C3STROM ASTRO DELUXE User manual

Please turn to the final
page
for tool kit checklist

Some Tips：
If you find typographical / textual errors, or you just have a suggestion for us, please feel free to let
us know by email at [e-mail]. We will offer a coupon as a token of gratitude to you.
We really appreciate your feedback!
We always look forward to seeing your photos or videos on Instagram, Facebook and Twitter. And
don't forget you can tag us on your social media to win large discount coupons.
Also, if you are happy with C3STROM's products and services, you can join our 'Affiliate' program.
Simply share your love of C3STROM with your friends and family to earn cashback rewards. It's a
win-win for everyone!

User Manual
Thank you for purchasing this C3STROM e-bike.
ASTRO DELUXE

Using This Manual
This manual contains detailed information about the product and its equipment, as well as
information about its operation, maintenance, and other useful tips for the owner. Please read it
carefully and familiarize yourself with the e-bike before use, in order to ensure safe use and
prevent accidents.
This manual contains instructions regarding safe operation and many warnings and cautions of
the consequences of improper or incomplete setup, operation, and maintenance. All information
in this manual should be read carefully and if you have any questions, contact C3STROM immedi-
ately. This manual and any other documents accompanying the e-bike should be retained for
future reference, but all contents of this manual are subject to change without notice.
NOTICE: This manual is not intended to be a complete and extensive reference book about service, maintenance,
and/or repairs. Please consult your dealer for service and technical support. You can find more information about our
products or find a dealer via www.c3strom.com. If you lack assembly experience, we recommend you seek assembly
services from your local ebike shop or dealer. Proper assembly and safe riding are essential.

CONTENTS
General Information ----------- 1
1.1. Frame Components ------------------- 1
1.2. Size & Specification ------------------- 2
1.3. PAS & Throttle ------------------------- 3
Battery ------------------------------------ 20
4.1. Battery Information ------------------- 20
4.2. Battery Charging ---------------------- 21
4.3. Battery & Charger Safety Warning - 22
Apps & Display --------------------- 14
3.1. App Download ------------------------- 14
3.2. Fingertip Control --------------------- 15
Assembly ------------------------------- 4
2.1. What’s in the Box ---------------------- 4
2.2. Assembly Process --------------------- 6
1
2
3
4
5
6
7
8
Warranty -------------------------------- 25
7.1. Warranty Terms --------------------- --- 25
7.2. This Limited Warranty Does Not Cover
---------------------------- 26
7.3. Shipping Damage --------------------- 27
7.4. FAQ About Warranty ------------- 27
Maintenance ------------------------- 24
6.1. Cleaning -------------------------------- 24
Tool Kit Checklist --------------- 29
Safety & Warning ----------------- 23

1. General Information
General Information Assembly Apps & Display Battery Safety & Warning Maintenance Warranty
1.1. Frame Components
Rear light
Fender
Rear Suspension
Motor
Chain
Crank Chainwheel Pedal
Disc brake
Front fork
Front light
Handlebar
Display
Half Twist
Saddle
Battery
1

General Information Assembly Apps & Display Battery Safety & Warning Maintenance Warranty
SIZE
A -- Maximum Seat Height 38.2’’
C -- Seat Length 18.3’’
B -- Standover Height 33.7’’
D -- Handlebar Height 39.9’’
E -- Bottom Bracket Height 11.6’’
F -- Front-Center 23.2’’
J -- Head Tube Angle 65°
I -- Total Length 72’’
H -- Wheelbase 48.8’’
G -- Chainstay Length 25.6’’
K -- Top Tube Horizontal 35.7‘’
C3STROM ASTRO DELUXE Specification
Motor
Enhanced 750W,
1800W Peak
Derailleur
single speed
3.5 Inch LCD With USB,
Visual Turn Signals
Removable Lithium-ion
1040Wh (52V20Ah)
SAMSUNG 21700 Cells
35A peak
frame-intergrated controller
Half twist throttle 4-piston hydraulic brake
203mm disc
Display
Aluminum Alloy single
point multi-turn point
Frame
Battery Controller
38T, 127mm
Crank Set
Throttle
20 inch x 4.0 inch
Anti-puncture tires
Tires
Brake
1.2. Size & Specification
2
A
D
B
C
K
J
G
E
F
H
I

General Information Assembly Apps & Display Battery Safety & Warning Maintenance Warranty
1.3. PAS & Throttle
Due to the powerful support of the motor, the rider will approach high speeds much faster than
when riding a conventional bicycle. To get used to this effect, and for your safety, we advise you to
first use the e-bike in a familiar setting without too much traffic in the surrounding area, when
driving it for the first time. When you first start biking, be aware of the electrical powered acceler-
ation that will instantly be provided by the motor. We advise using the lowest power level when
driving for the first time. When switching off pedal assistance, the e-bike can still be used just like
a regular bike. However, please note that when biking without using the battery, the lights of the
e-bike will not be in operation. When set at level 1 or above, the throttle will be on and will
provide smooth acceleration. If the throttle, brake lever, pedal assistance, or lighting are function-
ing abnormally, intermittently, or not working, please stop using your e-bike immediately. With
the throttle on-demand feature, you can use the throttle from a complete stop, rather than
pedaling first, which can help when riding up steep hills or through an area with lots of stop
signs. However, as a general practice, we recommend pedaling first, and before engaging the
throttle, whenever and wherever possible.
3

General Information Assembly Apps & Display Battery Safety & Warning Maintenance Warranty
2. Assembly
2.1. What’s in the box
Fully wrapped C3STROM ASTRO DELUXE with foam and cardboard
4

General Information Assembly Apps & Display Battery Safety & Warning Maintenance Warranty
2.1. What’s in the box
Pedal L*1
Pedal R*1
Charger*1
Charger Cable*1
User Manual*1
4 mm Allen Wrench*1
5 mm Allen Wrench*1
2.5mm Allen Wrench*1
13 / 15 mm DoubleWrench*2
8 / 10 mm DoubleWrench*1
Toolbox
5
Pedal L Pedal R
Charger
User Manual
Charger Cable
TION
REENTION
Keys
13 / 15 mm Double Wrench
15mm
13mm
13 / 15 mm Double Wrench
15mm
13mm
10 / 13 mm Double Wrench
13mm
10mm
5 mm Allen Wrench
4 mm Allen Wrench
2.5 mm Allen Wrench

General Information Assembly Apps & Display Battery Safety & Warning Maintenance Warranty
2.2. Assembly Process
6
Place the carton box upside down, and remove the 4 safe buckles
to lift the cover up.
c3strom.com

General Information Assembly Apps & Display Battery Safety & Warning Maintenance Warranty
2.2. Assembly Process
Please loosen the front wheel.
7

General Information Assembly Apps & Display Battery Safety & Warning Maintenance Warranty
1. Loosen the screws using the 4mm
Allen wrench and take the cap off
here.
3. Remove the display from the handle-
bar, please take care that the screws do
not fall off.
4. Attach the handlebar and tighten the
screws with the 4mm Allen wrench.
2. Loosen the screws with the 2.5mm
Allen wrench.
8
