Case CVX 140 User manual

CASE
CVX 140, CVX 150, CVX 160
CVX 175, CVX 195
Tractors
Sva 87532337

The safety labels on this machine use the terms 'Danger', 'Warning' or 'Caution'. These
terms are defined as follows:
●DANGER: This indicates an imminently hazardous situation which, if steps are not taken to
avoid it, will lead to death or serious injury. The colour assigned to the term 'Danger' is RED.
●WARNING: This term indicates a potentially hazardous situation which, if steps are not taken to
avoid it, can lead to serious injury. The colour assigned to the term 'Warning' is ORANGE.
●CAUTION: This term indicates a potentially hazardous situation which, if steps are not taken to
avoid it, can lead to minor or moderate injuries. This term is also used to warn the user of unsafe
practices. The colour assigned to the term 'Caution' is YELLOW.
! S E R V I C E B U L L E T I N
Sva 87532337 GE
©2006 CNH Österreich GmbH January 2007
Case is a registered trademark of CNH Österreich GmbH.
IN THIS MANUAL, THIS WARNING SYMBOL INDICATES IMPORTANT SAFETY
INFORMATION. WHEREVER THIS SYMBOL APPEARS, THE INFORMATION
FOLLOWING IT SHOULD BE READ CAREFULLY TO ENSURE THAT THE USER IS
AWARE OF THE POTENTIAL RISK OF INJURY OR DEATH. M171B
!
IMPROPER OPERATION OF THIS MACHINE CAN LEAD TO INJURY OR DEATH. BEFORE USING THIS
MACHINE, ENSURE THAT EVERY DRIVER FULFILS THE FOLLOWING REQUIREMENTS :
●The driver must be trained in the safe and correct manipulation of the machine.
●He must have read and understood the manual(s) regarding. the machine.
●He must have read and understood ALL safety labels on the machine.
●He must ensure that no one is standing in the working area.
●Before using the machine in a working area, he must have practised and trained in safe
manipulation of the machine's operating elements in a safe, open practice area.
It is your responsibility to comply with the applicable regulations and guidelines and to follow the
instructions given by CNH Österreich GmbH on working with and maintaining the machine.

TO THE USER .................................................................................................................................................. 1
ASSEMBLIES AND SERIAL NUMBERS......................................................................................................... 5
ASSEMBLIES AND SERIAL NUMBERS ..................................................................................................... 5
SAFETY AND SAFETY PANELS..................................................................................................................... 7
SAFETY AND SAFETY PANELS ................................................................................................................ 7
FITTINGS/OPERATING ELEMENTS ............................................................................................................. 13
FITTINGS/OPERATING ELEMENTS ........................................................................................................ 13
DRIVER’S SEAT ........................................................................................................................................ 14
CONTROL ELEMENTS ............................................................................................................................. 33
DRIVING OPERATION ................................................................................................................................... 51
BEFORE STARTING THE ENGINE .......................................................................................................... 51
DRIVER PRESENCE SWITCH ................................................................................................................. 51
BATTERY MASTER SWITCH (if fitted) ..................................................................................................... 52
STARTING PROCESS .............................................................................................................................. 53
TRACTOR OPERATION AT LOW TEMPERATURES (WINTER OPERATION) ...................................... 55
DRIVE STRATEGIES ................................................................................................................................ 57
STOPPING AND PARKING THE TRACTOR ............................................................................................ 59
STATIONARY CONTROL ......................................................................................................................... 60
PARK LATCH ............................................................................................................................................ 60
DRIVING CONSIDERATIONS ................................................................................................................... 61
TRANSMISSION ACTUATION .................................................................................................................. 63
CAB VENTILATION / HEATING ................................................................................................................ 72
HEIGHT ADJUSTABLE TOWING HITCHES (if fitted) ............................................................................... 75
SWIVEL-MOUNTED DRAWBAR ............................................................................................................... 78
AUTO PICK UP HITCH WITH HOOK hydraulically extending (if fitted) .................................................... 82
LUG DIMENSIONS FOR TRAILER/IMPLEMENT DRAWBAR .................................................................. 86
CABLE COUPLINGS FOR TRAILER BRAKES (if fitted) ........................................................................... 87
AUXILIARY ELECTRICAL CONNECTOR .................................................................................................89
WARNING LIGHTS .................................................................................................................................... 94
TOWING .................................................................................................................................................... 95
TRANSPORTING THE TRACTOR ............................................................................................................ 96
OPERATIONAL USE...................................................................................................................................... 97
OPERATING THE FRONT PTO SHAFT(if fitted) ................................................................................... 107
PREPARING THE REAR THREE POINT LINKAGE ............................................................................... 108
OPERATING THE ELECTRONIC EDC LIFTING EQUIPMENT CONTROL ........................................... 117
PREPARING THE FRONT POWER LIFT(if fitted) .................................................................................. 125
OPERATING THE FRONT 3 POINT HITCH ........................................................................................... 126
HEADLAND MANAGEMENT .................................................................................................................. 129
AUXILIARY CONTROL VALVES ............................................................................................................. 133
OPERATING THE AUXILIARY CONTROL VALVES ............................................................................. 139
DIFFERENTIAL LOCK ............................................................................................................................. 144
OPERATING FOUR-WHEEL DRIVE ....................................................................................................... 146
OPERATING FRONT AXLE INDEPENDENT SUSPENSION (if fitted) (if fitted) ..................................... 147
MOUNTING CONSOLE FOR EXTERNAL LEVERS ............................................................................... 148
TABLE OF CONTENTS

