Bticino HC4051A15US User manual

CAUTION
- To prevent severe shock or electrocution, always turn the power OFF at the service panel before working with wiring
- Improper wiring of any electrical device can cause serious injury or death and should only be installed by an Electrician or other qualified person.
- Install in accordance with national and local electrical codes
- Connect only copper or copper-clad wire to this device
- For ease of wiring when installing more than one device on the 3 modules supporting frame, we recommend the installer to use a 4 inch square junction box with the
appropriate Bticino mudring. This will avoid issues regarding wire fill and will make the wiring neater and easier
-
Grounding: cap green flying lead onto the supporting frame to ground wire in the box Verify Box Fill Rate -> see specific section in technical guide and NEC standards for details.
- Cleaning instrucions: To clean wallplates and devices, use a soft lint-free cloth. Don’t use window cleaners, household cleaners, aerosol sprays, alcohol, ammonia,
abrasives or solvent-based cleaners, that can damage the surface of the products.
G7202A03AP-10W44
Single pole switches
Rocker version:
HC4051A15US HS4051A15US HD4051A15US
HC4251A15US HS4251A15US HD4251A15US
HC4051A20US HS4051A20US HD4051A20US
HC4251A20US HS4251A20US HD4251A20US
Axial version:
HC4001A15US HS4001A15US HD4001A15US
HC4001A20US HS4001A20US HD4001A20US
3-way switches
Rocker version:
HC4053A15US HS4053A15US HD4053A15US
HC4253A15US HS4253A15US HD4253A15US
HC4053A20US HS4053A20US HD4053A20US
HC4253A20US HS4253A20US HD4253A20US
Axial version:
HC4003A15US HS4003A15US HD4003A15US
HC4003A20US HS4003A20US HD4003A20US
Momentary load controller
Rocker version only:
HC4055A15US HS4055A15US HD4055A15US
HC4255A15US HS4255A15US HD4255A15US
4-way switches
Rocker version only:
HC4054A15US HS4054A15US HD4054A15US
HC4054A20US HS4054A20US HD4054A20US
Led lamp for backlight
H4744B127
1) Wiring diagrams
1 2
L
1 2
L
1 2
L
1 2
L
1 2
L
N
L
L
1
L
N
L
1
2 L
1
2
L
1
2
L
N
L
1
2
L1
1
L2
N
L
L
1
L1
1 2 2
L2
N
L
L
1
L
N
L
1
2 L
1
2
L
1
2
L
N
L
1
2
L1
1
L2
N
L
L
1
L1
1 2 2
L2
N
L
L
1
L
N
L
1
2 L
1
2
L
1
2
L
N
L
1
2
L1
1
L2
N
L
L
1
L1
1 2 2
L2
N
L
L
1
L
N
L
1
2 L
1
2
L
1
2
L
N
L
1
2
L1
1
L2
N
L
L
1
L1
1 2 2
L2

2) Installation of a lamp for back-light
Depending on type of connection made, it is possible to achieve three different functions
2.1) Pilot
a) Single Pole Switch
b) Two 3-way switches (extra cable required)
c) Two 3-way + a 4-way switches (extra cable required)
Back-Light is when Load is
ON ON
OFF OFF
L1
1 2
L2
HOT (Black)
NEUTRAL (White)
GROUND (Green or Bare copper)
“TRAVELER” for 3-way circuit (Red)
Wire of backlight lamp
L
1
L 2
1
L 2
1
L 2
1
L 2
1
L1
1 2
L2
HOT (Black)
NEUTRAL (White)
GROUND (Green or Bare copper)
“TRAVELER” for 3-way circuit (Red)
Wire of backlight lamp
L
1
L 2
1
L 2
1
L 2
1
L 2
1
L1
1 2
L2
HOT (Black)
NEUTRAL (White)
GROUND (Green or Bare copper)
“TRAVELER” for 3-way circuit (Red)
Wire of backlight lamp
L
1
L 2
1
L 2
1
L 2
1
L 2
1

2.2) Illuminated
Not recommended for Compact Fluorescent Lamps (CFLs), refer to 2.1 or 2.3 for CFLs wiring options.
a) Single Pole Switch
b) Two 3-way switches
c) Two 3-way + a 4-way switches
Back-Light is when Load is
ON OFF
OFF ON
L
1
L 2
1
L 2
1
HOT (Black)
NEUTRAL (White)
GROUND (Green or Bare copper)
“TRAVELER” for 3-way circuit (Red)
Wire of backlight lamp
L
1
L 2
1
L 2
1
HOT (Black)
NEUTRAL (White)
GROUND (Green or Bare copper)
“TRAVELER” for 3-way circuit (Red)
Wire of backlight lamp
L1
1 2
L2
L 2
1
L 2
1
L
1
L 2
1
L 2
1
HOT (Black)
NEUTRAL (White)
GROUND (Green or Bare copper)
“TRAVELER” for 3-way circuit (Red)
Wire of backlight lamp

L 2
1
L 2
1
HOT (Black)
NEUTRAL (White)
GROUND (Green or Bare copper)
“TRAVELER” for 3-way circuit (Red)
Wire of backlight lamp
L1
1 2
L2
L
1
L 2
1
L 2
1
L 2
1
L 2
1
HOT (Black)
NEUTRAL (White)
GROUND (Green or Bare copper)
“TRAVELER” for 3-way circuit (Red)
Wire of backlight lamp
L1
1 2
L2
L
1
L 2
1
L 2
1
L 2
1
L 2
1
HOT (Black)
NEUTRAL (White)
GROUND (Green or Bare copper)
“TRAVELER” for 3-way circuit (Red)
Wire of backlight lamp
L1
1 2
L2
L
1
L 2
1
L 2
1
WARRANTY INFORMATION:
Bticino USA warranties its products to be free of defects in materials and workmanship for a period of five years.
There are no obligations or liabilities on the part of Bticino USA for consequential damages arising out of or in
connection with the use or performance of this product or other indirect damages with respect to loss of property,
revenue, or profit, or cost of removal, installation or reinstallation.
Bticino USA Customers Contact:
2800 De La Cruz Blvd
Santa Clara, CA 95050
Phone : [phone]
www.usa.bticino.com
U.S. Patent pending
2.3) Lighted: back-light is always ON.
a) Single Pole Switch
b) Two 3-way switches (extra cable required)
c) Two 3-way + a 4-way switches (extra cable required)
Back-Light is when Load is
ON
OFF
ON
