Canon iPF650 - imagePROGRAF Color Inkjet Printer User manual

Setup Guide
ENG
Introductory Information
QT5-2309-V1 ©CANON INC. 2009 Printed in JAPAN
1
Printer and stand 1704 × 1470 × 1362
i
j
k
c
d
e
f
g
h
b
a
These are the steps in printer installation.
Details for each step are given in this Setup Guide. Simply follow the instructions
to install the printer.
If an error message is displayed during setup or other problems occur, refer to
"Responding to Messages".
Introduction
Printer Installation space (W x D x H mm)
iPF650/iPF655
Printer alone 1397 × 1308 × 807
With stand attached 1397 × 1470 × 1362
Overview of Setup Space Required for Installation
Read this manual before attempting to operate the printer.
Keep this manual in a handy location for future reference.
iPF750/iPF755
MEM
O
Printera.
c.
Roll holder: Already attached to printer
d.
3-inch paper core attachment R
e. Printhead
f. Starter ink tanks:
Bk, MBk (x 2), C, M, Y
g. Sample paper
Package Contents
Some items are included with the printer but not described in this manual.
Keep these items in a safe place after setup because they are used in
various printing applications.
•
For instructions on using items not described in this manual, refer to the
User Manual.
•
A cable to connect the printer to a computer is not provided with the printer.•
h. Setup Guide (this document)
i. Set of printer documentation
j. Set of CD-ROMs
k. Power cord
b.
3-inch paper core attachment L
After installing the printer as shown in this Setup Guide, refer to the
documentation for instructions on operation and maintenance.
Daily operation
Detailed instructions
The Basic Guide includes three booklets containing the following information:
Instructions on basic operation
Troubleshooting tips and maintenance procedures
1
2
3
The User Manuals CD-ROM (User Manual) includes the following information:
Printer operating instructions
Printer driver instructions
Printing instructions
•
•
•
Maintenance procedures
Instructions for network printing
•
•
Troubleshooting tips
Printer menu descriptions
Printer driver function details
•
•
•
Specifications, details on consumables
and optional accessories, and other
information
•
Supported paper
The Paper Reference Guide provides information about paper.
In Windows, double-click the iPFxxxx Support desktop icon.
(iPFxxxx represents the printer model.)
•
You can access the User Manual and Paper Reference Guide as follows:
In Mac OS X, click iPF Support, added to the Dock.•
Printer Documentation
Preparations for transferring the printer, and instructions for
reinstalling the printer driver
• Canon, the Canon logo, and imagePROGRAF are trademarks or registered trademarks of CANON
INC.
• Microsoft and Windows are trademarks of Microsoft Corporation, registered in the U.S. and other
countries.
• Macintosh is a trademark of Apple Inc., registered in the U.S. and other countries.
• All other trademarks or registered trademarks described in this Setup Guide are the property of
their respective owners.
Preparations
Install the Printhead
Install the Ink Tanks
Load Cut Sheet Paper
Install the Printer Driver and
the User Manual
(P.2)
(P.3)
(P.4)
(P.5)
(P.6)
Store Accessories in the Pockets
(P.15)
Caution
Instructions in this Setup Guide show the iPF755 printer. Note that your printer may look different from these illustrations in some cases. However,
basic operations are the same.
•
+300mm
+10mm =0mm?㧖
+600mm
+200mm
+200mm
*Values enclosed in [ ] are for when the stand is attached.

2
Prepare the printer for use by installing the printer and connecting the power cord.
Remove the packing materials from the
top of the printer.
2
Install the printer. You can use the
following two methods for installing the
printer.
• Install with a stand
Assemble the stand and install the
printer referring to the Printer Stand
Setup Guide included with the stand.
After installation, proceed to step 4.
• Install without a stand on a table
Proceed to step 2.
1
Stands may be standard or optional
depending upon your model and location.
iPF750/iPF755: Standard
iPF650/iPF655: Optional (equipped as
standard in some locations)
•
MEM
O
Preparations
Remove the orange tape used to secure
the roll holder to the printer.
4
Three people should hold the printer's carrying handles and place the printer on a table or
other flat location.
When moving the printer, firmly grasp the
carrying handles. Holding the printer at
other positions is dangerous, and may
cause injury and damage if the printer is
dropped.
•
3
The iPF750/iPF755 weighs approximately
52 kg and the iPF650/iPF655 approximately
43 kg by themselves. Moving the printer
requires at least three people. Be careful
to avoid back strain and other injuries.
•
Caution
Plug the power cord into the power supply
connector on the right of the printer and
plug the other end into the outlet.
Move the printer to the location where you
will use it.
65
When moving the stand, lift the support rod
to the position (a) before closing the output
stacker and unlocking the 4 casters. Failure
to do so may lead to scratched flooring,
damage to the basket cloth, and injury.
• After you have moved the stand, be sure to
lock the 4 casters.
•
Caution
ON
OFF
a