TYRES/WHEELS/WHEELBASE/BALLAST................................................................................................ 149
FRONT AXLE AND FRONT AXLE TRACK WIDTH ADJUSTMENT ....................................................... 151
SETTING THE FRONT AXLE TRACK WIDTHS ..................................................................................... 152
SETTING THE REAR AXLE TRACK WIDTHS ....................................................................................... 154
ALL-WHEEL TYRE COMBINATIONS ..................................................................................................... 158
FRONT WHEEL FENDERS – ALL-WHEEL DRIVE TRACTOR (if fitted) ................................................ 160
TRACTOR BALLAST ............................................................................................................................... 161
LUBRICATION/MAINTENANCE.................................................................................................................. 165
ENVIRONMENTAL ISSUES .................................................................................................................... 165
PLASTICS AND GLASS FIBRE REINFORCED PARTS ........................................................................ 165
TOOL BOX .............................................................................................................................................. 165
PROOF METER ...................................................................................................................................... 166
BONNET .................................................................................................................................................. 167
LUBRICANTS AND FILL VOLUMES ....................................................................................................... 168
DAILY CHECKS ...................................................................................................................................... 175
ENGINE MAINTENANCE ........................................................................................................................ 179
ENGINE MAINTENANCE ........................................................................................................................ 189
MAINTENANCE OF HYDRAULIC UNIT ................................................................................................. 192
MAINTENANCE OF STEERING UNIT .................................................................................................... 193
MAINTENANCE OF FRONT AXLE ......................................................................................................... 194
BRAKE MAINTENANCE ......................................................................................................................... 197
MAINTENANCE OF TRAILER COUPLING ............................................................................................. 198
ELECTRICAL MAINTENANCE ............................................................................................................... 199
MAINTENANCE OF FRONT PTO SHAFT .............................................................................................. 200
MAINTENANCE OF FRONT HYDRAULICS ........................................................................................... 201
GENERAL MAINTENANCE .................................................................................................................... 202
ELECTRICAL SYSTEM ............................................................................................................................... 205
BATTERY ................................................................................................................................................ 205
REPLACING BULBS AND LAMPS ......................................................................................................... 208
FUSES and RELAYS ............................................................................................................................... 216
TECHNICAL DATA ...................................................................................................................................... 221
ENGINE ................................................................................................................................................... 221
ELECTRICAL SYSTEM ........................................................................................................................... 222
GENERAL MACHINE DATA ................................................................................................................... 223
VEHICLE WEIGHTS ................................................................................................................................ 227
VEHICLE DIMENSIONS .......................................................................................................................... 228
REVERSING OPERATION .......................................................................................................................... 229
INDEX .......................................................................................................................................................... 233

1
TO THE USER
CASE CVX 150 TRACTOR
SC07A003
Manufacturer:
CNH Österreich GmbH
Steyrerstrasse 32
A-4300 St. Valentin
AUSTRIA
Dealer’s stamp

