Canon iPF5000 - imagePROGRAF Color Inkjet Printer User manual

May 9 2006
Service Manual
iPF5000 series
iPF5000

Application
This manual has been issued by Canon Inc. for qualified persons to learn technical theory, installation, maintenance, and repair
of products. This manual covers all localities where the products are sold. For this reason, there may be information in this
manual that does not apply to your locality.
Corrections
This manual may contain technical inaccuracies or typographical errors due to improvements or changes in products. When
changes occur in applicable products or in the contents of this manual, Canon will release technical information as the need
arises. In the event of major changes in the contents of this manual over a long or short period, Canon will issue a new edition
of this manual.
The following paragraph does not apply to any countries where such provisions are inconsistent with local law.
Trademarks
The product names and company names used in this manual are the registered trademarks of the individual companies.
Copyright
This manual is copyrighted with all rights reserved. Under the copyright laws, this manual may not be copied, reproduced or
translated into another language, in whole or in part, without the written consent of Canon Inc.
Caution
Use of this manual should be strictly supervised to avoid disclosure of confidential information.
COPYRIGHT © 2001 CANON INC.
Printed in Japan

Introduction
i
Symbols Used
This documentation uses the following symbols to indicate special information:
Symbol Description
Indicates an item of a non-specific nature, possibly classified as Note, Caution, or Warning.
Indicates an item requiring care to avoid electric shocks.
Indicates an item requiring care to avoid combustion (fire).
Indicates an item prohibiting disassembly to avoid electric shocks or problems.
Indicates an item requiring disconnection of the power plug from the electric outlet.
Indicates an item intended to provide notes assisting the understanding of the topic in question.
Indicates an item of reference assisting the understanding of the topic in question.
Provides a description of a service mode.
Provides a description of the nature of an error indication.
Memo
REF.

Introduction
ii
The following rules apply throughout this Service Manual:
1. Each chapter contains sections explaining the purpose of specific functions and the relationship between electrical and mechanical systems with refer-
ence to the timing of operation.
In the diagrams, represents the path of mechanical drive; where a signal name accompanies the symbol , the arrow indicates the
direction of the electric signal.
The expression "turn on the power" means flipping on the power switch, closing the front door, and closing the delivery unit door, which results in
supplying the machine with power.
2. In the digital circuits, '1'is used to indicate that the voltage level of a given signal is "High", while '0' is used to indicate "Low".(The voltage value,
however, differs from circuit to circuit.) In addition, the asterisk (*) as in "DRMD*" indicates that the DRMD signal goes on when '0'.
In practically all cases, the internal mechanisms of a microprocessor cannot be checked in the field. Therefore, the operations of the microprocessors
used in the machines are not discussed: they are explained in terms of from sensors to the input of the DC controller PCB and from the output of the
DC controller PCB to the loads.
The descriptions in this Service Manual are subject to change without notice for product improvement or other purposes, and major changes will be com-
municated in the form of Service Information bulletins.
All service persons are expected to have a good understanding of the contents of this Service Manual and all relevant Service Information bulletins and be
able to identify and isolate faults in the machine."

