Carus Adapto CAI1200 User manual

Product information
Indoor station for hands-free talking
Carus Adapto
CAI1200, CAI1210

2
Table ofcontents
Scope of delivery...............................................................................................................3
Safety instructions.............................................................................................................3
General safety regulations ...............................................................................................3
Installation –protective measures....................................................................................3
Technical data....................................................................................................................4
Device overview.................................................................................................................4
Indication and operating elements...................................................................................5
Intended use.......................................................................................................................6
Max. number CAI12x0 in 3-wire operation.......................................................................6
Short description...............................................................................................................7
Basic module....................................................................................................................7
Function key modules 1 and 2 .........................................................................................7
Mounting and installation .................................................................................................8
Installation CAI1200 (wall mounting)................................................................................8
Install the bottom shell..................................................................................................8
Connect the lines..........................................................................................................8
Deinstall the device.......................................................................................................9
Installation CAI1210 (tabletop device)............................................................................10
Put up the table rack...................................................................................................10
Cable assignment.......................................................................................................10
Install the device.........................................................................................................11
Deinstall the device.....................................................................................................11
Wiring diagram...............................................................................................................12
Connection diagram.......................................................................................................12
Commissioning................................................................................................................12
Settings.............................................................................................................................13
Ring tone selection.........................................................................................................13
Factory settings..............................................................................................................14
Pre-adjusted times......................................................................................................14
Configuration options .....................................................................................................14
Programming the basic module .....................................................................................15
Manual programming .....................................................................................................15
Programming the function key of the basic unit with Service Device TCSK-01..............18
Programming the function key module .........................................................................19
Manual programming .....................................................................................................19
Programming further buttons......................................................................................20
Programming the function key module via Service Device TCSK-01.............................21
Labelling of the function keys ........................................................................................21
General information on the conduit in TCS audio systems.........................................22
Principle loop resistance.............................................................................................22
Measurement loop resistance.....................................................................................22
Repair................................................................................................................................23
Cleaning............................................................................................................................23
Information on disposal ..................................................................................................23
Warranty...........................................................................................................................24
Service..............................................................................................................................24

3
Scope of delivery
1 x CAI12x0 (top shell, bottom shell or tabletop device)
2 x release bracket
4 x Phillips head screw
4 x dowel
assembly instruction
Product information
instruction manual
programming table
Safety instructions
General safety regulations
!
Attention! Assembly, installation, commissioning and repair of electronic devices must
be carried out by qualified electricians and in compliance with the current standards.
When working on main power connections of 230V AC, the general and regional installa-
tion and safety regulations must be met. i.e. DIN VDE 0100
TCS:BUS system installations must be in compliance with the general safety regulations
for telecommunication systems according to VDE 0800. Including:
separated cable routing of high and low voltage lines,
minimum distance of 10 cm in case of a common cable routing,
use of separators between high and low voltage lines within shared cable ducts,
use of standard telecommunication lines, e.g. J-Y (St) Y with 0.8 mm diameter,
already existing lines (modernisation) with deviating cross-sections can be used in
compliance with the loop resistance.
Installation –protective measures
!
Through suitable measures to protect against lightning, it has to be ensured that a
voltage of 32 V DC is not exceeded at each connection.

4
Technical data
supply voltage: +24 V ±8 % (power supply and control unit)
housing: aluminium anodised (colors as listed in price list)
dimensions CAI1200: H 163 mm x W 285 mm x D 16 mm
dimensions CAI1210: H 156 mm x W 285 mm x D 150 mm
weight: 1404 g (CAI1200), 2136 g (CAI1210)
acceptable ambient temperature: 0 °C to 40 °C
input current: I(a) = 0.5 mA, I(P) = 7.1 mA
max. input current: I(Pmax) = 124 mA
3-wire installation necessary!
Device overview
indication ring
tone mute (red)
indication addition-
al functions (green)
door release
button
function key
light switch button
call OFF-button
ring tone volume
control
loudspeaker
function
keys
function indica-
tion (green)
microphone
speech
button
basic module
function key modules 1 and 2
labelling of the
function keys

5
Indication and operating elements
Term
Function
speech button
call acceptance, activate speaking,
simplex communication
end communication
ring tone selection (door call front-door station 2 AS > AS-
border*)
door release but-
ton
door release (factory setting)
end communication
ring tone selection (door call front-door station 1 AS > AS-
border)
trigger light switch function**
function key of the
basic module
control function 8 (factory setting)
internal calling (to indoor station)
door release automatic
call diversion
ring tone selection internal call (call from the indoor sta-
tion)
light switch button
switching lights
ring tone selection floor call (call from the flat door)
call OFF-button
ring tone stopper
end communication
initiate the programming
indication ring
tone mute (red)
call OFF is activated (LED is ON) or
indication for busy speech channel (LED blinks)
indication addi-
tional functions
(green)
door call, incoming internal call, speaking activated
door release automatic or call diversion, when activated
alternatively door status indication
ring tone volume
control
ring tone volume can be adjusted continuously
function key mod-
ules
Each with 10 keys. Each button can be programmed with 6
independent functions:
specific connection to one front-door,
specific internal call,
indication of sensor information,
call diversion of door calls,
send control function,
send 2 control functions alternating

6
function indica-
tions
Each with 10 keys. Each function key has its own function
indication. LED is ON when
a door call comes in
an internal call comes in
a control function from sensor comes in
call diversion is activated
send two control functions with unique serial number al-
ternately
* factory setting: AS-border = 0, limit value of the AS-address areas can be configured with
configuration software configo™ or can be configured in the factory on request.
** when light switch function is activated in the front-door station
Intended use
The CAI12x0 are indoor stations for hands-free talking. Manually controlled simplex
communication can be activated.
The CAI12x0 are equipped with extended functions and can be used for internal com-
munication as well as for triggering control and switching functions in the home envi-
ronment. Further, they can be used as communication and control centrals which are
easy to operate.
The CAI12x0 are suitable for surface-mount and can be used as tabletop device.
They can be used for the operation within TCS audio systems and combined audio /
video systems.
Max. number CAI12x0 in 3-wire operation
when using power supply
and control unit
max. number
CAI12x0
BVS20 or
NBV1000, 1 strand
3
VBVS05, 1 line
10
BVS20 + NGV1011
25
AS front-door station
VS power supply and control unit
IS indoor station
Note: The max. number of front-door stations which
can be connected is limited. Details are described in
the respective product information!