2
TO THE USER
How to use this manual
Read the manual before starting to use your tractor. Consult your dealer if you require any further information.
This manual contains important information about how to work safely with your Case tractor, and about how to
set it up and maintain it for reliable operation. To make this information easy for you to find, this manual is sub-
divided into separate chapters, as shown in the table of contents. The information about this tractor is divided
into four chapters:
1. INSTRUMENTS AND OPERATING ELEMENTS – This illustrates the layout of all the operating
elements.
2. WORKING INSTRUCTIONS – General tips for daily work with the tractor, e.g. starting/stopping the
tractor, operation of the transmission etc.
3. FIELD WORK – This chapter contains tips about various working applications, specifically involving the
use of equipment, e.g. three-point linkage, rear PTO shaft etc.
4. TYRES/WHEELS/TRACK WIDTHS/BALLASTING – This section lists settings for various different
tractor applications, e.g. tyre pressures, track widths etc.
Maintenance for this tractor is divided into two chapters:
1. LUBRICATION/MAINTENANCE – Regular maintenance intervals.
2. ELECTRICAL SYSTEM – General maintenance instructions for the electrical system.
IMPORTANT: To find specific points about your vehicle in this manual, please refer to the
alphabetically arranged index at the back of the manual.
Positional indications, e.g. front, back, right and left, are as viewed by someone on the driving seat looking in
the direction of travel.
Do NOT permit yourself or anyone else to drive this vehicle or carry out maintenance work on it until you or
that other person has read this manual. Only employ experienced drivers who have demonstrated their ability
to work with and maintain this vehicle properly and safely.
This tractor with its standard equipment and permitted auxiliary equipment is intended for use in agricultural
applications etc.
This vehicle is NOT to be used for any applications or purposes other than those described in this manual.
Contact an authorised dealer about any modifications, additions or conversion work which may be required to
enable your vehicle to comply with your national directives and safety requirements. The consent or official
approval of the manufacturer is required for any specialist add-on structural components. Product liability will
be declined if any unauthorised modifications are made.
Conformity declaration
This tractor complies with EC Directive (89/336/EEC) :
- Electromagnetic compatibility and is CE-marked.
Operating permit
These tractors are covered by a general operating permit for use on public highways throughout the EU,
subject to a type-dependent maximum speed limit of 40 km/h.
e1 * 2003/37 * 0278 subject to applicable conditions.
Over and above this, national approvals allow for certain versions to drive at speeds of up to 50 km/h.

3
TO THE USER
Software status
ARU Armrest 3.0.0.0
EEM Engine controller 1.3.0.0
FMGR Vehicle/transmission controller 3.0.0.0
SGR Transmission controller 3.0.0.0
ECCU Electronic central control unit 3.0.0.0
ECCU Electronic lifting equipment control 3.0.0.0
ICU 2 Display 3.0.0.0
Airborne noise emissions
In accordance with the specifications of EU directives, the noise levels permitted for the tractors described in
this operators manual are as follows.
* Measuring results in accordance with EU Directive 77/311/EU, Annex II.
Maximum noise level in the driver’s cab with windows and doors open or closed, tractor off load.
* Measuring results in accordance with EU Directive 74/151/EU, Annex IV.
*** with ejector exhaust system
Noise levels in the driver’s cab Driving noise level
Closed Open
Model Annex II* Annex II* Annex IV**
CVX 140 74,0
73,0*** 80,0 79,0*** 83,0 84,0***
CVX 150 74,0
73,0*** 80,0 79,0*** 83,0 84,0***
CVX 160 74,0
73,0*** 80,0 79,0*** 83,0 84,0***
CVX 175 74,0
74,0*** 80,0 79,0*** 84,0 84,0***
CVX 195 74,0
74,0*** 80,0 79,0*** 84,0 84,0***

4
TO THE USER
Keeping this manual safe
The Store this operators manual in the glovebox
provided in your tractor.
Ensure that this manual remains complete and in
good condition.
Ask your dealer for additional copies of the
manual, or for any other information or support
you require for your vehicle. Your dealer employs
highly trained technical specialists who are
familiar with the best method for repairing and
maintaining your vehicle.
IMPORTANT: This operators manual is a part
of your tractor. The operating instructions
MUST remain with the tractor if it is sold,
borrowed or hired.
SC06K059

