Burkert 8026 User manual

Quickstart
English Deutsch Français
Type 8026 - 8036 - SE36
Flowmeter and Flow transmitter
Durchflussmessgerät und Durchflusstransmitter
Débitmètre et transmetteur de débit

We reserve the right to make technical changes without notice.
Technische Änderungen vorbehalten.
Sous réserve de modifications techniques.
© Bürkert SAS, 2009 - 2020
Operating Instructions 2012/04_EU-ML 00567366 / Original_FR

3
Type 8026, 8036, SE36 ELEMENT
Contents
1. THE QUICKSTART ..........................................................................................5
1.1. Definition of the term device ........................................................5
1.2. Validity of the quickstart ..................................................................5
1.3. Symbols used .......................................................................................5
2. INTENDED USE ................................................................................................6
3. BASIC SAFETY INFORMATION ...............................................................7
4. GENERAL INFORMATION ...........................................................................8
4.1. Contact .....................................................................................................8
4.2. Warranty conditions ...........................................................................8
4.3. Information on the Internet ............................................................8
5. TYPE LABEL .......................................................................................................9
6. TECHNICAL DATA ........................................................................................10
6.1. Conditions of use .............................................................................10
6.2. Conformity to standards and directives...............................10
6.2.1. Conformity to the pressure equipment directive ..........10
6.2.2. UL certification .....................................................................11
6.3. Materials ...............................................................................................11
6.4. Fluid data ..............................................................................................12
6.5. Electrical data ....................................................................................14
7. INSTALLATION ............................................................................................... 15
7.1. Safety instructions...........................................................................15
7.2. Installation of a Type 8026 on a pipe ....................................17
7.2.1. Install the fitting Type S020 in the pipe .........................17
7.2.2. Install the device into the fitting .......................................18
7.2.3. Complete the installation ...................................................18
7.3. Installation of a Type 8036 on a pipe ....................................18
7.3.1. Install the Type S030 in the pipe .....................................18
7.3.2. Assemble the Type SE36 to the Type S030 ................19
7.3.3. Complete the installation ...................................................19
7.4. Installation of a Type SE36 flow transmitter with
a Type S070 or a Type S077 sensor-fitting in a pipe ....19
7.4.1. Install the Type S070 or Type S077 in a pipe ..............19
7.4.2. Assemble the Type SE36 to the Type S070 or
Type S077 ............................................................................20
7.4.3. Complete the installation ...................................................20
7.5. Wiring ......................................................................................................21
7.5.1. Mating connector with article number 917116 ...........21
7.5.2. Equipotentiality of the installation ....................................21
7.5.3. Device variant with 1 connector, 1 NPN transis-
tor output and 1 current output .......................................23
7.5.4. Device variant with 1 connector, 2 transistor
English

4
Type 8026, 8036, SE36 ELEMENT
outputs and 1 current output ............................................24
7.5.5. Device variant with 2 connectors ....................................25
8. ADJUSTMENT AND COMMISSIONING ............................................27
8.1. Safety instructions...........................................................................27
8.2. Display module .................................................................................27
8.2.1. Mount the display module .................................................28
8.2.2. Icons and LEDs ...................................................................28
8.2.3. Navigation button ................................................................29
8.2.4. Dynamic functions ...............................................................31
8.3. Operating levels ................................................................................ 31
8.4. Set the data displayed in Process level .............................. 32
8.5. Choose the units for the totalizers displayed in
Process level ......................................................................................33
8.6. Choose the connection mode of the outputs .................. 33
8.7. Set the parameters of the current outputs ........................34
8.8. Set the parameters of the transistor outputs ................... 35
8.9. Activate or deactivate the Hold function ............................. 36
8.10. Adjust the current outputs ..........................................................37
8.11. Enter the K-factor or use a Teach-in procedure ............. 38
9. MAINTENANCE AND TROUBLESHOOTING ..................................39
9.1. Safety instructions...........................................................................39
10. PACKAGING, TRANSPORT ................................................................... 40
11. DISPOSAL .....................................................................................................40
English

