REALiS — LCOS PROJECTORS
n WUX
4000 D n WUX 4000
n WUX
10 MARK II D n WUX 10 MARK II
n SX
7 MARK II D n SX 7 MARK II
n SX
80 MARK II D n SX 80 MARK II
n SX
800 n SX 60 n X 700
LV SERIES — LCD PROJECTORS
n LV-
8310 n LV- 8215 n LV- 7590 n LV- 7385
n LV-
7380 n LV- 7285 n LV- 7280
Index
REALiS
LCOS Projectors
WUX
10 Mark II D
WUX
10 Mark II . . . . 1
WUX
4000 D
WUX
4000 . . . . . . 2
SX
7 Mark II D
SX
7 Mark II . . . . . 4
SX
80 Mark II D
SX
80 Mark II . . . . . 5
SX
60 . . . . . . . . . 6
SX
800 . . . . . . . . 7
X
700 . . . . . . . . . 8
LV Series
LCD Projectors
LV-
8310
LV- 8215 . . . . . . . 9
LV-
7385
LV- 7380 . . . . . . .10
LV-
7285
LV- 7280 . . . . . . .11
LV-
7590 . . . . . . .12
Optional Accessories
LV-
7590 . . . . . . .13
REALiS . . . . . . . .14
LV Series . . . . . . .15
Comparison
Chart . . . . . . . . .16
Throw Distance
Chart . . . . . . . . .19

At the heart of our LV Multimedia
Projectors lies the amazing
combination of illumination
and flexibility. Among its many
advantages: dramatic image
reproduction, razor-sharp
projection in short and long
range and remarkable resolution
and contrast — all with minimal
internal reflection, flare or
ghosting. User-friendly features
like easy lamp replacement,
sleek ergonomic design and
convenient carrying handle round
out the refined functionality of
our newest models.
An ideal balance of consistency,
color and image clarity make the
Canon LV Series ideal for many
venues.
When it comes to demonstrating sheer performance, no one
outshines Canon. Our REALiS and LV Series Multimedia
Projectors are powerful proof of how Canon's focus on the
optical sciences results in outstanding projection technology.
Using revolutionary LCOS
technology, Canon projectors will
display your images in ways that
leave your audiences amazed.
LCOS stands for Liquid Crystal
on Silicon — a technology
whose high aperture ratio allows
for the reproduction of seamless
images.
The benefits of Canon AISYS-
enhanced LCOS technology
will absolutely floor you.
Astoundingly accurate image
reproduction. Print legibility down
to 7-point type. Breathtaking
colors in crisp, exquisite and
pixel-free clarity and detail.
Offering a significantly larger
display area, our WUXGA and
SXGA+ projectors allow you to
view more data than either XGA
or WXGA. For performance you
have to see to believe, step up
to the new reality. Step up to
REALiS projectors.
Sharpen your performance
with LCD projection:
The Canon LV Series
Take your presentation to
the LCOS extreme – with
Canon REALiS Projectors
(helvetica)

FEATURES
n 1.5x Optical Powered Zoom Lens (10:0 Lens Offset)
n AISYS-Enhanced LCOS Technology
n 1000:1 Contrast Ratio
n HDMI Version 1.3 Deep Color with 1080p Support
n Full 10-bit Image Processing:
Capable of displaying over 1 billion colors
n DVI-I Interface with HDCP (HD Ready)
n DICOM Simulation Mode (WUX10 Mark II D only)
n Photo Image Mode
n Network Ready RJ-45 Port
n Auto/Manual Keystone Correction (+/- 20˚ Vertical)
n Throw Distance: 3.9 to 29.9 ft. (1.2 to 9.1 m)
n Projected Image Size: 40 to 300 in.
n Auto Setup
n Quiet Operation: 36/32 dB (Normal/Quiet Mode)
n Long Lamp Life 3000h (Quiet Mode)
n 3-Year Parts and Labor Limited Warranty
120-Day Lamp Warranty
• Projector • Wireless Remote Control (AAA batteries included)
• Computer Cable (DVI-VGA) • Component to VGA Adapter Cable
• Power Cable • Lens Cap • Soft Carrying Case • Quick Start Guide
• Warranty Information
(W x D x H): 11.2 x 13.2 x 4.5 in. (284 x 336 x 114 mm)
10.8 lbs (4.9 kg)
KIT CONTENTS
DIMENSIONS & WEIGHT
Bring WUXGA High-Definition features to the business
environment in this compact, lightweight, high-performance projector.
WUX10
SX80
SX7
SX800
SX6
SX60
X700
LV7590
LV7375
LV7370
LV7265
LV8300
WUX4000
1
See back page for details on our “Triple P” Loaner Service Program.
WUX10 MARK II D
WUX10 MARK II
WUXGA
1920 x 1200 3200 Lumens
LCOS
Technology
Item Codes: 4231B005 (WUX10 Mark II D), 4231B002 (WUX10 Mark II)

23
LV-7585
Lens changes must be performed by a Canon-authorized representative.
Optional Accessories
FEATURES
n 3 Optional Lenses Available
n 1.5x Zoom Lens
n Long Focus Zoom Lens
n Ultra Wide Angle Lens
n AISYS-Enhanced LCOS Technology
n 1000:1 Contrast Ratio
n Motorized Lens Shift
n HDMI Version 1.3 Deep Color with 1080p Support
n DVI-D Interface with HDCP
n Network Ready RJ-45 Port
n DICOM Simulation Mode (WUX4000 D only)
n Keystone Correction (V= Vertical / H= Horizontal)
n 1.5x Zoom Lens (-11°/+20° V, +/-20° H)
n Long Focus Zoom Lens (+/-20° V, +/-20° H)
n Ultra Wide Angle Lens (+/-13° V, +/-20° H)
n Quiet Operation: 39/36 dB (Normal/Quiet Mode)
n Long Lamp Life (4,000 hours in Quiet Mode)
n 3-Year Parts and Labor Limited Warranty
120-Day Lamp Warranty
KIT CONTENTS
Three optional lenses and motorized lens shift make
the WUX4000 Series ideal installation models.
See back page for details on our “Triple P” Loaner Service Program.