Contents
Contents
Chapter 1 PRODUCT DESCRIPTION
1.1 Product Overview ........................................................................................................................................... 1- 1
1.1.1 Product Overview .................................................................................................................................... 1- 1
1.2 Features ........................................................................................................................................................... 1- 1
1.2.1 Printhead................................................................................................................................................... 1- 1
1.2.2 Ink Tank..................................................................................................................................................... 1- 2
1.2.3 Cutter ......................................................................................................................................................... 1- 2
1.2.4 Auto Roll Feed Unit ................................................................................................................................. 1- 2
1.2.5 Consumables............................................................................................................................................ 1- 3
1.3 Product Specifications ................................................................................................................................... 1- 4
1.3.1 Product Specifications ............................................................................................................................ 1- 4
1.4 Detailed Specifications................................................................................................................................... 1- 5
1.4.1 Printing Speed and Direction ................................................................................................................. 1- 5
1.4.2 Interface Specifications........................................................................................................................... 1- 5
1.5 Names and Functions of Components........................................................................................................ 1- 7
1.5.1 Front........................................................................................................................................................... 1- 7
1.5.2 Rear ........................................................................................................................................................... 1- 7
1.5.3 Carriage..................................................................................................................................................... 1- 8
1.5.4 Inside ......................................................................................................................................................... 1- 8
1.6 Basic Operation............................................................................................................................................... 1- 9
1.6.1 Operation Panel ....................................................................................................................................... 1- 9
1.6.2 Printer Stats Transition ......................................................................................................................... 1- 10
1.6.3 Main Menu .............................................................................................................................................. 1- 10
1.7 Safety and Precautions................................................................................................................................1-17
1.7.1 Safety Precautions ................................................................................................................................. 1- 17
1.7.1.1 Moving Parts.................................................................................................................................... 1- 17
1.7.1.2 Adhesion of Ink ............................................................................................................................... 1- 17
1.7.1.3 Electric Parts.................................................................................................................................... 1- 18
1.7.2 Other Precautions .................................................................................................................................. 1- 19
1.7.2.1 Printhead.......................................................................................................................................... 1- 19
1.7.2.2 Ink Tank............................................................................................................................................ 1- 20
1.7.2.3 Handling the Printer........................................................................................................................ 1- 20
1.7.3 Precautions When Servicing Printer ................................................................................................... 1- 22
1.7.3.1 Notes on the Data Stored in the Printer ...................................................................................... 1- 22
1.7.3.2 Confirming the Firmware Version................................................................................................. 1- 22
1.7.3.3 Precautions against Static Electricity........................................................................................... 1- 22
1.7.3.4 Precautions for Disassembly/Reassembly ................................................................................. 1- 22
1.7.3.5 Self-diagno stic Feature................................................................................................................. 1- 22
1.7.3.6 Disposing of the Lithium Battery................................................................................................... 1- 22
Chapter 2 TECHNICAL REFERENCE
2.1 Basic Operation Outline................................................................................................................................. 2- 1

Contents
2.1.1 Printer Diagram ........................................................................................................................................ 2- 1
2.1.2 Print Driving .............................................................................................................................................. 2- 2
2.2 Firmware .......................................................................................................................................................... 2- 2
2.2.1 Operation Sequence at Power-on......................................................................................................... 2- 2
2.2.2 Operation Sequence at Power-off......................................................................................................... 2- 2
2.2.3 Print Control.............................................................................................................................................. 2- 3
2.2.4 Print Position Adjustment Function ....................................................................................................... 2- 4
2.2.5 Head Management .................................................................................................................................. 2- 4
2.2.6 Printhead Overheating Protection Control........................................................................................... 2- 4
2.2.7 Pause between Pages............................................................................................................................ 2- 4
2.2.8 White Raster Skip .................................................................................................................................... 2- 4
2.2.9 Sleep Mode............................................................................................................................................... 2- 4
2.3 Printer Mechanical System ........................................................................................................................... 2- 6
2.3.1 Outline........................................................................................................................................................ 2- 6
2.3.1.1 Outline ................................................................................................................................................ 2- 6
2.3.2 Ink Passage............................................................................................................................................... 2- 6
2.3.2.1 Ink Passage ....................................................................................................................................... 2- 6
2.3.2.2 Ink Tank Unit ..................................................................................................................................... 2- 7
2.3.2.3 Carriage Unit ..................................................................................................................................... 2- 9
2.3.2.4 Printhead.......................................................................................................................................... 2- 12
2.3.2.5 Purge Unit ........................................................................................................................................ 2- 12
2.3.2.6 Maintenance Cartridge................................................................................................................... 2- 16
2.3.2.7 Air Flow............................................................................................................................................. 2- 16
2.3.3 Paper Path............................................................................................................................................... 2- 17
2.3.3.1 Outline .............................................................................................................................................. 2- 17
2.3.3.2 Paper Path ....................................................................................................................................... 2- 18
2.3.3.3 Cutter Unit........................................................................................................................................ 2- 29
2.4 Printer Electrical System ............................................................................................................................. 2- 30
2.4.1 Outline...................................................................................................................................................... 2- 30
2.4.1.1 Overview .......................................................................................................................................... 2- 30
2.4.2 Main Controller ....................................................................................................................................... 2- 31
2.4.2.1 Main controller components.......................................................................................................... 2- 31
2.4.3 Carriage Relay PCB............................................................................................................................... 2- 33
2.4.3.1 Carriage PCB components ........................................................................................................... 2- 33
2.4.4 Motor Driver............................................................................................................................................. 2- 33
2.4.4.1 Cutter driver PCB components..................................................................................................... 2- 33
2.4.4.2 Roll feed unit PCB components ................................................................................................... 2- 33
2.4.5 Maintenance Cartridge Relay PCB ..................................................................................................... 2- 34
2.4.5.1 Maintenance cartridge relay PCB components ......................................................................... 2- 34
2.4.6 Power Supply.......................................................................................................................................... 2- 34
2.4.6.1 Power supply block diagram......................................................................................................... 2- 34
2.5 Detection Functions with Sensors.............................................................................................................. 2- 35
2.5.1 Sensors for covers................................................................................................................................. 2- 35
2.5.2 Ink passage system............................................................................................................................... 2- 36
2.5.3 Carriage system..................................................................................................................................... 2- 38
2.5.4 Paper path system................................................................................................................................. 2- 40
2.5.5 Others ...................................................................................................................................................... 2- 42