5
The Quickstart
Type 8026, 8036, SE36 ELEMENT
1.2. Validity of the quickstart
The quickstart is valid for the following devices:
• Type 8026 flowmeter, from version V2
• Type 8036 flowmeter, from version V2
• Type SE36 flow transmitter, from version V2
Mention V2 is given on the device Type-label. Refer to chpt. 5.
1.3. Symbols used
Danger
Warns against an imminent danger.
▶Failure to observe this warning can result in death or in serious
injury.
Warning
Warns against a potentially dangerous situation.
▶Failure to observe this warning can result in serious injury or
even death.
Caution
Warns against a possible risk.
▶Failure to observe this warning can result in substantial or minor
injuries.
1. THE QUICKSTART
The quickstart describes the entire life cycle of the device. Please
keep the quickstart in a safe place, accessible to all users and any
new owners.
The quickstart contains important safety information.
Failure to comply with these instructions can lead to hazardous
situations. Pay attention in particular to the chapters Basic safety
information and Intended use.
▶Irrespective of the device variant, read the quickstart. If you do not
understand the content of the quickstart, then contact Bürkert.
▶When the symbol is marked inside or outside the device,
carefully read the Operating Instructions.
The quickstart explains how to install, adjust, and commissioning the
device.
A detailed description of the device can be found in the related
Operating Instructions available on the internet at:
country.burkert.com
1.1. Definition of the term device
The term device that is used in the quickstart refers to the following
products:
• Type 8026 flowmeter
• Type 8036 flowmeter
• Type SE36 flow transmitter
English

6
Intended use
Type 8026, 8036, SE36 ELEMENT
notiCe
Warns against material damage.
Indicates additional information, advice or important
recommendations.
Refers to information contained in this quickstart or in other
documents.
▶Indicates an instruction for risk prevention.
→Indicates a work step that you must carry out.
Indicates a result.
2. INTENDED USE
Use of the device that does not comply with the instructions
could present risks to people, nearby installations and the
environment.
Type 8026 flowmeter and Type 8036 flowmeter are intended for
the measurement the flow rate of liquids.
Type SE36 flow transmitter associated with a sensor-fitting is
intended for the measurement of the flow rate of liquids.
▶Use the device in compliance with the characteristics and
commissioning and use conditions specified in the contractual
documents and in the Operating Instructions.
▶Do not use this device for security applications.
▶Only operate a device in perfect working order.
▶Store, transport, install and operate the device properly.
▶Only use the device as intended.
English

7
Basic safety information
Type 8026, 8036, SE36 ELEMENT
3. BASIC SAFETY INFORMATION
This safety information does not take into account any contingencies
or occurrences that may arise during installation, use and maintenance
of the device.
The operating company is responsible for the respect of the local
safety regulations including staff safety.
Risk of injury due to electrical voltage.
▶Before carrying out work on the system or the device, discon-
nect the electrical power for all the conductors and isolate it.
▶If the device is installed either in a wet environment or outdoors,
all the electrical voltages must be of max. 35 V DC.
▶All equipment connected to the device must be double insu-
lated with respect to the mains according to the standard UL/
EN 61010-1.
▶Observe all applicable accident protection and safety regula-
tions for electrical equipment.
Risk of injury due to pressure in the installation.
▶Before any intervention in the installation, stop the circulation of
fluid, cut off the pressure and drain the pipe.
▶Before any intervention in the installation, make sure that there is
no pressure in the pipe.
▶Observe the dependency between the fluid temperature and the
fluid pressure.
Risk of burns due to high fluid temperatures.
▶Use safety gloves to handle the device.
▶Before opening the pipe, stop the circulation of fluid and drain
the pipe.
▶Before opening the pipe, make sure that the pipe is completely
empty.
Risk of injury due to the nature of the fluid.
▶Respect the prevailing regulations on accident prevention and
safety relating to the use of dangerous fluids.
Various dangerous situations
To avoid injury, observe the following instructions:
▶Do not use the device in explosive atmospheres.
▶Do not use the device in an environment incompatible with the
device materials.
▶Do not use fluid that is incompatible with the device materials.
Find the compatibility chart on our homepage:
country.burkert.com
▶Do not subject the device to mechanical stress.
▶Do not make any modifications to the device.
▶Prevent any unintentional power supply switch-on.
English