WUXGA
1920 x 1200 4000 Lumens
LCOS
Technology
Item Codes: 4964B005 (WUX4000 D), 4964B002 (WUX4000)
WUX4000 D
WUX4000
WUX4000 D
WUX4000
WUX10
SX80
SX7
SX800
SX6
SX60
X700
LV7590
LV7375
LV7370
LV7265
LV8300
WUX4000
• Projector • Wireless Remote Control (AAA batteries included)
• Computer Cable (VGA-VGA) • Power Cable • Quick Start Guide
• Warranty Information
OPTIONAL PROJECTOR LENSES
1.5x Zoom Lens (RS-IL01ST)
n Throw Ratio: 1.5:1 - 2.25:1
n Focal Length: 23.0 - 34.5 mm,
1.5x Optical Zoom
n F-number: 1.89 - 2.65
n Projection Distances:
4.26 - 31.49 ft. (1.3 - 9.6 m)
n Lens Shift:
n Vertical: Down 15% - Up 55%
n Horizontal: Left 10% - Right 10%
n Screen Sizes: 40" - 300"
Long Focus Zoom Lens (RS-IL02LZ)
n Throw Ratio: 2.2:1 - 3.75:1
n Focal Length: 34.0 - 57.7 mm,
1.7x Optical Zoom
n F-number: 2.0 - 2.8
n Projection Distances:
6.23 - 46.58 ft. (1.9 - 14.2 m)
n Lens Shift:
n Vertical: Down 15% - Up 55%
n Horizontal: Left 0% - Right 10%
n Screen Sizes: 40" - 300"
Ultra Wide Angle Lens (RS-IL03WF)
n Throw Ratio: 0.8:1
n Focal Length: 12.8 mm
n F-number: 2.0
n Projection Distances:
2.29 - 17.06 ft. (0.7 - 5.2 m)
n Lens Shift:
n Vertical: Down 5% - Up 5%
n Horizontal: Left 2% - Right 2%
n Screen Sizes: 40" - 300"
(W x D x H): 14.96 x 16.92 x 5.90 in. (380 x 430 x 150 mm)
18.7 lbs (without lens)
DIMENSIONS & WEIGHT

4 5
FEATURES
n 1.7x Optical Powered Zoom Lens (9:1 Lens Offset)
n AISYS-Enhanced LCOS Technology
n 1000:1 Contrast Ratio
n DVI-I Interface with HDCP (HD Ready)
n Adobe RGB Color Space
n DICOM Simulation Mode (SX7 Mark II D only)
n Photo Image Mode
n Auto/Manual Keystone Correction
(+/- 20 degrees Vertical/Horizontal)
n Throw Distance: 3.9 to 29.5 ft. (1.2 to 9.0 m)
n Projected Image Size: 40 to 300 in.
n Auto Setup
n Quiet Operation: 35/31 dB (Normal/Quiet Mode)
n Audio Terminals: 3 Inputs, 1 Output
n Long Lamp Life 3,000 hours (Quiet Mode)
n 3-Year Parts and Labor Limited Warranty
120-Day Lamp Warranty
• Projector • Wireless Remote Control (AAA batteries included)
• Computer Cable (DVI-VGA) • Component to VGA Adapter Cable
• USB Cable • Power Cable • Lens Cap • Soft Carrying Case
• Quick Start Guide • Warranty Information
(W x D x H): 10.5 x 13.2 x 4.5 in. (266 x 336 x 114 mm)
10.6 lbs (4.8 kg)
(W x D x H): 13.0 x 13.4 x 4.8 in. (332 x 340 x 121 mm)
11.5 lbs (5.2 kg)
KIT CONTENTS
DIMENSIONS & WEIGHT DIMENSIONS & WEIGHT
Remarkable color and smooth reproduction make the SX7 series of
projectors perfect for applications with the most precise requirements.
KIT CONTENTS
Outstanding image quality, detail and color reproduction using
SXGA+ resolution enables realistic, full-screen display.
WUX10
SX80
SX7
SX800
SX6
SX60
X700
LV7590
LV7375
LV7370
LV7265
LV8300
WUX4000
WUX10
SX80
SX7
SX800
SX6
SX60
X700
LV7590
LV7375
LV7370
LV7265
LV8300
WUX4000
See back page for details on our “Triple P” Loaner Service Program.See back page for details on our “Triple P” Loaner Service Program.
SX7 MARK II D
SX7 MARK II
FEATURES
n 1.5x Optical Powered Zoom Lens (10:0 Lens Offset)
n AISYS-Enhanced LCOS Technology
n 900:1 Contrast Ratio
n HDMI Version 1.3 Deep Color with 1080p Support
n DVI-I Interface with HDCP (HD Ready)
n DICOM Simulation Mode (SX80 Mark II D only)
n Photo Image Mode
n Network Ready RJ-45 Port
n PC-Free Presentations and PictBridge
n Auto/Manual Keystone Correction (+/- 20˚ Vertical)
n Throw Distance: 3.9 to 29.9 ft. (1.2 to 9.1 m)
n Projected Image Size: 40 to 300 in.
n Auto Setup
n Quiet Operation: 35/31 dB (Normal/Quiet Mode)
n Audio Terminals: 3 Inputs, 1 Output
n Long Lamp Life 2,500 hours (Quiet Mode)
n 3-Year Parts and Labor Limited Warranty
120-Day Lamp Warranty
• Projector • Wireless Remote Control (AAA batteries included)
• Computer Cable (DVI-VGA) • Component to VGA Adapter Cable
• Power Cable • Lens Cap • Soft Carrying Case • Quick Start Guide
• Warranty Information
SX80 MARK II D
SX80 MARK II
SXGA+
1400 x 1050 3000 Lumens
LCOS
Technology
Item Codes: 4232B005 (SX80 Mark II D), 4232B002 (SX80 Mark II)
SXGA+
1400 x 1050 4000 Lumens
LCOS
Technology
Item Codes: 4233B008 (SX7 Mark II D), 4233B002 (SX7 Mark II)

SX800
SX60
FEATURES
n 1.7x Optical Powered Zoom Lens (9:1 Lens Offset)
n AISYS-Enhanced LCOS Technology
n 1000:1 Contrast Ratio
n 2000:1 Contrast Ratio in Home Cinema Mode
n DVI-I Interface with HDCP (HD Ready)
n Optional Network Adapter; RS-NA01 Compatible
n Auto/Manual Keystone Correction
(+/- 20˚ Vertical/Horizontal)
n Throw Distance: 3.9 to 29.5 ft. (1.2 to 9.0 m)
n Projected Image Size: 40 to 300 in.
