Canvas ROBSON 168-0048-0 User manual

ASSEMBLY INSTRUCTIONS
Toll free: 1-888-670-6684
IMPORTANT: Please read this manual carefully before beginning assembly of this
product. Keep this manual for future reference.
MODEL NO. 168-0048-0
ROBSON MEDIA STAND

IMPORTED BY TRILEAF DISTRIBUTION TRIFEUIL TORONTO, CANADA M4S 2B8
MADE IN CHINA

3
IMPORTANT SAFETY INSTRUCTIONS TABLE OF CONTENTS
IMPORTANT: Retain for future reference, and read carefully.
Warning! To reduce the risk of serious injury, read the following safety
instructions before assembling and using the media stand.
• Death or serious injury may occur when children climb on audio and/or video equipment furniture. A
remote control or toys placed on the furniture may encourage a child to climb on the furniture and as a
result may tip over onto the child.
• NEVER allow children to climb or play with the TV or furniture supporting the TV.
• NEVER place toys, food, remote, etc. on top of the TV or media stand.
• ALWAYS use either the safety hardware as instructed or other wall anchoring device.
• Relocating audio and/or video equipment on furniture not specifically designed to support audio and/or
video equipment may result in death or serious injury due to furniture collapse or over turning onto a child.
• Accommodates most flat-screen televisions up to 60” (152.4 cm) weighing 70 lb (31.75 kg) or less.
• Be sure to apply the TV warning label as shown in the instructions.
• Overloading shelves may result in furniture that can break or sag, or tip over which may result in injury.
• NEVER exceed the weight limits shown in the instructions.
• Place the heavier items on lower shelves as far back from the front as possible.
• Load the bottom surfaces first to avoid top-heavy furniture.
• Moving furniture that is not designed to be moved or equipped with castors may result in injury or damage
to furniture or personal property.
• ALWAYS unload shelves, starting with the top surfaces, before moving.
• NEVER push or pull furniture on carpet. Have a friend help lift properly to move and/or reposition it.
Important Safety Instructions 3
Parts List 4-7
Assembly Preparation 8
Assembly 9-22
Cleaning and Maintenance 23
Technical Data 23
Warranty 24

PARTS LIST
MODEL NO. 168-0048-0
4
Bottom - 1
F
Small Shelf - 2
K
Large Shelf - 1
J
Back - 1
H
Valance - 1
G
Right End - 1
A
Top - 1
E
Left Upright - 1
D
Right Upright - 1
C
Left End - 1
B

5
PARTS LIST
Right Door - 1
L
Short Brace - 1
P
Long Brace - 2
O
Leg - 2
N
Left Door - 1
M
Tube - 1
R
Foot - 1
Q

PARTS LIST
MODEL NO. 168-0048-0
6
Hidden Cam - 17
1
Pin with Sleeve - 8
7
Door Bracket - 4
6
Retaining Bar - 4
5
Bracket - 4
4
Wood Dowel - 12
3
Cam Screw - 17
2
Bumper Card - 1
12
Applique Card - 3
11
Nail - 30
10
Pull - 2
9
Metal Pin - 4
8

7
PARTS LIST
Warning Label - 1
13
Black 9/16” Large Head Screw - 8
18
Never use this furniture with a
TV that is too large or too heavy.
Severe injury or death can occur.
The TV and furniture will be
unstable and may tip.
-The TV must weigh less than
70 lbs.
-The base of the TV must be able
to sit completely on this shelf.
Refer to instruction book for
complete safety information.
Note: This is a permanent label.
Do not try to remove. Surface
will be damaged. 01/18
Ne jamais utiliser ce meuble avec
un téléviseur qui soit trop large ou
trop lourd. Risque de provoquer
des blessures graves, voire mor-
telles. Le téléviseur et le meuble
seront instables et risquent de
se renverser.
-Le téléviseur doit peser
31,75 kg ou moins.
-Le socle du téléviseur doit
pouvoir être placé complètement
sur cette tablette.
Consulter le manuel d’instructions
pour information complète
concernant la sécurité.
Remarque: Cette étiquette est
permanente. Ne pas essayer de la
retirer. Causer des dommages à
la surface. 01/18
WARNING AVERTISSEMENT•
Black 1-1/4” Wafer Head Screw - 8
17
Black 1-9/16” Wafer Head Screw - 4
16
Black 2” Flat Head Screw - 4
15
L-Wrench - 1
14
Black 3/8” Machine Screw - 4
22
Black 1/2” Hex Head Screw - 10
21
Black 1/2” Flat Head Screw - 8
20
Black 1/2” Pan Head Screw - 8
19

