Broyhill A101007600 User manual

Eagle Brooke 10x12 ft Soft Top
Gazebo W/C&N
ASSEMBLY INSTRUCTION
ITEM#: A101007600
SKU#: 810452404
Need help? We are here for you!
1.866.578.6569
24/7 • Toll Free

Country of Origin: China Production Number: 2020300015
The limited warranty is extended to the original purchaser and applies to material and manufacturer’s
defect provided the item is maintained with care and used only for personal, residential purposes.
Safety Information
 More than four people are required for this
assembly.
 Some parts may contain sharp edges. Wear
protective gloves.
 When assembling and using this product,
basic safety precautions should always be
followed to reduce the risk of personal
injury and damage to equipment. Please read
all instructions before assembly and usage.
Warranty: 1 Year
WHAT IS COVER?
IMPORTANT
KEEP THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE.
CAUTION: Do not climb on top of the
gazebo. Falling off the gazebo can
result in serious injury.
NOTICE: For outdoor use
DANGER: This unit is heavy! Do not assemble
this item alone.
WARNING: Do not leave the gazebo where there
is a risk of high wind, as possible damage will
occur to the structure.
WARNING: Keep all flame and heat sources
away from this gazebo fabric. This Gazebo is
made with fabric that meets CPAI-84
specifications for flame resistance. It is not fire
proof. The fabric will burn if left in continuous
contact with any flame source. The application
of any foreign substance to the gazebo fabric
may render the flame-resistant properties
ineffective.

3/ 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
IMPORTANT
How many people needed for the installation work
TOOLS NEEDED
Provided in hardware pack

4/ 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
EXPLODED DRAWING

5/ 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
Parts List
Label
Part Number
Description
Qty
Part Image
A
P000200233
Post
4
B
P000100151
Base
4
C
P006100091
Base Cover
4
D1
P000400523
Long left Crossbeam
2
D2
P000400524
Long right Crossbeam
2
E1
P000400525
Short left Crossbeam
2
E2
P000400526
Short right Crossbeam
2
E3
P000500924
Beam connector
4
E4
P005600217
Beam Decorative parts
4
F
P005600123
Decorative parts
4
G
P005700212
Long Netting Tube
4
H
P005700213
Short Netting Tube
4
I
P000600733
Big Roof Sloping Beam
4
J
P000600734
Sloping Beam Lower
Tube
4
K
P000600735
Long Middle Beam
2
L
P000600736
Long Middle Beam Lower
Tube
2

6/ 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
M
P000600737
Short Middle Beam
2
N
P000600738
Short Middle Beam Lower
Tube
2
O
P000500613
Sloping Beam connector
4
P
P000500612
Middle Beam connector
4
Q
P000500611
Big Roof Connector
1
R
P000600732
Small Roof Sloping Beam
4
S
P000500610
Small Roof Connector
1
T1
P005600122
Finial
1
T2
P000100150
Decorative cover
1
U
P005800084
Hook
1
V
P001100297
Small Canopy
1
W
P001100296
Big Canopy
1
X
P001200106
Mosquito Netting
1
Y
P001300049
Curtain
1

7/ 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
Hardware Pack
Label
Part Number
Description
Qty
Add
Part Image
AA
H06015C11
M6 X 15 Bolt
88
5
BB
H06040C11
M6 X40 Bolt
8
1
CC
H19001C11
M6 Flat washer
104
5
DD
H14001C11
M6 Nut
8
1
EE
H13001C11
M6 Spring
washer
8
1
FF
P91206A07001
Plastic Cup
40
2
HH
P12401A01001
Φ8X180 Stake
8
0
II
P90701A07001
Ring
104
6
Z1
H00001C12
M6 Wrench
2
0
Z2
H00002C12
Allen Key
2
0

8/ 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
4X
4X
4X
4X
4X
4X

9/ 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
4X
4X
4X

10 / 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
2X
4X
2X
2X
2X
2X

11 / 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
4X
4X
2X
2X
2X
2X
2X

12 / 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
4X
2X
4X
4X
4X

13 / 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
1X

14 / 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
4X

15 / 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
4X

16 / 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
4X
4X
4X

17 / 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
4X
4X
4X
4X

18 / 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
4X

19 / 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
1X
1X
1X
4X
1X

20 / 35
Country of Origin: China Call 1(866) 578-6569 for assistance.
Or visit us at www.sunjoyonline.com
1X
1X
1X
1X