n Auto Setup
n Quiet Operation: 30/27 dB (Normal/Quiet Mode)
n Long Lamp Life up to 4,000 hours (Quiet Mode)
n 3-Year Parts and Labor Limited Warranty
120-Day Lamp Warranty
• Projector • Wireless Remote Control (AAA batteries included)
• Computer Cable (DVI-VGA) • Component to VGA Adapter Cable
• USB Cable • Power Cable • Lens Cap • Soft Carrying Case
• Quick Start Guide • Warranty Information
KIT CONTENTS
Whisper-quiet operation and Home Cinema Mode allow
for highest quality presentations.
• Projector • Wireless Remote Control (AAA batteries included)
• Computer Cable (VGA-VGA) • Component to VGA Adapter Cable
• Power Cable • Lens Cap • Soft Carrying Case • Quick Start Guide
• Warranty Information
KIT CONTENTS
With high definition and SXGA+ expanded display, this projector
offers an affordable option for high-definition projection.
FEATURES
n 1.5x Optical Powered Zoom Lens (10:0 Lens Offset)
n AISYS-Enhanced LCOS Technology
n 900:1 Contrast Ratio
n VGA/Component/Composite Inputs
n Auto Flesh Tone
n Auto/Manual Keystone Correction (+/- 20˚ Vertical)
n Throw Distance: 3.9 to 29.9 ft. (1.2 to 9.1 m)
n Projected Image Size: 40 to 300 in.
n Auto Setup
n Quiet Operation: 35/31 dB (Normal/Quiet Mode)
Audio Terminals: 3 Inputs, 1 Output
n Long Lamp Life 2,500 hours (Quiet Mode)
n 3-Year Parts and Labor Limited Warranty
120-Day Lamp Warranty
6 7
WUX10
SX80
SX7
SX800
SX6
SX60
X700
LV7590
LV7375
LV7370
LV7265
LV8300
WUX4000
See back page for details on our “Triple P” Loaner Service Program.
See back page for details on our “Triple P” Loaner Service Program.
(W x D x H): 10.5 x 13.2 x 4.5 in. (266 x 336 x 114 mm)
10.1 lbs (4.8 kg)
(W x D x H): 13.0 x 13.4 x 4.8 in. (332 x 340 x 121 mm)
11.5 lbs (5.2 kg)
DIMENSIONS & WEIGHT DIMENSIONS & WEIGHT
WUX10
SX80
SX7
SX800
SX6
SX60
X700
LV7590
LV7375
LV7370
LV7265
LV8300
WUX4000
SXGA+
1400 x 1050 2500 Lumens
LCOS
Technology
Item Code: 1292B002
SXGA+
1400 x 1050 3000 Lumens
LCOS
Technology
Item Code: 3289B002

X700
FEATURES
n 1.2x Optical Zoom Lens
n 16:10 Aspect Ratio for Wide Screen Content
n DVI-I Interface with HDCP
n Auto/Manual Keystone Correction (+/-30˚ Vertical)
n Throw Distance: 2.6 to 39.4 ft. (0.8 to 12.1 m)
n Projected Image Size: 21 to 300 inches
n Screen Color Correction with Whiteboard Mode
n Color Management System
n Network Ready RJ-45 Port
n 7W Built-in Speakers
n Reduced Power Consumption in Stand-By Mode
n Quiet Operation: 35/29 dB (Normal/Quiet Mode)
n Quick Start and Quick Power-Off
n Long Lamp Life 5,000 hours (Quiet Mode)
n 3-Year Parts and Labor Limited Warranty
120-Day Lamp Warranty
FEATURES
n 1.7x Optical Powered Zoom Lens (9:1 Lens Offset)
n AISYS-Enhanced LCOS Technology
n 1000:1 Contrast Ratio
n DVI-I Interface with HDCP (HD Ready)
n Optional Network Adapter; RS-NA01 Compatible
n Auto/Manual Keystone Correction
(+/- 20˚ Vertical/Horizontal)
n Throw Distance: 3.9 to 29.5 ft. (1.2 to 9.0 m)
n Projected Image Size: 40 to 300 inches
n Auto Setup
n Quiet Operation: 35/31 dB (Normal/Quiet Mode)
n Audio Terminals: 3 Inputs, 1 Output
n Long Lamp Life up to 3,000 hours (Quiet Mode)
n 3-Year Parts and Labor Limited Warranty
120-Day Lamp Warranty
• Projector • Wireless Remote Control (AAA batteries included)
• Computer Cable (VGA-VGA) • DVI to VGA Adapter
• Power Cable • Lens Cover • Soft Carrying Case
• Quick Start Guide • Warranty Information
• Projector • Wireless Remote Control (AAA batteries included)
• Computer Cable (DVI-VGA) • Component to VGA Adapter Cable
• USB Cable • Power Cable • Lens Cap • Soft Carrying Case
• Quick Start Guide • Warranty Information
KIT CONTENTSKIT CONTENTS
With WXGA resolution and a sleek, portable design, these
projectors meet the increasing demand for widescreen display.
With 4000 lumens and a host of easy-to-use features, this
projector offers affordability and exceptional image quality.
8 9
WUX10
SX80
SX7
SX800
SX6
SX60
X700
LV7590
LV7375
LV7370
LV7265
LV8300
WUX4000
See back page for details on our “Triple P” Loaner Service Program. See back page for details on our “Triple P” Loaner Service Program.