Contents
Chapter 3 INSTALLATION
3.1 Installation.........................................................................................................................................................3- 1
3.1.1 Making Pre-Checks ..................................................................................................................................3- 1
3.1.1.1 Making Pre-Checks...........................................................................................................................3- 1
3.1.2 Unpacking and Installation ......................................................................................................................3- 1
3.1.2.1 Unpacking and Installation...............................................................................................................3- 1
3.1.3 Checking the Images/Operations ...........................................................................................................3- 7
3.1.3.1 Checking the Images /Operations ..................................................................................................3- 7
3.2 Transporting the Printer..................................................................................................................................3- 8
3.2.1 Transporting the Printer ...........................................................................................................................3- 8
3.2.1.1 Transporting the Printer....................................................................................................................3- 8
3.2.2 Reinstalling the Printer .............................................................................................................................3- 9
3.2.2.1 Reinstalling the Printer .....................................................................................................................3- 9
Chapter 4 DISASSEMBLY/REASSEMBLY
4.1 Service Parts....................................................................................................................................................4- 1
4.1.1 Service Parts.............................................................................................................................................4- 1
4.2 Disassembly/Reassembly..............................................................................................................................4- 1
4.2.1 Disassembly/Reassembly.......................................................................................................................4- 1
4.3 Points to Note on Disassembly and Reassembly ......................................................................................4- 3
4.3.1 Note on assemblies (or units) prohibited from disassembly..............................................................4- 3
4.3.2 Moving the carriage manually ................................................................................................................4- 3
4.3.3 Units requiring draining of ink.................................................................................................................4- 3
4.3.4 External Covers ........................................................................................................................................4- 4
4.3.5 Driving Unit ..............................................................................................................................................4- 11
4.3.6 Cutter........................................................................................................................................................4- 12
4.3.7 Carriage Unit ...........................................................................................................................................4- 13
4.3.8 Feeder Unit..............................................................................................................................................4- 18
4.3.9 Roll Feed Unit .........................................................................................................................................4- 22
4.3.10 Purge Unit..............................................................................................................................................4- 25
4.3.11 Waste Ink Collection Unit ....................................................................................................................4- 26
4.3.12 Ink Tank Unit .........................................................................................................................................4- 29
4.3.13 Head Management Sensor .................................................................................................................4- 31
4.3.14 Multi Sensor ..........................................................................................................................................4- 32
4.3.15 PCBs ......................................................................................................................................................4- 33
4.3.16 Opening the Cap/Moving the Wiper Unit..........................................................................................4- 33
4.3.17 Opening/Closing the Ink Supply Valve..............................................................................................4- 34
4.3.18 Draining the Ink.....................................................................................................................................4- 34
4.4 Applying the Grease .....................................................................................................................................4- 35
4.4.1 Applying the Grease ..............................................................................................................................4- 35
4.5 Adjustment and Setup Items .......................................................................................................................4- 38
4.5.1 Procedure after Replacing the Feed Roller HP Sensor or Feed Roller Encoder.........................4- 38
4.5.2 Procedure after Replacing the Carriage Unit or Multi Sensor.........................................................4- 38
4.5.3 Procedure after Replacing the Head Management Sensor.............................................................4- 40
Chapter 5 MAINTENANCE

