Bticino AXOLUTE Nighter User manual

349320 - 349321
AXOLUTE
Nighter &Whice
Installation manual
09/09-01 PC

1 Introduction 4
1.1 Warnings and tips 4
1.2 Package content 4
2 Description 5
2.1 Main functions 5
2.2 Front view 6
2.3 Video door entry function keys 7
2.4 Navigation keys 7
2.5 Rear view 8
3 Installation 9
3.1 Wall installation with metal base supplied 9
4 Quick configuration 10
5 Advanced configuration 13
5.1 Flexibility in composition 13
5.2 Customisation of texts 14
5.3 Other functionalities 15
5.4 Connection to the pc 16
6 Settings 17
6.1 Configuration menu 18
6.1.1 Options 19
6.1.2 Handset configuration 20
6.1.3 Reset 21
7 Trouble shooting 22
7.1 PUSH TO TALK mode 23
8 Appendix 24
Contents
Installation manual
3
AXOLUTE
Nighter &Whice

4
1 Introduction
1.1 Warnings and tips
Before proceeding with the installation read this manual carefully. The guarantee is automatically
cancelled in the case of negligence, incorrect use and tampering by unauthorised people.
Thus the Axolute Video Station:
- must only be installed indoors;
- must not be exposed to drips or splashes of water;
- must only be used on BTicino digital 2-wire video door entry systems.
1.2 Package content
The package contains:
Axolute Video Station•
Metal base for wall installation•
Installation manual•
User manual•
CD•
Cleaning cloth•

Installation manual
5
AXOLUTE
Nighter &Whice
2 Description
2.1 Main functions
The BTicino Axolute Video Station is the evolution of the video handset which can be used in man-
aging the home system. As well as all the 2-wire digital door entry functions, in systems combined
with the My Home multimedia system, Axolute Video Station can manage the home: from security
to well-being to entertainment (display of the alarm state, sound system, temperature setting in
single rooms) with sound system amplifier function.
It has an 8" colour LCD screen, audio stereo loudspeakers, icon menu, capacitive keypad with blue
LED backlit keys for navigation in the menu and video door entry function keys.
COMBINATIONS
Communication:
Allows access via the main menu page to a set of predefined video door entry function keys:
INTERCOM – intercom call to an audio handset
CAMERA – direct activation of the camera associated to the entrance panel or separate for video
CCTV
ACTIVATION – direct activation of the actuator associated to the entrance panel
SEQUENTIAL SWITCHING – sequential activation of the cameras in the system
Scenarios:
Can activate the first five scenarios saved in the scenario module.
Alarms:
Can display the divided zones, the system state and the last three alarms received with information
on them (date, time and type of alarm).
Sound system:
Can manage the BTicino digital sound system: cycle the sources and the tune/station of the active
source and adjust the volume of the local amplifier (if locally supplied).
Temperature control:
Can monitor the state of the temperature control unit, display and adjust the temperature (manu-
al) in the single zones of the home and set the Protection/Week/Off state.
Multimedia:
Can access and manage the multimedia system.

6
2.2 Front view
2 Description
1
3
4
8" colour LCD screen1 -
Microphone2 -
Navigation keys3 -
Led and Video door entry function keys4 -
2

Installation manual
7
AXOLUTE
Nighter &Whice
2.3 Video door entry function keys
2.4 Navigation keys
Connection key
Activates/deactivates the connection. If a call is received the LED flashes, during the
conversation it shines steadily.
At rest activates the paging function (if enabled).
Door lock key
In connection opens the door lock of the connected Entrance Panel, at rest that of
the associated Entrance Panel.
The LED signals its operation.
Staircase lights
Activates the staircase light relay.
Mute
Disables/enables the microphone during a sound connection. Activating the Mute during
the conversation the connection key LED turns red.
Call Exclusion
Disables/enables the call bell. If the bell is disabled, the exclusion LED lights up and the
Connection LED signals the call (flashing)
Activation Entrance Panel/Cycling
Activates the switching ON of the associated Entrance Panel and cycles any other Entrance
Panels/cameras.
key
Gives access to the menu; confirms the selection made.
keys
Inside the menus change the value set.
In audio/video connection allow quick access to the audio/video adjustments.
keys
Inside the menus selects the previous or next item.
key
Returns to the previous screen. If on the first screen switches the display OFF.