WUX10
SX80
SX7
SX800
SX6
SX60
X700
LV7590
LV7375
LV7370
LV7265
LV8300
WUX4000
(W x D x H): 10.5 x 13.2 x 4.5 in. (266 x 366 x 114 mm)
10.6 lbs (4.8 kg)
(W x D x H): 12.5 x 13.2 x 4.4 in. (317 x 336 x 111 mm)
7.3 lbs (3.3 kg)
DIMENSIONS & WEIGHT DIMENSIONS & WEIGHT
LV-8310
LV-8215
XGA
1024 x 768 4000 Lumens
LCOS
Technology
Item Code: 2224B002
2600
Lumens (LV-8215)
WXGA
1280 x 800 3000 Lumens (LV-8310)
LCD
Technology
Item Codes: 4328B002 (LV-8310), 4329B002 (LV-8215)

FEATURES
n 1.2x Optical Zoom Lens
n DVI-I Interface with HDCP
n Auto/Manual Keystone Correction (+/-30˚ Vertical)
n Throw Distance: 2.6 to 39.4 ft. (0.8 to 12.1 m)
n Projected Image Size: 21 to 300 inches
n Screen Color Correction with Whiteboard Mode
n Color Management System
n Network Ready RJ-45 Port
n 7W Built-in Speakers
n Reduced Power Consumption in Stand-By Mode
n Quick Start and Quick Power-Off
n Quiet Operation: 35/29 dB (Normal/Quiet Mode)
n Long Lamp Life 5,000 hours (Quiet Mode)
n 3-Year Parts and Labor Limited Warranty
120-Day Lamp Warranty
• Projector • Wireless Remote Control (AAA batteries included)
• Computer Cable (VGA-VGA) • DVI to VGA Adapter
• Power Cable • Lens Cover • Soft Carrying Case
• Quick Start Guide • Warranty Information
KIT CONTENTS
With high brightness, and easy to use features, these
projectors are a great solution in environments with ambient light.
10 11
WUX10
SX80
SX7
SX800
SX6
SX60
X700
LV7590
LV7375
LV7370
LV7265
LV8300
WUX4000
See back page for details on our “Triple P” Loaner Service Program.
LV-7385
LV-7380
(W x D x H): 12.5 x 13.2 x 4.4 in. (317 x 336 x 111 mm)
7.3 lbs (3.3 kg)
DIMENSIONS & WEIGHT
FEATURES
n 1.2x Optical Zoom Lens
n 2000:1 Contrast Ratio with Built-In Auto Iris
n DVI-I Interface with HDCP
n Auto/Manual Keystone Correction (+/-30˚ Vertical)
n Throw Distance: 2.6 to 39.4 ft. (0.8 to 12.1 m)
n Projected Image Size: 21 to 300 inches
n Screen Color Correction with Whiteboard Mode
n Color Management System
n Network Ready RJ-45 Port
n 7W Built-in Speakers
n Reduced Power Consumption in Stand-By Mode
n Quiet Operation: 35/29 dB (Normal/Quiet Mode)
n Quick Start and Quick Power-Off
n Long Lamp Life 5,000 hours (Quiet Mode)
n 3-Year Parts and Labor Limited Warranty
120-Day Lamp Warranty
• Projector • Wireless Remote Control (AAA batteries included)
• Computer Cable (VGA-VGA) • DVI to VGA Adapter
• Power Cable • Lens Cover • Soft Carrying Case
• Quick Start Guide • Warranty Information
KIT CONTENTS
These value-driven projectors deliver incredible clarity and
are ideal for a wide variety of environments.
WUX10
SX80
SX7
SX800
SX6
SX60
X700
LV7590
LV7375
LV7370
LV7265
LV8300
WUX4000
See back page for details on our “Triple P” Loaner Service Program.
(W x D x H): 12.5 x 13.2 x 4.4 in. (317 x 336 x 111 mm)
7.3 lbs (3.3 kg)
DIMENSIONS & WEIGHT
LV-7285
LV-7280
3000
Lumens (LV-7380)
XGA
1024 x 768 3500 Lumens (LV-7385)
LCD
Technology
Item Codes: 4324B002 (LV-7385), 4325B002 (LV-7380)
2200
Lumens (LV-7280)
XGA
1024 x 768 2600 Lumens (LV-7285)
LCD
Technology
Item Codes: 4326B002 (LV-7285), 4327B002 (LV-7280)

LV-7590
12 13
LV-7590
OPTIONAL PROJECTOR LENSES
Lens changes must be performed by a Canon-authorized representative.
Ultra Wide-Angle Lens (LV-IL01)
n Throw Ratio: 0.8:1
n Focal Length: 22.33 mm
n F-number: 2.5
n Projection Distances: 3.7 – 6.4 ft.
(1.13 to 1.96 m)
n Screen Sizes: 70" - 120"
Ultra Long Focus Zoom Lens (LV-IL04)
n Throw Ratio: 4.2:1 – 6.0:1
n Focal Length: 111.6 – 155.2 mm,
1.4x Optical Zoom
n F-number: 2.06 – 2.73
n Projection Distances: 11.4 - 82 ft.
(3.48 to 25 m)
n Lens Shift:
Vertical: Up 50%
Horizontal: Left 10% - Right 10%
n Screen Sizes: 40" - 300"
Wide-Angle Zoom Lens (LV-IL02)
n Throw Ratio: 1.3:1 – 1.8:1
n Focal Length: 34.33 – 48.02 mm,
1.4x Optical Zoom
n F-number: 2.5 – 3.06
n Projection Distances: 3.2 – 25.4 ft.
(0.98 to 7.74 m)
n Lens Shift:
Vertical: Up 50%
Horizontal: Left 10% - Right 10%
n Screen Sizes: 40" - 300"
Long Focus Zoom Lens (LV-IL03)
n Throw Ratio: 2.3:1 – 4.2:1
n Focal Length: 63.5 – 111.5 mm,
1.8x Optical Zoom
n F-number: 2.03 – 2.89
n Projection Distances: 8.9 – 46.7 ft.
