Canon PAPER DECK-C1 User manual

COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
FEB. 1999 FY8-13FP-000
2 ××500 SHEET
PAPER DECK-C1
REVISION 0

COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
COPYRIGHT © 1999 CANON INC.
Printed in Japan
Imprimé au Japon
Use of this manual should be strictly
supervised to avoid disclosure of confi-
dential information.
IMPORTANT
THE INFORMATION CONTAINED HEREIN IS PUBLISHED BY CANON INC., JAPAN.
SPECIFICATIONS AND OTHER INFORMATION CONTAINED HEREIN MAY VARY SLIGHTLY
FROM ACTUAL MACHINE VALUES OR THOSE FOUND IN ADVERTISING AND OTHER PRINTED
MATTER.
ANY QUESTIONS REGARDING INFORMATION CONTAINED HEREIN SHOULD BE DIRECTED TO
THE COPIER SERVICE DEPARTMENT OF THE COMPANY.
Prepared by
OFFICE IMAGING PRODUCTS TECHNICAL SUPPORT DEPARTMENT 1
OFFICE IMAGING PRODUCTS TECHNICAL SUPPORT DIVISION
CANON INC.
7-5-1, Hakusan, Toride-shi, Ibaraki 302-8501 Japan

COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
This service manual provides basic information required in performing field service to
maintain the product quality and functions of 2×500 Sheet Paper Deck-C1.
Each chapter consists of the following sections:
Chapter 1, “Introduction,” Specifications, Names of Parts.
Chapter 2, “Operation Overview,” Description of the mechanical and electrical operat-
ing principles and timing by function.
Chapter 3, “Mechanical System,” Description of mechanical structure, and disassem-
bly, assembly and adjustment methods.
Chapter 4, “Maintenance and Inspection,” Table of periodic replacement parts and
consumables replacement targets, periodic service list and parts to be cleaned during a
customer service call.
Chapter 5, “Operation Failure Countermeasures,” Standards/ adjustments, operation
failure countermeasures and delivery failure countermeasures.
“Appendices,” Signal name list, general circuit diagram, special tools, solvent and oil
list.Note that since installation procedure instructions are packed with the 2 ×500 Sheet
Paper Deck-C1, no installation procedures are provided in this manual.
Changes of the contents made for the sake of product improvements will be notified
in Service Information (Technical Information) whenever such changes are made.
Gaining a sound and thorough understanding of the copier through careful reading of
this service manual and the subsequently issued Service Information (Technical
Information) bulletins is the only way to develop the technical skill necessary to prolong
product quality and functionality and the practical ability to be able to determine the
cause of breakdowns.
i
INTRODUCTION

COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
CONTENTS
CHAPTER 1 INTRODUCTION
I. SPECIFICATIONS....................................1-1
II. NAMES OF PARTS..................................1-2 A. External View.....................................1-2 B. Cross-section Diagram ......................1-3
CHAPTER 2 OPERATION OVERVIEW
I. BASIC CONFIGURATION........................2-1
A. Overview............................................2-1
B. Inputs and outputs to the Paper
Deck Driver PCB................................2-2
II. PAPER FEED AND DELIVERY
SYSTEM ..................................................2-5
A. Overview............................................2-5
B. Paper Feed, Delivery .........................2-8
C. Jam Detection..................................2-18
III. POWER SUPPLY...................................2-20
A. Overview..........................................2-20
B. Protective Functions ........................2-21
CHAPTER 3 MECHANICAL SYSTEM
I. EXTERNAL COVERS..............................3-1
A. Exteranal Cover Types.......................3-1
B. Left cover ...........................................3-2
C. Right cover.........................................3-2
D. Rear cover..........................................3-2
E. Delivery cover ....................................3-2
F. Upper Front Cover .............................3-3
II. DRIVE ASSEMBLY ..................................3-4
A. Delivery Unit.......................................3-4
B. Paper Feed Unit.................................3-4
C. Registration Roller .............................3-7
D. Pick up roller, Pick up/ Feeding
Roller, Separation Roller....................3-7
E. Paper Delivery Unit Sensor................3-8
F. Registration Paper Sensor,
Jam Sensor........................................3-8
G. Cassette 3/4 Sensor; Cassette 3/4
Remaining Paper Sensors 1, 2;
Cassette 3/4 Paper Out Sensor.........3-9
H. Paper Feed Solenoid .........................3-9
I. Registration Roller Clutch................3-10
J. Delivery Motor..................................3-11
K. Lifter motor.......................................3-11
L. Paper Feed Motor............................3-12
III. PCBs......................................................3-13
A. Lifter Motor Driver PCB....................3-13
B. Paper Feed PCB..............................3-13
C. Cassette 3 Paper Size Detector
PCB..................................................3-14
D. Cassette 4 Paper Size Detector
PCB..................................................3-15
E. LED PCB..........................................3-15
IV. POWER SUPPLY...................................3-16
A. Power Supply Unit............................3-16
CHAPTER 4 MAINTENANCE AND INSPECTION
I. PERIODICALLY REPLACED PARTS.......4-1
II. CONSUMABLES AND DURABLES ........4-1
III. SCHEDULED SERVICING ......................4-1
IV. PARTS TO BE CLEANED DURING A
CUSTOMER SERVICE CALL..................4-2
iii

COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
APPENDIX
A. SIGNAL NAMES AND CODE LIST.........A-1
B. GENERAL CIRCUIT DIAGRAM..............A-3 C. SPECIAL TOOLS.....................................A-5 D. LIST OF SOLVENTS AND OILS.............A-5
CHAPTER 5 TROUBLESHOOTING
I. STANDARDS AND ADJUSTMENTS.......5-1
A. Overview............................................5-1
B. Operational Checks to be Performed
by the User.........................................5-1
C. Operational Checks to be Performed
by the Service Engineer.....................5-2
II. TROUBLESHOOTING
MALFUNCTIONS.....................................5-6
III. TROUBLESHOOTING JAMS...................5-8
A. Paper Jams........................................5-8
B. Incomplete Feed ..............................5-11
IV. LOCATION OF ELECTRICAL PARTS...5-12
A. Sensor..............................................5-12
B. Solenoids, Clutches and Motors......5-13
C. PCBs................................................5-14
V. LIST OF VARIABLE RESISTORS (VR),
LEDS, CHECK PINS BY PCB...............5-15
A. Paper Deck Driver PCB...................5-16
B. Paper Size Detection Switch PCB...5-17
C. User LED PCB.................................5-17
iv

COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 1
INTRODUCTION
I. SPECIFICATIONS....................................1-1
II. NAMES OF PARTS..................................1-2 A. External View.....................................1-2 B. Cross-section Diagram ......................1-3

I. SPECIFICATIONS
CHAPTER 1 INTRODUCTION
1-1
COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
Item
Type of paper feed paper
Paper feed paper size
Cassette 3
Cassette 4
Cassette type
Cassette 3
Cassette 4
Cassette specifications
Operating environment
Temperature
Humidity
Atmospheric pressure
Max. Power Consumption
Noise (Official noise
pollution value, as per
ISO 9296)
Dimensions
Weight
Power supply
Specifications
Plain paper, coloured paper, thick paper
B4, A4, legal and letter size plain paper
(64 g/m2to 105 g/m2recommended paper)
A3, B4, A4, ledger, legal and letter size plain paper (64 g/m2to
105 g/m2recommended paper)
Universal (can be changed to B4, legal, letter and A4 size
paper)
Universal (can be changed to ledger, A3, B4, legal, letter and
A4 size paper)
Depth: 50 mm (can contain up to 500 sheets of 64 g/m2paper)
10 to 32.5°C
20 to 80% RH
746 to 1013 hPa (560 to 760 mmHg)
Approx. 48.9 W or less (at a room temperature of 20°C and
rated power supply voltage)
Sound power level (1 dB = 10 dB) 7.1 dB or less (printing)
6.5 dB or less (stand-by)
Sound pressure level 54 dB or less (printing)
49 dB or less (stand-by)
629 (W) ×520 (D) ×651 (H) mm
Approx. 30 kg
100 to 120 V ±10% (50/60 Hz ±2 Hz)
200 to 240 V ±6% (50 Hz ±2 Hz)
Specifications are subject to change for the sake of product improvements.