Contents
5.1 Periodic Replacement Parts ......................................................................................................................... 5- 1
5.1.1 Periodic Replacement Parts .................................................................................................................. 5- 1
5.2 Consumable Parts .......................................................................................................................................... 5- 1
5.2.1 Consumable Parts ................................................................................................................................... 5- 1
5.3 Periodic Maintenance..................................................................................................................................... 5- 1
5.3.1 Periodic Maintenance.............................................................................................................................. 5- 1
Chapter 6 TROUBLESHOOTING
6.1 Troubleshooting .............................................................................................................................................. 6- 1
6.1.1 Outline........................................................................................................................................................ 6- 1
6.1.1.1 Outline of Troubleshooting .............................................................................................................. 6- 1
6.1.2 Troubleshooting When Warnings Occur............................................................................................... 6- 1
6.1.2.1 Ink Lvl: Chk XX (1000,1001,1002,1003,1004,1005,1006,1008,1009,100A,100B,100C) ..... 6- 1
6.1.2.2 MTCart Full Soon (1100) ................................................................................................................. 6- 1
6.1.2.3 Mist Full Soon (1101) ....................................................................................................................... 6- 1
6.1.2.4 GARO W12xx: xx stands for digits (1221,1222,1223,1225,1231,1232,1233,1234,1235).... 6- 1
6.1.2.5 Feed Limit... (100F) .......................................................................................................................... 6- 1
6.2 Location of Connectors and Pin Arrangement........................................................................................... 6- 2
6.2.1 Main controller PCB ................................................................................................................................6-2
6.2.2 Carriage relay PCB................................................................................................................................6-13
6.2.3 Cutter driver PCB................................................................................................................................... 6- 20
6.2.4 Power supply .......................................................................................................................................... 6- 21
6.2.5 Roll feed unit PCB ................................................................................................................................. 6- 22
6.3 Version Up ..................................................................................................................................................... 6- 22
6.3.1 Firmware Update Tool .......................................................................................................................... 6- 22
6.4 Service Tools................................................................................................................................................. 6- 23
6.4.1 Tool List................................................................................................................................................... 6- 23
Chapter 7 SERVICE MODE
7.1 Service Mode................................................................................................................................................... 7- 1
7.1.1 Service Mode Operation......................................................................................................................... 7- 1
7.1.2 Service Mode Map................................................................................................................................... 7- 1
7.1.3 Details of Service Mode.......................................................................................................................... 7- 5
7.2 Special Mode................................................................................................................................................. 7- 11
7.2.1 Special Modes for Servicing ................................................................................................................ 7- 11
Chapter 8 ERROR CODE
8.1 Outline .............................................................................................................................................................. 8- 1
8.1.1 Outline ....................................................................................................................................................... 8- 1
8.2 Warning Table ................................................................................................................................................. 8- 1
8.2.1 Warnings ................................................................................................................................................... 8- 1
8.3 Error Table ....................................................................................................................................................... 8- 1
8.3.1 Error Code List ......................................................................................................................................... 8- 1
8.4 Sevice Call Table............................................................................................................................................ 8- 4
8.4.1 Service call errors .................................................................................................................................... 8- 4