(2.73 to 14.23 m)
n Lens Shift:
Vertical: Up 50%
Horizontal: Left 10% - Right 10%
n Screen Sizes: 60" - 300"
Optional Accessories
FEATURES
n 5 Optional Lenses Available
n Ultra Wide Angle Lens
n Wide Angle Zoom Lens
n Long Focus Zoom Lens
n Ultra Long Focus Zoom Lens
n 1.3x Zoom Lens
n 1800:1 Contrast Radio
n Powered Lens Shift: V (1:1-10.0), H (2:3-3:2)
n DVI-D Interface with HDCP
n Auto-Winding Filter System
n Manual Keystone Correction
(+/-40˚ Vertical, +/-20˚ Horizontal)
n Easy Integration into Local Control System or Existing
Network (optional network adapter needed)
n Quiet Operation: 39/35 dB (Normal/Quiet Mode)
n Long Lamp Life (3,000 hours in Quiet Mode)
n 3-Year Parts and Labor Limited Warranty
120-Day Lamp Warranty
• Projector • Wireless Remote Control (AAA batteries included)
• Computer Cable (VGA-VGA) • Power Cable • USB Mouse Control
Cable • Lens Cap • Quick Start Guide • Warranty Information
KIT CONTENTS
7000 lumens, optional lenses and the Auto-Winding
Filter System provide installation-friendly design.
WUX10
SX80
SX7
SX800
SX6
SX60
X700
LV7590
LV7375
LV7370
LV7265
LV8300
WUX4000
See back page for details on our “Triple P” Loaner Service Program.
(W x D x H): 14.6 x 17.3 x 7.4 in. (370 x 440 x 187 mm)
25.1 lbs (11.4 kg)
DIMENSIONS & WEIGHT (WITHOUT LENS)
XGA
1024 x 768 7000 Lumens
LCD
Technology
Item Code: 4823B002
1.3x Zoom Lens (LV-IL05)
n Throw Ratio: 1.77:1 - 2.30:1
n Focal Length: 48.2 – 62.6 mm,
1.3x Optical Zoom
n F-number: 1.7 - 2.0
n Projection Distances: 4.6 – 48.2 ft.
(1.4 – 14.7 m)
n Lens Shift:
Vertical: Up 50%
Horizontal: Left 10% - Right 10%
n Screen Sizes: 31" - 400"

14 15
LV Series
REALiS
Product Model No. Use with
n WUX4000 D / WUX4000
n WUX10 MARK II D / WUX10 MARK II
n SX7 MARK II D / SX7 MARK II
n SX80 MARK II D / SX80 MARK II
n SX800 n SX60 n X700
RS-LP03
RS-LP04
RS-CL07
RS-LP05
RS-LP06
RS-CL08
15.75"-23.60"
RS-CL09
23.60"-39.37"
RS-CL10
RS-CL11
LV-CA29
*Compatible with RS-CL07, RS-CL10 and RS-CL11
DVI-D Cable
REALiS Wheeled Carrying Case
Compatible with all REALiS Models
Except 4000 D/ 4000
Ceiling
Extension*
RS-CA01 9.8'
RS-232C
Cable
Replacement
Lamp
RS-NA01
Network
Adapter
Ceiling Mount
1025V632 18"
n
n n n
n
n n n
n n
n
n n n
n
n n n
n n
n n
n
n n
n
n
n
n
n
n
LV-LP32
LV-LP31
LV-CL15
LV-CA32
LV-CA29
n n n
n n n
n n n
n n n
n n n
n n n
n n n
n n n
n LV-8310 n LV-8215 n LV-7590 n LV-7385
n LV-7380 n LV-7285 n LV-7280
Ceiling Mount
Adapter
Component
Cable
Product Model No. Use with
Replacement
Lamp
DVI-D Cable
ATTACHMENT LENS FOR REALiS
SX7 MARK II D / SX7 MARK II / SX60 / X700
0.7x Wide Angle Converter Lens T-WC070
Allows you to expand the projected image size — without changing the distance
between the projector and screen. Simply attach it onto a compatible Canon
REALiS projector via the slip-on adapter, and adjust the image size.** Excellent
for shorter projection distances for meeting rooms, rear-projection, etc.
n Dimensions: 4.67" (d) x 2.14" (l)
Rear Thread: 58mm x 0.75mm pitch
Net Weight: 16 oz. (353 grams)
n
Accessories included: 58mm adapter ring to be
slipped over the projector lens housing; security
leash to connect converter with projector
n Wide Angle Throw Ratio (with adapter): 1.02:1
Optional Accessories
Optional Accessories
**Converter lens limits the zoom range of the projector.
Canon has built its reputation as an industry leader in product
reliability, service and support. No matter what Canon
consumer product you buy, expect a top-rate experience.
From our cutting edge technology to industry-leading
response times for service and support, Canon USA strives for
complete customer satisfaction in everything we do.
www.usa.canon.com/prosatisfaction
1-800-OK-CANON
Replacement
Air Filter RS-FL01
n
Remote Control RS-C04
n
LV-LP33
n
LV-CL13
n
High Ceiling
Mount Adapter LV-CL14
n
n
Network Imager LV-NI03

16
COMPARISON CHART
REALiS
NEW
Computer Input 1
Inputs Input 2
Video
Support
COMPARISON CHART
REALiS
NEW
Computer Input 1
Inputs Input 2
Scanning
Frequency
Video
Support
WUX4000 D
WUX4000
WUX10 Mark II D
WUX10 Mark II SX7 Mark II D SX7 Mark II
FEATURE
1 Supports digital or analog signals. 2 Can be analog pc or 5 BNC input. 3 HDCP Compliant. 4 Using analog PC input 2 and VGA to RGB adapter.
Native Resolution WUXGA SXGA+
(1920 X 1200) (1400 x 1050)
Max. Resolution 1920 x 1200 1600 x 1200
Supported
Aspect Ratio 16:10 4:3
Imaging Device 0.7" LCOS x 3 0.55" LCOS x 3
Brightness 3200 Lumens 4000 Lumens 4000 Lumens 3000 Lumens
Uniformity 88%
Contrast 1000:1 1000:1
Digital Keystone
± 20° Vertical ± 20˚ Vertical ± 20˚ Vertical
(Auto/Manual) See Page 2 (Auto/Manual) (Auto/Manual)
± 20° Horiz. (Manual)
DICOM Mode WUX10 Mark II D Only WUX4000 D Only SX7 Mark II D Only SX80 Mark II D Only
Photo Mode Both Models Both Models
Lens Offset 10:0, Fixed Motorized Lens Shift 9:1, Fixed 10:0, Fixed
Auto Iris No
Zoom 1.5x Powered, See Page 3 1.7x Powered, 1.5x Powered,
12x Digital 12x Digital 12x Digital
Focus Powered, Powered Powered,
(Auto/Manual) (Manual) (Auto/Manual)
Screen Size 40" - 300"
Projection Distance 3.9 - 29.9 ft. See Page 3 3.9 - 29.5 ft. 3.9 - 29.9 ft.
