Cardo Systems S-800 User manual

When Technology Meets Design
CARDO SYSTEMS, INC.
Gebrauchsanleitung
Guide d’Utilisation
Guida di Avvio
Guia de usario
User Guide
Cardo

english
Congratulations and thank you for choosing the Cardo S-800
Bluetooth®headset. This User Guide will help you learn about the
Cardo S-800’s many features, allowing you to make the best use of
your headset.
CARDO S-800 OVERVIEW
1 Microphone
2 Multi-Function Wheel (MFW)
3 LED Status Indicator
4 Power and Hot Dial Button
5 Charging Jack
6 Control Button (CTRL)
7 Speaker
8 Earloop
1 4 7
5
26
3
8
english
2

english
3
GETTING STARTED
To use your Cardo S-800 (“the headset”), please follow these
initial steps:
• Charge your headset
• Pair your headset with a Bluetooth®-enabled mobile phone.
1. CHARGING YOUR HEADSET
The headset comes with a built-in rechargeable battery. Prior to using
the headset, make sure to charge the headset for at least 4 hours.
Normally it takes approximately 2 hours to fully charge the headset.
1.Connect the charger to an AC wall outlet and the charger plug to
the headset’s Charging Jack. The headset’s LED status indicator
will be red during charging.
2.When the battery is fully charged, the red LED will turn off.
3.Disconnect the charger from AC wall outlet and the headset.
NOTE: Charging indication may be delayed for a few seconds if
the headset has not been used for a long time or the battery is
drained.
The fully charged battery offers up to 8 hours talk time and up to
one week standby time.
2. PAIRING YOUR HEADSET
Before you can use your headset you must pair it to your
Bluetooth-enabled mobile phone. If you do not have a Bluetooth-
enabled mobile phone, please visit http://www.cardosystems.com /BTA
for information on the Cardo BTA II Bluetooth Adapter.

english
4
1.Turn on your phone and turn ON its Bluetooth function.
2.Make sure the headset is turned OFF, then press and hold the
Power Button for approximately 8 seconds until the LED status
indicator begins alternating blue and red, indicating that the
headset is in Pairing Mode.
3.Set the phone to search for Bluetooth devices by following the
instructions in the phone’s user guide. This is usually found in the
phone’s Bluetooth menu and may be referred to as “discover” or
“add” a device.
4.After a few seconds, the phone will list the “Cardo S-800” as a
discovered device. Select it from the list and press “OK” or “Yes”.
5.When prompted, enter the passkey “0000” (4 zeros) and press
“OK” to complete the pairing.
6. When the pairing is complete, your phone will conrm that the
pairing was successful and the headset’s LED status indicator
will begin ashing slowly in blue.
You should now be able to make and receive calls using your
headset. To initially connect the headset to your phone, you may
need to tap the CTRL Button once on the headset.
IMPORTANT: If pairing is not completed within 2 minutes
while the Pairing Mode is activated, the headset will return to
Standby mode, ashing blue once every three seconds and
you must start the Pairing process again from Step 2 above.
NOTE: Your headset can pair with up to 8 phones, and will
automatically connect to the last phone connected to the headset.

english
5
To connect to a different paired phone, go to the Bluetooth menu
of the active phone and disconnect the headset. Then go to the
Bluetooth menu of the phone you wish to connect and connect the
headset by selecting it from the list of Paired Devices.
3. WEARING YOUR HEADSET
The S-800 headset can be worn on either your left or right ear.
There are two ways in which you can wear the S-800 headset.
1.Without the earloop: Gently insert the headset without an
earloop into your ear, and it will hold itself in place securely.
2.With the earloop: Insert the straight section of the pin of the
earloop to a suitable depth so that the speaker ts snugly in your ear.
The earloop is exible, and may be adjusted for maximum comfort.
The lanyard for the S-800 provides
an easy and convenient way of
carrying your headset while it is not
in use.
1.To attach the headset to the
lanyard, insert the speaker into the
upper loop of the lanyard. Then pull
the headset downwards into the
lower loop, until it is held securely
in place.
2.To release the headset from the
lanyard, simply pull the headset
forward at a downward angle.
Upper
loop
Lower
loop

english
6
4. USING YOUR HEADSET – BASIC FUNCTIONS 5. USING YOUR HEADSET – ADVANCED FUNCTIONS
1. Redial the last dialed number
During Standby, press the MFW inwards to redial the last dialed number.
2. Reject an incoming call
During an incoming call, press and hold the CTRL Button for 3
seconds.
3. Call waiting / Toggling between calls
During an incoming call and one call on hold or waiting, tap the
MFW inwards to answer the incoming call or toggle between calls.
4. Conference call
During an active call and one call on hold, press and hold the MFW
inwards for 3 seconds to combine both calls into a Conference call.
Function Required Action
Turn ON/OFF the headset Press and hold the Power Button for at least 4 seconds
Answer a call Tap the CTRL Button*
End a call Tap the CTRL Button
Make a call from
your phone
Dial normally from your phone and the call will be transferred to
the headset (subject to phone settings).
Make a call using
Voice Dial
During Standby, tap the CTRL Button, wait for the tone and say
the name of the person you wish to call. (Your mobile phone
must support the Voice Dial feature.)
Increase the volume
Move the MFW up by steps. When you hear a beep, it is at maximum.
Decrease the volume Move the MFW down by steps.When you hear a beep, it is at minimum.
Mute the microphone During a call, tap the MFW inwards to turn on/off mute.
* Note: wait until you hear the incoming call on the headset (not only on the phone)

