Canvas WINDSOR 168-0071-2 User manual

WINDSOR DINING CHAIRS
MODEL NO. 168-0071-2
ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670-6684

We believe the power of decor and
how it makes up the fabric of your home.
That’s why CANVAS assortment gets
its inspiration from Canadians and
the way they live.
From on-trend furniture pieces, to
Holiday Decor and Outdoor Living,
CANVAS makes it easy to refresh your
space to reflect your unique style and
the way you live.
We welcome your thoughtful
comments and feedback so please
visit our website to tell us about
your experience.
We would love to see how you bring
CANVAS to life. Please share your
photos using #mycanvasstyle.

Parts Lists/Exploded Views 4
Step-by-Step Instructions 8
Warranty 10
Caring for your item 10
TABLE OF CONTENTS
TOOLS REQUIRED
No. 2 Phillips Screwdriver
Tip Shown Actual Size
DO NOT USE POWER TOOLS
To avoid damage, ensure screws
are hand tightened.
TO ASSEMBLE YOUR UNIT
2 people
This product is intended for domestic indoor use only.
The product should be placed on a flat horizontal surface.
Arrange necessary manpower when assembling or moving the product.
Do not push furniture, especially on a carpeted floor. Have someone help
you lift heavy items and set it in place.
Check all screws periodically for tightness. When required, tighten them again.
WARNING! TO REDUCE THE RISK OF SERIOUS INJURY,
READ THE FOLLOWING SAFETY INSTRUCTIONS BEFORE
ASSEMBLING AND USING THE DINING CHAIR.
3
• Do not exceed maximum weight capacity of 242 lb (110 kg).
WINDSOR DINING CHAIR

PARTS LIST
1
1
WINDSOR DINING CHAIR4
ITEM DESCRIPTION QUANTITY
A Seat
B Right Leg
C
D Stretcher
Left Leg
PARTS LIST
1
1

EXPLODED VIEW
5
A
B
C
D
WINDSOR DINING CHAIR

PARTS LIST
4
4
2
1
WINDSOR DINING CHAIR6
ITEM DESCRIPTION QUANTITY
1 M6x35 Bolt
2 M6x50 Bolt
3 M6x10 Lock Washer
4 M6x18 Washer
5 M6 Barrel Nut
6 Wooden Cap
7 4x60 Allen Key
4
2
2

EXPLODED VIEW
7
1 2
3 4 5
6 7
WINDSOR DINING CHAIR

D
B
C
6
2
5
26
7
5
STEP 1
REQUIRES B, C, D, 2, 5, 6, 7
Attach RIGHT LEG (B), LEFT LEG (C) and STRETCHER (D) using M6 BARREL NUT (5),
2 5 6 7
BOLT (2), 4x60 ALLEN KEY (7), and WOODEN CAP (6).
X2 X2 X2 X1
WINDSOR DINING CHAIR8
STEP-BY-STEP INSTRUCTIONS

x4
A
7
4
3
1
x4 x4 x4 x1
STEP 2
REQUIRES A, 1, 3, 4, 7
Attach SEAT (A) into the assembled legs shown in Step 1 using M6x35 BOLT (1),
1 3 4 7
M6x10 LOCK WASHER (4), M6x18 WASHER (3) and 4x60 ALLEN KEY (7).
STEP-BY-STEP INSTRUCTIONS
WINDSOR DINING CHAIR 9

STEP BY STEP GUIDE
10 WINDSOR DINING CHAIR
WARRANTY
CARING FOR YOUR ITEM
Wipe clean with a damp
cloth.
WEIGHT LIMIT: Do not
exceed maximum
weight capacity of
242 LBS (110 KG)
1 2
This CANVAS™ product carries a one (1) year warranty against defects in workmanship and
materials. Trileaf Distribution agrees to replace the defective product free of charge within the
stated warranty period, when returned by the original purchaser with proof of purchase. This
product is not guaranteed against wear or breakage due to misuse and/or abuse.
Made in Vietnam
Imported by Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
MODEL NO. 168-0071-2

Exclusively at Canadian Tire
