Burlington S14 User manual

Full Traditional High Level Golden Oak WC seat including Medium Ornate Brackets - Chrome S14
Full Traditional High Level Mahogany WC seat including Medium Ornate Brackets - Chrome S15
Full Traditional Low Level Golden Oak WC seat including Medium Ornate Brackets - Chrome S19
Full Traditional Low Level Mahogany WC seat including Medium Ornate Brackets - Chrome S20
C1 - 2
Parts supplied:
Ø6mm
1x
Tools required:
1x
screw
8x
rawl plug
8x
2x 2x 8x
screw
ornate
bracket
fixing bolt
back board
seat
1
Place the seat in the final position. Mark the fixing hole positions
through the pan holes with a pencil on the underside the seat.
Turn the seat over, and place on a protective mat.
Drill holes (recommended depth 15mm) in the marked
positions using the Ø11mm drill bit.
Fix the plugs supplied into the drilled holes using the
allen key.
23
Ø11mm
Ø11mm
ST4.2*12.8mm Ø4.2*38mm
8mm
1x
allen key

C2 - 2
Screw the fixing bolts into the plugs, and attach on the washer.
Reposition the seat with the fixing bolt inserted into the
pan holes. Ensure the position is fit, and fix onto the pan
by sliding up the rubber washer, brass washer and finally
tighten by the nut.
Place the ornate bracket into the fit position. Mark the fixing
hole positions onto the wall and the seat by pencil.
Drill holes using the Ø6mm drill bit following the marked
positions, and insert the wall plugs.
(NOTE: In the event that the wall fixings supplied being
inappropriate for the wall, please source alternatives).
Fix the ornate bracket onto the seat with the screws supplied
following the mark positions.
8x
8x
16x
456
789
Ø6mm
8x
Reposition the seat against the wall, align the ornate
bracket holes with the predrilled holes on the wall, fix onto
the wall by tightening the screw supplied. Finally attach
the back board to the wall and seat using a suitable
mastic for use with wood and tiled surfaces.