english
7
5. Transfer calls to/from headset
During a call, press and hold the CTRL Button for 3 seconds to
transfer the call between the headset and the mobile phone.
NOTE: On some phones, transferring a call to the headset requires
just a tap of the CTRL Button.
6. Hot Dial Function
The S-800 allows you to call any of three different phone numbers
at the press of a button.
In order to use the Hot Dial function, you must rst congure
your mobile phone’s Speed Dial settings. Please refer to your
mobile phone’s user guide for instructions on saving Speed Dial
numbers.
To Hot Dial:
• Speed dial #2: Tap the Hot Dial Button once.
• Speed dial #3: Tap the Hot Dial Button twice rapidly.
• Speed dial #4: Tap the Hot Dial Button three times rapidly.
7. SWAP (Swapping connection between two active mobile phones)
The S-800 allows you to swap, i.e. to alternately use one among
the last two phones to which it has been connected.
To SWAP between phones:
•While both phones are turned on and the headset is in Standby
mode, double-press the MFW inwards.
•The headset will switch to the second phone.

english
8
• Each time you double-press the MFW, the alternate phone
connects to the headset.
NOTE: This feature may only be used when the headset and both
phones are in Standby mode.
8. Battery Status Indicator
To check the status of the headset’s battery, press and hold the
CTRL Button for at least four seconds while the headset is in
Standby mode.
The LED Status Indicator will ash for two seconds as follows:
• Blue Full charge
• Red and Blue Medium charge
• Red Weak charge
9. Locating the Headset (Buzzer Function)
The S-800 allows you to locate the headset by activating an audible buzzer.
To activate the Buzzer:
• Dial a number with the mobile phone and press Send/Talk.
• While the call is in progress (or even while still ringing), turn the
mobile phone’s volume buttons up, then down, repeating the up/
down sequence ve or more times.
• The headset will start buzzing.
10. Call back the last incoming caller (Callback Function)
The S-800 allows you to place a call to the phone number of the
last incoming, missed or rejected call.

english
9
To use the Callback function:
• While in Standby mode, rapidly move the MFW down twice and
release (double down-click).
NOTE: The Callback number memory will be cleared if:
1. The headset is disconnected from the current phone and
connected to a different phone.
2. The headset is turned off or has been charged.
3. The last incoming caller had a blocked or restricted number.
NOTE: This feature is not supported by some mobile phones.
11. Auto-Answer Function
The S-800 allows you to automatically answer all incoming calls
using the Auto-Answer function. Please note that once this feature
is activated you are subject to unintended eavesdropping. Use of
this feature is at your own risk!
Learn more at www.cardosystems.com/faq/s800/autoanswer
When Auto-Answer mode is enabled and there is an incoming
call, the headset will ring for a few seconds and then automatically
answer the call without the need to press the CTRL Button. Auto-
Answer is disabled by default.
To enable/disable Auto-Answer:
• While in Standby mode, press and hold the MFW upwards for
seven seconds.
• When the Auto-Answer function is enabled, the blue Status
Indicator will begin ashing rapidly.

english
10
NOTE:
• Auto-Answer will not answer an incoming call if you are currently
on a call (Call Waiting).
• Turning off the headset will disable the Auto-Answer function.
• Auto-answer can be enabled again after turning on the headset
by following the instructions above.
12. Button Lock
The S-800 allows you to lock its buttons, preventing the buttons
from being accidentally pressed.
To lock/unlock the buttons on the headset:
• While in Standby mode, simultaneously press the MFW and the
CTRL Button for at least four seconds.
13. Disabling / enabling the LED Status Indicator
The S-800 allows you to turn off the ashing LED Status Indicator.
• While in Standby mode, move the MFW down and hold for at
least four seconds.
• The Status Indicator will stop/begin ashing, depending on
whether you are disabling/enabling the Status Indicator.
14. Changing the Wheel orientation
The default conguration of the headset is designed for use on your right
ear. This means that clicking up on the MFW towards the small ‘+’ sign
on the headset increases the volume one step at a time, while clicking down
towards the ‘-’ sign on the headset decreases the volume one step at a time.
If you wear the headset on your left ear, the S-800 allows you to