3
Repeat steps 5 to 9 to install all of the ink
tanks.
9
Close the ink tank cover.
10 11
Never touch the ink holes (a)
or metal contacts (b). Touching
these parts may cause stains,
damage the ink tank, and affect
print quality.
•
Avoid dropping the ink tank after
removing it from the pouch.Otherwise,
ink may leak and cause stains.
•
Do not remove and shake ink tanks that
have already been installed in the printer
because ink may leak out.
•
a
b
If the ink tank does not fit in the holder,
make sure the color of the ink tank lock
lever matches the color of the ink tank, and
check the orientation of the ink tank.
•
897
If the ink lamp is not lit, repeat steps 5, 8,
and 9.
•
Close the ink tank lock lever until it clicks
into place. Make sure the ink lamp is lit in
red.
Open the pouch and remove the ink tank. Insert the ink tank into the holder facing
as shown, with the ink holes down.
Load all six ink tanks.
Install the Ink Tanks
When the following screen appears, use
the ▲and ▼keys to select a language
and press OK.
Select your local time zone and press OK.
Press the power button to turn on the
printer.
1 2 3
Data
Message
Power
Menu
Back
Stop
Navigate
FEED Cut
Load
㪈㪆㪌
Time Zone
0:London (GMT)
+1:Paris,Rome
+2:Athens,Cairo
+3:Moscow
+4:Eerevan,Baku
Data
Message
㪈㪆㪉
Language
English
ᣣᧄ⺆
Français
Italiano
Deutsch
4 5 6
Failure to shake ink tanks may result in
reduced print quality because ink ingredients
have settled on the bottom of the tank.
•
Instructions on ink tank installation
are shown on the display screen. As
instructed, grab the handle on the ink tank
cover to open it.
While pressing the stopper of the ink tank
lock lever inwards, open the ink tank lock
lever upwards.
Shake the ink tanks gently 1 to 2 times
before opening the pouch.

4
b
a
Push the printhead fixer lever all the way
back.
Pull the printhead fixer cover down toward
the front to lock the printhead in place.
Insert the printhead into the carriage (b)
with the ink holes (a) facing away from the
printer as shown in the figure. Carefully
push the printhead firmly into the carriage
(b), ensuring that the part covered by
the protective part does not touch the
carriage.
678
Close the top cover.
9
Next, install the printhead.
Install the Printhead
When installing the printhead, do not
move the carriage (a) from the position
shown in the figure.
If you move the carriage (a), a warning
noise sounds and the printhead cannot
be installed.
If you have moved the carriage (a),
close the top cover. The carriage (a)
moves to the position shown in the
figure.
•
Open Upper Cover is shown on the
display screen. As instructed, open the top
cover.
Instructions on printhead replacement are
shown on the display screen.
Pull the printhead fixer lever forward all
the way to open it completely.
12
a
Remove the orange protective part (a).
To remove orange protective part (b),
push the grip (c) as you remove the part.
5
• Do not reattach the protective part after
removing it. Dispose of these materials
according to local regulations.
Never touch the parts covered by the
protective part. This may damage the
printhead and affect printing quality.
•
The printhead contains ink, so be careful
not to spill it once the protective part is
removed.
•
Lift the printhead fixer cover to open it
fully.
Hold the printhead by the grips (a) as you
remove it from the pouch.
a
a
34
a
bc