7
Short description
Basic module
blue door release button with floor door release function (can be activated)
speech button: for call acceptance and changeover key speaking / listening
function key (ex works allocated with control function) with alternative allocation (can be
activated) internal call, door release automatic, call diversion
light switch button
ring tones can be adjusted by the resident, 13 ring tones can be selected
acoustic call distinction between 2 front-doors, flat door and internal call
ring tone volume can be adjusted manually
ring tone mute with optical indication
optical indication of door calls
optical display of a busy line in case of an established voice connection
automatic hands-free talking after internal call can be activated
one parallel call can be activated
sending sender serial number in case of internal calls can be de-/activated, source indi-
cation at CAI11x0 or CAI2xx0 possible (with configuration software configoTM)
unlimited communication time can be de-/activated (with configuration software con-
figoTM)
(limited by other indoor or front-door stations, to which a voice connection is estab-
lished)
audio privacy function and automatic call cut-off
Function key modules 1 and 2
Each function key can be configured with any of the six functions.
Specific connection to one front-door: Establishing a voice connection can be initiated
from the front-door or from the indoor station.
Door release by pressing the programmed button.
Key function: Establishing a voice connection to the calling front-door station, door re-
lease.
Indication: incoming door calls. (The AS-address is programmed and blocked in the
front-door station.)
Toggle: When several front-door stations are programmed, it is possible to toggle be-
tween them. The existing connection is terminated and afterwards a new connection is
established.
Specific internal calling: Key function. Sending an internal call to an indoor station. At
the called indoor station the incoming internal call can be indicated.
Sensor functions: Status indication of incoming control functions of sensors via LED.
Call diversion. Key function: De-/Activate the function.
Indication: Function de-/activated (does not work in case of internal calls).
send control function with unique serial number (not pre-programmed)
Send two control functions with unique serial number alternately.
Key function (example for button 1): first keystroke –control function 11 is sent, second
keystroke –control function 41 is sent (see programming)
Indication: LED is on –control function 11 was sent, LED off –control function 41 was
sent.

8
Mounting and installation
Installation CAI1200 (wall mounting)
Attention! The indoor stations have to be (de-)installed only voltage-free!
Ensure not to over tighten the screws when installing the wall bottom shell on uneven sur-
faces. Otherwise the plate might be deformed. Further, the devices may not be locked into
position correctly on the bottom shell.
Install the bottom shell
For an optimal operation, a mounting height of 1.6 m is
recommended.
In order to place the cables without any problems, the
device must be installed on a flush-mounted socket.
Position the flush-mounted socket behind the cable
entry. Ensure that the connection terminal does not
contact the flush-mounted socket.
Do not use the bottom shell as drilling template!
Only use the bottom shell as aid for marking the holes.
Install the bottom shell directly to the wall and use the
enclosed screws to fix it.
Connect the lines
acceptable cross-section (diameter)
0.08 … 0.82 mm2(Ø 0.32 … 1.0 mm)
max. number of wires per terminal contact
each 2 x 0.8 mm, 3 x 0.6 mm
Further wires have to be connected via auxiliar terminals!
Use only connecting lines with the same diameter within one terminal contact.
Connect the lines according to the labelling.
a
b
E
P

9
Install the device
Take the device into both hands and
position it on the bottom shell.
Position the device centrally on the
bottom shell and leave out a little
space of 10 mm to the bottom edge
of the bottom shell.
Press the device flush to the bottom
shell (1). Slide it carefully and verti-
cally downwards (2) until the lock
pins of the bottom shell lock into the
holes in the rear panel of the device.
Slide it downwards until stop.
To make sure that the device is
locked correctly, slightly try to push
it upwards. That should not be pos-
sible.
Lock pins 4 x:
Deinstall the device
For deinstalling the device, the enclosed
release bracket is necessary.
Insert the release bracket into the opening
of the bottom shell behind the device (1).
Push the device upwards (2) and pull it out
towards you (3).
(1)
(2)
(1)
(3)
(2)

10
Installation CAI1210 (tabletop device)
Attention! The indoor stations have to be (de-)installed only voltage-free!
The table rack is pre-configured and has to be connected to a RJ45 socket. Therefore
please note the connection diagram under cable assignment.
1 bottom shell
2 lock pins
(4 x)
3 connecting cable
(2.5 m)
4knurled screws
5 grub screw
(hexagonal socket)
Put up the table rack
Turn the table rack into the desired position and
fix the position by tightening the knurled screws
by hand.
The cable is already pre-installed.
Cable assignment
Wires
Plug PIN no.
Connect to
connection terminal:
2
3
4
5
orange-green
green-white
blue
blue-white
a
b
E
P
Note: Wires for video only!
6
7
8
green
brown-white
brown
M
V1
V2
1
5
max. 60°
4
3
2
