CAB 4614-200L User manual

Service Manual
4614
MADE IN GERMANY
Stroke-Blow Applicator

2 2
Family Type
Stroke-Blow Applicator 4614-200L
4614-300L
4614-400L
4614-200R
4614-300R
4614-400R
Edition: 03/2019 - Part No. 9009626
Copyright
This documentation as well as translation hereof are property of cab Produkttechnik GmbH & Co. KG.
The replication, conversion, duplication or divulgement of the whole manual or parts of it for other intentions than its original
intended purpose demand the previous written authorization by cab.
Editor
Regarding questions or comments please contact cab Produkttechnik GmbH & Co. KG.
Topicality
Due to the constant further development of our products discrepancies between documentation and product can occur.
Please check www.cab.de for the latest update.
Terms and conditions
Deliveries and performances are effected under the General conditions of sale of cab.
Service Manual
for the following products
Germany
cab Produkttechnik GmbH & Co KG
Karlsruhe
Phone [phone]
www.cab.de
USA
cab Technology, Inc.
Chelmsford, MA
Phone [phone]
www.cab.de/us
Taiwan
cab Technology Co., Ltd.
Taipei
Phone [phone]
www.cab.de/tw
China
cab (Shanghai) Trading Co., Ltd.
Guangzhou
Phone [phone]
www.cab.de/cn
France
cab Technologies S.à.r.l.
Niedermodern
Phone [phone]
www.cab.de/fr
Mexico
cab Technology, Inc.
Juárez
Phone [phone]
www.cab.de/es
China
cab (Shanghai) Trading Co., Ltd.
Shanghai
Phone [phone]
www.cab.de/cn
South Africa
cab Technology (Pty) Ltd.
Randburg
Phone [phone]
www.cab.de/za

3
1 Introduction............................................................................................................................................4
1.1 Instructions...............................................................................................................................................4
1.2 Intended Use............................................................................................................................................4
1.3 Safety Instructions....................................................................................................................................4
1.4 Safety Marking.........................................................................................................................................5
1.5 Environment.............................................................................................................................................5
2 Product Description...............................................................................................................................6
2.1 Important Features...................................................................................................................................6
2.2 Technical Data..........................................................................................................................................6
2.3 Overview without cover............................................................................................................................7
2.4 Contents of Delivery.................................................................................................................................9
3 Operation..............................................................................................................................................10
3.1 Standard Operation................................................................................................................................10
3.2 Cleaning.................................................................................................................................................10
4 Error Messages....................................................................................................................................12
4.1 Error messages of the printer.................................................................................................................12
4.2 Error messages of the applicator...........................................................................................................12
5 Installation............................................................................................................................................13
5.1 Factory default Settings .........................................................................................................................13
5.2 Tools.......................................................................................................................................................14
5.3 Mounting and dismounting the cover.....................................................................................................14
5.4 Mounting the applicator..........................................................................................................................15
5.5 Transportation lock.................................................................................................................................15
5.6 Mounting the Pad...................................................................................................................................16
5.7 Mounting the Blow Tube.........................................................................................................................16
5.8 Connecting the Compressed Air ............................................................................................................17
6 Adjustments .........................................................................................................................................18
6.1 Pad Adjustments....................................................................................................................................18
6.2 Vacuum Adjustments..............................................................................................................................19
6.3 Blow Tube and Support Air Adjustments................................................................................................20
6.4 Adjusting the Sensor on Cylinder Z........................................................................................................21
6.5 Adjusting the Product Sensor.................................................................................................................22
6.6 Lift Speed of Cylinder Z..........................................................................................................................23
6.7 End Position Dampening........................................................................................................................24
6.8 Adjusting the Options for Movement in Direction Z................................................................................24
7 Conguration........................................................................................................................................25
7.1 Method for Changing the Printer Setup..................................................................................................25
7.2 Quick Mode for Setting the Delay Times................................................................................................25
7.3 CongurationParametersoftheApplicator ...........................................................................................26
7.4 Setting the Peel Position........................................................................................................................27
7.5 Activation of Peel-off Mode....................................................................................................................27
8 Test Operation......................................................................................................................................28
8.1 Test Mode without Print Job...................................................................................................................28
8.2 Test Mode with Print Job........................................................................................................................28
9 Spare Parts...........................................................................................................................................29
9.1 Retainer Assembly.................................................................................................................................29
9.2 Pneumatics Retainer Assembly .............................................................................................................30
9.3 Electronics Retainer Assembly...............................................................................................................31
9.4 Guiding Cylinder Assembly 200/300......................................................................................................32
9.5 Guiding Cylinder Assembly 400.............................................................................................................33
9.6 Cylinder Assembly Z 200/300 ...............................................................................................................34
9.7 Cylinder Assembly Z 400 ......................................................................................................................35
10 Drawings...............................................................................................................................................36
10.1 Block Diagram Type 4614/16.................................................................................................................36
10.2 Pneumatic drawing Type 4614/16..........................................................................................................37
10.3 Label Position Type 4614 L....................................................................................................................38
10.4 Label Position Type 4614 R..................................................................................................................39
11 Index......................................................................................................................................................40
Table of Contents

