Camoplast Tatou UTV T4S User manual

Camoplast Solideal Inc.
4162, Burrill - Local A
Shawinigan, (Québec) G9N 0C3- CANADA
E-mail : [e-mail]
Website : www.camoplastsolideal.com
IMPORTANT
The Camoplast UTV T4S, from Camoplast Hi-Performance Tracks,
where first and foremost designed to provide the best
performance in terms of traction and floatation in conditions of
extreme terrain such as deep snow and mud. The track were also
designed for side-by-side type vehicles that can ride at a maximum
speed of 40 km/h (about 70 km/ h on speedometer). Exceeding this
speed when the terrain conditions are dry can cause premature
wear and or major breakdowns on the track system. If breakage
occurs due to excessive speed, damage will not be covered under
normal warranty. It is the user's responsibility to abide by these
terms of use.
IMPORTANT
Please read carefully each part of this document as well as model
specific Installation Guidelines prior to assembling, installing and
using the track system.
IMPORTANT
The way to use the Camoplast Hi-Performance Tracks Camoplast
UTV T4S track system has a direct link with the longevity of the
system components. Sportive driving, rapid direction changes
and repeated fast turns (more specifically on power steering
vehicles) are not advised. This driving manners increase risk of
derailing and can cause premature wear and or major breakdowns
on the track system which will not be covered under normal
warranty.
Original notice
Translations in other languages available at www.camoplastsolideal.com
®and MC are trademarks of Camoplast Solideal Inc.
All rights reserved. ©2015 Camoplast Solideal Inc.
Printed in Canada.

TABLE OF CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
HINTS AND TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
USER NOTICE AND DISCLAIMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
USING THE ATV WITH TRACKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
INSTALLATION, REMOVAL AND RE-INSTALLATION . . . . . . . . . . . . . . . . . . . 16
ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
INSTALLATION OF A RUBBER TRACK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
BREAK-IN PERIOD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
REPLACEMENT OF A WHEEL WITH EXTRACTOR . . . . . . . . . . . . . . . . . . . 40
TENSIONER ALIGNMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
MAINTENANCE SCHEDULE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
LUBRICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
WEAR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
2-YEAR LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
SERIAL NUMBER LOCATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
TECHNICAL SUPPORT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
’’CE’’ DECLARATION OF CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 783

1
INTRODUCTION
INTRODUCTION
Thank you for choosing Camoplast UTV T4S, a Camoplast
Hi–Performance Tracks UTV Track System, (hereinafter
referred to as the "System"). You have made the right choice.
This system will provide you with all the traction, performance
and durability you require for recreational or work purposes and
allows for year-round operation. This track system for utility
vehicle,side-by-side (hereinafter referred to as the "UTV")
provides exceptional floatation with very low ground pressure.
Its strong lightweight steel frame, its internal sprockets, adapted
to the vehicle’s capacity, and its track, specifically designed for
UTV, make it the best system on the market.
SAFETY
This guide uses the following symbols to emphasize particular
information :
CAUTION: Indicates a potentially hazardous situation which, if
not avoided, may result in damage to vehicle components.
NOTE: Indicates supplementary information.
WARNING
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.

2
SAFETY
On the track system frames, the following warning sticker is
affixed:
USER MANUAL - Every user must read User
Manual before attempting to operate vehicle
equipped with track systems. If track systems
are sold or in any way tranferred to a new
user, the User Manual must also be
transferred to the new user.
MOVING PARTS - Hands or fingers caught
between moving parts of the equipment
present a danger to life or limb. Turn motor
off before servicing track systems.
"MAINTENANCE SCHEDULE" SECTION
OF USER MANUAL - Follow instructions
contained in the Maintenance Schedule
section of the User Manual to ensure safe
and long–lasting operation of track systems.