8
General information
Type 8026, 8036, SE36 ELEMENT
Various dangerous situations
To avoid injury, observe the following instructions:
▶Only qualified and skilled staff may carry out the installation and
maintenance work.
▶Ensure a defined or controlled restart of the process after a
power supply interruption.
▶Observe the general technical rules.
notiCe
Elements and components that are both sensitive to electrostatic
discharges
▶The device contains electronic components that are sensitive
to electrostatic discharges. The components may be damaged
if they are touched by an electrostatically charged person or
object. In the worst case scenario, the components are instantly
destroyed or disabled as soon as they are activated.
▶To minimise or even avoid any damage caused by an electro-
static discharge, take all the precautions that are described in
the EN 61340-5-1 norm.
▶Do not touch any of the live electrical components.
4. GENERAL INFORMATION
4.1. Contact
To contact the manufacturer of the device, use following address:
Bürkert SAS
Rue du Giessen
BP 21
F-67220 TRIEMBACH-AU-VAL
The addresses of our international sales offices are available on the
internet at: country.burkert.com
4.2. Warranty conditions
The condition governing the legal warranty is the conforming use of
the device in observance of the operating conditions specified in the
Operating Instructions.
4.3. Information on the Internet
You can find the Operating Instructions and technical data sheets for
Type 8026, Type 8036 and Type SE36 at: country.burkert.com
English

9
Type label
Type 8026, 8036, SE36 ELEMENT
5. TYPE LABEL
8026 Flow-Meter V2
Supply: 14-36VDC 40W max.
Output: 1x4-20mA 2xTransistors 500 mA Max
Cell: HALL INSERTION SHORT
Process: Temp -15...+100°C, PN10 Bar
Limited by fitting material and fluid temp
IP65-IP67 W41MT
S-N:2024
00560861 1:V+
2:NPN/PNP1
3:0V
4:NPN/PNP2
1
4
5
6
8
2
911
12
14
13
18
15
3
17
19
7
10
16
1. Type of the device
2. Measured quantity
3. Device version
4. Maximum power consumption
5. Maximum current available at a transistor output
6. Nominal pressure of the fluid
7. Manufacturing code
8. Pin assignment of an electrical connection
9. Certification
10. Conformity marking
11. Article number
12. Serial number
13. Warning: Before using the device, take into account the tech-
nical specifications described in the Operating Instructions.
14. IP-Code
15. Restrictions for fluid temperature and fluid nominal pressure
16. Fluid temperature range
17. Sensor specifications
18. Outputs
19. Operating voltage
Fig. 1: Type-label (example)
English

10
Technical data
Type 8026, 8036, SE36 ELEMENT
6. TECHNICAL DATA
6.1. Conditions of use
Ambient temperature –10...+60 °C
Air humidity < 85%, without condensation
Use Indoor and outdoor
▶Protect the device against electromag-
netic interference, ultraviolet rays and,
when installed outdoors, the effects of
the climatic conditions.
IP-Code
1) not evaluated by UL
IP67 1) and IP65 1), according to
IEC / EN 60529
Mating connectors must be wired,
plugged and tightened.
Housing lid must be fully tightened and
locked
Operating condition Continuous operation
Mobility of the device Fixed device
Degree of pollution Degree 2 according to UL/EN 61010-1
Installation category Category I according to UL/EN 61010-1
Maximum height above
sea level
2000 m
6.2. Conformity to standards and
directives
The applied standards, which verify conformity with the EU direc-
tives, can be found on the EU-Type examination certificate and/or
the EU declaration of conformity (if applicable).
6.2.1. Conformity to the pressure
equipment directive
▶Make sure that the device materials or the fitting materials are
compatible with the fluid.
▶Make sure that the pipe DN is adapted for the device or the fitting
used.
▶Observe the fluid nominal pressure (PN) for the device or the
fitting used. The nominal pressure (PN) is given by the device
manufacturer or the fitting manufacturer.
Type 8026 flowmeter, Type S030, Type S070 and Type S077 fit-
tings conform to Article 4, Paragraph 1 of the Pressure Equipment
Directive 2014/68/EU under the following conditions:
• Device used on a piping (PS = maximum admissible pressure;
DN = nominal diameter of the pipe)
Type of fluid Conditions
Fluid group 1, Article 4, Paragraph 1.c.i DN≤25
Fluid group 2, Article 4, Paragraph 1.c.i DN≤32
or PSxDN≤1000 bar
English