Chapter 1 PRODUCT DESCRIPTION

Contents
Contents
1.1 Product Overview .......................................................................................................................................................... 1-1
1.1.1 Product Overview......................................................................................................................................................................... 1-1
1.2 Features.......................................................................................................................................................................... 1-1
1.2.1 Printhead....................................................................................................................................................................................... 1-1
1.2.2 Ink Tank ....................................................................................................................................................................................... 1-2
1.2.3 Cutter............................................................................................................................................................................................ 1-2
1.2.4 Auto Roll Feed Unit ..................................................................................................................................................................... 1-2
1.2.5 Consumables ................................................................................................................................................................................ 1-3
1.3 Product Specifications ................................................................................................................................................... 1-4
1.3.1 Product Specifications.................................................................................................................................................................. 1-4
1.4 Detailed Specifications .................................................................................................................................................. 1-5
1.4.1 Printing Speed and Direction ....................................................................................................................................................... 1-5
1.4.2 Interface Specifications ................................................................................................................................................................ 1-5
1.5 Names and Functions of Components ........................................................................................................................... 1-7
1.5.1 Front ............................................................................................................................................................................................. 1-7
1.5.2 Rear .............................................................................................................................................................................................. 1-7
1.5.3 Carriage ........................................................................................................................................................................................ 1-8
1.5.4 Inside ............................................................................................................................................................................................ 1-8
1.6 Basic Operation ............................................................................................................................................................. 1-9
1.6.1 Operation Panel ............................................................................................................................................................................ 1-9
1.6.2 Printer Stats Transition............................................................................................................................................................... 1-10
1.6.3 Main Menu ................................................................................................................................................................................. 1-10
1.7 Safety and Precautions................................................................................................................................................. 1-17
1.7.1 Safety Precautions ...................................................................................................................................................................... 1-17
1.7.1.1 Moving Parts ................................................................................................................................................................................................. 1-17
1.7.1.2 Adhesion of Ink............................................................................................................................................................................................. 1-17
1.7.1.3 Electric Parts ................................................................................................................................................................................................. 1-18
1.7.2 Other Precautions ....................................................................................................................................................................... 1-19
1.7.2.1 Printhead .......................................................................................................................................................................................................1-19
1.7.2.2 Ink Tank ........................................................................................................................................................................................................ 1-20
1.7.2.3 Handling the Printer ...................................................................................................................................................................................... 1-20
1.7.3 Precautions When Servicing Printer .......................................................................................................................................... 1-22
1.7.3.1 Notes on the Data Stored in the Printer......................................................................................................................................................... 1-22
1.7.3.2 Confirming the Firmware Version................................................................................................................................................................ 1-22
1.7.3.3 Precautions against Static Electricity............................................................................................................................................................ 1-22
1.7.3.4 Precautions for Disassembly/Reassembly ....................................................................................................................................................1-22
1.7.3.5 Self-diagno stic Feature ................................................................................................................................................................................ 1-22
1.7.3.6 Disposing of the Lithium Battery ................................................................................................................................................................. 1-22

Chapter 1
1-1
1.1 Product Overview
1.1.1 Product Overview
0013-2854
This printer is capable of printing on A4- to A2-size cut sheets and its maximum print width is 17 inches. This printer is a desktop large-format printer twelve-color
(dye- and pigment-based colors) printer that can be used to print office documents as well as handy POP and posters. An auto roll feed unit holder is optionally
available for printing on roll media.
F-1-1
T-1-1
1.2 Features
1.2.1 Printhead
0012-6187
Printhead set on the carriage is a 6-color integral disposable type.
On the printhead, two rows of 1,280 nozzles (total 2,560 nozzles) are arranged in a staggered pattern. .
If print quality does not improve despite carrying out the specified cleaning, the printhead must be replaced with a new one. Generally, it is recommended that the
printhead be replaced about 12 months after you have opened the package.
F-1-2
[1] Top Cover [10] Power Supply Connector
[2] Ink Tank Cover [11] Ethernet Connector
[3] Cassette [12] USB Port
[4] Operation Panel [13] IEEE1394 Board(option)
[5] Paper Tray Unit [14] Printhead
[6] Output Stacker [15] Ink Tank
[7] Auto Roll Feed Unit(option) [16] Cleaning Brush
[8] Roll Horder Set(option)
[9] Back Cover
[1]
[2]
[4]
[6]
[5]
[3]
[7]
[9]
[10] [11]
[12]
[8]
[13]
[14] [15] [16]

