AIR-EAGLE®SR
2.4 GHz RF Receiver
Electro-Hydraulic Solenoid Control
MODEL 38-2100-DC
DESCRIPTION
The AIR-EAGLE SRis an RF system designed for short to medium range
wireless remote control of electrical apparatus in a varietyof industrial
applications. Each system consists of a 4-relay receiver and handheld or
contact input transmitter. The integral high current relays in the receiver
are user-programmable for anycombination of momentaryor latching
operation, and can be directlyinterfaced with the customer's equipmentor
P.L.C. Capable of receiving remotesignals transmitted from up to 300
feet away (with the SR Transmitter) or up to 1200 feetaway (with the SR
Plus Transmitter), the model 38-2100-DC utilizes spread-spectrum
technology and provides theutmost security and reliability even in the
noisiest RF environments.
APPROVALS
United States (FCC) OUR-XBEEPRO
Canada (IC) 4214A-XBEEPRO
Europe (CE) ETSI
APPLICATIONS
Doors, gates, barriers, tail gates, electricallycontrolled hydraulic valves,
propaneshut off controls, winches, anchor lifts, lights, sprinkling systems,
movie screens, curtains, news weather screens, alarm systems, skeet
throwers, saw millapplications, grain or aggregate chutes, conveyor belts,
boat lifts, and more.
INSTALLATION
DISCONNECT DC Power from all equipment before installation.
1. Mount the AIR-EAGLE SR RECEIVER in a convenient location.
2. Install antenna. The unit has an antenna connector located on the
rightside ontheenclosure. Attach the suppliedportable antenna to
this connector.
3. Connect DC power and control to the proper terminals in your control
circuit.
TERMINAL STRIP WIRING
1 N/O Relay #1 7 N/O Relay #3 13 (-) 9-36VDC INPUT
2 C Relay #1 8 C Relay #3 14 (+) 9-36VDC INPUT
3 N/C Relay#1 9 N/C Relay#3
4 N/O Relay #2 10 N/O Relay #4
5 C Relay #2 11 C Relay #4
6 N/C Relay#2 12 N/C Relay#4
Dimensions(withmounting plate) 6.3” L x 4.8”W x 2.3” H
CONTROLS AND INDICATORS
TER1
D6
R11
D7
D3
R3
VR1
D2
MOV1
F1
BP1
BP2
MOV2
REL1
MOV3 MOV4
+
C3
FET3
+
+
INPUT OUT
--
PWR1
D1
R10
C1
C2
FET2
RF1
R9
D4
R8
R4
R5
R2
SEL1
D5
FET1
R6
FET4
LED1
R7
IC1
T1
R1
LED4LED3 REL4REL3 LED2
REL2
3.3V
N/O C N/C
- +
||
1 2
|
|| | | |
N/O C N/C 43
AC/DC INPUT
N/O C N/C N/O C N/C
.
LED1 Illuminates when relay #1 is energized
LED2 Illuminates when relay #2 is energized
LED3 Illuminates when relay #3 is energized
LED4 Illuminates when relay #4 is energized
RF1 RFmodule that receives data from the remote
transmitter
REL1 thru REL4 Four SPDT output control relays
SEL1 Seven dip switches for selecting relay options
and operating frequency

AIR-EAGLE®SR
2.4 GHz RF Receiver
Electro-Hydraulic Solenoid Control
MODEL 38-2100-DC
RELAY & FREQUENCY SET-UP
The unit is shipped from the factory with SEL1 switches in the open
positions. All four relays will operate as maintained momentaryand unit is
receiving commands onfrequency one. If you wish to change these
default settings, follow the instructions on the table below.
Note: On this model, when Relays #1 or #2 are energized, Relay #3
will also be energizedto provide constant power to solenoid.
REMOVE POWER FROM RECEIVER BEFORE CHANGING ANY
OF THE FOLLOWING DIP SWITCH SETTINGS!
RELAY CONFIGURATION
SEL1
SWITCH
NUMBER OPEN CLOSED
"1" Relay #1 momentary Relay #1 toggle/latch
"2" Relay #2 momentary Relay #2 toggle/latch
"3" Relay #3 momentary Relay #3 toggle/latch
"4" Relay #4 momentary Relay #4 toggle/latch
FREQUENCY SET-UP
Frequency
Selection SEL1 –
SWITCH NUMBER
“5”
SEL1 –
SWITCH NUMBER
“6”
1 OPEN OPEN
2 CLOSED OPEN
3 OPEN CLOSED
4 CLOSED CLOSED
OTHER
SEL1
SWITCH
NUMBER
“7”
Reserved for future use
SPECIFICATIONS
DC Input 9 – 36 VDC @ 10 Watts
Relay Contacts SPDT 5 amp @ up to 36 VDCper relay
Fuse Protected 1 amp
Transceiver Frequency 2.4 GHz Spread Spectrum
Receiver Range – Dependant upon transmitter – see below:
Using 38 Series TX Approximately 300 feet
Using 36 Series TX Approximately 1200 feet
Receiver Channels Four independentnetworks
Operating Temperature -40oF to +185oF
Enclosure Polycarbonate /NEMA 4, 4x, 12 + 13
REPLACEMENT PARTS & ACCESSORIES
PC Board 38-2102-DC
2.4GHz Rt. Angle TNC Rubber Duck Antenna 99-ANT-0004
Air-Eagle SR Transmitter 38-1300
Air-Eagle SR Plus Transmitter 36-1300
Optional Antennas/Accessories:
2.4GHz TNC Portable Antenna 49-1201
2.4GHz Mobile Magnetic Mount Antenna 49-2201
2 Ft. Bulkhead Assembly (Used whenmounting
receive inside another enclosure) 49-5004
LIMITED WARRANTY STATEMENT
BWI Eagle Inc. warrants the Air-Eagle Remote Control System, if properly
used and installed, will be free from defects inmaterial and workmanship
for a period of 1 year after date ofpurchase. Said warrantyto include the
repair or replacement of defective equipment. This warranty does not
cover damage due to externalcauses, including accident, problems with
electrical power, usage not in accordance with product instructions,
misuse, neglect, alteration, repair, improper installation, or improper
testing. This limited warranty, and any implied warranties that may exist
under state law, applyonlyto the original purchaser of the equipment, and
last only for as long as such purchaser continues to own the equipment.
This warrantyreplaces all other warranties,express or implied including,
but not limited to, the implied warranties or merchantability and fitness for
a particular purpose. BWIEaglemakes no express warranties beyond
thosestated here. BWI disclaims without limitation, implied warranties of
merchantabilityand fitness for a particular purpose. Some jurisdictions do
not allow the exclusion of implied warranties sothis limitation maynot
apply to you. To obtain warrantyservice, contact BWI Eagle for a return
material authorization. When returning equipment to BWI Eagle, the
customer assumes the risk of damage or loss during shipping and is
responsible for the shipping costs incurred.
