CAMDEN CX-ED1259-L User manual

CX-ED1259-L
‘RIM’ Electric Strike
Installation Instructions
1. Description
Camden CX-ED1259-L Grade 1 RIM strike for pullman
latches offer the very best strike quality and performance.
The strike design delivers unparalleled application exibility,
with eld selectable voltage, fail safe/fail secure operation
and mechanical adjustment of the strike body.
1- 4 PIN power connector
1- 3 PIN door status
connector
4- Wire nuts
2- M5 x self tapping screws
4- M6 x 30 screws
2- M5 x 25 screws
spacers
4- M2.5 x 4 screws
1- MOV
1- Cover plate
This Package Includes:
Page 1 of 3
2. Specifications
Voltage 12/24V AC/DC
Current Draw 280mA@12V DC
140mA@24V DC
Static Strength 1,500 Lbs.
Dynamic Strength 70 Ft-Lbs.
Endurance 1,000,000 Cycles (Factory Tested)
250,000 Cycles (UL Verified)
Fire Rating UL 10C/CAN4-S104
3 hrs. (Fail Secure Only)
Mode Field Selectable
Fail Safe/Fail Secure
Mech. Adjustment Strike Body/Faceplate
Operation AC-Buzz
DC-Silent
Duty Continuous
Latch Bolt Monitor SPDT, 100mA @ 24V DC
Dimensions (Body) 9” H x 1 3/4” W x 1/2” D
(230mm x 45mm x 12.7mm)
3. Dimensions
9" [230.0 mm]
13
4" [45.0 mm]
1
2" [12.7 mm]
UL 1034
Burglary
UL10C/
CAN4-S104,
3hr. Fire rating

CX-ED1259-L ‘RIM’ Electric Strike
1a. Close door, then mark horizontal center line of Push
bar keeper.
2a. Using center line, measure (101.5mm) top and bottom,
then mark for self-tapping screws.
2b. Drill (15mm dia.) Hole, as per template, for
connecting wires
2c. Fix strike body with SCW425T self-tapping screws.
3. Close door, and if necessary, adjust so that strike and
push bar keeper are well aligned, then mark remaining
screw positions.
4a. Remove strike, and drill threads at screws position.
4b. Connect wires as per drawing.
4c. Fix strike with remaining screws (M6 x 30 at both ends /
M5 x 25 in the middle)
4d. Place cover plate on the strike. Install the M2.5 x 4
screws.
4. Installation
Page 2 of 3
R
HORIZONTAL
CENTERLINE
HORIZONTAL
CENTERLINE
Jamb
Self-tapping SCREWS x 2pcs
(SCW425T)
Wire hole
106,5
106,5
213
21,5
R+23
R+28
n15
Jamb
Jamb
M6(2pcs)
Jamb
HORIZONTAL
CENTERLINE
M5(2pcs)
M6(2pcs)
M6 x 30 SCREW x 4pcs
(SC630A)
M5 x 25 SCREW x 2pcs
(SC525E)
Spacer (Install as needed)
M2.5 x 4 SCREW x 4pcs
M2.5(4pcs)
213
90
25
STEP 1
STEP 3
STEP 2
STEP 4
STEP 5
Note: The products are intended to be installed in accordance with the
installation wiring diagram and mechanically assembled drawings
provided with each product. The local authority having jurisdiction (AHJ)
and the National Electric Code, NFPA 70. When installed with a fail secure
manner, the local authority shall be consulted with regard to the use of
possible panic hardware to allow emergency exit from the secure area.
The electric door strike shall be installed in such a way and in such
location as not to impair the operation of an emergency exit or panic
hardware mounted on the door.

Door Status Sensor
(Closed position)
White = N/O
Orange = COM
Grey = N/C
