HUBBARD 2-TIER SHOE STORAGE CABINET
MODEL NO. 168-0081-8
ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670-6684

4
8
19
TABLE OF CONTENTS
TOOLS REQUIRED
• This product is intended for domestic indoor use only.
• The product should be placed on a flat horizontal surface.
• Arrange necessary manpower when assembling or moving the product.
Do not push furniture, especially on a carpeted floor. Have someone help
you lift heavy items and set in place.
• Check all screws periodically for tightness. When required, tighten them again.
WARNING! TO REDUCE THE RISK OF SERIOUS INJURY,
READ THE FOLLOWING SAFETY INSTRUCTIONS BEFORE
ASSEMBLING AND USING THE STORAGE CABINET.
•
•
Do not exceed maximum eight capacity of 44 lb (20 kg).
Clean with your favourite furiture polish or wipe clean with a damp cloth.
3
HUBBARD 2-TIER SHOE STORAGE CABINET
19
Warranty
Caring for your item
Parts List/ Exploded View
Step-by-Step Instructions
That's why the CANVAS assortment gets
its inspiration from Canadians and the
way they live.
From on-trend furniture pieces, to
Holiday Decor and Outdoor Living,
CANVAS m
space
ake
ee
s it easy to refresh your
your unique style and
the way you live.
We welcome your thoughtful
comments and feedback p so lease
visit our website to tell us about
your experience.
We would love to see how you bring
CANVAS to life. Please share your
photos using #mycanvasstyle.
o
We believe the power of decor and
how it makes up the fabric of your home.
No. 2 Phillips Screwdriver
Tip Shown Actual Size Hammer 2 people
To avoid damage, ensure screws are
hand tightened. DO NOT USE POWER
TOOLS TO ASSEMBLE YOUR UNIT

4 5
ITEM DESCRIPTION QUANTITY
Top 1
Left End 1
Right End 1
2
Divider Fronts
Drawer Fronts
2
Divider Backs 2
Drawer Bottoms 2
Support Rail 1
Skirt 1
Skirt Back 1
Backs 2
PARTS LIST EXPLODED VIEW
1
4
5
6
7
9
10
11
8
2
3
HUBBARD 2-TIER SHOE STORAGE CABINET HUBBARD 2-TIER SHOE STORAGE CABINET

6 7
ITEM DESCRIPTION QUANTITY
A Angle Head Screws 10
B Wood Dowels 10
C Hidden Cams 10
D Silver Flat Head Screws 28
E Fasteners 4
F 2
G Long Screws 2
H Pan Head Screws 2
I Left Flip Frames 2
J Right Flip Frames 2
L Expanding Screws 2
K Anti-Tip Hardware 2
Screws
PARTS LIST EXPLODED VIEW
A
B
C
D
E
F
G
H
I
J
K
L
HUBBARD 2-TIER SHOE STORAGE CABINET HUBBARD 2-TIER SHOE STORAGE CABINET

8 9
STEP 1
REQUIRES D, I, J, 4
NOTE: Two people are needed to build this unit.
Fasten LEFT FLIP FRAME (I) and RIGHT FLIP FRAME (J) to DRAWER FRONT (4),
using twelve SILVER FLAT HEAD SCREWS（D）.
Hand tighten twelve SILVER FLAT HEAD SCREWS.
Repeat for second DRAWER FRONT.
NOTE: Ensure the SILVER FLAT HEAD SCREWS (D) are in the exact holes.
STEP 2
REQUIRES D, I, J, 6, 7
Fasten LEFT FLIP FRAME (I) and RIGHT FLIP FRAME (J) to DIVIDER BACK (6) and
Drawer Bottom (7), using eight SILVER FLAT HEAD SCREWS（D).
Hand tighten eight SILVER FLAT HEAD SCREWS.
Repeat for second DRAWER FRONT.
NOTE: Ensure eight SILVER FLAT HEAD SCREWS (D) are in the exact holes.
Ensure the SILVER FLAT HEAD SCREWS are tightened.
D
D
HUBBARD 2-TIER SHOE STORAGE CABINET HUBBARD 2-TIER SHOE STORAGE CABINET
STEP-BY-STEP INS STRUCTION
DJ D
I
D
D

