Case MX100 Configuration guide

Copyright © 2000 Case Corporation
Don 7-73524 Printed in France
February 1999 (Revised October 2000)
CASE UNITED KINGDOM LIMITED
MX100, MX110, MX120 and MX135 Tractors
Schematic Set Don 7-73514
Table of Contents
Section Pub. No.
Safety Rules, General Information and Torque Specifications....................1001 8-86531
General Specifications and Torques ...........................................................1002 7-39021
Electrical Troubleshooting and Schematics.................................................4001 7-73650
Instrument Cluster Programming.................................................................4002 7-71332
Hydraulic Troubleshooting and Schematic..................................................8001 7-73630
Pedal, Lever and Switch Adjustments.........................................................9001 7-66351
Hitch/MFD/Differential Lock Controller Calibration, Error Codes
and Schematics up to PIN JJE956905 (Europe) or
PIN JJA96840 (North America).............................................................10002 7-73290
Hitch/MFD/Differential Lock Controller Calibration, Error Codes
and Schematics from PIN JJE956906 (Europe) or
PIN JJA96841 (North America).............................................................10002 7-73542
Independent Front Suspension Axle
Calibration, Error Codes, Troubleshooting and Schematics .................10003 7-73900
PTO/FNR Controller and Powershift
Configuration, Error Codes and Schematics.........................................10006 7-73281
Programming the PTO/FNR Controller and Hitch/MFD/
Differential Lock Controller....................................................................10010 7-74001
epcatalogs.com

epcatalogs.com

CASE UNITED KINGDOM LIMITED Copyright 1996 Case Corporation
Don 8-86531 March 1996
Section
1001
SAFETY, GENERAL INFORMATION
AND TORQUE SPECIFICATIONS
1001
epcatalogs.com

1001-2
Don 8-86530 Issued 3-96
Template Name: SM_2_col
Template Date: 1994_04_05 Alt= to hide template information Alt+ to display template information
TABLE OF CONTENTS
SAFETY ................................................................................................................................................................. 3
GENERAL INFORMATION
Cleaning ............................................................................................................................................................. 5
Inspection ........................................................................................................................................................... 5
Bearing ............................................................................................................................................................... 5
Needle Bearings ................................................................................................................................................. 5
Gears ................................................................................................................................................................. 5
Oil Seals, O-Rings And Gaskets ........................................................................................................................ 5
Shafts ................................................................................................................................................................. 5
Service Parts ...................................................................................................................................................... 5
Lubrication .......................................................................................................................................................... 5
STANDARD TORQUE DATA FOR NUTS AND BOLTS
Chart 1 (Plain Nuts/Bolts) ................................................................................................................................... 6
Chart 2 (Phosphate Coated Nuts/Bolts) ............................................................................................................. 6
Chart 3 (Zinc or Cadmium Plated Nuts/Bolts) .................................................................................................... 7
epcatalogs.com

1001-3
Don 8-86531 Issued 3-96
Template Name: SM_2_col
Template Date: 1994_04_05 Alt= to hide template information Alt+ to display template information
SAFETY
This symbol means ATTENTION! BECOME ALERT! YOUR SAFETY
IS INVOLVED. The message that follows the symbol contains
important information about safety. Carefully read the message.
Make sure you fully understand the causes of possible injury or
death.
!
To prevent injury always follow the Warning,
Caution and Danger notes in this section and
throughout the manual.
Put the warning tag shown below on the key for the
key switch when servicing or repairing the machine.
One warning tag is supplied with each machine.
Additional tags Part Number 331-4614 are
available from your service parts supplier.
WARNING: Read the operators manual to
familiarize yourself with the correct
control functions.
WARNING: Operate the machine and
equipment controls from the seat
position only. Any other method could
result in serious injury.
WARNING: This is one a man machine, no
riders allowed .
!
!
!