Throw Ratio (D:W) 1.48 - 2.18 : 1 See Page 3 1.46 - 2.43 : 1 1.48 - 2.18 : 1
DVI-I
1
DVI-D DVI-I
1
DVI-I 1
D-sub 15
2 D-sub 15
D-sub 15
2
D-sub 15
2
Computer Outputs N/A D-sub 15 D-sub 15
H:15 ~ 75kHz, H:15 ~ 75 kHz, H:15 ~ 100kHz, H:15 ~ 75kHz,
V:50 ~ 85Hz, V:50 ~ 85kHz, V:50 ~ 100Hz, V:50 ~ 85Hz,
Dot Clock: 170MHz Dot Clock: 162MHz
10
Dot Clock: 170MHz Dot Clock: 170MHz
Video HDMI, DVI-1,
3
HDMI, DVI-D, DVI-I
3
, Component,
4
HDMI, DVI-I3, Component,4
Inputs Component,
4
Composite Component, Composite S-Video, Composite S-Video, Composite
1080p / 1080i / 1035i 1080p / 1080i / 720p 1080i / 1035i / 720p 1080p / 1080i / 1035i
720p / 576p / 576i 576p / 480p / 480i 576p / 576i / 480p 720p / 576p / 576i
480p / 480i 480i 480p / 480i
Audio Stereo audio input x3, Stereo audio input x2 Stereo audio input x3, Stereo audio input x3,
Input/Output Stereo audio output x 1 Stereo audio output x1 Stereo audio output x 1 Stereo audio output x 1
USB Input N/A Mouse (USB) PictBridge (USB)
Serial Control D-sub 9 Mini DIN 8 D-sub 9
Network Yes, RJ-45 N/A Yes, RJ-45
Lamp Type 275W NSH (AC) 330W NSH (AC) 275W NSH (AC) 230W NSH (AC)
Lamp Life Normal/Quiet 2000 / 3000 Hours 3000/4000 hours 2000 / 3000 Hours 2000 / 2500 Hours
Noise Level Normal/Quiet 36 / 32 dB 39 / 36 dB 35 / 31 dB 35 / 31 dB
Power Voltage AC 100 - 240V, 50/60Hz AC 100 - 240V, 50/60Hz
Dimensions (WxDxH) 11.2" x 13.2" x 4.5" 14.96" x 16.92" x 5.90"
11
10.5" x 13.2" x 4.5" 13.0" x 13.4" x 4.8"
Weight 10.9 lbs. 18.7 lbs
11
10.6 lbs. 11.5 lbs
Warranty 3 years parts and labor / 120-day lamp warranty

17 18
H: 2:3 - 3:2, Variable
2600 Lumens (LV-7285)
2200 Lumens (LV-7280)
3500 Lumens (LV-7385)
3000 Lumens (LV-7380)
LV Series
SX60 SX800 X700 LV-7590
REALiS
5 With MLA 6 In Home Cinema Mode 7 One RCA input and one 5BNC input 8 Contrast Ratio 2000:1 with Auto Iris
LV-8310 LV-8215 LV-7385
LV-7380 LV-7285
LV-7280
NEW
± 20° Vertical
(Auto/Manual)
± 20° Horiz. (Manual) ± 20° Vertical
(Auto/Manual) ± 20° Vertical
(Auto/Manual)
± 20° Horiz. (Manual) ± 40° Vertical
± 20° Horiz. (Manual)
9 Using PC input 1 and optional VGA to RGB adapter 10 or less 11 without lenses.
180W NSHA (LV-7380)
SX80 Mark II D
SX80 Mark II
WXGA XGA
(1280 x 800) (1024 x 768)
1600 x 1200
16:10 4:3
0.59" LCD
5
x 3 0.63" LCD
5
x 3 0.63" LCD x 3
3000 Lumens 2600 Lumens
85%
500:1 450:1 500:1 500:1 / 2000:1
8
± 30° Vertical (Auto/Manual)
N/A
N/A
9.1 : 0.9 8.4 : 1.6
No Yes
1.2x (Manual)
Manual
21" - 300"
2.6 - 39.4 ft. 2.6 - 37.1 ft.
1.62 - 1.95 : 1 1.53 - 1.84 : 1
DVI-I
1
D-sub 15
2
D-sub 15
H:15~100kHz, V:50~120kHz, Dot Clock 108MHz
Component Video (with adapter)
9
, Composite, S-Video
1080i / 720p / 576p / 576i / 480p / 480i
Stereo Mini-Jack input x2, Stereo RCA input x1 (R/L),
Stereo Mini-Jack output x1
N/A
D-sub 9
Yes, RJ-45
230W NSHA
4000 / 5000 Hours
35 / 29 dB
AC 100 - 240V, 50/60Hz
12.5" x 13.2" x 4.4"
7.3 lbs.