Chapter 1
1-2
1.2.2 Ink Tank
0013-0608
The ink tank is disposable.
There are twelve pigment-based ink colors (matte black,black,photo cyan,cyan,photo magenta,magenta,yellow,red,blue,green,gray,and photo gray).
This printer features a mechanism by which only the correct color ink tank will fit in the given slot.
When the message No Ink is displayed, replace the ink tank with a new one. Also, each ink tank should generally be replaced six months after you have opened the
package.
F-1-3
1.2.3 Cutter
0013-3524
A round-blade cuter comes with the cutter unit.
F-1-4
1.2.4 Auto Roll Feed Unit
0013-2356
Auto Roll Feed Unit (option)
The auto roll feed unit is optionally available to use roll media with this printer.
F-1-5
Roll holder set (option)
This set consists of roll holder, holder stopper, 3-inch paper tube attachment (two), and borderless printing spacer (commonly used for 2-inch paper tube and 3-inch
paper tube).
[Roll holder]
F-1-6
[Holder stopper]
F-1-7
[3-inch paper tube attachment](2 pcs.)
F-1-8
[Borderless printing spacer]

Chapter 1
1-3
F-1-9
1.2.5 Consumables
0013-0609
Printhead
The consumable print head is the same as that supplied with the printer.
F-1-10
Ink Tanks
The consumable ink tanks are available in twelve colors (matte black, black, photo cyan, cyan, photo magenta, magenta, yellow, red, blue, green, photo gray, and
gray). They are the same as those supplied with the printer. Each ink tank must be replaced with a new one six month after you have opened the package.
F-1-11
Maintenance cartridge
The consumable maintenance cartridge is the same as that supplied with the printer.
F-1-12

