369711
Video KIT
Installation manual
01/13-01 PC

2

Video Kit
Installation manual
3
Contents
1 Introduction 4
1.1 Warnings and tips 4
1.2 Basic diagram 5
2 Description 6
2.1 Entrance panel 6
2.2 Internal unit 7
3 Installation 9
3.1 Entrance panel installation 9
3.2 Internal Unit installation 12
3.3 Cable section (mm2) 14
4 Configuration 15
4.1 Entrance panel configuration 15
4.2 Internal unit configuration 16
4.2.1 Selection of the M mode 17
4.2.2 Meaning of the symbols 19
4.2.3 Completing the Quick Configuration 20
4.2.4 Configuration menu 21
5 Badge programming 23
5.1 Manager master badge 23
5.1.1 New manager master badge 23
5.1.2 Deleting the manager master badge 25
5.2 Resident badge 26
5.2.1 New resident badge 26
5.2.2 Cancellation of all the residents badges saved in the memory 28
5.3 Reset 29
6 Diagrams 30
6.1 Diagram with relay door lock 30
6.2 Staircase light control 31
6.3 Secondary door lock control 32
6.4 Diagram with additional internal unit 33
7 Trouble shooting 34
7.1 Adjustment volume 34
7.2 Push to Talk mode 35

4
1.1 Warnings and tips
Before proceeding with the installation read this manual carefully. The guarantee is automatically
cancelled in the case of negligence, incorrect use and tampering by unauthorised people.
The Video KIT must only be used on BTicino 2 wire digital systems.
Old system with bell
Existing system with 3 wires and just call.
230 Vac
PS
BUS TK BUS PI
346830
BUS 2 1
}
346000
032206
IP30
PRI230V~ 50 - 60Hz 260mA
BUS
2-1 27V 1,2A
PRI
New video door entry system
System installed without the need for changing the existing 2 wires: call, video, and door lock.
230 Vac 12 V
1 Introduction

Video Kit
Installation manual
5
1.2 Basic diagram
PS
BUS TK BUS PI
346830
BUS 2 1
230 Vac
}
346000
0322 06
IP30
PRI 230V~ 50 - 60Hz 260mA
BUS
2-1 27V 1,2A
PRI
ON
OFF
MODP
N
BUS
PL S+ S-
A
T SN
P
BUS
A=Door lock pushbutton
S+ S- =18 V; 4 A impulsive;
250 mA holding current (30 Ω max)

6
2.1 Entrance panel
2 Description
6
7
9
3
8
4
5
2
1
1 - Antenna / badge reader
2 - Enable / disable the door lock release confirmation sound
3 - Reset / badge programming pushbutton
4 - Microphone adjustment
5 - Loudspeaker adjustment
6 - Green LED: door open notification
7 - Green LED: communication active
8 - LED flashing green: call forwarded; LED flashing red: system busy
9 - Configurator socket

Video Kit
Installation manual
7
2.2 Internal unit
1 - Microphone.
2 - Colour LCD display; displays the menus which guide the use and programming operation,
shows the pictures taken by the entrance panel or other cameras.
3 - Navigation keypad; navigates inside the menus, confirms (OK key) or cancels (C key) the
programming operations.
4 - Switch ON entrance panel and cycling key.
5 - Connection key; activates/deactivates the sound connection.
6 - Connection LED.
7 - Loudspeaker.
8 - Door lock LED.
9 - Door lock key; activates the electric door lock of the associated or connected entrance panel.
10 - Answering machine status notification LED.
11 - Pushbutton for enabling/disabling the answering machine function.
12 - Call bell exclusion LED. It lights up when the bell volume is set to 0.
2
1
3
5
4
68 7
9
10
11
12

8
3
4
2
1
1 - Connection to the BTicino 2-wire digital system BUS
2 - Stretch end ON/OFF microswitch
3 - Configurator socket
4 - Connector for extra power supply
For proper magnetic coupling between the
Internal Unit and the sound device, it is rec-
ommended to stay 25-35 cm from the front
side of the device.
Remember that the presence of metal and
background noise generated by electric/
electronic equipment (e.g. computers), can
affect the quality and the performance of
the coupling device.
2
5
-3
5 c
m
40cm
Inductive loop use: Switch hearing device in T position.
2 Description

Video Kit
Installation manual
9
3 Installation
3.1 Entrance panel installation
The camera must not be installed in front of large light sources, or in places where the subject
viewed remains in deep shadow. To solve the problems described above change the height at
which the camera is installed, normally 160 to 165 cm, to a height of 180 cm, and face the lens
downwards to improve the quality of the views.
Note: in poor lighting conditions cameras with colour CMOS detector are less sensitive than black/
white cameras. An extra lighting source should be added in poorly lit rooms.
1
2
160 –165 cm 135 –140 cm
140 cm
50 cm
185 mm
106 mm 35 mm
5 mm
max
3