3 years parts and labor / 120-day lamp warranty
230W NSHA (LV-7385) 180W NSHA
SXGA+ XGA XGA
(1400 x 1050) (1024 x 768) (1024x 768)
1600 x 1200
4:3
0.7" LCOS x 3 0.55" LCOS x 3 0.7" LCOS x 3 1.3" LCD
5
x 3
2500 Lumens 3000 Lumens 4000 Lumens 7000 Lumens
88% 90%
1000:1 / 2000:1
6
900:1 1000:1 1800:1
N/A
N/A
9:1, Fixed 10:0, Fixed 9:1, Fixed
V: 1:1 - 10:0, Variable
No
1.7x Powered, 1.5x Powered, 1.7x Powered,
12x Digital 12x Digital 12x Digital See Page 13
Powered,
(Auto/Manual)
40" - 300" 31" - 400"
2.9 - 29.5 ft. 3.9 - 29.9 ft. 3.9 - 29.9 ft. See Page 13
1.46 - 2.43 : 1 1.48 - 2.18 : 1 1.46 - 2.43 : 1 See Page 13
D-sub 15 DVI-I
1
DVI-D
D-sub 15 D-sub 15 5BNC
N/A D-sub 15
H:15 ~ 100kHz, H:15 ~ 75kHz, H:15 ~ 100kHz, H:15 ~ 100kHz,
V:50 ~ 100Hz, V:50 ~ 85Hz, V:50 ~ 100Hz, V:48 ~ 100Hz,
Dot Clock: 170MHz Dot Clock: 170MHz Dot Clock: 170MHz Dot Clock: 180MHz
DVI-I,
3
Component,
4
Component,
4
DVI-I Component,
4
Component x2,4
S-Video, Composite Composite S-Video, Composite Composite, S-Video
1080i / 1035i / 720p 1080i / 1035i / 720p 1080i / 1035i / 720p 1080i / 1035i / 720p
575p / 575i / 480p 576p / 576i / 480p 575p / 575i/ 480p 575p / 480p / 575i / 480i
480i 480i 480i (PsF / 24, 25, 30)
Stereo audio input Stereo audio input x3, Stereo audio input x2
x 1 Stereo audio output x1 Stereo audio output x1
Mouse (USB) N/A Mouse (USB)
Mini DIN 8 D-sub 9 Mini DIN 8 D-sub 9
Optional Adapter N/A Optional Adapter Optional Network
(RS-NA01) (RS-NA01) Imager (LV-NI03)
180W NSH (DC) 230W NSH (AC) 275W NSH (AC) 330W NSHA
2500 / 4000 Hours 2000 / 2500 Hours 2000 / 3000 Hours 2000 / 3000 Hours
30 / 27 dB 35 / 31 dB 40 / 35 dB
AC 100 - 240V, 50/60Hz
10.5 x 13.2 x 4.5" 13.0" x 13.4" x 4.8" 10.5 x 13.2" x 4.5" 14.6" x 17.3" x 7.4"
11
10.1 lbs. 11.0 lbs. 10.6 lbs. 28.7 lbs.
11
3 years parts and labor / 120-day lamp warranty
Native Resolution WUXGA SXGA+
(1920 X 1200) (1400 x 1050)
Max. Resolution 1920 x 1200 1600 x 1200
Supported
Aspect Ratio 16:10 4:3
Imaging Device 0.7" LCOS x 3 0.55" LCOS x 3
Brightness 3200 Lumens 4000 Lumens 4000 Lumens 3000 Lumens
Uniformity 88%
Contrast 1000:1 1000:1
Digital Keystone ± 20° Vertical ± 20˚ Vertical ± 20˚ Vertical
(Auto/Manual) See Page 2 (Auto/Manual) (Auto/Manual)
± 20° Horiz. (Manual)
DICOM Mode WUX10 Mark II D Only WUX4000 D Only SX7 Mark II D Only SX80 Mark II D Only
Photo Mode Both Models Both Models
Lens Offset 10:0, Fixed Motorized Lens Shift 9:1, Fixed 10:0, Fixed
Auto Iris No
Zoom 1.5x Powered, See Page 3 1.7x Powered, 1.5x Powered,
12x Digital 12x Digital 12x Digital
Focus Powered, Powered Powered,
(Auto/Manual) (Manual) (Auto/Manual)
Screen Size 40" - 300"
Projection Distance 3.9 - 29.9 ft. See Page 3 3.9 - 29.5 ft. 3.9 - 29.9 ft.
Throw Ratio (D:W) 1.48 - 2.18 : 1 See Page 3 1.46 - 2.43 : 1 1.48 - 2.18 : 1
DVI-I 1 DVI-D DVI-I 1 DVI-I
1
D-sub 15
2 D-sub 15
D-sub 15
2
D-sub 15
2
Computer Outputs N/A D-sub 15 D-sub 15
H:15 ~ 75kHz, H:15 ~ 75 kHz, H:15 ~ 100kHz, H:15 ~ 75kHz,
V:50 ~ 85Hz, V:50 ~ 85kHz, V:50 ~ 100Hz, V:50 ~ 85Hz,
Dot Clock: 170MHz Dot Clock: 162MHz 10 Dot Clock: 170MHz Dot Clock: 170MHz
Video HDMI, DVI-1,
3
HDMI, DVI-D, DVI-I
3
, Component,
4
HDMI, DVI-I3, Component,4
Inputs Component,
4
Composite Component, Composite S-Video, Composite S-Video, Composite
1080p / 1080i / 1035i 1080p / 1080i / 720p 1080i / 1035i / 720p 1080p / 1080i / 1035i
720p / 576p / 576i 576p / 480p / 480i 576p / 576i / 480p 720p / 576p / 576i
480p / 480i 480i 480p / 480i
Audio Stereo audio input x3, Stereo audio input x2 Stereo audio input x3, Stereo audio input x3,
Input/Output Stereo audio output x 1 Stereo audio output x1 Stereo audio output x 1 Stereo audio output x1
USB Input N/A Mouse (USB) PictBridge (USB)
Serial Control D-sub 9 Mini DIN 8 D-sub 9
Network Yes, RJ-45 N/A Yes, RJ-45
Lamp Type 275W NSH (AC) 330W NSH (AC) 275W NSH (AC) 230W NSH (AC)
Lamp Life Normal/Quiet 2000 / 3000 Hours 3000/4000 hours 2000 / 3000 Hours 2000 / 2500 Hours
Noise Level Normal/Quiet 36 / 32 dB 39 / 36 dB 35 / 31 dB 35 / 31 dB
Power Voltage AC 100 - 240V, 50/60Hz AC 100 - 240V, 50/60Hz
Dimensions (WxDxH) 11.2" x 13.2" x 4.5" 14.96" x 16.92" x 5.90"
11
10.5" x 13.2" x 4.5" 13.0" x 13.4" x 4.8"
Weight 10.9 lbs. 18.7 lbs
11
10.6 lbs. 11.5 lbs
Warranty 3 years parts and labor / 120-day lamp warranty

©2010 CANON U.S.A., INC.
