Casanoov HICKER B200 User manual

HICKER B200
INSTRUCTION MANUAL / NOTICE DE MONTAGE / MONTAGEANLEITUNG / MANUAL DE MONTAJE / MANUAL DE MONTAGEM / MANUALE DI MONTAGGIO / MONTAGEHANDLEIDING / INSTRUKCJA MONTAŻU
EN FR DE ES PT IT NL PL
STI-000044
EN
FR
DE
ES
PT
IT
NL
PL
The manual should be read prior to beginning installation and keep after
Le manuel doit être lu avant de commencer l’installation et conservé après
Das Handbuch sollte vor Beginn der Installation gelesen und nach der Installation aufbewahrt werden.
El manual debe ser leído antes de comenzar la instalación y mantenerlo después
O manual deve ser lido antes do início da instalação e mantido após
Il manuale deve essere letto prima di iniziare l’installazione e conservato dopo
De handleiding moet voor het begin van de installatie worden gelezen en na de installatie worden bewaard
Instrukcję należy przeczytać przed rozpoczęciem instalacji i zachować ją po
CAUTION / ATTENTION / ACHTUNG / ATENCIÓN / ATTENZIONE / AANDACHT / UWAGA
!

EN
FR
DE
ES
PT
IT
NL
PL
3
25
47
69
91
113
135
157
Manual translated from English version using automatic translator. In case of question please refer to english version.

EN
3
CAUTION
• This product must be installed by well-trained skilled personnel in compliance with the safety
regulations the field of residential and commercial swing gate opener devices.
Unqualified personnel may damage the instruments and cause harm to the public.
• Electric Power must be disconnected prior to installation, or performing any maintenance.
• Please read the manual carefully before installation. Incorrect installation or misuse of product
may cause seriously damage to users and property.
• If the electric cable is damaged or broken, it must be replaced by a whole and properly insulated
wires, to avoid electric shock or any hazardous environments.
• Keep the wireless transmitters out of children reach.
• Do not allow children or other individuals to stand by the path of the motor arms or the path
of the gates while in operation.
• Do not use the remote wireless transmitters when the gates are out of sight.
• Do not install the products in corrosive, inflammable, and/or explosive environments.
• Avoid installing the motor arm where the override manual release key is exposed to the public.
!

EN
4
(Required) (Required) (Required) (Required) (Required)
(Required) (Required) (Required) (Recommended)
Tools Required
x2 x1 x1 x2 x2
x2 x2 x2 x4 x2
x2 x4 x2 x4
K L M N
A B C D
F G H I J
E

EN
5
Serial Number

EN
6
Product overview
Max single-leaf weight : 200 KG
Environment Temperature : -20°C ~ +50°C
Protection Class : IP55
Max gate open angle : 110 degree
Continue running time : 5 minutes
Dual Swing Gate automation’s Gross weight : 17.5KG
Motor voltage : 24VDC 60W
Input power : 220VAC±10%
Rotational speed : 300 RPM
Arm’s extended speed : 2.4 cm/s
Arm’s max travel : 400 mm
Max single-leaf length : 3 meters
620mm
400mm
897mm
64mm
65mm
75mm
80 mm
Technical specifications

EN
7
Open the gate manually : Use the manual override key to release the clutch to
open or close the gate manually.
Manual unlocking
Swing Gate automation Features & Options
Flash lamp (optional)
Control box
Photo cells
1
2
3
4
5
6
Swing gate opener motor
Remove auto-close and keep the central stop
Remote control
6
1
2
3
3
4
4
2x1,5 mm2
2x 0,5 mm2
4x0,5 mm2
2x0,75 mm22x1,5 mm2
230V~2x1,5 mm2
5