II. NAMES OF PARTS
A. External View
CHAPTER 1 INTRODUCTION
1-2
COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
[1] Positioning pin
[2] Delivery assembly
[3] Storage space
[4] Cassette 4
[5] Cassette 3
[6] User LED
[7] Interface connector
[8] Power supply receptacle
Figure 1-201
[1] [2]
[3]
[4]
[5]
[6]
[7]
[8]

B. Cross-section Diagram
CHAPTER 1 INTRODUCTION
1-3
COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
[1] User LED
[2] Cassette 3
[3] Cassette 4
[4] Paper feed roller
[5] Delivery roller 1
[6] Separation roller
[7] Registration paper sensor lever
[8] Registration roller
[9] Delivery roller 2
[10] Jam sensor lever
[1] [2] [3] [4] [5] [6] [7] [8] [9] [10]
Figure 1-202

COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB.1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 2
OPERATION OVERVIEW
I. BASIC CONFIGURATION........................2-1
A.Overview............................................2-1
B.Inputs and outputs to the Paper
Deck Driver PCB................................2-2
II. PAPER FEED AND DELIVERY
SYSTEM..................................................2-5
A.Overview............................................2-5
B.Paper Feed, Delivery.........................2-8
C.Jam Detection..................................2-18
III. POWER SUPPLY...................................2-20
A.Overview..........................................2-20
B.Protective Functions........................2-21
1.This chapter describes the objective and role of each function, the relationship between the electri-
cal and mechanical systems and also gives an overview of the operation timing of each part by func-
tion.
The symbol in the outline diagram indicates the transmission of mechanical drive, and the
symbol together with a signal name indicates the flow of electric signals.
2.In the descriptions of the digital circuits of the cassette feeding unit, “1”indicates a high electric sig-
nal level and “0”indicates a low electric signal level.
The cassette feeding unit incorporates microprocessors, but as their internal operation cannot be
checked, a description of microprocessor operation has been omitted.
Since it is assumed that service engineers will not repair printed circuit boards on the customers’
premises, descriptions of printed circuit boards are limited to overviews illustrated with block dia-
grams.Consequently, circuit descriptions cover from sensors to the input sections of the major print-
ed circuit boards and from the output sections of the major printed circuit boards to the loads, as well
as block diagrams of each function.

I. BASIC CONFIGURATION
A. Overview
The unit transports the paper to the printer assembly.
The operation sequence of the unit is controlled by the paper deck driver PCB. This
PCB incorporates an 8-bit microprocessor (IC201) that performs operation sequence
control and control of serial communications with the option controller PCB.
The paper deck driver PCB drives solenoids, motors, etc. in response to commands
transmitted from the option controller PCB, via serial communication lines. The paper
deck driver PCB also notifies the option controller PCB of sensor and switch information,
via the serial communication lines.
Figure 2-101
CHAPTER 2 OPERATION OVERVIEW
2-1
COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
Option controller
PCB
Paper deck driver
PCB
Power supply
assembly
Other option
driver PCB
Registration
roller clutch
Paper feed
solenoid
Sensors/Switches
Paper feed motor
Delivery motor
Motor
LED PCB