11
Technical data
Type 8026, 8036, SE36 ELEMENT
Type of fluid Conditions
Fluid group 1, Article 4, Paragraph 1.c.ii DN≤25
or PSxDN≤2000 bar
Fluid group 2, Article 4, Paragraph 1.c.ii
DN≤200
or PS≤10 bar
or PSxDN≤5000 bar
6.2.2. UL certification
Devices with variable key PU01 or PU02 are UL-certified devices
and comply also with the following standards:
• UL 61010-1
• CAN/CSA-C22.2 n°61010-1
Identification on the device Certification Variable key
UL recognized PU01
Measuring
Equipment
EXXXXXX
®
UL listed PU02
6.3. Materials
Table 1 : Materials, all device variants
Part Material
Housing stainless steel 316L 1.4404,
PPS
Housing seals EPDM
Housing lid PC
Housing-lid seal silicone
Display module PC, PBT
M12 male connector, M12 female
connector
• nickel-plated brass
• stainless steel, on request
Holder of the electrical
connections
stainless steel 1.4404 (316L)
Screws stainless steel
G2'' nut PC
Table 2 : Materials specific to the Type 8026 and in contact with the
fluid
Part Material
Flow-sensor holder PVDF
Holder seal FKM, by default
Paddle-wheel axis, paddle-
wheel shaft Ceramic (Al2O3)
English

12
Technical data
Type 8026, 8036, SE36 ELEMENT
Part Material
Paddle wheel PVDF
Table 3 : Materials specific to the Type SE36
Part Material
Quarter-turn system PC
6.4. Fluid data
10
9
8
7
6
5
4
3
2
1
0
-10 +10 +30 +50 +70 +90 +110
A
PVC (PN10)
PP (PN10)
T (°C)
P (bar)
PVC + PP
PVDF (PN10)
(PN10)
PVDF + Metal
Metal
A: Operating range
Fig. 2: Dependency between the fluid temperature and the fluid
pressure, Type 8026 associated to a fitting Type S020
Type of fitting
• Type 8026 • Type S020
• Type SE36 • Type S030, Type S070 or
Type S077
Fluid temperature
• Type 8026 • –15...+100 °C
Take into account the
dependency between the
fluid temperature and the fluid
pressure. Refer to Fig. 2
• Type 8036, Type SE36 • Refer to the Operating
Instructions that are delivered
with the fitting used.
Fluid pressure Also refer to the requirements
of the Pressure Equipment
Directive: see chpt. 6.2.1
• Type 8026
2) not evaluated by UL
• PN102)
Take into account the
dependency between the
fluid temperature and the fluid
pressure. Refer to Fig. 2
• Type 8036, Type SE36 • Refer to the Operating
Instructions that are delivered
with the fitting used.
English

13
Technical data
Type 8026, 8036, SE36 ELEMENT
Type of fluid
• Type 8026, Type 8036 • Neutral or slightly aggressive
fluids
• Type SE36 with a Type S070
fitting or Type S077 fitting
• Viscous fluids, free of solid
particles
Fluid viscosity
• Type 8026, Type 8036 • 300 cSt max.
• Type SE36 with a Type S070
fitting or Type S077 fitting
• Refer to the Operating
Instructions that are delivered
with the fitting used.
Solid particle rate in the fluid
• Type 8026, Type 8036 • ≤ 1 %
• Type SE36 with a Type S070
fitting or Type S077 fitting
• 0 %
Flow rate measurement for Type 8026 and Type 8036
• Measurement range • 0.3...10 m/s
• Linearity • ±0.5 % of the full scale
(10 m/s)3)
• Repeatability • ±0.4 % of the measured
value3)
• Measurement deviation with
standard K-factor
• ±2.5 % of the measured
value3)
• Measurement deviation with a
Teach-in procedure
• ±1 % of the measured value
(at the value of the teach-in
flow rate)3)
Flow rate measurement for Type SE36 with fitting Type S070
or fitting Type S077
• Measurement range
- viscosity > 5 mPa.s - Type S070: 2...1200 I/min
- Type S077: 2...1200 I/min
- viscosity < 5 mPa.s - Type S070: 3...616 I/min
- Type S077: 3...616 I/min
• Measurement deviation
- with standard K-factor - Type S070: ±0.5 % of the
measured value3)
- Type S077: ±1 % of the
measured value3)
- with K-factor determined
with a teach-in procedure
or with the specific K-fac-
tor, engraved on the fitting
- Type S070: ±0.5 % of the
measured value (at the
value of the teach-in flow
rate)3)
- Type S077: ±0.5 % of the
measured value (at the
value of the teach-in flow
rate)3)
• Repeatability • ±0.03 % of the measured
value3)
3) Determined in the following reference conditions: fluid = water,
water temperature and ambiant temperature = 20 °C, upstream and
downstream distances respected, appropriate pipe dimensions.
English