EN
8
•When Gate is Obstructed : Gate stops.
•Optional : The Gate Opener Controller can be connected to a solar system, a Flash light warning, a photocell, back up battery, keypad
and other access control devices.
•Speed Control : Gate opening and closing speed can be adjusted.
•Gentle Start : The Gate Opener is equipped with a soft start function.
•Auto Close : The Gate Opener System is equipped with Auto close function with adjustable closing time delay.
•Single or Dual Gate : Either Single or Dual Swing Gate can be opened.
•Multiple Remote Transmitters : The Controller can easily accommodate several unique extra remotes to control the swing gate opener.
•Battery Back Up : DC 24V back up battery can be incorporated
•Optional Devices : DC 24V Gate Lock, photocell ,keypad , photocell, push button, large size or small size control box.
The Gate Opener can be configured to allow smooth noiseless operation.
The Gate Opener can be configured to enable open condition as default, or close condition as default depending on the placement of the
provided hardware brackets.
General options and accessories
Construction Drill and Bolts
Ix2
Dx2
Jx2
Drill 4 Holes of 14mm Diameter.
Use the appropriate bolt or
screw according to the material
of your support.
If the post is hollow, we advise
you to chemically seal your
installation.
Screws are not included
Place the Motor Connecting
Bracket and Tighten with the
Provided Screws. Ref. I x 2.
A
B
C
B

EN
9
CABLE MUST NOT BE INSTALLED ABOVE THE MOTOR ARM.
IT MAY PINCH AND STRIP THE CABLE AND CAUSES ELECTRIC SHOCK.
WARNING
Fixing motor on bracket. Watch that the electric cable is in the proper position !
!
Power supply cable is in down position.
Manual unlocking slot on top position.
Endless screw arm is facing ground.
2
1
3
1
3
5
6
4
4
6
OK KO
Gx2
Mx2

EN
10
Installation of Extended End Motor Arms to Gates
USE BUBBLE LEVEL
K
D
mm

EN
11
Drill 2 holes 10.2 mm in diameter with a spacing of 84 mm between the 2 holes.
Place the 2 slotted hole door support over the drilled holes.
Place the end motor bracket on the gate bracket by unscrewing the worm screw bolt and screwing it
onto the bracket and tighten it properly.
(Please note that the bolts used to attach the front bracket to the gate are not supplied as the
thickness of each gate is different).
Insert the locking pin and clamping washers
Unlock the motor. Open and close the gate manually to ensure correct operation.
A
B
C
D
Installation of Motor’s Arms to Gates
84
10.2
AB
C
D
E

EN
12
The distance between the edge of the post and
the fixed hinge of the motor
The distance between the door hinge
and the centre line of the engine hinge
A
B
INSTALLATION : OPENING INWARDS

EN
13
INSTALLATION : OPENING OUTWARDS
A
B
The distance between the edge of the post and
the fixed hinge of the motor
The distance between the door hinge
and the centre line of the engine hinge

EN
14
FIXING OF THE STOPS
Set the opening limit switch of the geared motor as follows:
A. Unlock the geared motor
B. Loosen the mechanical stop screw.
C. Place the gate leaf manually in the desired opening position.
D. Then place the mechanical stop against the pivot and tighten the screws.
E. Place the gate leaf manually in the closed position and lock the gear motor.
A
B
C
D
E

EN
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
21
23
24
25
26
27
28
29
SIDE terminal is used for connecting any external device that operates double gate.
COM terminal is COMMON used for connecting the “ground” of external devices.
SIDE terminal is used for connecting any external device that operates single gate.
Swipe Card terminal is used for connecting any external devices that will operate to
open the gate.
COM terminal is COMMON used for connecting the “ground” of external devices.
Infrared terminal is used for connecting photo electric sensor.
12V DC output is used for connecting photo electric sensor (Continuous output cur-
rent <=200mA).
24V battery output is used for connecting the back up battery +.
24V battery output is used for connecting the back up battery -.
24V DC output is used for connecting external device. (such as photo electric sensor,
max current output 1A).
GND is used for connecting the “ground” of external devices.
24V DC lamp output is used for connecting flash light +.
24V DC lamp output is used for connecting flash light -.
24V DC lock output—the NF terminal which used for connecting the electric lock.
COM is COMMON used for connecting the “ground” of lock.
24V DC lock output—the NA terminal which used for
connecting the magnetic lock.
24V DC alarm output.
24V DC alarm output.
Motor1 terminal is used for connecting the motor 1 installed
on the gate that opens later and close first. This terminal
connect 1st red wire (from your left hand side to right hand
side).
Motor2 Delay terminal is used for connecting the motor 2
installed on the gate that opens first and close later. This ter-
minal connect 1st blue wire ( from your left hand side to right
hand side). NOTE! If for single gate, the gate motor just can
connect the Motor2 Delay terminal.
AC24V input is used for connecting the transformer.
AC24V input is used for connecting the transformer.
Digital display is used for showing you the setting data.
INC+ is used for figure increase when setting the data.
FUN is used for recorde the data.
DEC- is used for figure decrease when setting the data.
Learning button is used for program/remove remote.
Control board wiring diagram
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18
19
20
20 21
22
22
2324
25
26 27 28
29