4 4
1 Introduction
1.1 Instructions
Important information and instructions in this documentation are designated as follows:
Danger!
Draws attention to an exceptionally great, imminent danger to your health or life due to hazardous
voltages.
!
Danger!
Draws attention to a danger with high risk which, if not avoided, may result in death or serious injury.
!
Warning!
Draws attention to a danger with medium risk which, if not avoided, may result in death or serious injury.
!
Caution!
Draws attention to a danger with low risk which, if not avoided, may result in minor or moderate injury.
!
Attention!
Draws attention to potential risks of property damage or loss of quality.
i
Note!
Advice to make work routine easier or on important steps to be carried out.



Environment!
Gives you tips on protecting the environment.
Handling instruction
Reference to section, position, illustration number or document.
Option(accessories,peripheralequipment,specialttings).
Time Information in the display.
1.2 Intended Use
• The device is manufactured in accordance with the current technological status and the recognized safety rules.
However, danger to the life and limb of the user or third parties and/or damage to the device and other tangible
assets can arise during use.
• The device may only be used for its intended purpose and if it is in perfect working order, and it must be used with
regard to safety and dangers as stated in the operating manual.
• The device applicator mounted on a cab printer of the Hermes+ series is intended exclusively for applying suitable
materials that have been approved by the manufacturer. Any other use or use going beyond this shall be regarded
as improper use. The manufacturer/supplier shall not be liable for damage resulting from unauthorized use; the
user shall bear the risk alone.
• Usage for the intended purpose also includes complying with the operating manual, including the manufacturer‘s
maintenancerecommendationsandspecications.
i
Note!
The complete and current version of the documentation can be found in the Internet.
1.3 Safety Instructions
!
Attention!
Initiation,adjustmentsandchangingofpartsaretobeperformedbyqualiedservicepersonnelonly.
!
Warning!
This is a class A product. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.
• Before mounting the delivered components disconnect the printer from the power supply and close the shutoff
valve at the applicator.
• Only connect the device to other devices which have a protective low voltage.
• Switch off all affected devices (computer, printer, accessories) before connecting or disconnecting.

5
1 Introduction
• In operation, moving parts are easily accessible.
This applies especially for the zone, where the pad is moved between the starting and the labelling position.
During operation do not reach into that zone and keep long hair, loose clothes, and jewelry distant. Before any
manipulations in those areas, close the shutoff valve.
• The device may only be used in a dry environment, do not expose it to moisture (sprays of water, mists, etc.)
• Do not use the device in an explosive atmosphere.
• Do not use the device close to high-voltage power lines.
• Perform only those actions described in this manual.
• Unauthorized interference with electronic modules or their software can cause malfunctions.
• Otherunauthorizedworkonormodicationstothedevicecanalsoendangeroperationalsafety.
• There are various warning stickers on the device. They draw your attention to dangers. Warning stickers must
therefore not be removed, as then you and other people cannot be aware of dangers and may be injured.
1.4 Safety Marking
1
3
2
1: Risk of injuries by moving parts!
2: The cylinder is under pressure
also if the printer is switched off.
Possibility of residual energy!
3: Danger of crushing to hand and
ngersbythemovingpad!
!
Attention!
Never remove or cover safety markings!
Replace it in case of damage!
Fig. 1 Safety marking
1.5 Environment



Obsolete devices contain valuable recyclable materials that should be sent for recycling.
Send to suitable collection points, separately from residual waste.
The modular construction of the print module enables it to be easily disassembled into its component parts.
Send the parts for recycling.