5
ASSEMBLIES/SERIAL NUMBERS
ASSEMBLIES AND SERIAL NUMBERS
Enter the type designation for the vehicle, the Product Identification Number (P.I.N.) and serial numbers
below in their corresponding lines. When ordering components or requesting information, you may need
to quote this numerical data to the CASE dealer.
Keep a written record of these identification numbers. Store these data records and the vehicle licensing
documentation in a safe place. If the vehicle is ever stolen, notify the local police of these identification
details.
Details on the type plate
SS06M191
Arrangement of individual numbers
TRACTOR
SC04A088
Type designation _________________________
Product Identification Number _______________
TRACTOR
SC05M013
Type designation _________________________
Product Identification Number_______________
DBD096777*D4SB2*

6
ASSEMBLIES/SERIAL NUMBERS
ENGINE
SC05M012
Serial no. _______________________________
ENGINE
SC04A140
Serial no. _______________________________
ALL-WHEEL DRIVE AXLE (if fitted)
SC04A091
Serial no. _______________________________
CAB
SC04A89
Serial no. _______________________________
CARTRIDGE
SC04A094
Serial no. _______________________________
ALL-WHEEL DRIVE AXLE independent
suspension (if equipped with this)
SC04A092
Serial no. _______________________________
620-98/1_R10838

7
SAFETY/SAFETY PANELS
SAFETY AND SAFETY PANELS
SAFETY
Before entry into service, first read this operators manual and the safety instructions and ensure you satisfy all
the requirements stipulated.
You need to be aware that your own safety and the safety of others depends on how well you maintain and
operate this vehicle. Before attempting to work with the vehicle, first familiarise yourself with the layout and
function of all the instruments and controls (‘operating elements’). BEFORE STARTING WORK, ALWAYS
TRY OUT ALL OPERATING ELEMENTS IN A SAFE LOCATION.
READ THIS MANUAL COMPLETELY and ensure that you understand the purpose and function of all the
operating elements. Every item of equipment possesses restrictions of one kind or another. Prior to starting
work, always ensure that you are able to correctly estimate the speed, braking action, steerability, stability and
load-bearing characteristics of this vehicle.
The safety instructions contained in this manual are not a substitute for safety regulations, insurance
requirements, federal, regional and local legislation. You must therefore always ensure that your vehicle is
equipped fully in accordance with applicable legislation and directives.
Modifications to this vehicle are only possible within the context of technical values and are subject to due
compliance with layout guidelines, and any modifications which might affect homologation must be reported to
the relevant authorities.
CNH Austria strives at all times to improve your personal safety: the company does this by manufacturing
tractors equipped with ever better protective equipment, and through due reference to the rules governing
safe operation.
INTENDED APPLICATION
This tractor is intended primarily for use in agricultural, rural community or forestry operations (intended
application). The primary function of the tractor is to deliver tractive power, and can be used for pulling, pushing,
carrying or operating defined items of equipment and machinery, or for pulling a trailer.
Any usage extending beyond the scope of the above list is defined as improper use. The manufacturer
declines to accept any liability for resultant damage and injury. The operator is solely liable for such risk.
Correct usage also involves strict compliance with the operating, maintenance and repair instructions
specified by the manufacturer.
This Case tractor can only be used, maintained and repaired by people who are familiar with the special
characteristics of this vehicle and who have been advised of the relevant safety regulations (accident
prevention).
Due compliance is mandatory with all applicable accident prevention specifications and with other generally
recognised directives and guidelines governing technical safety, health & safety at work and road traffic
safety.
The manufacturer rejects any liability for damage or injury resulting from modifications made to this vehicle
independently by the operator.
IN THIS MANUAL THIS WARNING SYMBOL IS USED TO INDICATE IMPORTANT
NOTES ON SAFETY. WHEREVER THIS SYMBOL APPEARS, ALL ENSUING
INSTRUCTIONS MUST BE READ CAREFULLY AND THE READER MUST BE AWARE
OF THE POTENTIAL RISKS OF INJURY OR EVEN FATALITY. M171B
!!
!