Chapter 1
1-4
1.3 Product Specifications
1.3.1 Product Specifications
0013-0610
Type Bubble jet large-sized paper printer
Feeding system Automatic feeding of one roll media (option)/Cassette paper feeding/
One cut sheet (manual feed from front)/One cut sheet (manual feed from
top)
Feeding capacity - Roll media (option)
One roll at the back/Outer diameter of roll: 150 mm or less/Inner
diameter of paper tube: 2 or 3 inches
-Cut sheet
Cassette:250 sheets(A4), 100 sheets(A3), 50 sheets(A2)
Delivery method Delivers the media with its printed side up in the forward direction.
Sheet delivery capability - Roll media (option)
1 sheet
- Cut sheet
50 sheets (plain paper of A3 or smaller) or 20 sheets (plain paper of larger
than A3)
Cutter Automatically cuts paper laterally. Cartridge-type (with round blade)
Type of media Plain paper, plain paper (high quality), plain paper (vivid color), coated
paper, extra heavy coated paper, premium matte paper, high-quality
dedicated paper, matte photo paper, photo glossy paper, photo semi-
glossy paper, photo glossy paper (heavy), photo semi-glossy paper
(heavy), professional photo paper, super photo paper, super photo paper
(silky), glossy paper, synthetic paper, adhesive synthetic paper, proofing
paper, newspaper proofing paper, tracing paper (CAD), semi-translucent
matte film (CAD), POP board
Supported thickness Roll media: 0.07 to 0.8 mm
Cassette: 0.08 to 0.3 mm
Manual feed from top: 0.08 to 0.5 mm
Manual feed from front: 0.5 to 1.5 mm
Media size (Roll media) Maximum size: 432 mm x 18 m
Minimum size: 203.2 mm x 203.2 mm
Maximum outside diameter: 150 mm
Media size (Cut sheet) - Manual feed from top
Maximum size: 432 mm x 609.6 mm (W x L)
Minimum size: 203.2 mm x 279 mm (W x L)
- Manual feed from front
Maximum size: 432 mm x 609.6 mm (W x L)
Minimum size: 203.2 mm x 520 mm (W x L)
Printable area (Roll media) Area excluding 3mm from the top, 3 mm from the bottom, and 3 mm
from the left and right edges.
Borderless printing: 0 mm from the top, bottom, and left and right edges.
Width of media allowing borderless printing:10inches, JIS B4, A3+,
14inches, 16inches, 17inches, ISO A2/A3
Media type allowing borderless printing:Coated paper (heavy), photo
glossy paper, photo semi-glossy paper, photo glossy paper (heavy),
photo semi-glossy paper (heavy), photo glossy paper, photo semi-glossy
paper, fine art (photo), fine art (photo heavy), fine art (painting),
premium matte, fine art (watercolor), fine art (block print)
Printable area (Cut sheet) Area excluding 3 mm from the top, 23 mm from the bottom (3 mm when
supplied from the cassette), and 3 mm from the left and right edges.
Printing assurance area (Roll
media)
Printing assurance area (Roll sheet)
Area excluding 20 mm from top, 20 mm from the bottom and 5 mm from
the left and right edges (standard size).
Printing assurance area (Cut
sheet)
Printing assurance area (cut sheet)
Area excluding 20 mm from the top, 23 mm from the bottom (20 mm
when fed from the cassette), and 5 mm from the left and right edges
(standard size).
Interface USB2.0, Ethernet, IEEE1394 (option)
Printhead/Ink Tank type Printhead and separate ink tanks
Printhead [PF-01] Number nozzles: 2560 nozzles per color
Ink tank [PFI-102]MBK,BK,GY,PGY,R,G,B,C,M,Y,PC,PM
Capacity: 130 ml per color (Ink tanks supplied with the printer contain
90 ml of each color.)
Detection functions (Cover
system)
Detects opening/closing of the top cover and ink cover.
Detection functions (Ink passage
system)
Detects presence/absence of ink tank, ink level, presence/absence of the
maintenance cartridge, waste ink full level, presence/absence of the
printhead, and opening/closing of the supply valve.
Detection functions (Carriage
system)
Detects the ambient temperature, head temperature, presence/absence of
the head, and no ink ejection.