5
When printhead adjustment ends, paper is
printed with an adjustment pattern and is
ejected.
While holding the paper, press the release
lever (a) backwards to remove the paper.
9
a
Load paper for adjusting the printhead into the printer.
Follow these steps to load cut sheet paper into the printer. The sample paper provided is used in this example.
Load Cut Sheet Paper
Return unused paper to the pouch it
came in, and store it away from heat,
humidity and direct sunlight.
•
Slide the width guide (a) and align it
with the mark for the size of paper to be
loaded. In this example, align the width
guide with A2 to align it with the size of the
sample paper.
Select type of paper for printhead adj.
is shown on the display screen. Check
that Cut Sheet is selected and press OK.
Instructions on loading cut sheets are
shown on the display screen.
Prepare one sheet of paper.
Refer to the packaging for the paper to
check which side is the printable surface.
12
a
3
Only one sheet can be loaded in the
printer. Do not load two or more sheets.
Doing so might cause a paper jam.
•
Wrinkled or warped paper might cause
paper jams. Be sure to flatten the paper
out before loading it.
•
Load paper with the printable surface
face up.
Insert the paper until its leading edge
touches a stop and you hear a tone.
4
A message confirming paper advance is
shown on the display screen. Press OK.
6
Pull the release lever forward.
Printer setup is now complete.
For how to load roll paper, refer to the Basic
Guide (1), to the User Manual installed
at "Install the Printer Driver and the User
Manual", or to the instructions displayed by
the navigation function of the control panel.
•
Follow the procedure below to display the
navigation on how to load roll paper.
1.Press Navigate.
2.Use the ▲and ▼keys to select Load Roll
Paper and press OK.
3.Use the ▲and ▼keys to select View Op.
Guide and press OK.
The navigation starts.
MEM
O
10
The screen for selecting the paper type is
shown on the display screen. Press ▲or
▼to select the type of paper loaded in the
printer.
Select Coated Paper and press OK.
Then from the menu that appears, select
Coated Paper and press OK.
7
The paper is advanced.
MEM
O
During printer installation, ink fills the system
between the ink tanks and printhead. In
addition, printheads are cleaned to keep the
printer in optimal condition. This may cause
the maintenance cartridge capacity indicator
to drop to about 80%, but this is not a problem
with the printer.
When paper advance ends, the system
is automatically filled with ink for the first
time and printhead adjustment is started.
It takes a total of about 20 minutes.
Make use of this time by referring to
"Install the Printer Driver and the User
Manual" on page 6 to install the printer
driver and the User Manual on your PC.
8
Adjust the position of the width guide (a)
to the size of the paper to be loaded.
Make sure the width guide fits properly
against the edge of the paper to prevent it
from being tilted or wrinkled.
5
a

6
In the Printer Selection window, select
The printer is connected directly to a
computer and click Next.
When the following dialog box is
displayed, make sure the printer is on
and use the USB cable to connect the
printer to the computer.
In the Printer Installation dialog box,
select Install with USB Connection, and
click Next.
7 8
6
If a warning message is displayed, click
Retry to try again.
•
MEM
O
In the Select Country or Region of Use
window, select the country or region of
use and click Next.
After reading the license agreement, click
Yes.
Confirm that the required installation
items are selected in the Installation List
window, and then click Next.
3 54
MEM
O
Point at a software title to view a
summary of the software.
•
For USB connections
MEM
O
In the Setup Menu window, click Install
Printer Driver.
Use a USB cable that conforms to the
Hi-Speed USB specification.
Connect the USB cable to the printer
as instructed during installation of the
relevant printer driver. If you connect the
USB cable before installing the printer
driver, the printer driver may not be
installed correctly.
•
•
To choose a different language, click
Language.
•
After making sure the printer is not
connected to the computer, turn the
computer on. Insert the provided User
Software CD-ROM for your operating
system in the CD-ROM drive.
1 2
Windows
You can print from Windows via USB or TCP/IP (network) connections.
The installation procedure varies depending on how your printer is
connected. Install the printer driver and the User Manual as follows.
Installation requires administrative rights (such as those of Administrator).
Be sure to log on using an account with administrative rights before
installation.
•
<Compatible Operating Systems>
Windows Vista, Windows Server 2008, Windows Server 2003,
Windows XP, Windows 2000
MEM
O
The following screen may be displayed during installation depending on
the security settings of your computer.
Select Deactivate the block and click Next.
•
Install the Printer Driver and the User Manual