EN
16
TURN OFF ELECTRICY BEFORE CONNECTING THE CONTROL BOARD
TO THE 230V AND TO ACCESSORIES.
123 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 21
20 22
25 26
2 side and 1 side are for connect
open device, such as push but-
ton, wired keypad, camera video,
GSM controller etc...
!

EN
17
-
+
IR
+-
+
-
-
-
+
+
+
+-
+ +
- -
-
-
+
OUT
-
COM
COM
-
+
12V
05 COM
=
06 IR
=
07 12V
=
=
19
=
20
=
21
=
22
BLUE
BROWN
BROWN
BLUE
19 20 21 22

EN
18
Button “1” depressed to operate single gate;
Button “2” depressed to operate double gate;
Button “3” depressed for alarm output
Program new remote control:
> First step
Press the LEARN button on the control board [29] for about 1 second, the indicator LED would turn off,
then now means have already enter learning Second step:
Press any button of the new remote control for about 2 second, then digital display would show the
remote number while indicator LED on board starts flash four times with one buzzer sound then now
means the learning successfully.
Note! After you press LEARN button, if not receive the new remote signal within 5s, indicator LED would
turn on and exit learning. Remove remote control:
Press and hold the LEARN button for about 5 second, if with one buzzer sound and indicator LED light
on, then now means remove remote successfully.
After power on, digital display will self-check from 00-99 with buzzer sound. If indicator LED light on,
buzzer stop sound, it means the system is normal.
Basic operation method:
Press and hold the [ FUN] button until the digital display shows PO. Now you enter the menu setting.
You could through adjust the [INC+] [DEC-] to increase or decrease the serial number or numerical
value. After data adjust well then press [ FUN] to store the data. With one sound of buzzer, the store
successfully.
After store the data, the digital display would still on the menu number you just set, if you need to enter
next menu setting, please press [INC+] or [DEC-] to choose and confirm with [FUN] to enter the menu
number you want to set. Such as after you store the P0 value and press [FUN] to store it, then now the
digital display would still show the number P0, and if you want go further to adjust P1, please press one
[INC+], then digital display show P1, later press [FUN] to enter the P1 setting.
If you not need to enter next menu setting, you could press [LEARN] button to exit the menu setting.
Remote control
Setting of the control board

EN
19
MANUAL
SETTING
FUN RANGE
( INC +/ DEC - )
DEFAULT
SETING
MARKED
ON BOARD
P0 Soft start time setting 0-6 s 2 s SOFT START
P1 Motor 1 low speed running stall
force adjustment.
0-20Level 6th Level Ml LOW OVER
LOAD
P2 Motor 1 high speed running stall
force adjustment.
0-20Level 10th Level M1 HI OVER
LOAD
P3 Motor 2 low speed running stall
force adjustment.
6th Level 10th Level M2 LOW OVER
LOAD
P4 Motor 2 high speed running stall
force adjustment.
0-20Level 10th Level M2 HI OVER LOAD
P5 To set the high speed running time 0-33s 5s HI-SPEED
P6 To set the auto close time after
swipe card
0-99s 10s CARD-CLOSE
AUTO CLOSE
P7 To set the Interval time on opening
the door
0-10s 0(close) OPEN DELAY
P8 To set the Interval time on closing
the door
0-10s 0(close) CLOSE DELAY
P9 To set auto close time 0-99s 0(close) AUTO CLOSE
PA To set lamp alarm output control 0
PB To set lock 0-2s
PC Button of remote selection 0-3 3
PD To choose photocell work en NC or
NO
0-1 1(NC)
PE To choose single/double gate open 0-1 0(Double)
PO RESET 0-1 0(Double) RESET