8
2.5 Rear view
Configurator socket1 -
Mini-USB connector for connection to the PC2 -
Loudspeakers to play voice and stereo sound3 -
Screw to fasten the Video Station to the metal base4 -
Connector for extra power supply5 -
Connector for connection of the BTicino 2-wire digital system BUS6 -
Stretch end ON/OFF microswitch7 -
2
3
71
2 Description
34
5
6
33

Installation manual
9
AXOLUTE
Nighter &Whice
3 Installation
3.1 Wall installation with metal base supplied
To fasten the base use screw anchors and screws of the correct size.
Do not fasten the base directly to the flush-mounted box.
To complete the installation turn the fastening screw
in the lower part of the Video Station anticlockwise.
Make sure that the nut
is positioned at the
lower end.
After making all the connections fasten
the Axolute Video Station to the base
being careful to arrange the wires so
that they are not damaged.
1 2 3 4
7
8
5
BUS 12
346000
230 Vac
6

10
4 Quick configuration
N = (in double figures) address of the device in the video door entry system
P = address of the Entrance Panel associated with the device
M = mode (defines the main menu page and thus the functions which can be used)
CAUTION
If the device is configured by configurations the con-
figuration CANNOT BE EDITED from the menu
The quick configuration is recommended for standard video door entry systems where no special
functions are required and short installation times are important.
In this case the device is configured physically, inserting the configurators in sockets N, P and M.
The configurator in M defines the video door entry mode corresponding to a predefined set of five
video door entry functions.
QUICK CONFIGURATION BY MEANS OF M CONFIGURATOR
Note: If the apartment has the 2-wire apartment interface item 346850 the Axolute Video Station
should be configured using Advanced Configuration

Installation manual
11
AXOLUTE
Nighter &Whice
M= 6
Selection of mode M
The main menu page will be made up of a set of predefined video door entry functions which can
be selected with M = 0 – 6.
M= 0
M= 1
M= 2
M= 3
M= 4
M= 5
The main menu page always has
the ve selected functions plus
SETTINGS which goes to a page
dedicated to the device settings
and congurations.
INTERCOMMUNICATING I
INTERCOMMUNICATING I
CAMERA I
ACTIVATION I
CAMERA I
CAMERA I
ACTIVATION I

12
Completing the Quick Configuration
After the Axolute Video Station has been configured and switched on the red “connection LED”
flashes, to indicate that the configuration must be finished.
Press any key, the Axolute Video Station display shows the language selection menu.
SUMMARY CONFIG.
ADDRESS N : 01
ADDRESS P : 02
MODE M : 06
> CONFIGURATION END
LANGUAGE SELECT.
LANGUAGE: -ENGLISH+
> CONFIRM
4 Quick configuration
IINTERCOMMUNICATING: intercommunicating call to the Handset with address N same
as the number indicated by the icon selected. (e.g.: INTERCOMMUNICATING 4 intercom-
municating call address to the Handset with N = 4)
CAMERA: direct activation of the camera with the same address as the associated Entrance
Panel increased by a number equal to that indicated by the icon selected. (e.g. CAMERA 2
activates the camera with address P+2)
ACTIVATION: activation of the actuator with the same address as the associated Entrance
Panel increased by a number equal to that indicated by the icon selected.
(e.g. ACTIVATION 3 opening of the Entrance Panel door lock (configured with P+3) directly
without the call or activation of actuator item 346200 (configured with P+3 and MOD=5)
or activation of actuator item 346230 (configured with P+3)
CYCLE CAMERAS: cyclically activates the cameras in the system starting from the associ-
ated Entrance Panel P (just one complete cycle is performed)
The display shows a mask summarising the configuration
made
The display and the connection LED go out.
The Axolute Video Station is ready for normal working.
Select CONFIRM
Select the language required from those offered
Press OK to confirm the selection
Press OK to confirm the configuration

Installation manual
13
AXOLUTE
Nighter &Whice
Configuration from PC by means of the TiAxoluteNighterAndWhiceStation software in the CD sup-
plied lets you configure the main menu page without being limited to a predefined set of func-
tions. The type, parameters and text of each function can be customised.
Greater flexibility in composing the menu.•
Customisation of texts.•
Other ways of managing the house-automation systems•
the call to a second-level page containing mixed functions can be entered•
enter the PROFESSIONAL STUDIO, HANDSFREE, PAGING and MULTIMEDIA commands, which•
otherwise can only be called from the SETTINGS menu, in the first page or in a second level
page.
5 Advanced configuration
the first page can be written with the functions and the house-automation systems which•
your system effectively has
5.1 Flexibility in composition
PERSONAL
BEDROOM
PERSONAL
PAGING