7
In the Finish window, select Restart my
computer now and click Restart.
After reviewing the installation results in
the Complete Installation window, click
Next.
MEM
O
Be careful not to insert the USB cable
into the Ethernet port.
•
109
After reading the software license
agreement, select I accept the terms of
the license agreement, and then click
Next.
Click Install.
The installation process begins.
After installation is completed, click Finish.
The User Manual is now installed.
14 15 16
When the Install User Manual dialog
box is displayed, insert the provided User
Manuals CD-ROM in the CD-ROM drive
and click Next.
Click Next.
1311 12
The printer driver settings take effect after
the computer restarts. This completes
printer driver installation.
An iPFxxxx Support desktop icon
is created after installation. (iPFxxxx
represents the printer model.)
Next, install the User Manual.
MEM
O
Use the LAN cable to connect the LAN
port on the back of the printer to the hub
port. Pass the network cable through the
wiring bracket (a).
Make sure the printer is on.
Turn the computer on and insert the
provided User Software CD-ROM for
your operating system in the CD-ROM
drive.
For TCP/IP (network) connections
When you first connect the printer to the network
• If the printer is on, the Link indicator
under the LAN port lights.
1000Base-T
connection
The LED on the bottom
lights green.
100Base-TX
connection
The LED on the top lights
orange.
10Base-T
connection
The LED on the top lights
green.
a
1 2

8
After reading the license agreement, click
Yes.
6
MEM
O
In the Printer Selection window, select
The printer is connected to computers
in a network and click Next.
After reading the precautions in the
Getting Ready window, select Find
available printers in the network and
click Next.
Available printers are listed in the Search
Results window.
Select a printer from the list on either
their IPv4 Devices or IPv6 Devices tabs
and click Next.
The IPv6 Devices tab is displayed in Windows Vista and Windows Server 2008.
If the printer you want to use is not displayed in the list on the IPv6 Devices tab, connect via IPv4
instead.
If the printer you want to use is not displayed in the list of printers on the IPv4 Devices tab, refer to
"When the printer cannot be found on the network" on page 9 to setup and configure an IP address
for the printer.
•
•
•
7 8
9
In the Method of Configuring IP
Addresses window, enter the IP address
in Configure manually, under Method of
Configuring IP Addresses. Click Install
to start the installation process. Also enter
your preferred name for the printer in
Device Name and the installation location
in Printer Location under Information
About Printer to Configure, as desired.
The installation process begins.
•If you use a DHCP server for automatic assignment of the printer's IP address, printing
may no longer be possible after the printer is turned off and on. This is because a different
IP address has been assigned. When using DHCP server functions, consult your network
administrator and configure the settings in one of the following ways:
Configure the setting for dynamic DNS updating
In RemoteUI, activate the setting Enable DNS Dynamic Update. (→"Configuring the Printer's
TCP/IP Network Settings", User Manual)
•
Configure the setting for assignment of the same IP address each time the printer starts up•
10
MEM
O
MEM
O
In the Select Country or Region of Use
window, select the country or region of
use and click Next.
5
Point at a software title to view a
summary of the software.
•
To choose a different language, click
Language.
•
In the Setup Menu window, click Install
Printer Driver.
Confirm that the required installation
items are selected in the Installation List
window, and then click Next.
4
3

9
If your printer cannot be found when
connecting to the network for the first time,
setup an IP address for the printer and
then configure it on the printer.
When ink fills the system for the first time,
after printhead adjustment is finished,
specify the IP address on the printer's
control panel.
On the tab selection screen of the control
panel, press the ◄and ►keys to select
(Settings/Adjustments) and press
OK.
When ink fills the system for the
first time, do not operate the
printer until printhead adjustment
is finished.
•
Use the ▲and ▼keys to select Interface
Setup and press OK.
No Paper Loaded
OK:Setting/Adj. Menu
Remaining Amount
㪈㪇㪇㩼
Maint. cart.
Enter the IP address. Navigate through the
following menus using the ▲and ▼keys
on the control panel.
1.Select IPv4 and press OK.
2.Select IPv4 Settings and press OK.
3.Select IP Address and press OK.
4.Enter the IP address.
4
Use the ▲and ▼keys to select TCP/IP
and press OK.
MEMO
How to enter IP addresses
1.Press the ◄and ►keys to select a field
for inputting values.
2.Use the ▲and ▼keys to input values.
• Pressing ▲increases the value by
one. However, 0 comes after 255.
• Pressing ▼decreases the value by
one. However, 255 comes after 0.
• Holding down either the ▲or ▼keys
continually increases or decreases the
value.
3. Press OK once you have finished.
Press Menu.
Press OK on the registration confirmation
message that appears.
The IP address is set on the printer.
Next, restart installation of the printer
driver.
When the printer cannot be found on the network
12
3
5
6
MEM
O
In the Search Results window, select
Specify the IP address of available
printers in the network and click Next.
The IP Address Specification window
appears. Follow steps 8-11 on page
11-12 to finish installing the printer driver.
If the following screen appears, click Retry
and select Specify the IP address of
available printers in the network on the
next screen that appears.
•
Next, follow steps 12-16 on page 7 to
install the User Manual.
7
Next, follow steps 12-16 on page 7 to
install the User Manual.
The printer driver settings take effect after
the computer restarts.
This completes
printer driver installation
.
An iPFxxxx Support desktop icon
is created after installation. (iPFxxxx
represents the printer model.)
In the Finish window, select Restart my
computer now and click Restart.
After reviewing the installation results in
the Complete Installation window, click
Next.
12
11 13