8
SAFETY/SAFETY PANELS
RULES FOR GENERAL SAFETY
AND FOR ACCIDENT PREVENTION
●In addition to the instructions contained in these operating instructions, you must also observe the
rules governing general safety and accident prevention.
●Comply with relevant legislation whenever you are using public highways.
●Before starting work, first familiarise yourself with all the equipment and operating elements and their functions. It is
too late to do this once you have started working with the equipment.
●Before setting off, check the immediate area around the vehicle (e.g. children). Ensure you have a clear
field of view.
●Never leave the engine running in confined spaces. Ensure there is adequate ventilation.
●Exercise caution when handling fuels. Increased risk of fire. Never fill the fuel tank near naked flames or
near flying sparks. Do not smoke while refuelling.
●Before refuelling, switch off engine and remove key from ignition. Never top up fuel tank in confined areas. Wipe up
spilled fuel immediately.
●To prevent the risk of fire, always keep the vehicle in a clean condition.
●Exercise caution when handling battery acid (toxic and corrosive).
TRANSPORTING PEOPLE
●Never carry passengers unless a legally acceptable passenger seat is provided.
●No other form of passenger transport is permitted.
●Children must only ever be transported in specially designed seats (available in trade retail outlets.)
DRIVING OPERATION
●Always adapt vehicle speed to suit prevailing conditions. When driving uphill or downhill, and when traversing slopes, avoid
any sudden cornering action. When cornering, always disengage the differential lock. Never disengage the clutch when
driving downhill.
●Connect up trailers and/or equipment properly. The driving characteristics, steerability and braking action of this
vehicle are all affected by the presence of towed equipment, trailers or ballast weights. You must therefore ensure
at all times that you have enough strength to steer and brake the vehicle safely.
●Pay due attention to the maximum permitted axle loads and the gross tractor weight.
●When cornering while towing or carrying implements, pay due attention to the additional size and inertia weight of that
equipment.
!!
!!
!!

9
SAFETY/SAFETY PANELS
LEAVING THE TRACTOR
●When leaving the tractor, always ensure that it is not able to roll away (apply parking brake, chock the
wheels).
●Remove the ignition key and lock the cab.
●Never leave the tractor unattended while the engine is running.
●Never leave the driver’s platform/cab while the tractor is in motion.
●Before exiting the tractor, lower the implement or attachment unit to the ground.
TRAILED EQUIPMENT
●When connecting up trailers or implements, exercise particular caution – and never step between tractor
and implement.
●Secure trailer and implements to prevent them from rolling away.
●Only start up the tractor once all guards are attached and are in their correct protective positions.
OPERATING THE P.T.O
●Before installing and removing the propshaft, always first switch off the engine.
●When operating the PTO, never allow anyone to stand near the rotating PTO shaft or drive shaft.
●Protective guards must be fitted over the input shaft and PTO stub shaft. Refer to Page 105.
●Implements with a high inertia torque do not stop immediately after the PTO shaft has been switched off.
Use propshafts with an overrun sprag unit. Before cleaning or carrying out adjustments, always wait until
the implement has finished working and has come to a complete stop.
●Immediately after removing the propshaft, cover the PTO shaft with a protective cap.
MAINTENANCE AND OTHER WORK
●Never carry out maintenance work on the tractor while the engine is running. Follow the instructions in this
manual or consult the dealer.
●Fluid (hydraulic oil) escaping under high pressure can penetrate the skin and cause serious injuries. If any
fluid does penetrate your skin, always seek immediate medical attention, otherwise serious infections
might occur.
●Dispose of waste oil, fuel and used filters in accordance with local legislation. Do not drain oil into the
ground or the drainage/sewerage system. Proceed in an environmentally aware manner.
●Tighten the wheel nuts after the number of operating hours specified in this manual. Refer to Page 156.
●Before carrying out any repair work to the electrical system on this vehicle, always first disconnect the
battery earth/ground strap. Refer to Page 207.
●Only use genuine parts made by the manufacturer of this vehicle. All spare parts must comply with the
technical requirements of the vehicle manufacturer.
!!
!!
!!
!!

10
SAFETY/SAFETY PANELS
HAZARDOUS CHEMICALS
●Serious injury can result from exposure to hazardous chemicals, or physical contact with them. The fluids,
oils, paints, adhesives, coolants etc. Used on your vehicle can be dangerous.
●Always consider the environmental implications before carrying out any maintenance work on the vehicle,
and prior to disposing of old fluids and waste oil. NEVER drain oil or operating fluids into the ground, or
into containers which might develop leaks.
●For instructions on proper disposal, you should consult your local environmental authorities, a recycling
company or that company’s appointed agents.
BASIC RULE
●Always inspect your tractor before starting it up to ensure it is safe for use on roads and during working
operations.
! !
!!

Our support email:
[e-mail]