B. Inputs and outputs to the Paper Deck Driver PCB
Inputs and outputs to the Paper Deck Driver PCB (1/3)
Figure 2-102
CHAPTER 2 OPERATION OVERVIEW
2-2
COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
Paper deck driver PCB
"0" when sensor detects paper.
Registration
paper sensor
PS1
J207-
4 -6
-5 REGS*
J308-
3 -1
-2
J305-
4 -6
-5 P5VB1
"0" when sensor detects paper.
Jam
sensor
PS2
J207-
1 -3
-2 JAMS*
J307-
3 -1
-2 P5VB2
J209-3
-1
-2
J209-
6 -4
-5
J305-1 -
3
-2
Delivery motor
SPM2
FED1AD
FED1AND
FED1BD
FED1BND
J206-
1 -2
-3
-4
Delivery motor rotation
control signal.
J302-4
-3
-2
-1
+24V
J207-7 -
8
J306-1
-2
Registration
roller clutch
REGCLD* The registration roller rotates
when "0".
CL1 J210-2
-1
Drive motor
SPM1
DRVAD
DRVAND
DRVBD
DRVBND
J205-
1 -2
-3
-4 Motor rotation control signal.
To option controller
PCB
+24V
J201-5/-10/-15
-1
-3
-4
-6
-12
-13
-2/-7/-8/-9/-11/-14
TXI
RXO
CONTO
CKI
STRBI
PWRON-IN
Serial signal (input)
Serial signal (output)
Communications ready signal
Clock signal
Strobe signal
Power-on signal
Serial signal (input)
Serial signal (output)
Communications ready signal
Clock signal
Strobe signal
Power-on signal
+24V
TXO
RXI
CONTI
CKO
STRBO
PWRON-OUT
J202-5/-10/-15
-1
-3
-4
-6
-12
-13
-2/-7/-8/-9/-11/-14
To other option driver
PCB
J301-
4 -3
-2
-1
Jxxx-1
-2
-3
-4
Jxxx-1
-2
-3
-4

Inputs and outputs to the Paper Deck Driver PCB (2/3)
Figure 2-103
CHAPTER 2 OPERATION OVERVIEW
2-3
COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
Paper feed PCB
“0” when the delivery assembly
is open.
RDOORS*
“0” when cassette 4 is detected.
LDECKC*
“0” when cassette 3 is detected.
UDECKC*
These two sensors in
combination detect the amount
of paper remaining in cassette 4.
LPVS2
LPVS1
UPVS2
UPVS1
“0” when there is paper
in cassette 4.
LDECKS
These two sensors in
combination detect the amount
of paper remaining in cassette 3.
“0” when there is paper
in cassette 3.
UDECKS
+5V
FEDAD
FEDAND
FEDBD
FEDBND
Paper feed motor rotation
control signal.
+24V
PUPSLD* “0” when the arm is lowered.
Paper deck driver PCB
Delivery
assembly
sensor
PS3
Cassette 4
sensor
PS1201
Cassette 3
sensor
PS1202
PS1203
PS1204
PS1205
PS1206
PS1207
PS1208
Feeder
motor
SPM3
J1203-2
-1
Cassette paper
feed solenoid
SL1
J1202-1
-2
-3
-4
Cassette 4
remaining paper sensor 1
Cassette 4
remaining paper sensor 2
Cassette 3
remaining paper sensor 1
Cassette 3
remaining paper sensor 2
Cassette 4
paper out sensor
Cassette 3
paper out sensor
P5VBDOR
GND
RDOORS -6
J208-18
J14-3 J1206-1
-2
-1 -2 -3 -16
-10-12
-6-16
-12
-10
-13
-7
-14
-8
-15
-5
-11
-9
-5
-15
-2
-1
-4
-3
-9-11 -17
J1201-5
J1201-4
J1201-20
-19
-18
-17

Inputs and outputs to the Paper Deck Driver PCB (3/3)
Figure 2-104
CHAPTER 2 OPERATION OVERVIEW
2-4
COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
Paper deck driver PCB
User LED control signal
LED PCB
J209-1
-2
-3 GREEN LED
J1-3
-2
-1 RED LED
User LED
Detects the size of cassette 4.
Cassette 4
paper size
detection
switch
SW1601
SW1602
SW1603
SW1604
LSIZE1
LSIZE2
LSIZE3
LSIZE4
Cassette size detection
PCB
Detects the size of cassette 3.
Cassette 3
paper size
detection
switch
SW1601
SW1602
SW1603
SW1604
USIZE1
USIZE2
USIZE3
USIZE4
Cassette size detection
PCB
J229-1
-2
-3
J219-3
-2
-1
J1601B-1
-2
-3
-4
-5
-9
-8
-7
-6
J204-10
J1601A-1
-2
-3
-4
-5
-4
-3
-2
-1
J204-5
LED1