10
In the Printer Selection window, select
The printer is connected to computers
in a network and click Next.
After reading the precautions in the
Getting Ready window, select Find
available printers in the network and
click Next.
Available printers are listed in the Search
Results window.
Select a printer from the list on either
their IPv4 Devices or IPv6 Devices tabs
and click Next.
The installation process begins.
687
MEM
O
After reading the license agreement, click
Yes.
In the Select Country or Region of Use
window, select the country or region of
use and click Next.
Point at a software title to view a summary
of the software.
•
Confirm that the required installation
items are selected in the Installation List
window, and then click Next.
4 53
MEM
O
In the Finish window, select Restart my
computer now and click Restart.
After reviewing the installation results in
the Complete Installation window, click
Next.
Printers already connected to the network
are labeled Available in IP Address
Status.
•
If the printer you want to use is not
displayed in the list of printers, select
Specify the IP address of available
printers in the network and click Next.
The IP Address Specification window
appears. Follow steps 8-11 on page 11-12
to finish installing the printer driver and the
User Manual.
•
The IPv6 Devices tab is displayed in
Windows Vista and Windows Server 2008.
•
109
MEM
O
MEM
O
Make sure the printer is on.
Turn the computer on and insert the
provided User Software CD-ROM for your
operating system in the CD-ROM drive.
If the printer is already connected to the network
To choose a different language, click
Language.
•
In the Setup Menu window, click Install
Printer Driver.
If the printer is already connected to
the network, confirm the IP address
assigned to the printer. Ask your network
administrator for further information.
•
If the printer is on, the Link indicator under
the LAN port lights.
•
1000Base-T
connection
The LED on the bottom
lights green.
100Base-TX
connection
The LED on the top lights
orange.
10Base-T
connection
The LED on the top lights
green.
1 2

11
11
Next, follow steps 12-16 on page 7 to
install the User Manual.
The printer driver settings take effect after
the computer restarts. This completes
printer driver installation.
An iPFxxxx Support desktop icon
is created after installation.
(iPFxxxx
represents the printer model.)
6 7
In the Printer Selection window, select
The printer is connected to computers
in a network and click Next.
After reading the precautions in the
Getting Ready window, select Specify
the IP address of available printers in
the network and click Next.
8
In the IP Address Specification window,
select either IPv4 Address or IPv6
Address to enter the printer's IP address
and click Install.
The installation process begins.
Ask your network administrator for the
IP address, as needed.
•
MEM
O
IPv6 Address is displayed in Windows
Vista and Windows Server 2008.
•
5
After reading the license agreement, click
Yes.
3 4
MEM
O
In the Select Country or Region of Use
window, select the country or region of
use and click Next.
Confirm that the required installation
items are selected in the Installation List
window, and then click Next.
Point at a software title to view a summary
of the software.
•
When entering the printer's IP address manually
1
MEM
O
• If the printer is on, the Link indicator under
the LAN port lights.
1000Base-T
connection
The LED on the bottom
lights green.
100Base-TX
connection
The LED on the top lights
orange.
10Base-T
connection
The LED on the top lights
green.
If the printer is already connected to
the network, confirm the IP address
assigned to the printer. Ask your network
administrator for further information.
•Make sure the printer is on.
Turn the computer on and insert the
provided User Software CD-ROM for
your operating system in the CD-ROM
drive.
2
In the Setup Menu window, click Install
Printer Driver.
MEM
O
To choose a different language, click
Language.
•

12
11
The printer driver settings take effect after
the computer restarts. This completes
printer driver installation.
An iPFxxxx Support desktop icon
is created after installation.
(iPFxxxx
represents the printer model.)
Next, follow steps 12-16 on page 7 to
install the User Manual.
10
In the Finish window, select Restart my
computer now and click Restart.
9
After reviewing the installation results in
the Complete Installation window, click
Next.