10
4
5
CLAC
1 2
CLAC
4 5
CLAC
3
3 Installation

Video Kit
Installation manual
11
8
7
6
9



Press
hard
5 – 10 mm

12
3.2 Internal Unit installation
The video internal unit must respect the following installation rules:
- it must only be installed indoors
- it must not be exposed to water drops or splashes
- do not block the ventilation openings
- it must be used only on SCS BTicino 2-wire systems.
An improper use of the item can compromise its safety features.
Recommended height, unless different regulations are specified.
168 mm
150 mm
30 mm
160 –165 cm 135 –140 cm
3 Installation

Video Kit
Installation manual
13
1
2
3
4
1
To secure the base in place use wall plugs and screws of suitable sizes.
Do not directly fasten the base to the flush mounted box.
To remove the internal unit from the base lower the securing tab A using a screwdriver and push
the internal unit up.
A

14
D
B C
A
PS
BUS TK BUS PI
346830
IP30
PRI
PRI 230 V~ 50 - 60 Hz 260mA
346000
}
BUS
2 - 1 27V 1,2A
CEBEC
N
N
F
3.3 Cable section (mm2)
A B C D
> 0,2 mm250 m 50 m 50 m 30 m
BTicino L4669
0,35 mm250 m 50 m 50 m 30 m
0,28 mm2140 m 115 m 100 m 30 m
BTicino C9881U/5E
AWG24 UTP5
145 m 80 m 65 m –
BTicino 336904 200 m 200 m 200 m 50 m
One PTT 278 TP – 0,28 mm2200 m 115 m 100 m 30 m
OneSYT + Digital TP – 5/10 145 m 80 m 65 m –
OneSYT + Num TP – 5/10 145 m 80 m 65 m –
GIGA TW CAT5E – AWG24 145 m 80 m 65 m –
One SYT + NumTP – 8/10 200 m 200 m 200 m –
Cable ARB.6060-1 – 6/10 50 m 50 m 50 m –
Cable EV6R – 6/10 50 m 50 m 50 m –
1 mm2– – – 100 m
3 Installation

Video Kit
Installation manual
15
4.1 Entrance panel configuration
Number of the configurator - T
0 = no
configurator 123 4 567
4 s 1 s 2 s 3 s as
pushbutton 6 s 8 s 10 s
Every time the configuration is altered the system must be switched off and back on again,
waiting for about 1 minute.
4 Configuration
P: do not configure
N: do not configure
T: door lock timer relay
S: do not configure
P N T S
Door lock timer with residents badge
Number of the configurator - T
0 = no
configurator 123 4 567
4 s 1 s 2 s 3 s 4 s 6 s 8 s 10 s

16
N = do not configure
P = do not configure
M = mode (it defines the main menu page and therefore the functions that can be used).
4.2 Internal unit configuration
N P M
4 Configuration

Video Kit
Installation manual
17
M=0
M=2
M=3
M=1 M=4
M=5
4.2.1 Selection of the M mode
The main menu page will consist of a set of preset video door entry system and home automation
functions that may be selected with M = 0 – 9.
The page includes 5 functions plus the “Settings” , which opens a page for the adjustment of
the settings and the configuration of the device.

18
M=6
M=7
M=8
M=9
The default configuration is: M=0.
4 Configuration

Video Kit
Installation manual
19
Intercom
Intercom call to the Internal unit with the N address number indicated by the selected icon.
E.g.: INTERCOM 4 intercom call to the internal unit with N = 4).
Activation
Activation of the actuator with the same address as the associated Entrance Panel in-
creased by a number equal to that indicated by the icon selected.
(e.g. ACTIVATION 2 opening of the Entrance Panel door lock (configured with P+2) directly
without the call or activation of actuator 346200 (configured with P+2 and MOD=5) or
activation of actuator 346230 (configured with P+2).
Cycle cameras
Cyclically activates the cameras in the system starting from the associated Entrance Panel
P (just one complete cycle is performed).
Answering machine
It can be used to record audio/video messages from the entrance panel in case of absence;
memos can also be recorded directly from the video Internal Unit.
Staircase lights
Activates the relay which switches the staircase lights ON/OFF.
4.2.2 Meaning of the symbols
Alarms
It only gives the possibility of displaying the status of the alarm central unit and, in case of
alarm, of the type of alarm.
Scenarios
It gives the possibility of activating a scenario configured in the scenario module, and with
the same address as the number shown on the icon.
E.g.: ICON 1 - SCENARIO 1 active.

20
4.2.3 Completing the Quick Configuration
After powering the internal unit, press any key to display the language selection menu.
The display goes off.
The internal unit is ready for normal operation.
The display shows a mask summarising the
configuration made.
Select CONFIRM.
Select the language required from those
offered.
Press OK to confirm the selection.
Press OK to confirm the configuration.
SUMMARY CONFIG.
ADDRESS N : 00
ADDRESS P : 00
MODE M : 06
> CONFIGURATION END
LANGUAGE SELECT
LANGUAGE: - ENGLISH +
> CONFIRM
4 Configuration