EN
20
1. To set the soft start time:
When digital display indicate P0, the gate opener
is on the soft start time setting. The soft start time
adjustable from 0-6s, 0s means close the soft start
time, max soft start time 6s. Each time you press and
release the [INC+] button, the figure increase by 1;
each time you press and release the [DEC-] button,
the figure decrease by 1. Press the [FUN] button to
store the data when the soft start time chosen, then
the soft start time setting finished (Factory set 2s).
2. To set the level of stall force:
2a-- When digital display indicate P1, the gate
opener is on Motor 1 low speed running stall force
adjustment. There is 0-20 levels for optional, each
time you press and release the [INC+] button, the
figure increase by 1; each time you press and release
the [DEC-] button, the figure decrease by 1. Press the
[FUN] button to store the data when the stall force
level chosen, then the stall force of Motor 1 low speed
running stall force adjustment finished. (factory set 6
level)
2b-- When digital display indicate P2, the gate ope-
ner is on Motor 1 high speed running stall force ad-
justment. There is 0-20 levels for optional. Each time
you press and release the [INC+] button, the figure
increase by 1; each time you press and release the
[DEC-] button, the figure decrease by 1. Press the
[FUN] button to store the data when the stall force
level chosen, then the stall force of Motor 1 high
speed running stall force adjustment finished. (fac-
tory set 10 level)
2c-- When digital display indicate P3, the gate
opener is on Motor 2 low speed running stall force
adjustment. There is 0-20 levels for optional. Each
time you press and release the [INC+] button, the
figure increase by 1; each time you press and release
the [DEC-] button, the figure decrease by 1. Press
the [FUN] button to store the data when the stall
force level chosen, then the stall force of Motor 2 low
speed running stall
force adjustment finished. (factory set 6 level)
2d-- When digital display indicate P4, the gate ope-
ner is on Motor 2 high speed running stall force ad-
justment. There is 0-20 levels for optional. Each time
you press and release the [INC+] button, the figure
increase by 1; each time you press and release the
[DEC-] button, the figure decrease by 1. Press the
[FUN] button to store the data when the stall force
level chosen, then the stall force of Motor 2 high
speed running stall force adjustment finished. (fac-
tory set 10 level)
3. To set the high speed running time: 11
When digital display indicate P5, the gate opener is
on high speed running time setting. There is 0-33s
for optional. 0s means without high speed running,
gate opener would keep running in slow speed. Max
high speed running time 33s. Each time you press
and release the [INC+] button, the figure increase by
1; each time you press and release the [DEC-] but-
ton, the figure decrease by 1. Press the [FUN] button
to store the data when the high speed running time
chosen, then the high speed running time setting fi-
nished. (factory set 5s)
4. To set the auto close time after swipe card:
When digital display indicate P6, the gate opener is
on auto close time setting ( NOTE! this auto close
time just means the auto close function which realize
through external device-). There is 0-99s for optio-
nal. 0 means the gate opener would not auto close
after swipe card. Max auto close time after swipe
card 99s. Each time you press and release the [INC+]
button, the figure increase by 1; each time you press
and release the [DEC-] button, the figure decrease
by 1. Press the [FUN] button to store the data when
the auto close time after swipe card chosen, then the
auto close time after swipe card finished. (factory set
10s)
5. To set the interval time:
5a. When digital display indicate P7, the gate ope-
ner is on open interval time setting. There is 0-10s
for optional. 0s means double gates open simul-
taneously. “1” means the Motor 1 start to open 1 se-
cond before Motor 2 start to open. Max open interval
time 10s. Each time you press and release the [INC+]
Setting of the control board