8
GARANTIEASSEMBLY PREPARATION
Needed for Assembly:
LET US HELP YOU!
DO NOT RETURN YOUR PRODUCT TO THE STORE. CALL US FIRST!
1-888-670-6684
If you have questions regarding your product, require warranty
assistance, or have damaged or missing parts, please call our customer
service toll-free helpline. Contact us for assistance, we’re here to help.
Hammer
No. 2 Phillips Screwdriver
Tip Shown Actual Size 1 person
CAUTION!
IMPORTANT: Please read and understand this manual before any assembly. Before beginning
assembly of product, make sure all parts are present. Compare parts with packaging contents
list. If any part is missing, or if you have any questions, contact the service centre at
1-888-670-6684 (toll free).
Place all parts from the box in a cleared area and position them on the floor in front of you.
Remove all packing materials and place them back into the box. Do not dispose of the packing
materials until assembly is complete. Read each step carefully before beginning any assembly
and make sure you understand each step. If you are missing a part, please call our toll-free
number for assistance 1-888-670-6684.
MODEL NO. 168-0048-0
• Proper placement of your media stand is essential.
• Keep children away during assembly.
This product contains small parts which can be swallowed by children.
• Keep fingers away from the places where they can be pinched or trapped
• Do not attempt to assemble the media stand if any parts are missing.

9
ASSEMBLY
Step 1
Requires A, B, C, D, F, G, 1
Push seventeen HIDDEN CAMS (1) into the ENDS (A and B), UPRIGHTS (C and D),
BOTTOM (F), and VALANCE (G).
B
F
G
A
C
D
The arrow in the HIDDEN
CAM must point toward the
hole in the edge of the board.
Hole
Arrow
(17 used)
Arrow
1
1

10
ASSEMBLY
MODEL NO. 168-0048-0
Step 2
Requires A, B, E, 2
Turn seventeen CAM SCREWS (2) into the exact holes shown in the ENDS (A and B)
and TOP (E).
2
E
B
2
A
(17 used)

11
ASSEMBLY
Step 3
Requires B, F, G, 3
Insert one WOOD DOWEL (3) into the LEFT END (B).
Fasten the VALANCE (G) to the LEFT END (B). Tighten one HIDDEN CAM.
NOTE: Ensure the WOOD DOWEL in the LEFT END has been inserted into the VALANCE (G).
Insert one WOOD DOWEL (3) into the LEFT END (B).
Fasten the BOTTOM (F) to the LEFT END (B). Tighten two HIDDEN CAMS.
NOTE: Ensure the WOOD DOWEL in the LEFT END has been inserted into the BOTTOM (F).
Unfinished edge
B
F
G
B
3
1
2
Surface with
HIDDEN CAMS
3
3
Surface with
HIDDEN CAMS
The groove
must be here.
Unfinished edge

12
ASSEMBLY
MODEL NO. 168-0048-0
Step 4
Requires A, C, D, 3, 15
Insert two WOOD DOWELS (3) into the RIGHT END (A).
Fasten the RIGHT END (A) to the BOTTOM (F) and VALANCE (G). Tighten two
HIDDEN CAMS.
NOTE: Ensure the WOOD DOWELS in the RIGHT END have been inserted into the
BOTTOM and VALANCE.
Insert two WOOD DOWELS (3) into the BOTTOM (F).
Fasten the UPRIGHTS (C and D) to the BOTTOM (F). Use four BLACK 2” FLAT
HEAD SCREWS (15).
NOTE: Ensure the WOOD DOWELS in the BOTTOM have been inserted into the UPRIGHTS.
3
3
A
F
G
F
C
D
Unfinished edge
Surface with
HIDDEN CAMS
3 15
Notch
15

13
ASSEMBLY
Step 5
Requires E, 3
Insert six WOOD DOWELS (3) into the TOP (E).
Fasten the TOP (E) to the ENDS (A and B), UPRIGHTS (C and D), and VALANCE (G). Tighten
eleven HIDDEN CAMS.
NOTE: Ensure the WOOD DOWELS in the TOP have been inserted into the ENDS, UPRIGHTS,
and VALANCE.
B
E
3
A
C
D
3(6 used)
Edge with more
CAM SCREWS
G

