Cardo Systems scala rider Q-solo User manual

Installation Guide
Attach the scala rider audio Kit to your helmet using
the standard Backplate (Option A) or one of the Glue
Plates (Option B).
INSTALLING THE AUDIO KIT
ON YOUR HELMET
PARTS REQUIRED (OPTION A):
OPTION A – USING THE BACKPLATE
1 2
3
Loosen both screws
1
Push the Backplate between the helmet’s
outer shell and inner padding
2
Tighten the screws
3
* For details on attaching or removing the unit from the
audio kit, refer to the back side of this installation guide.
DISCLAIMER
The Glue Plate is oered as a secondary option yet
Cardo does not recommend using it,
unless the Backplate cannot be installed on your helmet.
Cardo shall bear no responsibility whatsoever for
damage of any kind caused as a result of gluing.
24 hours
Press
or
PARTS REQUIRED (OPTION B):
OPTION B – USING THE GLUE PLATE
THIS CAN ONLY BE DONE ONCE!
1
2
3
Remove the Backplate by taking out both screws
Use the Alcohol pad to clean the exact spot on the
helmet
●Choose which of the two Glue Plates is most suitable
for your helmet
●Peel o protective backing sheet
Press the Glue Plate onto the helmet for 15 seconds
as shown
Allow the glue to dry for 24 hours
Attach cradle to the Glue Plate and fasten both
screws tightly
4
5
6
CONTENTS
8
4
Alcohol
Pad
Alcohol
Pad
5
12
9
10
11
7
1
A
B
2
3
4
Cradle
Hybrid microphone
Release tab
Speakers
Speaker jack
Replacement microphone
sponge
Allen wrench
5
Alcohol pads
Speaker booster pads
Rectangular velcro pads
Square velcro pads
Glue Plates (choose 1)
Hybrid microphoneclip
Backplate
7
8
9
10
11
6
12
A
3
2
B
1
DE -
http://cardosystems.com/q-solo-download
für eine Bedienungsanleitung und eine Kurzanleitung
in Deutsch
EN-
http://cardosystems.com/q-solo-download
for a manual and pocket guide in English
ES-
http://cardosystems.com/q-solo-download
para un manual y la guía de bolsillo en español
FR-
http://cardosystems.com/q-solo-download
pour un manuel et un guide de poche en français
IT-
http://cardosystems.com/q-solo-download
per il manuale e la guida tascabile in italiano

PLACING THE SPEAKERS
1
2
3
ATTACHING AND REMOVING THE UNIT
FROM THE AUDIO KIT
MAN01010 INSTALLAT IO NG UI DE 2017EN 015

www.cardosystems.com

suppor[email protected]

USA & Canada: 1-800-488-0363
International: [phone]
POSITIONING THE HYBRID MICROPHONE
1
2
Remove the left cheek pad to expose the inner shell
●Clean the designated area
●Peel o and stick the velcro pad and attach the
hybrid Microphone in place.
●For a more secure attachment use the second
velcro pad and the supplied clip as shown.
Ensure arrow is positioned towards your mouth.
1
2
PARTS REQUIRED:
REMOVING
1
Push
Slide up
2
ATTACHING
Click!
PARTS REQUIRED:
Using two speakers inside the helmet may be prohibited
in certain jurisdictions. If this is the case, position both
speakers on one side of the helmet.
Attach the speaker with the shorter wire onto the
left velcro pad. Cross the long speaker wire over the
center of the helmet to enhance FM radio reception.
Attach the second speaker onto the right Velcro pad.
Re-attach the cheek pads.
Remove both cheek padsto expose the inner shell
● Clean the designated area
● Peel o and stick the velcro pads
** To use the optional speaker booster pads , place
them between the Velcro pad and the speaker.
1
2
3
For best clarity, place speakers directly opposite and
close to the ears. Helmets with deep recesses may
require padding to bring the speakers closer for ideal
positioning. Optional speaker booster pads are provided
for this purpose.