14
Technical data
Type 8026, 8036, SE36 ELEMENT
6.5. Electrical data
Operating voltage
• device variant with 2 or 3
outputs (2 wires)
• 14...36 V DC
• connection to main supply:
permanent through external
safety extra-low voltage
(SELV) and through limited
power source (LPS)
• filtered and regulated
• oscillation rate: ±10 %
• device variant with 4 outputs
(3 wires)
• 12...36 V DC
• connection to main supply:
permanent through external
safety extra-low voltage
(SELV) and through limited
power source (LPS)
• filtered and regulated
• oscillation rate: ±10 %
Power source (not supplied) • Limited power source
according to UL/EN 60950-1
standards
• or limited energy circuit
according to UL/EN 61010-1,
Paragraph 9.4
Current consumption
• device variant with 2 or 3
outputs (2 wires)
• 25 mA max. (at 14 V DC)
• device variant with 4 outputs
(3 wires)
• 5 mA max. (at 12 V DC)
Current consumption, with
loads on the transistors
1 A max.
Power consumption 40 W max.
Protection against polarity
reversal
yes
Protection against voltage
spikes
yes
Protection against short
circuits
yes, transistor outputs
Current output 4...20 mA, sink or source,
through wiring and through
software setting, 22 mA to
indicate a fault (software setting)
• device variant with only 1
current output (2 wires)
• maximum loop impedance:
1100 W at 36 V DC, 610 W at
24 V DC, 180 W at 14 V DC
• device variant with 2 current
outputs (3 wires)
• maximum loop impedance:
1100W at 36 V DC, 610 W at
24 V DC, 100 W at 12 V DC
English

15
Installation
Type 8026, 8036, SE36 ELEMENT
Transistor output
• device variant with only 1
transistor output
• NPN, 700 mA max.,
1...36 V DC
• device variant with 2 transistor outputs
- type - NPN or PNP. Through wir-
ing and through software
setting
- NPN output - 1...36 V DC, 700 mA max.
(or 500 mA max. if 2 tran-
sistor outputs are wired)
- PNP output - supply voltage, 700 mA
max. (or 500 mA max. if
2 transistor outputs are
wired)
- protection - galvanically insulated,
protected against overvolt-
ages, polarity reversals and
short-circuits
7. INSTALLATION
7.1. Safety instructions
Danger
Risk of injury due to electrical voltage.
▶Before carrying out work on the system or the device, discon-
nect the electrical power for all the conductors and isolate it.
▶If the device is installed either in a wet environment or outdoors,
all the electrical voltages must be of max. 35 V DC.
▶All equipment connected to the device shall be double insu-
lated with respect to the mains according to the standard UL/
EN 61010-1.
▶Observe all applicable accident protection and safety regula-
tions for electrical equipment.
Risk of injury due to pressure in the installation.
▶Before any intervention in the installation, stop the circulation of
fluid, cut off the pressure and drain the pipe.
▶Before any intervention in the installation, make sure that there is
no pressure in the pipe.
▶Observe the dependency between the fluid temperature and the
fluid pressure.
English

16
Installation
Type 8026, 8036, SE36 ELEMENT
Danger
Risk of burns due to high fluid temperatures.
▶Use safety gloves to handle the device.
▶Before opening the pipe, stop the circulation of fluid and drain
the pipe.
▶Before opening the pipe, make sure that the pipe is completely
empty.
Risk of injury due to the nature of the fluid.
▶Respect the prevailing regulations on accident prevention and
safety relating to the use of dangerous fluids.
Warning
Risk of injury due to non-conforming installation.
▶The electrical and fluid installation can only be carried out by
qualified and skilled staff with the appropriate tools.
▶Install appropriate safety devices (correctly rated fuse and/or
circuit-breaker).
▶Respect the installation instructions for the fitting used.
Warning
Risk of injury if the dependency between the fluid pressure
and the fluid temperature is not respected.
▶Observe the dependency between the fluid temperature and the
fluid pressure for the device. Refer to chpt. 6.4.
▶Observe the dependency between the fluid temperature and
the fluid pressure for the fitting used. Refer to the Operating
Instructions of the fitting used.
Warning
Risk of injury due to unintentional switch on of power supply
or uncontrolled restart of the installation.
▶Avoid unintentional activation of the installation.
▶Guarantee a defined or controlled restart of the process after
any intervention on the device.
English