10 11
STEP 3
REQUIRES A, 2, 3
Insert three ANGLE HEAD SCREWS (A) into LEFT END (2).
Hand tighten the ANGLE HEAD SCREWS.
Insert three ANGLE HEAD SCREWS (A) into RIGHT END (3).
Hand tighten the ANGLE HEAD SCREWS.
STEP 4
REQUIRES A, K, H, 1
Insert four ANGLE HEAD SCREWS (A) into the TOP (1).
Fasten two ANTI-TIP HARDWARE (K) to the TOP (1), using two Pan Head Screws (H).
Hand tighten two PAN HEAD SCREWS (H).
NOTE: Ensure the ANGLE HEAD SCREWS are in the exact holes.
HUBBARD 2-TIER SHOE STORAGE CABINET HUBBARD 2-TIER SHOE STORAGE CABINET
STEP-BY-STEP INS STRUCTION
A
A
A
A
A
A
A
A
K
K
H
H
A
A
A
A
H
AK

12 13
STEP 5
REQUIRES B, C , 2 , 3 , 8 , 9, 10
Insert four WOOD DOWELS (B) into SKIRT (9) and SKIRT BACK (10).
Insert two WOOD DOWELS (B) into SUPPORT RAIL (8).
Insert six HIDDEN CAMS (C) into SUPPORT RAIL (8) and SKIRT BACK (10).
Fasten SUPPORT RAIL (8) and SKIRT BACK (10) to LEFT END (2) and RIGHT END (3).
Hand tighten six HIDDEN CAMS (C).
NOTE：Ensure the HIDDEN CAMS are tightened.
STEP 6
REQUIRES 2, 3, 11
Insert the BACK (11) into the groove between the LEFT END (2) and the RIGHT END (3).
Mark equal margins along all four edges of the BACK (11).
Push on opposite corners of your unit if needed to make it “square”.
HUBBARD 2-TIER SHOE STORAGE CABINET
STEP-BY-STEP INS STRUCTION
B
C
B
C
B

14 15
REQUIRES B, C, F, 1, 2, 3, 8, 11
Insert four WOOD DOWELS (B) to THE TOP (1).
Insert four HIDDEN CAMS (C) into LEFT END（2）and RIGHT END（3）.
Fasten the TOP (1) to LEFT END (2) and RIGHT END (3).
Hand tighten the four HIDDEN CAMS.
Fasten the BACK (11) to SUPPORT RAIL (8), using two SCREWS (F).
Hand tighten two SCREWS (F).
STEP 8
STEP 7
REQUIRES D, E, I, J, 2, 3
Retrieve completed drawers.
Insert FASTENER (E) to aflix it to the LEFT FLIP FRAME (I), using one
SILVER FLAT HEAD SCREW (D).
Hand tighten one SILVER FLAT HEAD SCREW (D).
Repeat above step for RIGHT FLIP FRAME (J).
Repeat above step for Bottom Drawer.
HUBBARD 2-TIER SHOE STORAGE CABINET HUBBARD 2-TIER SHOE STORAGE CABINET
D E
STEP-BY-STEP INS STRUCTION
CF
B
B
F
F
B
C
C
B
E
D

16
STEP 9 STEP 10
REQUIRES G, K, L
Carefully stand your unit upright and place in its final location.
Using ANTI-TIP HARDWARE as a guide, mark 2 spots on the wall.
Insert two EXPANSION SCREWS (L) into the wall.
Insert two EXPANSION SCREWS (L) into the wall. Hammer EXPANSION SCREWS into the wall.
Fasten ANTI-TIP HARDWARE (K) to the WALL, using two LONG SCREWS (G).
Hand tighten the LONG SCREWS.
This completes assembly.
17HUBBARD 2-TIER SHOE STORAGE CABINET
HUBBARD 2-TIER SHOE STORAGE CABINET
STEP-BY-STEP INS STRUCTION
D
G
L
D
D
J
I
D
L
K
G
L
REQUIRES D, I, J, 5
Fasten DIVIDER FRONT (5) to LEFT FLIP FRAME (I) and RIGHT FLIP FRAME (J),
using four SILVER FLAT HEAD SCREWS (D).
Hand tighten four SILVER FLAT HEAD SCREWS.
Repeat above step for the BOTTOM DRAWER.

18 HUBBARD 2-TIER SHOE STORAGE CABINET
MAXIMUM WEIGHT CAPACITY
This unit has been designed to support the maximum loads shown. Exceeding these
load limits could cause sagging, instability, product collapse, and/or serious injury.
Please make sure that all the objects are removed before moving the assembled unit.
The unit must be lifted by more than one person, not dragged or pushed. Failure to do so
will cause product damage, instability, product collapse, and/or serious injury.
STEP-BY-STEP INS STRUCTION
44 lb (20 kg)