english
11
change the MFW orientation from right to left ear, so that pressing
the MFW up still increases the volume, and pressing down
decreases the volume. Only volume orientation is affected.
To set the headset for left ear orientation:
• Make sure the headset is turned off.
• Now turn it on by pressing the CTRL Button and the Power Button
simultaneously for 4 seconds.
• Once you see 3 blue ashes followed by a single simultaneous
ash of the red and blue lights, the headset is powered on and
you may release the buttons.
NOTE:
The headset will revert to its default right ear conguration once it
is turned off. In order to regularly use the headset in left ear conguration,
always turn on the headset using the CTRL + Power Button procedure above.
ADVANCED FUNCTIONS REFERENCE
Function Required Action
Redial the last dialed number During Standby, tap the MFW inwards (some phones
may require tapping twice).
Reject an incoming call During an incoming call, press and hold the CTRL
Button for 3 seconds.
Call waiting / Toggling
between calls
During an incoming call and one call on hold or waiting,
tap the MFW inwards.
Conference Call During an active call and one call on hold, press and
hold the MFW inwards for 3 seconds.
Transfer calls to / from
headset
During a call, press and hold the CTRL Button for 3
seconds.
Hot Dial Tap the Hot Dial Button 1, 2, or 3 times rapidly to call
Speed Dial #2, #3, or #4 respectively.
SWAP between active phones During Standby, double-press the MFW inwards.

english
12
Function Required Action
Battery Status Indicator Press and hold the CTRL Button for 4 seconds;
Blue=Full, Red/Blue=Medium, Red=Weak.
Locating the headset
(Buzzer)
Dial a call, then press VolUp/VolDn on the phone 5 or
more times.
Call back the last incoming
caller (Callback)
During Standby mode, rapidly move the MFW down
twice and release (double down-click).
Auto-Answer On/Off During Standby mode, press and hold the MFW
upwards for 7 seconds.
Button Lock On/Off During Standby mode, simultaneously press the MFW
and the CTRL Button for at least 4 seconds.
Disabling / enabling the
LED Status Indicator
During Standby mode, move the MFW down and hold
for at least four seconds.
Changing the Wheel
orientation
Turn on the headset by pressing and holding the CTRL But-
-
ton and the Power Button simultaneously for 4 seconds.
6. STATUS LIGHTS
Missed Call Indicator
Whenever a call is missed or rejected, the red and blue Status
Indicator will begin ashing simultaneously, notifying you of the
missed call.
To clear this Missed Call Indicator, press any button on the
headset.
NOTE: This feature is not supported by some mobile phones.
The headset uses the following Status Indicators to display its
status:

english
13
Status Light Auto-Answer Status
Single blue ashing slowly (every 3 sec) Disabled Standby mode
Double blue ashing slowly (every 3 sec) Disabled During a call
Red and blue simultaneously ashing slowly Disabled Missed call
Red ashing slowly (every 3 sec) Disabled Low battery
Single blue ashing rapidly Enabled Standby mode
Double blue ashing rapidly Enabled During a call
Red and blue simultaneously ashing rapidly Enabled Missed call
Red ashing rapidly Enabled Low battery
Alternating red/blue ashing Pairing mode
3 blue ashes Power ON
3 red ashes Power OFF
None
Headset is off or Status
Indicator is disabled
7. AUDIO TONES
With the exception of the actions described in the following table, all
actions are followed by a single tone to conrm that the headset has
accepted the action. A double tone means that the action has failed.
Action Tone
Mute On/off tone and mute reminder tone every 20 seconds
Volume up Tone on maximum volume
Volume down Tone on minimum volume
Locate the headset Buzzing
Call back list is empty Two short beeps

english
14
8. Support
For additional information visit our website at
www.cardosystems.com or contact us at:
Email: [e-mail]
FAQ: www.cardosystems.com/faq/s800/
10. Accessories
Accessories for your Cardo S-800™ headset may be ordered
online at www.cardosystems.com/S800/Accessories.
FCC NOTICE
This equipment complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Warning: Changes or modications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment. Use only approved batteries and chargers. This equipment has been
tested and found to comply with Part 15 of the FCC rules. These limits are de-
-
signed to provide reasonable protection against harmful interference in a resi-
-
dential installation.
This equipment generates and can radiate radio frequency energy, and if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. Your Cardo S-800TM

english
15
headset is designed to operate at the maximum strength allowed by the FCC.
This means that your headset can communicate only over a certain distance
subject on the location of the cell phone, base unit and headset, your vehicle,
the construction and layout of your home or ofce. Weather conditions can
also affect performance.
NEVER OPEN THE HEADSET AS THIS MAY CAUSE DAMAGE OR INJURY
AND WILL VOID WARRANTY
NOTE: If this equipment causes harmful interference to radio or television re--
ception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help.
EUROPEAN CE NOTICE
The Cardo S-800TM headset (the “Product”) is in conformity with the following es--
sential requirements of Council Directive 1999/5/EC (referred to as R&TTE Direc-
-
tive): Articles 3.1a, 3.1.b and 3.2. The Product is manufactured in accordance with
Annex II of the above directive.
DECLARATION OF CONFORMITY (DOC)
The Cardo S-800TM headsetiscompliant withandadoptstheBluetooth® Specica--
tion 2.0 and has successfully passed all interoperability tests that are specied
in the Bluetooth® specication. However, interoperability between the device and
other Bluetooth®-enabled products is not guaranteed.

Copyright © 2007 The Cardo S-800™
is developed and
manufactured by
Cardo Systems, Inc.
All rights reserved.
The Bluetooth®
word mark and
logos are owned
by the Bluetooth
SIG, Inc.
english
16
