Bristan WMNT11 C Mounting instructions

Installation Instructions
and User Guide
Wall Mount 11 First Fix Kit
Model covered:
Model covered:Model covered:
Model covered: WMNT11 C
Please keep this booklet for future
Reference
Installer, when you have read these
instructions please ensure you leave them
with the user

Thank you for choosing Bristan, the UK’s leading taps and showers expert We have
designed this product with your enjoyment in mind To ensure that it works to its
full potential, it needs to be fitted correctly These fitting instructions have been
created to give you all of the information you need and, if you need any further help,
please do not hesitate to give us a call on 0844 701 6273
• Please read these instructions thoroughly and retain for future use
• All products manufactured and supplied by Bristan are safe provided they are installed
correctly, used correctly and receive regular maintenance in accordance with these
instructions
•If you are in any doubt about your ability to install this product safely you must
If you are in any doubt about your ability to install this product safely you must If you are in any doubt about your ability to install this product safely you must
If you are in any doubt about your ability to install this product safely you must
employ the services of an experienced qualified plumber
employ the services of an experienced qualified plumber employ the services of an experienced qualified plumber
employ the services of an experienced qualified plumber
• Remove all packaging and check all components before starting installation
• Warning:
Warning: Warning:
Warning: Before starting any installation please consider the following: Prior to
drilling into walls, check that there are no hidden electrical wires, cables or water
General Information
drilling into walls, check that there are no hidden electrical wires, cables or water
supply pipes This can be checked with the aid of an electronic detector
• If power tools are used do not forget to: - Wear eye protection
- Unplug equipment after use
•This product must not
must not must not
must not be modified in any way as this will invalidate the guarantee
•Your fitting has components with a high quality finish and should be treated with care
to preserve the visible surfaces All finishes will wear if not cleaned correctly The only
safe way to clean your product is to wipe with a soft damp cloth Stains can be
removed using washing up liquid All bathroom cleaning products (powders and
liquids) will damage the surface of your fitting, even the non-scratch cleaners
Note:
Note:Note:
Note: Never use abrasive detergents or disinfectants or those containing alcohol,
hydrochloric acid or phosphoric acid
Bristan recommend E-cloth for cleaning all of our bathroom & kitchen
products Using just water, E-cloth gives a smear free, deep clean by
breaking up and holding dirt, which normal cloths leave behind Order
through your Bristan stockist (order code: ECLOTH)
2Need help?
Need help? Need help?
Need help? Give us a call on 0844 701 6273
0844 701 6273 0844 701 6273
0844 701 6273 and speak to one of our trained advisors

Installation
1 Choose position
1 Choose position1 Choose position
1 Choose position
Choose the position where the wall
mount fixing will be installed
Mark a 230mm x 50mm rectangle on
the plaster board wall surface where
the wall mount fixing is to be fitted
Warning:
Warning: Warning:
Warning: Please check for any
hidden electrical wires, cables or
water supply pipes before drilling /
cutting into the wall
Cut out the marked rectangle in the
plaster board
230mm
50mm
plaster board
2 Terminate pipework
2 Terminate pipework2 Terminate pipework
2 Terminate pipework
Terminate sufficient 15mm diameter
supply pipes 150mm apart through the
plasterboard wall surface ensuring a
sufficient amount protrudes through
the wall surface
3 Fit backplate
3 Fit backplate3 Fit backplate
3 Fit backplate
Push the backplate over the
protruding pipework
3
Need help?
Need help? Need help?
Need help? Give us a call on 0844 701 6273
0844 701 6273 0844 701 6273
0844 701 6273 and speak to one of our trained advisors

Installation
4 Secure backplate
4 Secure backplate4 Secure backplate
4 Secure backplate
The backplate has two methods of
fixing
a) Tighten backplate fixing lugs
a) Tighten backplate fixing lugsa) Tighten backplate fixing lugs
a) Tighten backplate fixing lugs
Tighten the two screws in the middle
of the backplate and the two screws
either side of the inlet holes By
tightening these screws it will
tighten the backplate fixings lugs
against the plaster board
b) Screw backplate to wall
b) Screw backplate to wallb) Screw backplate to wall
b) Screw backplate to wall
Using suitable screws secure the
backplate to the plasterboard wall
surface The backplate has holes in
surface The backplate has holes in
each corner to allow for suitable
fixings
5 Cut pipework
5 Cut pipework5 Cut pipework
5 Cut pipework
Once the backplate has been
secured to the wall surface the
pipework will need to be cut back
There must be10mm +/-2mm
of pipework protruding past the
brass insert on the backplate
4Need help?
Need help? Need help?
Need help? Give us a call on 0844 701 6273
0844 701 6273 0844 701 6273
0844 701 6273 and speak to one of our trained advisors

Installation
6 Fit olive and connector
6 Fit olive and connector6 Fit olive and connector
6 Fit olive and connector
Place the olives over the protruding
supply pipework
Screw the threaded fixing bridge
connectors onto the backplate until
just tight and then tighten a
further ½ to ¾ turn to
compress the olives
7 Finish wall surface
7 Finish wall surface7 Finish wall surface
7 Finish wall surface
Complete the wall surface by tiling
over the backplate as shown in the
diagram opposite
This wall fixing is suitable for tile
5
Need help?
Need help? Need help?
Need help? Give us a call on 0844 701 6273
0844 701 6273 0844 701 6273
0844 701 6273 and speak to one of our trained advisors
This wall fixing is suitable for tile
thicknesses between 6-15mm
8 Fit shrouds
8 Fit shrouds8 Fit shrouds
8 Fit shrouds
Screw the shrouds onto the threaded
fixing bridge connectors The front
shrouds can be adjusted to suit
different thicknesses
Once installed this wall mount fixing
kit will accept all bar type showers
with 150mm centres
Rear Shroud
Front Shroud