14
5.2 Customisation of texts
The items in the Axolute Video Station menu (e.g. SCENARIO 4 = Night SCEN,
COMMUNICATION = Intercom in the home) can be customised.
The following are also possible for the following systems:
ALARMS
customise the messages associating a descriptive text to the zone where the alarm comes from•
change the channel combination - type of alarm.•
5 Advanced configuration
TEMPERATURE CONTROL
customise the description of 10 system zones•
SOUND SYSTEM
customise the description of 6 Rooms/Amplification sound points•
customise the description of 4 sources•
BEDROOM
10/06 10:20
DRAWING
CD
KITCHEN
22.5 (+2)
18.5 °C
20.5 °C

Installation manual
15
AXOLUTE
Nighter &Whice
COMMUNICATION
INTERCOMMUNICATING I
SCENARIO I
5.3 Other functionalities
SCENARIOS AND COMMUNICATION
More than one call for scenarios and communication can be added in the first page.
In this way up to 30 scenario or communication functions can be entered
SOUND SYSTEM
can select and control up to 6 Rooms/Amplification sound points, specifying the address•
wanted
can select and control up to 4 Sources, specifying the address wanted•
TEMPERATURE CONTROL
select and control up to 10 system zones, specifying the address wanted•
In the example at the side 12 communication functions and 18 scenarios can be entered.

16
5.4 Connection to the pc
To transfer the configuration made with the TiAxoluteNighterAndWhiceStation software or up-
date the firmware connect to the Axolute Video Station to the PC using USB-miniUSB cable.
In order for the communication to occur, the Axolute Video Station must be powered and not
physically configured.
5 Advanced configuration
BUS

Installation manual
17
AXOLUTE
Nighter &Whice
After configuring the Axolute Video Station, you can view and modify the configuration settings
in the SETTINGS menu.
6 Settings
CONFIGURATION
ADJUSTMENT
SERVICES
MESSAGGES
BELLS
INFORMATION
For information about these
menus please consult the User
manual in the CD enclosed.
AREA RESERVED FOR
CONFIGURATION OF
THE DEVICE
! WARNING !
OPTIONS
PARAMETER MODE
H CONFIGURATION
RESET
SETTINGS
SETTINGS
CONFIGURATION

18
CONFIGURATION
SETTINGS
Access to the Configuration menu
6.1 Configuration menu
6 Settings
! WARNING !
AREA RESERVED FOR
CONFIGURATION OF THE
DEVICE
> QUIT
CONTINUE
! WARNING !
AREA RESERVED FOR
CONFIGURATION OF THE
DEVICE
QUIT
> CONTINUE
A WARNING message is displayed
Select CONFIGURATION
Press OK to confirm
Select SETTINGS
Press OK to confirm
Select CONTINUE
Press OK to confirm
Select QUIT
Press OK to quit

Installation manual
19
AXOLUTE
Nighter &Whice
> OPTIONS
PARAMETER MODE
H CONFIGURATION
RESET
> SLAVE <NO>
MASTER CLOCK <NO>
PAGING <NO>
DEFAULT
SLAVE <NO>
MASTER CLOCK <NO>
PAGING <NO>
> DEFAULT
SLAVE – the Video Station configured <YES> allows the
installation of several Video stations configured with
the same N address (max. 3: 1 MASTER – 2 SLAVE).
MASTER CLOCK – the Video Station configured <YES>
periodically sends the devices on the system a frame to
synchronise the time
PAGING – the Video Station configured <YES> is ena-
bled to transmit the paging call.
6.1.1 Options
On selecting OPTIONS access is possible to the following system settings.
Select OPTIONS
Press OK to confirm
Select (e.g.: SLAVE)
Select <NO>/<YES>
Press Cto return to the next page
Press OK to confirm
Select DEFAULT to return to the factory settings
(all <NO>)

20
OPTIONS
PARAMETER MODE
> H CONFIGURATION
RESET
H CONFIGURATION
> ADDRESS N :01
ADDRESS P :00
CONFIRM
H CONFIGURATION
ADDRESS N :01
ADDRESS P :00
> CONFIRM
6.1.2 Handset configuration
On selecting H CONFIGURATION the address (N) of the Axolute Video Station and/or the associ-
ated Entrance Panel (P) can be edited.
6 Settings
Select HCONFIGURATION
Press OK to confirm
Select CONFIRM
Press OK to confirm
Press OK to confirm
Select ADDRESS (N) and/or (P)
Select CONFIRM
Set the address