6 6
2 Product Description
2.1 Important Features
• The supporting air and the vacuum as well as the speed of the cylinder are adjustable. That way the applicator
can be adapted to different label materials and sizes.
• To avoid contamination within the vacuum channels they are cleaned by air pressure impulse at the end of each
application.
• For operation in a system the I/O interface of the printer can be used.
2.2 Technical Data
Label transfer method Blow pad with height sensor
4614 L/R 2100
Label width in mm for Hermes+4 20 -114
for Hermes+6 on request
Label height in mm 20 - 100
Compressed air pressure 0.45 MPa (4.5 bar)
Sound pressure level under 74 dB(A)
Product during
labeling xed ¢
in motion ¢
Labeling onto the
product from the top ¢
from below ¢
sideways ¢
Product height x ¢
variable ¢
Product distance to lower edge
at cylinder stroke 200 mm up to mm 140
300 mm up to mm 240
400 mm up to mm 340
Cycle time about frequency/min.1) 30
1) Determined at 100 mm stroke below device/smallest label height/print speed 100 mm/s .
Table 1 Technical Data

7
2.3 Overview without cover
1
2
3
4
5
6
7
8
12
10
support air
vacuum
13
14
9
Drosselventile Vakuum/Stützluft
y
x
z
11
Throttle valves Vacuum/Support air
Front View
Table 2 Overview - Front View Fig. 2 Throttle Valve Vacuum and Support Air
1 Throttle valve cylinder - move in Z-direction
2 Stopper for the operation mode "Blow on", transport lock
3 Knurled screw for attaching the applicator to the
printer
4 Setting screw to adjust the angle between applicator
and printer
5 Compressed air connector
6 Shutoff valve
7 Setting screw for vertical adjustment cylinder assembly
8 Throttle valve cylinder - move out Z-direction
9 Screwtoxthehorizontalpadposition- X-direction
10 Pad - customized
11 Product sensor
12 Blow tube support air
13 Support air throttle valve
14 Vacuum throttle valve
2 Product Description

8 8
1
17
16
8
12
10
15
Rückansicht
18
19
20
21
22
24
23
z
xy
Back View
Fig. 3 Overview - Back view Fig. 4 Overview - Control system
1 Throttle valve cylinder - move in Z-direction
8 Throttle valve cylinder - move out Z-direction
10 Pad - customized
12 Blow tube
15 Sensor start position cylinder Z
16 Locking for hinges
17 Interface to the printer
18 Valve Cylinder Z
19 Cover plate
20 Valve Blow air
21 Valve Vacuum and Support air
22 PCB Applicator Control
23 PCB Applicator Interfaces
24 Vacuum Generator
2 Product Description

9
2 Product Description
2.4 Contents of Delivery
4
1
3
2
- Applicator (1)
- Screws (part of the pad) (2)
- Blow tube (as ordered) (3)
- Pad (as ordered) (4)
- Documentation
Fig. 5 Contents of delivery
i
Note!
Please keep the original packaging in case the applicator needs to be returned.
!
Attention!
The device and printing materials will be damaged by moisture and wetness.
Set up label printer with applicator only in dry locations protected from splashes, dampness and water.

10 10
3 Operation
3.1 Standard Operation
Check all external connections.
Load the material.
Open the shutoff valve.
!
Attention!
Ensure that the pad is not covered by a label when switching on the printer-applicator system otherwise
the vacuum sensor may be calibrated incorrectly.
Switch on the printer.
i
Note!
If the pad is not in the start position when the printer is switched on an error message appears on the
display.
Press button pause on the printer.
The applicator will move into the starting position and is ready for work.
Press the feed button at the printer.
A synchronization feed is released. The processed labels have to be removed manually. After a few seconds the
printer carries out a short backfeed to position the front edge of the next label at the printing line.
i
Note!
This synchronization also has to be carried out when the print job has been interrupted with the cancel button.
Synchronizing is not necessary when the print head was not lifted between print jobs. This also applies if
the printer was powered off between print jobs.
Start a print job
Start the labelling process via PLC interface.
Error messages during labelling process are shown in the display of the printer Error messages.
3.2 Cleaning
!
Attention!
Never use solvent and abrasive.
2
1
Clean the outside surfaces with multi purpose cleaner.
Remove dust particles and leftover label pieces with a soft
brush and/or vacuum cleaner.
Especially at the slide foil (1) debris may gather. To ensure
an ideal takeover and handling of the label it is necessary
to clean the surface of slide foil at regular intervals.
Clean the surface of the product sensor (1) with glass
cleaner and a cotton bud.
Fig. 6 Cleaning pad with slide foil