Chapter 1
1-5
1.4 Detailed Specifications
1.4.1 Printing Speed and Direction
0013-3710
T-1-2
*1 The print engine may automatically select 1-way printing depending on the printing image type (graphic image, etc.). The printing direction can be selected
using the printer driver.
1.4.2 Interface Specifications
0012-6200
a. USB (standard)
(1) Interface type
USB 2.0, Full speed (12 Mbits/sec), High speed (480 Mbits/sec)
(2) Data transfer system
Control transfer
Bulk transfer
(3) Signal level
Compliant with the USB standard.
(4) Interface cable
Detection functions (Paper path
system)
Detects presence/absence of paper, remaining paper, cutter position,
presence/absence of the cassette, leading/trailing edge of paper, paper
width, and skew.
Operating noise During printing: Approx. 53 dB (A) or less
During standby: Approx. 35 dB (A) or less
Operating environment Temperature: 15 oC to 30oC
Humidity: 10% to 80% without dew condensation
Print quality guaranteed
environment
Temperature: 15 oC to 30oC
Humidity: 10% to 80%RH
Power supply 100-120 VAC (50/60 Hz), 220-240 VAC (50/60 Hz)
Power consumption (Maximum) During printing: Max. 100 W
Power consumption In power save (sleep) mode: 6 W or less(220-240 VAC: 7W or less)
During standby: 1 W or less
Printer unit dimensions
(WxDxH)
Without roll media unit (option): 999 x 733 x 317 mm
With roll media unit (option): 999 x 810 x 344 mm
Weight Without roll media unit (option): Approx. 45 kg
With roll media unit (option): 49 kg
Media Type Print Priority Print Quality Print-pass Printing direction(*1) Print resolution
Plain Paper
Plain Paper(High Quality)
Plain Paper(High Grade)
Image Draft 2-pass Bi-directional 1200x1200dpi
Standard 4-pass Bi-directional 1200x1200dpi
High 8-pass Bi-directional 1200x1200dpi
Line Drawing/
Text
Draft 2-pass Bi-directional 1200x1200dpi
Standard 4-pass Bi-directional 1200x1200dpi
Office Document Standard 4-pass Bi-directional 1200x1200dpi
High Resolution Paper
Coated Paper
Heavyweight Coated Paper
Image Standard 4-pass Bi-directional 1200x1200dpi
High 8-pass Bi-directional 1200x1200dpi
Highest 12-pass Bi-directional 2400x1200dpi
Premium Matte Paper
Matte Photo Paper
Image Standard 6-pass Bi-directional 1200x1200dpi
High 8-pass Bi-directional 2400x1200dpi
Highest 16-pass Bi-directional 2400x1200dpi
Glossy Photo Paper
Semi-Glossy Photo Paper
Heavyweight Glossy Photo Paper
Heavyweight SemiGlos Photo Paper
Glossy Paper
Photo Paper Plus
Photo Paper Plus Semi-Glos
Synthetic Paper
Adhesive Synthetic Paper
Backlit Film
Backprint Film
Thin Fabric Banner 2
Proofing Paper
Fine Art Photo
Fine Art Heavyweight Photo
Fine Art Textured
Fine Art Watercolor
Fine Art Block Print
Canvas Matte 2
Japanese Paper Washi
POP Board
Image Standard 6-pass Bi-directional 1200x1200dpi
High 8-pass Bi-directional 2400x1200dpi
Highest
16-pass Bi-directional 2400x1200dpi
CAD Tracing Paper
CAD Tranclucent Matte Film
Line Drawing/
Text
Draft 2-pass Bi-directional 1200x1200dpi
Standard 4-pass Bi-directional 1200x1200dpi
High 8-pass Bi-directional 2400x1200dpi

Chapter 1
1-6
Twisted-pair shielded cable, 5.0 m max.
Compliant with the USB standard.
Wire materials: AWG No.28, data wire pair (AWF: American Wire Gauge)
AWG No.20 to No.28, power distribution wire pair
(5) Interface connector
Printer side: Series B receptacle compliant with USB standard
Cable side: Series B plug compliant with USB standard
b. Network (standard)
(1) Interface type
Interface compliant with IEEE802.3
(2) Data transfer system
10Base-T/100Base-TX
(3) Signal level
Input: Threshold
10Base-T: Max. +585 mV, Min. +300 mV
100Base-TX: Turn-on +1000 mV diff pk-pk, Turn-off +200 mV diff pk-pk
Output:
10Base-T: +2.2 V to +2.8 V
100Base-TX: +0.95 to +1.05 V
(4) Interface cable
Category 5 (UTP or FTP) cable, 100 m or shorter
Compliant with ANSI/EIA/TIA-568A or ANSI/EIA/TIA-568B
(5) Interface connector
Printer side: Compliant with IEEE802.3, ANSI X3.263, ISO/IEC60603-7
c. IEEE1394 (option)
(1) Interface type
Interface compliant with IEEE1394-1995, P1394a (Version 2.0)
(2) Data transfer system
Asynchronous transfer
(3) Signal level
Input:
Differential input voltage:
During S100 settlement: +173 mV to +260 mV
During data reception: +142 mV to +260 mV
During S200 settlement: +171 mV to +262 mV
During data reception: +132 mV to +260 mV
During S400 settlement: +168 mV to +265 mV
During data reception: +118 mV to +260 mV
Output:
Differential output voltage: +172 mV to +265 mV
(4) Interface cable
Twisted-pair shielded cable, 4.5 m max.
Compliant with IEEE1394-1995 standard or P1394a (Version 2.0) standard
(5) Interface connector
Printer side: 6-pin connector (socket) compliant with IEEE1394 standard
Cable side: 6-pin connector (plug) compliant with IEEE1394 standard
Cable side: RJ-45 type compliant with ANSI/EIA/TIA-568A or ANSI/EIA/TIA-568B
