PRODUCT INFORMATION
BULLETIN
105 Bonnie Drive
Butler, PA 16002
724-283-4681
724-283-5939 (fax)
www.bwieagle.com
AIR-EAGLE®SR PLUS
2.4 GHz RF Transceiver
MODEL 36-40100-AC
DESCRIPTION
The AIR-EAGLE SRPLUS TRX is an R.F. transceiver capable of
transmitting and receiving commands from up to 600 feet away. This
model comes equipped with one dry contact input and one 5amp relay
output. When combined with another transceiver this allows the user to
transmit information out and receive a confirming signal back that the
operation was performed. This unit has eight user-selectable network
frequencies to allow multiple systems to operate simultaneously in the
same area without interference.
APPROVALS
United States (FCC)
OUR-XBEEPRO
Canada (IC)
4214A-XBEEPRO
Europe (CE)
ETSI
INSTALLATION
DISCONNECT Power from all equipment before installation.
1. Mount the transceiver in a convenient location.
2. Install control wiring to terminalstrip.
3. Install antenna onto antenna connector located on the right side on
the enclosure.
4. Connect supplied power input cable to your external power source.
TERMINAL STRIP WIRING
TER 3
DRY CONTACT INPUT
TER 2
RELAY OUTPUT
TER 1
AC/DC POWER INPUT
1
Input 1 C
1
N/O
1
100-250 VAC
2
Input 1
2
C (common)
2
100-250 VAC
3
N/C
3
Ground
Dimensions (with mounting plate) 7.07L x 3.57W x 1.62H
CONTROLS AND INDICATORS
Power –LED1
Illuminates green whenunit is powered
TX –LED2
Illuminates red when unit is transmitting
Relay –LED3
Illuminates green whenrelay is energized
RF1
RF module that sends data to the remote
receiver
SEL1
Seven dip switches for selecting options and
network frequency
TER3
Dry contact input
TER2
Relay output
TER1
Power Input

AIR-EAGLE®SR PLUS
2.4 GHz RF Transceiver
MODEL 36-40100-AC
RELAY & FREQUENCY SET-UP
The unit is shipped from the factory with SEL1 switches in the open
positions. The relay will operate as maintained momentary and unit is
receiving commands on frequency one. If you wish to change these
default settings, follow the instructions onthe table below.
1) Remove power from unit.
2) Remove back cover.
3) Select desired settings using table below.
4) Reattach cover and apply power.
5) Programming is now complete.
RELAY CONFIGURATION
SEL1
(SW1-2)
Relay Operation
SW1
SW2
Momentary (default)
OPEN
OPEN
Toggle/Latch
CLOSED
OPEN
Latching
OPEN
CLOSED
Maintained Momentary –Relay mimics button or input –when
depressed or closed, relay will be energized; when released, relay de-
energizes
Toggle/Latch –Relay changes (and holds) its state each time the
corresponding button or input is depressed or closed.
Latching –Relay requires two buttons or inputs for operation –
momentary press of 1st button energizes relay; momentary press of 2nd
button de-energizes relay
OPTIONS
SW #
OPEN
CLOSED
SW3
Vibrating Feedback Off
(default)
Vibrating Feedback On
SW4
Repeater Mode Off (default)
Repeater Mode On
FREQUENCY SET-UP
SEL1
(SW5-7)
Network
Frequency
SW5
SW6
SW7
1 (default)
OPEN
OPEN
OPEN
2
CLOSED
OPEN
OPEN
3
OPEN
CLOSED
OPEN
4
CLOSED
CLOSED
OPEN
5
OPEN
OPEN
CLOSED
6
CLOSED
OPEN
CLOSED
7
OPEN
CLOSED
CLOSED
8
CLOSED
CLOSED
CLOSED
SPECIFICATIONS
Power Input
100-250 VAC, 5 W, 50/60 Hz
Transmitter Frequency
2.4 GHz Spread Spectrum
Transmit Data
Dry Contact Input
RF Output Power
60 mW
Transmit Range
Up to 600 Feet
Note: Max range figures are estimates, based on free-air terrain with limited sources of
interference. Actual range will vary based on transmitting power, orientation of transmitter
and receiver, height of transmitting antenna, height of receiving antenna, weather
conditions, interference sources in the area, and terrain between receiver and transmitter,
including, but not limited to, indoor and outdoor structures such as walls, metal objects,
trees, buildings, hills, and mountains.
RF Networks
Eight Independent Frequencies
Relay Contact
SPDT 5 amp @ 120 VAC or 30VDC
Antenna Connection
TNC Female Connector
Operating Temperature
-40oF to +185oF
Enclosure
Polycarbonate NEMA 4, 12, 13 –IP66
Weight
Approx 2 lbs.
DIMENSIONS

AIR-EAGLE®SR PLUS
2.4 GHz RF Transceiver
MODEL 36-40100-AC
ACCESSORIES
Standard Antenna (Included):
2.4GHz TNC “Rubber Duck” Antenna
49-1201
High Gain Antennas –
Used to help achieve max range in both non line of sight and line
of sight applications. - Contact BWI Eagle for recommendations
2.4GHz Thru-Hole Mount Omni Directional Antenna
49-2201
2.4GHz Magnet Mount Omni Directional Antenna
49-2202
2.4GHz Omni Directional Antenna
49-3201
2.4GHz Yagi Antenna
49-3202
High Quality Coax Cables –
Used to connect external high gain antennas to control unit
Flex Coax Cable w/Connectors –Available
in 5’,15’,25’,30’,40’,60’,80’,100’ Lengths
49-4000-XX
(XX = # of Feet)
Bulkhead Extensions –
Used to provide an external antenna connection whenmounting
control unit inside another enclosure
TNC Male to TNCBulkhead CableAssembly
- Available in 2’, 4’, 7’ Lengths
49-5004-X-ISO
(X = # of Feet)
LIMITED WARRANTY STATEMENT
BWI Eagle Inc. warrants theAir-Eagle Remote Control System, if properly
used and installed, will be free from defects inmaterial and workmanship
for a period of 1 year after date of purchase. Said warranty to include the
repair or replacement of defective equipment. This warranty does not
cover damage due to external causes, including accident, problems with
electrical power, usage not in accordance with product instructions,
misuse, neglect, alteration, repair,improperinstallation, or improper
testing. This limited warranty, and any impliedwarranties that may exist
under state law, apply only to the original purchaser of the equipment, and
last only for as long as such purchaser continues to own the equipment.
This warranty replaces all other warranties, express or implied including,
but not limited to, the implied warranties or merchantability and fitnessfor
a particular purpose. BWI Eaglemakes no express warranties beyond
thosestated here. BWI disclaims without limitation, implied warranties of
merchantability and fitness for a particular purpose. Some jurisdictions do
not allowthe exclusion of implied warranties so this limitation may not
apply to you. To obtain warranty service, contact BWI Eagle for a return
material authorization. When returning equipment to BWI Eagle, the
customer assumes the risk of damage or loss duringshipping and is
responsible for the shipping costs incurred.
DOCUMENT DATE: 10/25/2020 / PRODUCT REV. 4