PRINTED IN U.S.A.
Specifications and availability are subject to change without notice.
Weight and dimensions are approximate. Canon and REALiS are
registered trademarks of Canon Inc. in the United States and may
also be registered trademarks in other countries. imageANYWARE is
a trademark of Canon. Microsoft and Windows are either registered
trademarks or trademarks of the Microsoft Corporation in the United
States and/or other countries. HDMI, the HDMI logo and High
Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC. Other names and products
not mentioned above may be registered trademarks or trademarks
of their respective companies. Warning: Unauthorized recording of
copyrighted materials may infringe on the rights of copyright owners
and be contrary to copyright laws.
0149W593 12/10
1-800-OK-CANON
www.usa.canon.com/projectors
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042 U.S.A.
Canon Canada, Inc.
6390 Dixie Road
Mississauga, Ontario L5T 1P7 Canada
Canon Latin America
703 Waterford Way, Suite 400
Miami, FL 33126 U.S.A.
Canon Mexicana, S. de R.L. de C.V.
Blvd. Manuel Ávila Camacho
No. 138, Piso 17
Col. Lomas de Chapultepec
C.P. 11000 México, D.F. México
Canon’s Projector Protection Program, also known
as “Triple P,” is a service program that provides a
loaner projector of equal or
greater quality in the
event that your projector needs to be repaired.
n Free to any buyer within the 3-year new product
limited warranty
n Canon Customer Support Center toll-free hotline:
1-800-828-4040
n Customer Service Hours: 8 a.m. to midnight,
Monday - Friday and 10 a.m. to 8 p.m., Saturday EST
n For next business day delivery of loaner projector(s),
a Customer Activation Form must be received by Canon
Customer Support Center by 3 p.m. EST (Monday - Friday)
n Customer must provide a valid credit card as security
for the loaner unit
n Delivery not available on Saturday and Sunday
n Program available for products purchased and utilized
in the U.S.A. only
n Applies to Canon Multimedia Projectors only
n Loaner unit based on availability
n Program subject to change at any time without
any given notice
LV-7385, LV-7380, LV-7285, LV-7280
Projection Image Size 25" 40" 60" 100" 200" 300"
Wide 2.6' 3.9' 6.2' 10.2' 20.3' 30.8'
Tele 3.0' 4.9' 7.2' 12.1' 24.6' 37.0'
Projection
Distance
Projection
Distance
REALiS SX80 MARK II D, SX80 MARK II, SX800
Projection Image Size 40" 80" 100" 150" 200" 300"
Wide 3.9' 7.9' 9.8' 14.8' 19.7' 29.9 '
Tele 5.6' 11.5' 14.4' 21.7' 29.2' —
REALiS SX7 Mark II D, SX7 Mark II, SX60, X700
Projection Image Size 40" 80" 100" 150" 200" 300"
Wide 3.9’ 7.9' 9.8' 14.8' 19.7' 29.5'
Tele 5.9’ 11.5' 14.4' 21.7' 29.2' —
Projection
Distance
Projection
Distance
REALiS WUX10 MARK II D, WUX10 MARK II
Projection Image Size 40" 80" 100" 150" 200" 300"
Wide 3.9' 7.9' 9.8' 14.8' 20.0' 29.9 '
Tele 5.6' 11.5' 14.4' 22.0' 29.2' —
PROJECTOR THROW DISTANCE CHART
Projection
Distance
REALiS WUX4000 D, WUX4000 (1.5x Zoom Lens RS-IL01ST)
Projection Image Size 40" 80" 100" 150" 200" 300"
Wide 1.3' 2.6' 3.2' 4.8' 6.4' 9.6 '
Tele 1.9' 3.9' 4.8' 7.2' 9.6' 14.5'
Projection
Distance
REALiS WUX4000 D, WUX4000 (Long Focus Zoom Lens RS-IL02LZ)
Projection Image Size 40" 80" 100" 150" 200" 300"
Wide 1.9' 4.2' 4.7' 7.1' 9.5' 14.2 '
Tele 3.2' 7.2' 8.0' 12.1' 16.1' 24.2'
Projection
Distance
REALiS WUX4000 D, WUX4000 (Ultra Wide Angle Lens RS-IL03WF)
Projection Image Size 40" 80" 100" 150" 200" 300"
Fixed 0.7' 1.6' 1.7' 2.6' 3.4' 5.2 '
Projection
Distance
LV-7590 (Wide Angle Zoom Lens LV-IL02)
Projection Image Size 40" 80" 100" 150" 200" 300"
Wide 3.3' 6.7' 8.3' 12.6' 16.8' 25.4'
Tele 4.7' 9.5' 12.0' 18.1' 24.3' 36.4'
Projection
Distance
LV-7590 (Long Focus Zoom Lens LV-IL03)
Projection Image Size 40" 80" 100" 150" 200" 300"
Wide 5.8' 12.1' 15.3' 23.1' 31.0' 46.7'
Tele 10.8' 22.2' 27.8' 41.9' 56.1' 84.3'
Projection
Distance
LV-7590 (Ultra Long Focus Zoom Lens LV-IL04)
Projection Image Size 40" 80" 100" 150" 200" 300"
Wide 11.4' 22.3' 27.7' 41.3' 54.8' 81.9'
Tele 15.8' 30.9' 38.5' 57.5' 76.5' 114.6'
Projection
Distance
LV-7590 (1.3x Zoom Lens LV-IL05)
Projection Image Size 40" 80" 100" 150" 200" 300"
Wide 4.6' 9.4' 11.8' 17.9' 23.9' 36.1'
Tele 6.0' 12.3' 15.3' 23.2' 31.0' 46.7'
LV-7590 (Ultra Wide Angle Lens LV-IL01)
Projection Image Size 70" 80" 100" 120"
Fixed 3.8' 4.3' 5.3' 6.4'
Projection
Distance
LV-8310, LV-8215
Projection Image Size 25" 40" 60" 100" 200" 300"
Wide 2.6' 4.2' 6.4' 10.8' 21.7' 32.6'
Tele 3.2' 5.1' 7.7' 13.0' 26.1' 39.2'
Projection
Distance
19