17
Installation
Type 8026, 8036, SE36 ELEMENT
7.2. Installation of a Type 8026 on a
pipe
Follow the next steps to install the Type 8026 flowmeter properly:
7.2.1. Install the fitting Type S020 in the
pipe
→Select a fitting that is adapted to the fluid velocity. Refer to the
chart in the data sheet of the related fitting.
→Choose a place for the fitting on the pipe so that the following
conditions are met:
- air bubbles do not appear in the pipe, in the section around the
sensor (Fig. 3).
- the pipe is always filled in the section around the sensor
(Fig. 3).
Correct
Correct
Incorrect
Incorrect
flow direction
Correct Incorrect
Fig. 3: Air bubbles within the pipe / Filling of the pipe
Caution
Risk of damage when installing the fitting.
▶Respect the installation instructions given in the Operating
Instructions of the fitting.
English

18
Installation
Type 8026, 8036, SE36 ELEMENT
→Install the fitting in the pipe so that the paddle-wheel axis of the
device is horizontal (Fig. 4).
Fig. 4: Mounting positions for an horizontal paddle-wheel axis
7.2.2. Install the device into the fitting
A
B
→Make sure that there is a seal on the
device and that it is not damaged.
Replace the seal if necessary.
→Place nut A on the fitting and insert
circlip B into the groove.
→Carefully insert the device into the
fitting.
If assembly is correct, the device can
no longer rotate on itself.
→Secure the unit with nut A, tightening
only by hand.
Fig. 5: Installation of the flowmeter in the fitting
7.2.3. Complete the installation
→Wire the device (see chpt. 7.5).
→Energize the device.
→With the display module, set the K-factor or determine it through
a Teach-In procedure (see chpt. 8.11).
7.3. Installation of a Type 8036 on a
pipe
A Type 8036 flowmeter is composed of a Type SE36 flow trans-
mitter and a Type S030 sensor-fitting. Follow the next steps to install
the Type 8036 flowmeter properly:
7.3.1. Install the Type S030 in the pipe
→Select a sensor-fitting that is adapted to the fluid velocity. Refer
to the chart in the data sheet of the related fitting.
→Choose a place for the sensor-fitting on the pipe so that the fol-
lowing conditions are met:
- air bubbles do not appear in the pipe, in the section around the
sensor (Fig. 3, chpt. 7.2.1).
- the pipe is always filled in the section around the sensor (Fig. 3,
chpt. 7.2.1).
English

19
Installation
Type 8026, 8036, SE36 ELEMENT
Caution
Risk of damage when installing the fitting.
▶Respect the installation instructions given in the Operating
Instructions of the fitting.
→Install the sensor-fitting in the pipe so that the paddle wheel axis
is horizontal (Fig. 4, chpt. 7.2.1)
7.3.2. Assemble the Type SE36 to the Type
S030
SE36
S030
1
2
3
→1: Insert the flow transmitter in
the sensor holder.
→2: Turn the flow transmitter by a
quarter turn.
→3: To fix the flow transmitter to
the sensor-fitting, tighten the
screw to a torque of max. 1 N·m.
Fig. 6: Assembling the flowmeter
7.3.3. Complete the installation
→Wire the device (see chpt. 7.5).
→Energize the device.
→With the display module, set the K-factor or determine it through
a Teach-In procedure (see chpt. 8.11).
7.4. Installation of a Type SE36 flow
transmitter with a Type S070 or a
Type S077 sensor-fitting in a pipe
Follow the next steps to install the Type SE36 flow transmitter properly
on the Type S070 or Type S077 sensor-fitting, mounted in the pipe:
7.4.1. Install the Type S070 or Type S077
in a pipe
→Select a sensor-fitting that is adapted to the fluid viscosity. Refer
to the data sheet of the related fitting.
Caution
Risk of damage when installing the fitting.
▶Respect the installation instructions given in the Operating
Instructions of the fitting.
English

20
Type 8026, 8036, SE36 ELEMENT
Installation
→Install the sensor-fitting in the pipe so that the oval gear axes are
in the horizontal plane (see Fig. 7).
correct
Incorrect
Fig. 7: The oval gear axes must be horizontal (seen from the front)
7.4.2. Assemble the Type SE36 to the Type
S070 or Type S077
1
23
SE36
S077
S070
1. Insert the flow transmitter in the
sensor holder.
2. Turn the flow transmitter by a quarter
turn.
3. To fix the flow transmitter to the
sensor-fitting, tighten the screw or
the screws to a torque of max. 1 N·m.
Fig. 8: Assembling the flow transmitter with the sensor-fitting
7.4.3. Complete the installation
→Wire the device (see chpt. 7.5).
→Energize the device.
→With the display module, set the K-factor or determine it through
a Teach-In procedure (see chpt. 8.11).
English