14
ASSEMBLY
MODEL NO. 168-0048-0
Step 6
Requires H, 10
Unfold the BACK (H) and lay it over your unit.
Make equal margins along all four edges of the BACK (H). Push on opposite corners
of your unit if needed to make it “square”.
Fasten the BACK (H) to your unit using the NAILS (10).
NOTE: Tap NAILS into the holes that line up over the UPRIGHTS (C and D).
NOTE: Perforations have been provided for access through the BACK.
H
10
(30 used) 10
Unfinished surface
These holes must
line up over the
UPRIGHTS (C and D).

15
ASSEMBLY
Step 7
Requires N, O, P, Q, 14, 21
Fasten the SHORT BRACE (P) to the LONG BRACES (O). Tighten four BLACK 1/2”
HEX HEAD SCREWS (21) using the L-WRENCH (14).
Fasten the FOOT (Q) to the SHORT BRACE (P). Tighten two BLACK 1/2” HEX HEAD
SCREWS (21) using the L-WRENCH (14).
Fasten the LEGS (N) to the LONG BRACES (O). Tighten four BLACK 1/2” HEX HEAD
SCREWS (21) using the L-WRENCH (14).
O
O
These holes must
be facing up.
P
O
O
N
N
Q
14 21
(10 used)
21
21

16
ASSEMBLY
MODEL NO. 168-0048-0
Step 8
Requires N, O, 16, 17
Carefully turn your unit onto its top.
NOTE: Start each SCREW a few turns before completely tightening any of them.
Fasten the LEGS (N) to the BOTTOM (F). Use four BLACK 1-9/16” WAFER
HEAD SCREWS (16).
Fasten the LONG BRACES (O) to the BOTTOM (F). Use eight BLACK 1-1/4” WAFER
HEAD SCREWS (17).
O
O
N
N
F
(8 used)
16
17
16
16 17

17
ASSEMBLY
Step 9
Requires 4, 20
Carefully stand your unit upright.
Fasten four BRACKETS (4) to the VALANCE (G). Use four BLACK 1/2” FLAT
HEAD SCREWS (20).
NOTE: Position the BRACKETS exactly as shown.
G
4 20
4
20
(4 used)

18
ASSEMBLY
MODEL NO. 168-0048-0
Step 10
Requires J, K, R, 7, 8, 22
Fasten the TUBE (R) to the BRACKETS (4). Use four BLACK 3/8”
MACHINE SCREWS (22).
NOTE: Start each SCREW a few turns before completely tightening any of them.
Insert four METAL PINS (8) into the hole locations of your choice in the centre
surfaces of the UPRIGHTS (C and D). Set the grooves in the LARGE SHELF (J)
onto the PINS.
Insert eight PINS WITH SLEEVES (7) into the hole locations of your choice in the
ENDS (A and B) and UPRIGHTS (C and D). Set the SMALL SHELVES (K) onto
the PINS.
R
K
J
KA
C
D
B
7 8 22
8
(4 used)
7
(8 used)
4
22
(4 used)

19
ASSEMBLY
Step 11
Requires L, M, 5, 9, 19, 20
Fasten the RETAINING BARS (5) to the DOORS (L and M) exactly as shown. Use eight
BLACK 1/2” PAN HEAD SCREWS (19).
Fasten the PULLS (9) to the DOORS (L and M) exactly as shown. Use four BLACK 1/2”
FLAT HEAD SCREWS (20).
M
L
Surface with more holes
205 9 19
NOTE: The RETAINING BAR
should overhang the DOOR.
9
9
5
(8 used) 19
20
20

20
ASSEMBLY
MODEL NO. 168-0048-0
Step 12
Requires L, M, 6, 18
Place the RETAINING BARS on the DOORS (L and M) into the groove in
the BOTTOM (F).
Place the DOOR BRACKETS (6) onto the TUBE (R).
Fasten the DOOR BRACKETS (6) to the DOORS (L and M). Use eight
BLACK 9/16” LARGE HEAD SCREWS (18).
R
M
L
F
6 18
6
(8 used) 18
