Caraudio-Systems OBD-ASK-CDC Series User manual

Version 01.04.2011 OBD-ASK-CDC-xx
OBD-ASK-CDC-xx
CD-changer option OBD-coder
for BMW Business M-ASK navigation systems
To install a device to the factory CD-changer port (e.g. factory CD-changer, Dension Gateway
500, AUX-110), it is necessary to enable the CD-changer option in the navigation’s menu,
which can be done with the OBD-ASK-CDC-xx.
OBD-ASK-CDC-01 –One vehicle
OBD-ASK-CDC-10 –Ten codings
Delivery contents
Legal Information
Changes/updates of the vehicle’s software can cause malfunctions of the interface. We
offer free software-updates for our interfaces for one year after purchase. To receive a free
update, the interface must be sent in at own cost. Labor cost for and other expenses
involved with the software-updates will not be refunded.
Take down the SW-version and
HW-version of the interface boxes,
and store this manual for support
purposes.
HW______________
SW______________
OBD-ASK-CDC-xx

Version 01.04.2011 OBD-ASK-CDC-xx
Check compatibility of vehicle and accessories
Installation
1. Locate OBD-port and remove cover
2. Turn on ACC
3. Wait until the navigation has booted
4. Plug coder into OBD-port
5. The navigation will re-boot
6. When the navigation’s startup-screen shows, remove coder from OBD-port
To remove the CD-changer option from the navigation’s menu repeat steps 1.-6.
After the first use on a vehicle, the coder OBD-ASK-CDC-01 is personalized to this vehicle.
On this vehicle the enabling and removing the CD-changer option can be repeated without
limit. The OBD-ASK-CDC-10 can enable exactly 10 times regardless of the vehicle and remove
CD-changer option unlimited times.
Technical Support
Caraudio-Systems Vertriebs GmbH NavLinkz GmbH
manufacturer/distribution corporate sales/tech dealer-support
Rheinhorststr. 22 Eurotec-Ring 45
D-67071 Ludwigshafen am Rhein D-47445 Moers
phone [phone]
email [e-mail]
Legal disclaimer: Mentioned company and trademarks, as well as product names/codes are registered
trademarks ® of their corresponding legal owners.
Requirements
Vehicle 1series (E81/82/87/88), 3series (E90/91/92/93), 5series (E60/61),
6series (E63/64), X5 (E70), X6 (E71), Z4 (E89)
Navigation Navigation system Business with 6.5”monitor
Limitations
Factory-iPod-interface Must NOT be installed.