13
MEM
O
Macintosh
Install the printer driver that suits your printing environment.
<Compatible Operating Systems>
Mac OS X 10.3.9 or later
Use a cable to connect the printer to a computer or the network. When connecting to a
network, pass the network cable through the wiring bracket (a).
For USB connections
•For network connections
Be careful not to insert the USB cable into the Ethernet port.
•
Connect the printer to a computer
Make sure the printer is on.
Turn the computer on.
Connect the cable
•
You can print from Macintosh via USB or network connections such as
Bonjour or IP.
• Be sure to log in as a user with
administrative rights when installing the
printer driver.
Insert the provided User Software
CD-ROM for your operating system in the
CD-ROM drive.
On the desktop, double-click the CD-ROM
icon and then the iPF Printer Setup icon.
If the following screen is displayed, enter
the user name and password of a user
with administrative rights and click OK.
Click Next. After reading the software license
agreement, click Continue.
Click Agree.
Select the country or region where the
printer will be used and click Next.
Confirm that the required installation items
are selected, and then click Next.
Install the printer driver
a
User Software
1 2
Configure the computer
1 2
3 4 5
6 7 8

Install the User Manual
9 10 11
12 13
14 15 16
22
2120
19
17 18
14
Check the message and click Continue.
Select the region where the printer will
be used and the language of the user
manual to install, and then click OK.
Next, install the User Manual.
Double-click the iPFxxxx Manual
Installer icon on the CD-ROM.
(iPFxxxx
represents the printer model.)
Insert the provided User Manuals
CD-ROM in the CD-ROM drive.
Click OK.
The following screen is displayed and
paper information is updated. When the
paper information has been updated, the
screen is no longer displayed.
Click Continue. Exit other applications and click Continue.
The printer driver, additional printer driver
features, ICC Profiles, and the Media
Configuration Tool are now installed.
Click OK.
Click Quit. Click Next.
Select the printer to setup and
click Next.
This completes printer driver installation.
Next, select the printer to set up.
After entering your preferred name for the
printer in Printer Name and the installation
location in Location, click Register.
Click Finish.
MEM
O
To register the printer by entering its IP
address, click Registering IP Address.
Enter the IP address of the desired
printer in IP Address and click Next.
•
MEM
O
To register another printer, click Continue
Registration, and repeat steps 14 to 16.
•
MEM
O
If the same model of printer is already
registered on the computer, a screen is
displayed for printer selection. Select
the desired printer and click Next.
•

1 2
15
Click Install.
26
23 25 24
After installation is completed, click Quit.
The User Manual is now installed.
After reading the software license
agreement, click Continue.
Click Agree.
Store Accessories in the Pockets
Use the manual pocket to store the Basic Guide (which includes descriptions of basic printer
operations, routine maintenance, and troubleshooting tips), so you can refer to it as needed.
When using the stand, store the 3-inch
paper core attachment and other
accessories in the accessory pocket.
MEM
O
The accessory pocket is included with
the stand.
•

16
Error messages may appear on the display screen of the control panel during printer installation in some cases. If so, it may not indicate a problem with the
printer, and the issue may be easily resolved. Common messages and the causes are listed here with corrective actions. To respond to error messages other
than these, refer to the Basic Guide (2). For other detailed printer instructions, refer to the User Manual installed at "Install the Printer Driver and the User
Manual".
Responding to Messages
No printhead
Install printhead.
No ink tank loaded.
Check ink tank.
Load or reload the ink tank.
(see steps 4-11 on page 3)
The printhead is not installed.
Message Cause Corrective Action
Paper is crooked.
Push the release lever back, then
Pull out the cut sheet.
There is no ink tank of the indicated color in
the printer.
The loaded paper is crooked.
Install the printhead.
(see steps 1-9 on page 4)
Could not detect paper size. Push release
lever back,
Pull out the cut sheet.
The paper is loaded in the wrong position or
the paper is curled.
Hardware error.
xxxxxxxx-xxxx
(x represents a letter or number)
ERROR Exxx-xxxx
(x represents a letter or number)
Insert the maintenance cartridge. The maintenance cartridge is not installed.
Another kind of error has occurred.
You may have encountered an error that
cannot be resolved.
Turn off the printer and wait at least three seconds before restoring
the power. If the message still appears, write down the error code and
message, turn off the printer, and contact your Canon dealer for assistance.
Write down the error code and message, turn off the printer, and contact
your Canon dealer for assistance.
Install the maintenance cartridge.
Press the release lever backwards.
Pull out the paper.
1.
Pull the release lever forward.
3.
2.
4. Load or reload the paper.
