrew the grub screw and lift off the handle.
3. Unscrew the shroud and brass retaining plate and lift out the
cartridge complete with seals.
4. Grease seal and fit the new cartridge.
Note that there are locating pins on the bottom of the cartridge that fit
in holes inside the tap, to ensure it is fitted the right way round.
5. Refit the handle and tighten the grub screw. Replace the indice
plug.
Please Note: In the unlikely event you find a part missing please
contact our Customer Service Help line on 0844 701 6273 for
immediate despatch of part.