II. PAPER FEED AND DELIVERY SYSTEM
A. Overview
The paper deck driver PCB starts the paper feed operation when it receives the paper
feed command from the option controller PCB. Paper fed by the Pick up roller is trans-
ported to the feeder assembly by Pick up/feeding roller and the separation roller.The reg-
istration roller corrects any skew feed in the paper and then stops.
The paper deck driver PCB causes the paper feed motor (SPM3) to rotate.This caus-
es the Pick up roller, Pick up/Feedig roller and the separation roller to turn.
At the same time, after the paper deck driver PCB causes the motor (SPM1) to rotate,
the paper feed solenoid (SL1) is turned on. This lowers the Pick up roller to the surface
of the paper. As a result, the rotating Pick up roller feeds the paper to the feeder assem-
bly. The paper transported to the feeder assembly goes through the registration paper
sensor (PS1) and stops temporarily when it reaches the registration roller. When the
paper deck driver PCB subsequently receives the paper feed command it causes the
paper feed motor (SPM3) and the delivery motor (SPM2) to turn. At the same time, the
registration roller clutch (CL1) is turned on.This causes Pick up/feeding roller, the regis-
tration roller and delivery roller 2 to turn, and the paper is fed to the printer assembly.
There are two photo-interrupters (PS1 and PS2) in the delivery path that detect when
the paper reaches the path, and when it goes through it.
The paper deck driver PCB assembly assumes that a paper jam has occurred when
the paper does not reach or pass the sensors (in the paper feed path) within a specified
time. It then stops operation and notifies the option controller PCB that a paper jam has
occurred.
CHAPTER 2 OPERATION OVERVIEW
2-5
COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)

Figure 2-201
CHAPTER 2 OPERATION OVERVIEW
2-6
COPYRIGHT © 1999 CANON INC. CANON 2 ×500 SHEET PAPER DECK-C1 REV.0 FEB. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)
[1]: Cassette 3 paper size detection signal
[2]: Cassette 4 paper size detection signal
[3]: Cassette 4 remaining paper detection signal 1 (LPVS1)
[4]: Cassette 4 remaining paper detection signal 2 (LPVS2)
[5]: Cassette 4 detection signal (LDECKC*)
[6]: Cassette 4 paper out detection signal (LDECKS*)
[7]: Cassette 3 remaining paper detection signal 1 (UPSV1)
[8]: Cassette 3 remaining paper detection signal 2 (UPSV2)
[9]: Cassette 3 detection signal (UDECKC*)
[10]: Cassette 3 paper out detection signal (UDECKS*)
[11]: Registration paper detection signal (REGS*)
[12]: Multi-feed manual tray detection signal (MPTPS*)
PS1: Registration paper sensor
PS2: Jam sensor
PS1201: Cassette 4 sensor
PS1202: Cassette 3 sensor
PS1203: Cassette 4 remaining paper sensor 1
PS1204: Cassette 4 remaining paper sensor 2
PS1205: Cassette 3 remaining paper sensor 1
PS1206: Cassette 3 remaining paper sensor 2
PS1207: Cassette 4 paper out sensor
PS1208: Cassette 3 paper out sensor
PS1601: Cassette size detection switch
PS1601: Cassette size detection switch
PS1601: Cassette size detection switch
PS1601: Cassette size detection switch
PS1201
PS1207
PS1202
PS1208
SW1601
SW1602
SW1603
SW1604 PS1205
PS1206
PS1203
PS1204
11
SW1601
SW1602
SW1603
SW1604
Paper feed PCB
Pick up roller
Pick up/Feeding roller
Separation
roller
Separation
roller
Pick up
/Feeding
roller
PS1
PS2
Paper deck driver PCB
Option controller PCB
Serial communications
1
Delivery
roller
Registration
roller
Pick up roller
[1] [2] [3] [4] [5] [6] [7] [8] [9][10]