Guarantee
Bristan offers solid guarantees to provide
you with complete peace of mind
Taps and Mixers
Taps and MixersTaps and Mixers
Taps and Mixers
5 year parts and 1 year labour*
Gold, painted and special finishes
3 years parts only
All subject to proof of purchase
Mixer Shower Valves
Mixer Shower ValvesMixer Shower Valves
Mixer Shower Valves
1 year parts 1 year labour* (subject
to registration), or 1 year with proof of
purchase
Gold, painted and special finishes 3 years
parts only
Pumps and Power Showers
Pumps and Power Showers Pumps and Power Showers
Pumps and Power Showers
2 year parts 1 year labour* (subject to
registration)
Electric Showers/Instantaneous Water
Electric Showers/Instantaneous Water Electric Showers/Instantaneous Water
Electric Showers/Instantaneous Water
Heaters
HeatersHeaters
Heaters
*Labour provided by an approved Bristan
engineer Guarantee only applies to products
with a manufacturing fault A deferred
payment will be necessary in order to secure
any visits by our engineers which will be
charged if the problem is found not
notnot
not to be a
manufacturing fault If the fault is found to be
down to a manufacturing error, the payment
will be released and not charged
This guarantee applies to products purchased
within the United Kingdom or Republic of
Ireland, but does not apply to products used
commercially
The guarantee is only available to original
purchasers who have proof of purchase
The installation must allow ready access to all
products for the purpose of inspection,
maintenance or replacement
Any part found to be defective during the above
Heaters
HeatersHeaters
Heaters
2 year parts 1 year labour* (subject to
registration)
Accessories
AccessoriesAccessories
Accessories
5 year parts only Includes bathrooms
accessories, shower accessories (e g
hoses, handsets and poles), wastes, WC
levers and light pulls Gold, painted and
special finishes 3 years parts only
Sanitaryware
SanitarywareSanitaryware
Sanitaryware
5 year parts only Subject to proof of
purchase
Shower Enclosures and Shower Trays
Shower Enclosures and Shower Trays Shower Enclosures and Shower Trays
Shower Enclosures and Shower Trays
10 year parts (subject to registration), or 2
years with proof of purchase 1 year
labour* (subject to registration), or 1 year
with proof of purchase
Heated Towel Rails
Heated Towel RailsHeated Towel Rails
Heated Towel Rails
5 year parts only Gold, painted and special
finishes 3 years parts only All subject to
proof of purchase
Any part found to be defective during the above
guarantee period will be replaced without
charge, providing that the product has been
installed in accordance with the instructions,
used as intended, and regularly serviced
Servicing should be carried out at regular
intervals of no more than 12 months and more
frequently in hard water areas (heavy lime
scale) areas
In the unlikely event that any problems are
encountered with the product’s performance
on installation, you must obtain
guidance/authorisation from our Customer
Service Department, and be able to supply
proof and date of purchase, before any
remedial action is taken
The guarantee excludes general wear and tear
and damage caused by accident, misuse or
neglect, and does not cover the following:
6Need help?
Need help? Need help?
Need help? Give us a call on 0844 701 6273
0844 701 6273 0844 701 6273
0844 701 6273 and speak to one of our trained advisors

Guarantee & Service Policy
• Components that are subject to general wear and tear such as filters, seals, ‘O’ rings
and washers etc
• Damage caused by faulty installation
• Damage caused by lime scale or any waterborne debris
• Damage caused by inappropriate cleaning products (see cleaning section)
• Damage caused by the use of non-Bristan parts
•The product being used for a purpose other than intended by the manufacturer
In the interests of continuous product improvement Bristan reserves the right to alter
specification as necessary
Replacement Parts Policy
Replacement Parts PolicyReplacement Parts Policy
Replacement Parts Policy
Important:
Important:Important:
Important:
In the event of product or component malfunction, DO NOT tamper with or remove the product
from site Telephone the Customer Services Department and be prepared with the date of
purchase, model number and a clear description of the complaint
purchase, model number and a clear description of the complaint
Our service staff are fully qualified to advise on correct installation procedures and will be able
to diagnose whether the fault will require a replacement part or a visit from a Bristan engineer
If required, a service call will be booked and either yourself or an appointed representative (who
should be a person of 18 years or over) must be present during the visit
All site visits to products out of guarantee will be carried out free of any parts or labour charges
provided the conditions of the guarantee have been adhered to (the 2nd to 5th year of the
guarantee is parts only, unless registered)
All site visits to products out of guarantee will be subject to charges for parts and labour
Charges will also be levied on cancelled appointments, unless advised to Bristan at least 24
hours in advance of the agreed date and time
Should a product be discontinued, Spare parts stocks will be maintained, but in the event of a
part becoming unavailable Bristan reserve the right to supply a substitute of equal quality
In order to log an enquiry with us please visit http://www bristan com/customerservice
Please visit: www bristan com/sparesfinder in order to find spare parts for this product
Opening times: Please refer to the Bristan website
Customer Service: Tel: [phone] • Fax: [phone]
Tel: [phone] • Fax: [phone]Tel: [phone] • Fax: [phone]
Tel: [phone] • Fax: [phone]
7
Need help?
Need help? Need help?
Need help? Give us a call on 0844 701 6273
0844 701 6273 0844 701 6273
0844 701 6273 and speak to one of our trained advisors

Part Number: WMNT11 C
Issue: D2
Bristan Group Ltd
Birch Coppice Business Park
Dordon
Tamworth
Staffordshire
B78 1SG
Web: www bristan com
Email: enquire@bristan com
A Masco Company
