Bristan RV SNK C User manual

AFTERCARE INSTRUCTIONS
Your fitting has a high quality finish and should be treated with
care to preserve the visible surfaces. All surface finishes will
wear if not cleaned correctly, the only safe way to clean your
waste is to wipe with a soft damp cloth. Stains can be removed
using washing up liquid. All bath cleaning powders and liquids will
damage the surface of your fitting even the non-scratch cleaners.
GUARANTEE
All products are manufactured to the highest standards and a 5
year guarantee covers any defect in manufacture.
NOTE: The 5 year guarantee is invalidated if damaged by any
waterborne debris.
In the interests of continuous product development Bristan reserve
the right to alter specification as necessary.
PRODUCT CODE: RV SNK C
TELEPHONE HELPLINE: 0844 701 6273
Bristan Group Ltd
Birch Coppice Business Park
Dordon
Tamworth
Staffordshire
B78 1SG
UK
A Masco Company
Web Site: www.bristan.com
Telephone: [phone]
Facsimile: 0844 701 6275
Email: [email protected]
(
F
I RV SNK)
(
REV D
4
)
(SM)
Revolve
Sink Mixer
Fitting Instructions
& Contents List
Please keep these instructions for future reference
and request of replacement parts.

CD VALVE
CLEAN WASHER
AND SEAT
1
2
3
4
5
67
'C' PLATE
FIXING KIT
WATER PRESSURE
This mixer is suitable for use at all supply pressures. However for
optimum use both the hot and cold supplies should be reasonably
balanced. If the fitting is installed at low pressure (tank fed), then
the minimum distance from the outlet of the nozzle to the underside
of the cold tank should be approximately 2 metres to ensure
adequate performance. This mixer should be installed in compliance
with Water Regulations.
CONTENTS
1. Mixer body
2. O-ring
3. O-ring
4. C-shaped metal
washer
5. Threaded rod
6. Retainer
7. Tail pipes
`
INSTALLATION
1. Identify all components and check for completeness, particularly
before arranging fitting.
2. Fit the mixer to the sink using the 'C' plate fixing kit. The plinth (2)
and an O-ring (3) go between the fitting and the sink, and an O ring
(4) and the metal washer (5) on the underside of the sink, to be
secured by the threaded rod (6) and retainer (7).
3. Fit the tail pipes (8). Connect the hot and cold supplies.
4. Fully open both valves, letting it run for a few minutes to check
all joints and connections for leaks.
5. See over the page for aftercare instructions.
MAINTENANCE
If the fitting begins to drip:
1. Turn off the water supply.
2. Loosen grub screw under handle lever and remove handle.
Unscrew shroud and valve.
3. Carefully clean seating, rubber washer and ceramic disc.
4. Replace valve and handle, then turn on the water supply.
5. If problem persists contact our helpline quoting the product code.
Please Note: In the unlikely event you find a part missing please
contact our Customer Service Help line on 0844 701 6273 or email
[email protected] for immediate dispatch of part.
